GFW KORE BEDFRAME 120CM User manual

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list.
Do not destroy any of the packaging until you are certain that you have all the necessary parts
for the assembly.
CAUTION:There are small components used in the construction of this unit.These loose items should
be kept away from young children whilst assembling your unit to avoid the danger of choking hazards.
Thank you for purchasing the KORE BEDFRAME 120CM.
Please read the instructions carefully to ensure safe operation of the product.
V2 1/23
Page 1 of 10
4mm Allen key x 2
Tools Required
x2
15Minutes
Set Up
1900mm×1200mm×253mm 4ft SMALL DOUBLE

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 2 of 10
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
INFORMATION
•This product is intended for a maximum person’s weight of 110kg per side. Do not exceed
this weight.
•Due to the size of this product we recommend that it is assembled in the room intended for use.
•When you are ready to start, make sure that you have the right tools, plenty of space and a
clean, dry area for assembly.
•Unwrap all packaging materials and place the components on top of the carton box or on a
clean floor to prevent it from scratching.
•Check the pack and make sure you have all the parts listed.
•Ensure that this product is fully assembled and secured as illustrated before use.
•Check all screws or bolts are tightened and inspect regularly.
•This product should only be used on firm, level ground.
•Please dismantle for transportation
•Tools are included.
WARNINGS
•DO make sure the feet remain in contact with the ground.
•DO keep small parts out of reach of children.
•DO NOT use power tools to construct this product.
•DO NOT tighten screws until fully assembled.
•DO NOT over tighten screws or bolts.
•DO NOT use this product if parts are missing, damaged or worn.
•DO NOT stand on the product.
•DO NOT insert foreign objects into the product or attempt to repair this unit by yourself.
•When moving the bed always lift into position . Never drag or pull your bed otherwise
it could damage essential components.
CARE INFORMATION
•Never use scourers, abrasives or chemical cleaners.
•To clean wipe with a sponge and warm soapy water. Do not use solvent based cleaners
or detergents as they can bleach or damage the product.

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 3 of 10
Please check the pack contents before assembling the product.If any
components are missing,please contact your retailer.The fittings pack
contains small items that should be kept away from small children.
(NOT TO SCALE)
1
3
2
2
1
3
4
5
5
2
6

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 4 of 10
1
ADJUSTABLE CENTRE FEET
3PCS
Dimension: 30*20*20mm
END RAILS
2PCS
Dimension:
1200*253*25mm
ADHESIVE RUBBER
ANTI SLIP PADS
8PCS
Dimension: 22*22*3mm
SLATS
2SETS
Dimension:
1147*770*13mm
CENTRE SUPPORT RAIL
2PCS
Dimension:
939*80*65mm
2 3 4
567
Parts (NOT TO SCALE)
SIDE RAIL
2PCS
Dimension:
922*120*50mm
CENTRE SUPPORT FEET
1PC
Dimension:
645*120*80mm

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 5 of 10
CAUTION: There are many small components used in the
construction of this product. Please keep these components
away from young children whilst assembling this product .
If you keep the fittings in a bowl during assembly you will
be less likely to lose them!
Fixings (to scale)
Ref Dimensions Qty
A12
B
Bolt-M6x15
1
C
Bolt-M6x40
4
4mm Allen Key 2
F
(Not to scale)
E16
''T''Nut-Ø6x16
D4
Flat Washer-Ø6x16
Bolt-M6x25

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 6 of 10
Lay out all 4 sides on a soft surface i.e. Rug, Carpet or Packaging
Carton.
Layout Parts on Soft Surface
3
3
1
1

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 7 of 10
''T''Nut x 4
Flat washer x 4
4mm Allen key x 2
D
E
F
Step1 Parts Required
Step2 Parts Required
3side rail x 2
1End rails x 2
C
E
D
3
3
1
Flat washer x 4
4mm Allen key
E
F
15mm M6 Bolt x 4A
25mm M6 Bolt x4
C

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 8 of 10
Parts Required
Parts Required
5Centre support rail x 2
2Adjustable centre
feet x 3
4
4
5
iiii
4
3Side rail x 2
5Centre support rail x 2
40mm M6 Bolt x 1
B
15mm M6 Bolt x 8A
25mm M6 Bolt x4
C
Flat washer x 12
4mm Allen key x 2
E
F
1
Centre support feet x 1
4Centre support feet x 1
End rails x 2
Step3
Step4

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 9 of 10
Step5
Step6

KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
V2 1/23
Page 10 of 10
Parts Required
Suitable for all types and depth of mattress.
Keep instructions for future reference
Step7
