Getac V100 User manual

Rugged Mobile Computing Solutions
V100
USER’S MANUAL

%FD. 2012
TRADEMARKS
All brand and product names are trademarks or registered trademarks of
their respective companies.
NOTE
The information in this manual is subject to change without notice.
For the latest version of the manual, please visit the Getac website
at www.getac.com.

i
Table of Contents
Chapter 1 Getting Started .............................................................1-1
Getting the Computer Running............................................. 1-2
Unpacking ........................................................................... 1-2
Connecting to AC Power.................................................... 1-3
Opening and Closing the Cover ........................................ 1-4
Operating in Tablet Mode ................................................. 1-6
Turning On and Off the Computer ................................... 1-8
Taking a Look at the Computer............................................. 1-9
Front Components.............................................................. 1-9
Rear Components ............................................................. 1-11
Right-Side Components.................................................... 1-12
Left-Side Components ...................................................... 1-13
Top-open Components..................................................... 1-14
Bottom Components ........................................................ 1-16
Using Accessories .................................................................. 1-17
Using the Tether ............................................................... 1-17
Attaching the Handgrip Strap .........................................1-18
Attaching the Shoulder Strap..........................................1-18
Chapter 2 Operating Your Computer............................................2-1
Using the Internal Keyboard.................................................. 2-2
Typewriter Keys .................................................................. 2-2
Cursor-Control Keys............................................................ 2-2
Numeric Keypad ................................................................. 2-3
Function Keys...................................................................... 2-4

ii
Fn Key .................................................................................. 2-4
Hot Keys .............................................................................. 2-4
Using the Touchpad................................................................ 2-6
Configuring the Touchpad................................................. 2-8
Navigating on the Screen....................................................... 2-9
Using the Touchscreen ....................................................... 2-9
Using Multi-touch Gestures .............................................2-10
Using the Dual Mode Display (Optional)........................ 2-12
Using Landscape or Portrait View ...................................2-14
Using the Input Panel ........................................................... 2-16
Using the Network Features.................................................. 2-17
Using the Modem ............................................................. 2-17
Using the LAN................................................................... 2-18
Using the Wireless LAN .................................................... 2-18
Using the Bluetooth Feature................................................ 2-21
Turning Off/On the Bluetooth Radio .............................. 2-21
Connecting to another Bluetooth Device.......................2-21
Using the WWAN Feature (Optional).................................. 2-23
Installing a SIM Card......................................................... 2-23
Turning Off/On the WWAN Radio ..................................2-24
Connecting to WWAN Network ......................................2-25
Using the Fingerprint Scanner (Optional)...........................2-26
Chapter 3 Managing Power ...........................................................3-1
AC Adapter.............................................................................. 3-2
Battery Pack............................................................................. 3-3
Charging the Battery Pack ................................................. 3-3
Initializing the Battery Pack............................................... 3-4
Checking the Battery Level ................................................ 3-4
Replacing the Battery Pack................................................ 3-5
Battery Low Signals and Actions ....................................... 3-7
Power Management ............................................................... 3-8
Hibernation......................................................................... 3-9
Power-Saving Tips................................................................. 3-10

iii
Chapter 4 Expanding Your Computer...........................................4-1
Connecting an External Monitor ........................................... 4-2
Connecting a Serial Device..................................................... 4-3
Connecting a USB Device ....................................................... 4-4
Connecting an IEEE 1394 Device............................................ 4-5
Connecting Audio Devices ..................................................... 4-6
Using ExpressCards.................................................................. 4-7
Using PC Cards......................................................................... 4-9
Using Smart Cards (Optional)............................................... 4-11
Using SD Cards ...................................................................... 4-12
System Memory Upgrade ..................................................... 4-13
Chapter 5 Using BIOS Setup and System Recovery......................5-1
BIOS Setup ............................................................................... 5-2
When and How to Use ....................................................... 5-2
Information Menu .............................................................. 5-3
Main Menu.......................................................................... 5-4
Advanced Menu.................................................................. 5-5
Security Menu ................................................................... 5-11
Boot Menu ........................................................................ 5-13
Exit Menu .......................................................................... 5-14
System Recovery.................................................................... 5-15
Chapter 6 Using Getac Software ...................................................6-1
Using the OSD Control Panel ................................................. 6-2
Quick Button Setup ............................................................ 6-6
Using Button Manager ........................................................... 6-8
Using G-Manager.................................................................. 6-10
Starting G-Manager.......................................................... 6-10
System Tab ........................................................................ 6-11
Battery Tab........................................................................ 6-12
ECO Tab ............................................................................. 6-14
ECO Information............................................................... 6-15
Light Sensor Tab ............................................................... 6-16
Antenna Tab ..................................................................... 6-17

iv
Ignition Tab....................................................................... 6-18
Monitoring Tab................................................................. 6-19
GPS Status Tab .................................................................. 6-21
Using Getac Camera.............................................................. 6-22
Taking Pictures.................................................................. 6-24
Shooting Videos................................................................ 6-26
Using View Mode ............................................................. 6-27
Camera Settings................................................................ 6-31
Chapter 7 Caring for the Computer ..............................................7-1
Protecting the Computer ....................................................... 7-2
Using an Anti-Virus Strategy ............................................. 7-2
Using Action Center (for Windows 7) ............................... 7-2
Using the Cable Lock .......................................................... 7-3
Taking Care of the Computer ................................................ 7-4
Location Guidelines............................................................ 7-4
General Guidelines ............................................................. 7-4
Cleaning Guidelines............................................................ 7-5
Battery Pack Guidelines...................................................... 7-5
Touchscreen Guidelines...................................................... 7-7
When Traveling....................................................................... 7-8
Chapter 8 Troubleshooting............................................................8-1
Preliminary Checklist............................................................... 8-2
Solving Common Problems .................................................... 8-3
Battery Problems ................................................................ 8-3
Bluetooth Problems............................................................ 8-3
Display Problems................................................................. 8-4
Hardware Device Problems................................................ 8-5
Hard Disk Drive Problems................................................... 8-5
Keyboard, Mouse, and Touchpad Problems ..................... 8-6
LAN Problems...................................................................... 8-6
Power Management Problems .......................................... 8-7
Software Problems ............................................................. 8-7
Sound Problems .................................................................. 8-8

v
Startup Problems ................................................................ 8-8
WLAN Problems .................................................................. 8-9
Other Problems................................................................. 8-11
Resetting the Computer ....................................................... 8-12
Appendix A Specifications............................................................... A-1
Appendix B Regulatory Information .............................................. B-1
On the Use of the System.......................................................B-2
Class B Regulations .............................................................B-2
Safety Notices .....................................................................B-3
On the Use of the RF Device ..................................................B-6
USA and Canada Safety Requirements and Notices ........B-6
European Union CE Marking and Compliance Notices....B-9
User Notification of Take-back Service ...............................B-13

Getting Started 1-1
Chapter 1
Getting Started
Congratulations on purchasing this rugged computer.
This chapter first tells you step by step how to get the computer up and
running. Then, you will find a section briefly introducing the external
components of the computer.

1-2 Getting Started
Getting the Computer Running
This section guides you through the procedures for getting the computer
ready for operation.
Unpacking
After unpacking the shipping carton, you should find these standard items:
Notebook computer
Accessories:
−AC adapter
−AC power cord
−Shoulder strap
−Handgrip strap
−Stylus and tether
−Digitizer pen (option)
−Driver disc
−Documents
Inspect all the items. If any item is damaged or missing, notify your dealer
immediately.
Keep the shipping carton and packing materials in case you need to ship or
store the computer in the future.
