Gigaset C810 User manual

2
The base at a glance
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / overview.fm / 15.09.2011
Version 4, 16.09.2005
The base at a glance
Gigaset C810
1Display in idle status
2Talk LED (green)
– Lights up when the line is in use.
– Flashes on incoming call.
3Power LED (red)
Indicates that the telephone is powered on.
4Display keys (¢page 19)
5Control key (¢page 19)
6End/Back key
7INT key
– making internal calls (¢page 25)
– registering handsets (¢page 39)
8Recall key
– Consultation call (flash)
– Insert a dialling pause (press and hold)
9Speaker key
Switch between earpiece and speaker mode.
Lights up when the speaker is switched on.
10 Redial key (¢page 28)
11 Mute key
Mute the microphone (¢page 23)
12 Star key
Ringtone on/off (press and hold);
with an open connection: switch between dial
pulsing/tone dialling (press briefly);
Text input: Open table of special characters
13 Priority key (¢page 24)
Memory key for IP code (press and hold)
14 Hash key
Keypad lock on/off (press and hold in
idle status);
toggles between upper/lower case and digits
(in editing mode)
Menu
2011-08-17 09:30
Gigaset
12 1411
1
2
3
4
5
6
7
8
9
10 13

3
The base at a glance
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / overview.fm / 15.09.2011
Version 4, 16.09.2005
Gigaset C810 A
1Display in idle status
2Talk LED (green)
– Lights up when the line is in use.
– Flashes on incoming call.
– Flashes during paging.
3Power LED (red)
Indicates that the telephone is powered on.
4Display keys (¢page 19)
5Control key (¢page 19)
6End/Back key
7INT key
– making internal calls (¢page 25)
– registering handsets (¢page 39)
8Redial key (¢page 28)
9Mute key (¢page 23)
Mute the microphone
10 Recall key
- Consultation call (flash)
- Insert a dialling pause (press and hold)
11 Speaker key
Switch between earpiece and speaker mode
12 Answering machine key (¢page 58)
Switch answering machine (AM) on/off.
Lights up: AM is switched on.
Flashes: Unheard messages on the AM.
13 Skip back to the beginning of the message or
skip back to the previous message (press
twice).
14 Skip to next message (press once) or next
message but one (press twice).
15 Play/stop key
Play back new messages from answering
machine or cancel playback (press briefly).
Play back new and old messages (press and
hold).
16 Star key
Ringtone on/off (press and hold);
with an open connection: switch between dial
pulsing/tone dialling (press briefly);
Text input: Open table of special characters
17 Priority key (¢page 24)
Memory key for IP code (press and hold)
18 Hash key
Keypad lock on/off (press and hold in
idle status);
toggles between upper/lower case and digits
1
2
3
4
5
6
7
8
9
10
11
MenuMemo
2011-08-17 09:30
Gigaset
12 14 1513 16 1817

4
The base at a glance
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / overview.fm / 15.09.2011
Version 4, 16.09.2005
Base display symbols
The following symbols are displayed dependent on the settings and the operating status of
your telephone:
ôÃ æ î ˝Z
Memo
2011-08-17 09:30
Gigaset
Ã1
Menu
Directory opened (¢page 27)
Keypad locked (¢page 20)
New missed calls (¢page 29)
Telephone in talk mode
(receiver lifted or speaker activated)
Answering machine activated
(C810 A only) (¢page 58)
Ringtone switched off (¢page 31)
Current date and time (¢page 30)
Number of new messages on the
answering machine (C810 A only),
(¢page 58)

5
The handset at a glance
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / overview.fm / 15.09.2011
Version 4, 16.09.2005
The handset at a glance
1Display in idle status
2Battery charge status
(¢page 6)
3Display keys (¢page 34)
4End call key, On/Off key
End call, cancel function, go back one menu
level (press briefly), back to idle status (press
and hold), activate/deactivate handset (press
and hold in idle status)
5Hash key
Keypad lock on/off (press and hold in
idle status);
toggles between upper/lower case and digits
6Recall key
– Consultation call (flash)
– Insert a dialling pause (press and hold)
7Microphone
8Message key (¢page 48)
Access to calls and message lists;
Flashes: new message or new call
9Star key
Ringtone on/off (press and hold);
with an open connection: switch between dial
pulsing/tone dialling (press briefly);
Text input: Open table of special characters
10 Priority key (¢page 43)
Memory key for IP code (press and hold)
11 Key 1 (¢page 61)
Dial answering machine (C810 A only) (press
and hold)
12 Talk key
Flashes: incoming call;
Accept a call (press briefly);
13 Control key (¢page 34)
uinitiate an internal call;
vmute the microphone during a call;
topen audio settings;
sopen the directory;
14 Signal strength icon of the connection to the
base
15 Answering machine icon (C810 A only)
(¢page 61)
Answering machine switched on;
Flashes: Answering machine is recording a
message or is being operated by another inter-
nal party.
You can register up to four handsets to the
Gigaset C810/810 A, (¢page 39).
ÐÃ U
Menu
07:15
Redial
2011-10-14
INT 1
§§2§§
§§3§§
§§4§§
§§5§§
§§6§§
§13§
§12§
§§7§§
§§1§§
§§8§§
§§9§§
§11§
§14§
§15§
§10§

6
The handset at a glance
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / overview.fm / 15.09.2011
Version 4, 16.09.2005
Handset display symbols
The following symbols are displayed dependent on the settings and the operating status of
your telephone:
Signalling
Display in idle status
Keypad locked
Ringtone switched off
Signal strength
Number of new messages
u Ãon the answering
machine (C810 A only)
u™in the list of missed calls
Answering machine activated
(C810 A only)
Handset in talk mode
Battery charging state
Name of the handset
Ðó˝Ã æU
Menu
07:15
Redial
2011-10-14
INT 1
™
3
Ã
1
¼08:00
Current date
Current time
Alarm switched on and
wake-up time
External call Internal call Alarm clock
Ø«Ú ØåÚ Ø¼Ú
uReception signal between the base and handset:
good to poor: ÐiÑÒ
If the handset goes out of range a warning tone will be heard.
uBattery charge status:
–
=eVU(empty to full)
–=flashes red: batteries almost empty
–
eVU during charging, the symbol is outlined red
while the charging state changes periodically
uINT 1
Internal name of the handset (¢page 54)
uIf the answering machine is activated, the Ãicon will be dis-
played in the header (Gigaset C810 A only).
You can find additional information about your telephone at www.gigaset.com/gigasetc810.
Have fun using your new phone!
ÐÃU
Menu
07:15
Redial
2011-10-14
INT 1

7
Contents
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / C810-C810A_KomboIVZ.fm / 15.09.2011
Version 4, 16.09.2005
Contents
The base at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Gigaset C810 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Gigaset C810 A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Base display symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The handset at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Handset display symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Checking the pack contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting up the base and handset charging cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting up the handset for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
The Gigaset C810/810 A base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Keys on the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Correcting incorrect entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Activating/deactivating the keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Menu guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Base menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Making an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Quick dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Accepting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Calling Line Identification (CLI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Speaker mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the earpiece/speaker volume during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Switching to mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
IP dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Making internal calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Internal consultation/conference calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Accepting/rejecting call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Barging in to an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using the directory and lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Redial list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Call lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8
Contents
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / C810-C810A_KomboIVZ.fm / 15.09.2011
Version 4, 16.09.2005
Base settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Quick access to numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting the earpiece and speaker volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting the ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Activating/deactivating advisory tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setting the display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Restoring the base factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
The Gigaset C810H handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Keys on the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Correcting incorrect entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Activating/deactivating the keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Activating/deactivating the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Menu guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Handset menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Registering other handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
De-registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Locating a handset (paging) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Making an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Quick dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Accepting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Calling Line Identification (CLI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Speaker mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the earpiece/speaker volume during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Switching to mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Battery status control during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
IP dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Making internal calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Internal consultation/conference calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Accepting/rejecting call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Barging in to an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Using the directory and lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Redial list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Call lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

9
Contents
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / C810-C810A_KomboIVZ.fm / 15.09.2011
Version 4, 16.09.2005
Handset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Quick access to numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setting the alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Setting the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Activating/deactivating auto answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Changing the name of the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Restoring the handset factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Connecting the telephone to the PABX . . . . . . . . . . . . . . . . . . . . . . . 56
Settings on the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Changing the dialling mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Setting recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Setting an automatic prefix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Temporarily switching to tone dialling (DTMF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Settings on the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Changing the dialling mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting an automatic prefix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Temporarily switching to tone dialling (DTMF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Operating the answering machine (Gigaset C810 A only) . . . . . . 58
Operation via the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Activating/deactivating the answering machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Playing back messages/memos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Picking up a call from the answering machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Activating/deactivating call screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Recording memos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Recording an announcement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Operation via the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Activating/deactivating the answering machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Playing back messages/memos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Picking up a call from the answering machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Activating/deactivating call screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Recording an announcement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Setting the answering machine mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Setting the recording parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Remote operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Calling the answering machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Operating the answering machine remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Replaying messages remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Activating/deactivating the answering machine remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

10
Contents
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / C810-C810A_KomboIVZ.fm / 15.09.2011
Version 4, 16.09.2005
Customer Service & Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Questions and answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Contact with liquid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Writing and editing text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

11
Safety precautions
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / security.fm / 15.09.2011
Version 4, 16.09.2005
Safety precautions
Warning
Read the safety precautions and the user guide before use.
Explain their content and the potential hazards associated with using the telephone to your
children.
Only use the mains adapters supplied, as indicated on the underside of the base.
Only use the recommended, rechargeable batteries (¢page 66) as this could oth-
erwise result in significant health risks and personal injury.
The operation of medical appliances may be affected. Be aware of the technical con-
ditions in your particular environment, e.g. doctor's surgery.
Do not hold the rear of the handset to your ear when it is ringing or when speaker
mode is activated. Otherwise you risk serious and permanent damage to your hear-
ing.
Your Gigaset is compatible with the majority of digital hearing aids on the market.
However, perfect function with all hearing aids cannot be guaranteed.
The handset may cause an unpleasant humming or whistling noise in hearing aids
or cause them to overload. If you require assistance, please contact the hearing aid
supplier.
Do not install the base or charging cradle in bathrooms or shower rooms. The base
is not splashproof (¢page 66).
Do not use your phone in environments with a potential explosion hazard (e.g. paint
shops).
If you give your Gigaset to someone else, make sure you also give them the
user guide.
Please remove faulty bases from use or have them repaired by our Service depart-
ment, as they could interfere with other wireless services.
$
ƒ

12
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
First steps
Checking the pack contents
1. one Gigaset C810 or C810 A base
2. one Gigaset C810H handset
3. one charger for Gigaset C810H
4. two batteries
5. one battery cover
6. one receiver
7. one receiver cable
8. one phone cable
9. two mains adapter
10.one user guide C810/C810 A
11.one user guide C810H
or
1
2 3
4
5
6
7
8
9
10

13
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
Setting up the base and handset charging cradle
The base and charging cradle are designed for use in enclosed dry rooms with a temperature
range of +5°C to +45°C.
¤Install the base on a level, non-slip surface in a central location in your house or flat.
Please note
Make sure you observe the range of the base for the handset connection.
This is up to 300 m in unobstructed outdoor areas and up to 50 m inside buildings.
The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of
different varnishes and polishes used on today's furnishings, the occurrence of marks on the
surfaces cannot be completely ruled out.
¤The display is protected by a plastic film. Please remove the protective film!
Please note:
uNever expose the telephone to the influence of heat sources, direct sunlight or other electri-
cal devices.
uProtect your Gigaset from moisture, dust, corrosive liquids and vapours.
Connecting the base
¤Connect the receiver to the
telephone using the coiled cable
supplied 1.
¤Connect the telephone jack 2.
¤Then connect the mains adapter 3.
¤Insert the cables into the cable
ducts.
Please note:
uThe mains adapter must always be
connected, as the phone will not
operate without a mains connec-
tion.
¤Only use the mains adapter and
phone cord supplied. Pin connec-
tions on telephone cables can vary
(pin connections ¢page 67).
1
2
1
1
1
2
1
3
1
3

14
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
Connecting the handset charging cradle
1
2¤Connect the mains adapter to the port on the underside
of the charger 1.
¤Plug the mains adapter into the plug socket 2.

15
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
Setting up the handset for use
The display is protected by a plastic film. Please remove the protective film!
Inserting the batteries and closing the battery cover
Warning
Only use the rechargeable batteries (¢page 66) recommended by Gigaset Communica-
tions GmbH, i.e. never use conventional (non-rechargeable) batteries, as this could result in
significant health risks and personal injury. For example, the outer casing of the batteries
could be damaged or the batteries could explode. The phone could also malfunction or be
damaged as a result of using batteries that are not of the recommended type.
¤Insert the batteries the right way round.
The polarity is indicated in/on the battery
compartment.
¤First insert the battery cover at the top.
Then press the cover until it clicks into
place.
If you need to open the battery cover, for
instance to replace the batteries, place your
fingertip in the cavity at the lower side of the
cover and pull the battery cover upwards.

16
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
Placing the handset in the charging cradle
¤Place the handset in the charging cradle with its display facing forward.
The handset delivered is registered with the base at the factory. You do not need to complete a
registration. If you wish to use your handset with a different base or use further handsets with
your base, you will have to register the handset manually, ¢page 39.
To charge the batteries, leave the handset in the charging cradle.
Initial charging and discharging of the batteries
The correct charge level can only be displayed if the batteries are first fully charged and dis-
charged.
Please note
Only place the handset in the charging cradle that is intended for it.
Please note
uAfter the first battery charge and discharge you may replace your handset in the charg-
ing cradle after every call.
uAlways repeat the charging and discharging procedure if you remove the batteries from
the handset and reinsert them.
uThe batteries may warm up during charging. This is not dangerous.
uAfter a while, the charge capacity of the batteries will decrease for technical reasons.
¤Place the handset in the charging cradle for 10
hours.
¤Then remove the handset
from the charging cradle
and do not replace it until
the batteries are fully dis-
charged.
10 h

17
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls, and
so that the alarm can be used. You can set date and time on the base or any registered handset.
On the base
Your telephone is now ready to use!
¤Press the key below §§Menu§§ on the screen dis-
play to open the display menu.
The menu is opened. The first entry Date/
Time is selected.
¤Press the key below §§Ok§§ to start the date and
time settings.
¤The active input position flashes.
¤Press the right or left control key to change
the input position and correct an entry.
¤Enter the year, month and day as an 8-digit
number via the keypad. The first two digits
(20) are fixed, i.e. you only have to enter six
digits.
E.g. QO2Lfor
26/09/2011.
¤Press the key below §§Ok§§ to set the time.
¤Enter the hours and minutes in 4-digit for-
mat via the keypad, e.g. QM/5
for 07:15 am.
Change the input position with the control
key if necessary.
¤Press the key below §§Ok§§ to save your set-
tings.
The display shows Saved. You will hear a confir-
mation tone and the display will automatically
return to the main menu.
MenuMemo
2011-08-17 09:30
Gigaset
Date/Time
OkBack
2011-08-17
Date/Time
OkBack
02:30

18
First steps
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / starting.fm / 15.09.2011
Version 4, 16.09.2005
What would you like to do next?
Now you have successfully started your Gigaset, you will probably want to adapt it to your per-
sonal requirements. Use the following guide to quickly locate the most important subjects.
If you are unfamiliar with menu-driven devices such as other Gigaset telephones you should
first read the sections entitled "Using the base" on page 19 or "Using the handset" on page 34.
If you have any questions about using your phone, please read the tips on
troubleshooting (¢page 65) or contact our Customer Care team (¢page 65).
Information on ... ... is located here.
for the base
for the handset
page 31
page 51
Setting the ringtone and volume
for the base
for the handset
page 31
page 51
Setting the earpiece volume
Recording a personal announcement for the
answering machine
at the base
at the handset
page 60
page 62
Operating the telephone on a PABX page 56
Registering new Gigaset handsets to the base page 39
Transferring directory entries to new handset(s) page 28
g
g
g
g
g
g

19
Using the base
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / BS_using.fm / 15.09.2011
Version 4, 16.09.2005
The Gigaset C810/810 A base
Using the base
Control key
Below, the side of the con-
trol key you need to press
in the respective operat-
ing situation is marked in
black (top, bottom, right,
left), e.g. vfor "press
right on the control key" or tfor "press at
the top of the control key".
The control key has a number of different
functions:
When the base is in idle status
sOpen the directory.
vIncrease the ringer volume.
uDecrease the ringer volume.
tOpen the call list.
In the main menu
t, s, vor u
Navigate to the required func-
tion.
In submenus and lists
t/ sScroll up/down line by line.
In input fields
Use the control key to move the cursor up
t, down s, right vor left u. Press and
hold vor uto move the cursor word by
word.
During an call
sOpen the directory.
u/ vAdjust the loudspeaker volume
for earpiece and speaker mode.
Display keys
The functions of the display keys change
depending on the particular operating situ-
ation. Example:
Some important display keys:
§§Menu§§ Open the menu..
§§Option§§ Open a submenu for further
functions.
§§Ok§§ Confirm selection.
§§< C§§ Delete key: delete one charac-
ter/word at a time from right to
left.
§§Back§§ Go back one menu level or can-
cel operation.
§§Save§§ Store entry.
In the following description the instruction
“press the display key §XXX§“ means:
“press the display key below the display key
function labelled XXX“.
Keys on the keypad
#/ Q/ Getc.
Press the matching key on the
keypad.
~Enter digits or letters.
Display keys
MenuMemo
Display key functions

20
Using the base
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / BS_using.fm / 15.09.2011
Version 4, 16.09.2005
Correcting incorrect entries
You can correct incorrect characters in the
input fields by navigating to the incorrect
entry using the control key. You can then:
uDelete the character by briefly pressing
Ñor press and hold to delete the word
to the left of the cursor.
uInsert characters next to the cursor.
uOverwrite the highlighted (flashing)
character, e.g. when entering time and
date.
Activating/deactivating the
keypad lock
The keypad lock prevents any inadvertent
use of the phone.
#Press and hold the hash key in
idle status to activate or deacti-
vate the keypad lock. You will
hear the confirmation tone.
If the keypad lock is activated, the ˝sym-
bol is displayed and a warning tone will be
emitted when you press a key.
The keypad lock deactivates automatically
when you receive a call. It is reactivated
when the call is ended.
Menu guidance
You can access your telephone's functions
using a menu that has a number of levels.
The full menu tree is shown in the next sec-
tion, ¢page 21.
Opening the main menu
¤When the telephone is in idle status press
the Menu display key to open the main
menu.
Browsing through the menu
To access a function or to open the corre-
sponding submenu (next menu level):
¤Use the control key qto select the
required function/submenu and press
the display key §Ok§.
To return to the previous menu level or to
cancel the operation.
¤Briefly press the display key §Back§.
Reverting to idle status
You can revert to idle status from anywhere
in the menu as follows:
¤Press the end key B.
Or:
¤Do not press any key: after 2 minutes the
display will automatically revert to idle
status.
Settings that have not been saved by select-
ing the display key §Ok§ or §Save§ will be lost.
Illustration of menu operation in
the user guide
Menu operations are shown in the user
guide in abbreviated form.
Example:
The illustration:
§§Menu§§ ¢Audio Settings ¢Ringer
Settings ¢Ringer Melody
means:
¤Press the §§Menu§§ display key to open the
menu.
¤Use the control key qto select Audio
Settings, press §Ok§.
¤Use the control key qto select Ringer
Settings, press §Ok§.
¤Use the control key qto select Ringer
Melody, press §Ok§.
Please note
When the keypad lock is active, you can
call emergency numbers only using the
receiver at the base.

21
Using the base
Gigaset C810/810 A / CHN en/ A31008-M2327-Y101-1-7619 / BS_using.fm / 15.09.2011
Version 4, 16.09.2005
Base menu overview
To open the main menu press the §Menu§ display key.
Date/Time ¢page 30
Audio Settings Call Volume Earpiece Volume ¢page 31
Handsfree Volume ¢page 31
Ringer Settings Ringer Volume ¢page 31
Ringer Melody ¢page 31
Advisory Tones Key Tones ¢page 32
Confirmation Tones ¢page 32
Display Contrast ¢page 32
Base Settings Language ¢page 30
Reset Base ¢page 33
System Settings Music on Hold ¢page 32
System PIN ¢page 32
Additional Features Dialing Mode ¢page 56
Recall ¢page 56
Barge In ¢page 26
Auto Prefix Activation ¢page 56
Prefix No. ¢page 56
Call List Type All Calls ¢page 29
Missed Calls ¢page 29
Call Barring ¢page 33
Voice Mail Announcements Rec. Announcement ¢page 60
Play Announcement ¢page 60
Del. Announcement ¢page 60
Call Screening ¢page 59
