GFW JAKARTA LONG JOHN NEST OF TABLES User manual

Big Table Size: 120 x 39 x 42 cm (WDH)
Small Table Size: 54 x 39 x 36 cm (WDH)
Colour: Mango
Finish: Melamine Veneer
JAKARTA LONG JOHN NEST OF TABLES - ASSEMBLY INSTRUCTIONS
Thank you for purchasing the Jakarta Long John Nest.
Please read the instructions carefully to ensure safe operation of this product.
Batch No. 140317
Page 1 of 6
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking.
Tools Required
Number of people
x1
0.5 Hour
Set Up

JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 2 of 6
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
INFORMATION
CARE INFORMATION
•Never use scourers, abrasives or chemical cleaners.
•To clean, wipe with a damp sponge and warm soapy water.
•Do not use solvent based cleaners or detergents as they can bleach or damage the product.
WARNINGS
•Each table is designed to hold 10Kg in total. Do not exceed this weight.
•We recommend that this unit is assembled in the room intended for use.
•When you are ready to start, make sure that you have the right tools, plenty of space and a
clean, dry area for assembly.
•Unwrap all packaging materials and place the components on top of the carton box or on a
clean floor to prevent them from getting scratched.
•Check the pack and make sure you have all the parts listed.
•Ensure that this product is fully assembled as illustrated before use.
•Check all screws or bolts are tightened and inspect regularly.
•Tools not included unless specified in the parts list.
•This product should only be used on a firm and level floor.
•Please do not drag across the floor or carpet as legs may be damaged - lift into place.
•Make sure the legs remain in contact with the floor when being used.
•Keep small parts out of reach of children.
•DO NOT
•DO NOT
•DO NOT
•DO NOT
•DO NOT
•DO NOT
use tables for 12 Hours to allow dowel glue to dry - see Steps 2 & 3.
use power tools to construct this product.
tighten screws until parts are assembled or as advised in this guide.
over tighten screws or bolts.
use this product if parts are missing, damaged or worn.
sit or stand on the Tables.

JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 3 of 6
Parts and Fittings Checklist
Please check the pack contents before assembling the product. If any components are missing,
please contact your retailer.
The fittings pack contains small items that should be kept away from children.
1
2
2
3
3
4444
All parts are packed in one carton
Description: Short Side Panels
Qty: 4
Size: 310 x 388 x 50 mm
Carton No: 1/1
4
1
2
3
Description: Long Table Top
Qty: 1
Size: 1200 x 390 x 50 mm
Carton No: 1/1
Description: Tall Side Panels
Qty: 2
Size: 370 x 388 x 50 mm
Carton No: 1/1
Description: Short Table Tops
Qty: 2
Size: 540 x 390 x 50 mm
Carton No: 1/1

JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 4 of 6
12A
12B
12C
Item QuantityCode
Fittings (to scale)
Cam Lock
Dowel (60x10mm)
Cam Bolt
10 20 30 40 50 60 70 80
(35mm overall)
General Hints & Tips
A26mm
A
A
B
Tighten
Stop when
level
Fittings (not to scale)
QuantityCode Item
12K Cam Lock Cover
1L Wood Glue for Dowels

JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 5 of 6
STEP 1
STEP 2
For this step:
Tools required
For this step:
Tools required
Fittings required
B x4
C x4
K x4
L x1
C
Tighten
B
1
1
2
2
3
x2
A
A
A
A
A
A
A
A
Fittings required
A x12
C
C
C
C
BK
BK
K
B
K
Put glue in all x8 dowel
holes & allow to dry -
please do not use or move
table for at least 12 Hrs.
B
L
L

x2
JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 5 of 6
Warning:
STEP 3
STEP 4
Fittings required
For this step:
Tools required
B x8
For this step:
Tools required
C x8
C
C
C
C
BK
B
K
K
B
KB
K x8
Fittings required
Tighten
B
4
4
3
C
After assembling, please do not use or
move product for at least 12 hours to
make certain glue has time to dry.
L x1
Put glue in all x8 dowel
holes, one table at a time
& allow to dry. Please do
not move or use tables
for at least 12 Hrs.
L

JAKARTA LONG JOHN NEST ASSEMBLY INSTRUCTIONS
Batch No. 140317
Page 6 of 6
Assembly Completed
Your Jakarta Long John Nest is now completely assembled.
Periodically check to ensure that the components are in their proper position, free from damage.
Also, make sure the connectors are tight and secure.
Keep instructions for future reference
