Geyser ULTRA BIO 411 User manual

411
421
431
441
for soft water
for hard water
for ultra-hard
for ferruginous
MODIFICATIONS
OF GEIZER-ULTRA BIO

2
CONTENTS:
Purpose ......................................................................................................... 3
Specications................................................................................................ 4
Scope of supply ............................................................................................. 5
Getting connected ......................................................................................... 7
Getting started .............................................................................................. 8
Filter maintenance......................................................................................... 8
Regeneration ............................................................................................... 10
Warranty obligations ....................................................................................12
Thank you for buying the Geyser water lter!
Our developments and technologies make it possible to ensure the excellent water
quality in your house.
Water lter Geyser-ULTRA BIO – you can drink water without boiling it!
All functionality and the installation method are described in these Instructions.
Please carefully read it and keep for future reference.

3
PURPOSE
In the Geyser-Ultra Bio lters, there are employed both conventional water purication
methods: mechanical ltration, ion exchange, sorption and deferrization, and innovative ones:
decontamination, removal of viruses, cysts, bacteria, humic compounds. The effect of quasi-
deneutralization that is characteristic of the Aragon material makes it possible to produce not
only absolutely clean and safe water, but also tasty and useful water.
The Geyser-Ultra Bio water lters are distinguished by the logic and thoughtful nature of each
phase of purication, which results in the fact that the long useful operation time and stable
purication efciency is guaranteed for the entire system throughout the service life.
Due to the unique combination of the Aragon Bio and Disruptor cartridges, the Geyser-Ultra Bio
water lters are capable to protect you against contamination of all classes while maintaining
the natural composition of microelements in soft water, and to soften hard water and to make
it benecial to health.
The Aragon Bio cartridges guaranteed to remove from water not only harmful impurities but
also bacteria and viruses (Patent No. 2506232).
You can drink water puried by the Geyser-Ultra Bio lters without boiling it.
This is conrmed by:
• Scientic Research Institute named after A. N. Sysin (Moscow),
• Influenza Scientic Research Institute (St. Petersburg),
• Universita di Ferrara (Italy),
• Institut Paster (France).
Advantages of unique Aragon material (Patent No. 2203721):
High efciency of impurity removal (hardness salts, iron, heavy metals, radionuclides,
chlorine, etc.).
Active silver in the wash-fast form suppresses the growth of ltered bacteria.
The selndication of the useful operating time: scale formation or reduction in water
head indicate the need for the cartridge replacement.
Antirelease: all ltered impurities are permanently trapped in the labyrinth structure
of the cartridge.
Quasisoftening: in the process of ltration through the Aragon cartridge, water is
saturated with useful calcium – Aragonite (heart disease prevention). When boiling,
puried water forms no scale on heating elements.
GEIZER-ULTRA BIO PACKAGE CONTENTS
Model First stage Second stage Third stage casing Application
411 PFM, AFМ, РР Aragon S-BIО+В(Са) Disruptor/
ММB white
soft water
421 PFM, AFМ, РР Aragon 2-BIО Disruptor/
ММB white
hard water
431 Aragon 2-BIО BS Disruptor/
ММB white
ultra-hard water
441 BА Aragon H-BIО Disruptor/
ММB white
ferruginous water
FILTERING MATERIALS AND CARTRIDGES USED
Mechanical sediment - protection cartridge (EFМ, PFМ, PP) made of polypropylene
removes dirt, suspended matter and insoluble impurities from water.
Aragon S-BIO retains useful calcium in soft water.
Aragon 2-BIO has an increased useful life of removing hardness salts.
Aragon H-BIO: reduced hardness, removal of heavy metals.

4
The Ultra Bio 411 Model has a V(Ca) dispenser additionally installed inside its Aragon
М-BIO cartridge to enrich water with useful micro-elements.
Disruptor is the most recent technology to remove viruses, cysts, bacteria, humic
compounds. Unique ltering material based on nanoaluminium ber by American company
Ahlstrom. Efciently reduces a level of chlorine, iron and heavy metals
ММB is a cartridge of high-quality carbon ber. Efciently removes organic and chloro-
organic compounds, free chlorine, unpleasant odor and foreign taste. Silver contained in
the cartridge provides the bacteriostatic effect throughout the service life.
BS cartridge is intended for hard water. It contains food-compatible ion-exchange resin to
soften water (to remove hardness salts). This cartridge can be repeatedly used many times
after regeneration.
EFFICIENCY OF PRINCIPAL IMPURITIES PURIFICATION
Suspended impurities
(rust, sand, algae, other particles) over 5 µm 100%
Heavy and radioactive metals
(lead, cadmium, copper, strontium-90, caesium) up to 99%
Active chlorine 100%
Organic compounds up to 92%
Hardness salts up to 85%
Microorganism and coliform bacillus 99%
Hepatitis A virus, rotaviruses and Noroviruses 99%
MEAN SERVICE LIFE AND MEAN USEFUL OPERATION OF CARTRIDGES
Cartridge Service life*, months Useful operation*, l
Sediment-protection 12 up to 7,000
Aragon S-BIO/Aragon 2-BIO
Aragon H-BIO 12 up to 7,000
Disruptor/ММB 18 up to 10,000
BА** 6–8 up to 2,000
BS *** 12 up to 4,000
* depends on contamination degree of initial water
** given the iron content of water up to 1 mg/l with consideration for regeneration
*** at hardness up to 3 mg-eq/l with consideration for regeneration
SPECIFICATIONS
Overall dimensions of water purier assembly no more than, mm 380 × 310 × 140
Recommended ltration rate no more than 3.5 l/min
Operating pressure up to 7 atm
Frequency of BS cartridge regeneration (at hardness of 6–4 mg-eq/l) 200–400 l
Temperature of water to be ltered +4...+40 °С
Weight without packing no more than 6.5 kg

5
1. Filter assembly
2. Wrench for body
3. Wrench for bottom plug
4. Clear water faucet
5. Decorative cap
6. Rubber washer
7. Plastic washer
8. Fastening nut with washer
9. Piston
10. Collet clamp nut 1/4”
11. Connecting tube 1/4”
12. T-piece adapter with faucet knob
13. Manual
14. Packaging
SCOPE OF SUPPLY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
GETTING CONNECTED
Connection may be only done by a qualied technician or a manufacturer’s
representative! In case of do-it-yourself connection, strictly follow these instructions.
It is not recommended to dismantle the factory connections if it is not required.
Attention! All lter bodies passed the tightness test under high-pressure. To prevent
it from being cracked, always keep the Aragon cartridge in wet conditions. If there breaks
longer than 1 month in using the lter, make sure that water is always left in the lter body.
Attention! In case of the pressure increase higher than 6 atm in the system, it is required
that a pressure reducer to be installed upstream of the lter.
Prior to beginning the work, cut off the cold water supply to the connection point and
depressurize by opening any faucet located downstream of the water cut-off point.
Before the installation, make sure that the lter flasks are securely tightened (if
required, tighten up) and make the connection according to the instructions.
Attention! The position of the vertical sticker strictly in the middle of the lter front side
does not guarantee the connection tightness. The sticker position might change when the
threaded connection of the flask is tightened.

6
The system is to be connected to the cold
water mains.
1
5
6 3
2
8
15
9
6
10
4
7
Piston
15
12
13
14
11
1Bracket
2Adapter 1/2˝х 1/4˝
3Sealing ring
4Cartridge cases
5T-piece adapter with faucet knob
6Connecting tube 1/4”
7Cartridges
8Caps of cartridge cases
9 Collet clamp nut 1/4”
10 Faucet
11 Decorative cap
12 Rubber gasket
13 Plastic washer
14 Fastening nut with washer
CONNECTION DIAGRAM

7
CONNECTION TO WATER PIPELINE
1. Install T-piece adapter (А) into the cold water mains sealing the connections (Fig. 1).
2. Insert the plastic tube into nut (В) (Fig. 2). Insert the tube into the ball valve tting as
far as it will go and tightly screw the nut (Fig. 3).
2
В
А
1
CONNECTION OF CLEAN WATER FAUCET
Drill a hole 12 mm in diameter in the sink. Assemble the faucet as follows:
1. Faucet
2. Decorative cap
3. Rubber gasket
4. Plastic washer
5. Rubber washer
6. Metal washer
Secure the faucet on the sink. Pass through the blue-color tube into nut (Е) (Fig. 1). Insert
piston (Z) inside the tube as far as it will go. Put plastic stop ring (L) onto the tube end (Fig.
2). Screw the nut onto the threaded faucet rod (Fig. 3).
3
CONNECTION PROCEDURE
The system is to be connected to the cold water
mains. Remove the lter from its packing. Remove the
transportation plugs. Press a tip of a screwdriver against
the plastic ring in the connection and remove the plug
without applying force (Fig. 1).
Cut the tube of the connection kit into 2 pieces and
connect each one to the lter inlet and outlet.
Attention! Inlet – rst stage. Outlet – third stage.
Install the lter in the convenient place for use.
1

8
3
12
3
GETTING STARTED
Prior to using, wash through the lter for 2–5 minutes. The lter should be also washed
after the replacement of the cartridges and after the long-time (more than 5 days) of the
break in use.
After a new lter has been installed or the cartridges have been replaced, air remains
in the system. That would result in excessive aeration of water (visually, water may be of
milk-white color). As the lter operates, air is being removed from the system and puried
water will become clear.
2
1
Е
ZL
FILTER MAINTENANCE
When to provide maintenance Cartridge Type of maintenance
Occurrence of scale signs BS, Aragon 2-BIO Regeneration
Noticeable reduction in ltration
rate
PFМ, EFМ, PP Replacement
Aragon 2-BIO,
Aragon H-BIO,
Aragon S-BIO
Mechanical cleaning or replacement
Reduction in water quality Disruptor, ММB Replacement
Upon expiry of their useful operation time or service life, the cartridges shall be
replaced.
REPLACEMENT OF CARTRIDGES OF I, II, III STAGES
Cut off water at the inlet (Fig. 1). Open the clean water faucet to depressurize the
system (Fig. 2). Using the wrench, unscrew the lter flask (Fig. 3), check the conditions of
the O-ring and replace it, if required, then replace appropriate cartridge (Fig. 4, 5).

9
4 5 6
It is recommended that, prior to reinstallation, silicone grease (do not mix up with
sealant!) or vaseline should be applied on the O-ring.
Install the flask in place and tighten with the wrench.
Check the system for tightness opening water supply to the lter. (Fig. 6). The system
is ready for operation.
REPLACEMENT OF MINERALIZER FOR MODEL 411
tting piece В
2
13
Using the wrench for the bottom plug, screw out the bottom plug from the Aragon
М-BIO cartridge (Fig. 1), remove dispenser B(Ca).
When replacing the Aragon М-BIO cartridge, it is required to withdraw tting piece “В”
(Fig. 3) from the cartridge used and transfer it to a new cartridge.
Remove the lid of the new dispenser, insert it (Fig. 2) with its opened side facing
upwards. Screw in the bottom plug as far as it will go.
Reassemble the lter in reverse order and wash it through for 2–5 minutes. The system
is ready for operation.
Unscrew the flask using
the supplied wrench and
screw out the Aragon М-BIO
cartridge.
Drain water from it.

10
Removing of hardness salts from BS cartridge
Cut off water upstream of the lter and open the clean water faucet to depressurize
the system.
Unscrew the flask with the supplied wrench.
Remove the BS cartridge from the body.
Unscrew the cartridge cap and transfer the cartridge content into a glass or plastic
container with a capacity of at least 2 l.
Prepare 1 liter of saturated solution of cooking non-iodized salt (300 g of salt per 1 liter
of water) and pour it over ion-exchange resin.
Attention! Solution may be bubbling due to air escaping from resin.
Mix up the container content and leave it for 1–2 hours agitating it from time to time.
Carefully drain the salt solution. Pour cold water over resin. Mix up, drain water. Repeat
the operation two times more.
Transfer resin into the body and screw the cartridge cap.
Put the cartridge into the flask. If required, replace the O-rings. It is recommended that,
prior to installation, silicone grease (do not mix up with sealant!) or vaseline should be
applied on the O-ring. Install the flask in its place in the lter and tighten with the wrench.
Check the system for tightness opening water supply to the lter. Wash the lter through
for 2–5 minutes.
The system is ready for operation.
Attention! When carrying out the regeneration, it is required to prevent washing
solutions from contacting with eyes as it might bring pain. In case of contact, thoroughly
wash your eyes with water!
CARTRIDGE CLEANING AND REGENERATION
ATTENTION!
In replacement, it is recommended to use replaceable components Geyser. Failure
to comply with this requirement might result in changes to the functionalities and
specications of the water-purication system.
www.geizer.com
MANUFACTURER: AKVATORIYA LTD
Legal address:
69 Shosse Revolyutsii, build. 6, lit. A, Saint Petersburg, Russia 195279
Tel./Fax: [phone] (multichannel)
Mailing address:
195279, St. Petersburg, B.O. 379
e-mail: of[e-mail]
Internet-Shop: shop.geizer.com
You can have the full list and locations of the representative ofces on the web-site
www.geizer.com or by phone in St. Petersburg [phone]
ТU 3697-018-48981941-2009
Agreed price
Declaration of conformity:
ТС N RU Д-RU.HO03.B.00113 dated 12.03.2015

STATEMENT BY INSTITUT PASTER DE LILLE, FRANCE
REMOVAL OF MICROORGANISMS FROM WATER USING GEIZER FILTERS
In accordance with the test report based on the ltration of the articially contaminated ul-
tra-clean water, the GEYSER ARAGON BIO lters are capable to remove the bacterial and viral
contamination with the following parameters:
- Legionella pneumobilia, Serogroup 1 (CIP 103854): mean removal efciency 99.99987% (5.9
log)
- Salmonella Typhimurium (ATCC 14028): mean removal efciency 99.998% (4.8 log)
- Poliovirus, Sabin Strain of Type 1: mean removal efciency 99.84% (2.8 log)
- Rotavirus, Simiens Strain SA114F1: mean removal efciency 99.99% (4.0 log)
- Hepatitis A virus, Strain HM175/18f (ATCC VR-1402): mean removal efciency 96% (1.4 log)
Lille, September 03, 2014

MATTERS OF AFTERSALES SERVICE ARE TO BE ADDRESSED TO:
WARRANTY
The guaranteed service life of the lter is 5 years from the sales date. If the sales date
and a stamp of the sales company are missing, the guaranteed service life is calculated
from the date of lter manufacture. The warranty does not apply to the cartridges: for
those, the useful operation is indicated in the table on Page 4. When any factory defects
are found in them, the cartridges may only be replaced against the warranty after they have
been undergone the appraisal by the Aftersales Service representative.
The manufacturer disclaims the responsibility for the lter operation and for possible
consequences in cases where:
the lter or its component parts have mechanical damages;
in connecting and operating, the requirements of these instructions were not met or
original cartridges and components were not used;
cartridges have been overaged;
the lter was not used for the designed purpose (to treat hot or corrosive fluids).
The service life of the lter is 10 years. The maintenance and post-warranty service are
provided by the manufacturer or its regional representatives.
The Aftersales Service guarantees the free correction of defects, during a period of 6
months, in the lter connections and attachments, with above defects occurring due to the
manufacturer fault when installing the lter.
The shelf life of the lter - 3 year.
WARRANTY CARD
Date of issue:
To be completed by sales company
Date of sale
Stamp of the store
SAFETY PRECAUTIONS, STORAGE AND TRANSPORTATION
Prevent the lter and cartridges from being hit, dropped, exposed to negative temperatures
and direct sunlight. The lters may be transported in any enclosed means of transportation
(except for non-heated air plane compartments) according to the freight transport regulations
applicable for given means of transportation.
The lters shall be stored packaged at a distance of at least 1 m from heating appliance.
Avoid exposing to aerosols, aggressive and odorous substances.
Disposal shall be in accordance with the sanitary, environmental and other requirements
established by the national standards in the eld of environmental protection.
