This emergency open module must be connected into connection circuit between airlock
module and control panel and supplies the following functions:
- Airlock function can be switched OFF in an emergency (panic) situation. Thereafter both
doors open automatically if the push button S42 or S43 will be activated. (Principle 1;
Fig.: 1 + 2)
- OFF - respectively Re-made of the airlock function when using a latching key-switch S44
(Principle 2; Fig.: 3).
Both functions are single use functions and working independent from each other, whereby
OFF and Re - made of the airlock function has priority instead of the emergency function.
DESCRIPTION
Emergency open module
X44 X1
123456 14
SUPPLY EMERGENCY OPEN MODULE
The supply of 230VAC 50 Hz will be delivered about terminal X1 1.8 / 1.9 into theTS981.
Ina matterof shortcircuit a1Amicrofuseprotectsthesystem.

Page 5
The enclosure should be fitted directly beside the control panel. To connect the module, the
lateral rubber plug must be carefully opened. The module cable should be guided thru the hole
into the control enclosure, and following the pre-fitted cable gland may be softly tightened by
using the enclosed nut.
ThemoduleconnectionplugmustbefittedintotheSLFsocketoftheTS981controlpanel.Tocheck
theproperconnectiontheconnectioncablemaybepulledcarefully.
Thereafter the cable could be laid into the housing and cable gland should be finally tightened.
The SLF-Module A or B must be connected to the emergency open module.
To do so, follow description above.
ENCLOSURE INSTALATION
Control panel TS 981
12345678910
X43
87
6
5
4
3
21
SLF
Modul A or B
Emergency open module

Page 6








Note:
When Re-made during upwards travel of the door: If the button S41 will be
contacted both doors will be stopped.
When Re-made to emergency open function: This should be set only if both
doors are open. Thereafter one door must be closed to reactivate the airlock
function.
Principle 1:
In an emergency situation the airlock function will be switched OFF when activating
the button S42 or S43 and following both doors travelling to final open position.
If contacted S 42: Emergency open function activated
If contacted S 41: Emergency open function OFF, Airlock function ON
Fig.: 1
WIRING










Fig.: 2
If contacted S 43: Emergency open function activated

Page 7
WIRING
Prinzip 2:
OFF- respectively remaking of airlock function
Airlock OFF must always be made with a latching key-switch. (Fig. : 3) This latching switch
guarantees the OFF position and both doors can be used independent and in normal mode








12


Fig.: 3
Note:
To activate the airlock function after a re-made, the minimum of one
door must travel to the final closed position.
