2QUICK GUIDE | MyPIPETMAN®
Introduction
MyPIPETMAN® is an air displacement pipette that uses
disposable pipette tips. To meet user’s needs, MyPIPETMAN
is available in three offers, each with different levels of
technical and customization options. For more details, please
refer to MyPIPETMAN User’s Guide LT801622 available on
www.gilson.com.
MyPIPETMAN is available as variable volume, either single or
multichannel models.
●Eight single channel models cover a volume range from
0.2 μL to 10 mL.
●Eight multichannel models (4 models of 8 and 12
channels) cover a volume range from 0.5 μL to 300 μL.
Single Channel Models
●MyPIPETMAN pipette
●Quick Guide
●Tip ejector adapter equipped on the P2 and P10 models
●Bag of ten filters (only for P5000 and P10mL models)
●Certificate of Conformity
●Safety bag
Multichannel Models
●MyPIPETMAN pipette
●Quick Guide
●Ejector spacer for D10 tips (only for P10 models)
●Certificate of Conformity
●Safety bag
A A 50001
Year Month Production
number
YEAR CODE
2022 T
2023 U
2024 W
2025 X
2026 Y
2027 Z
MONTH CODE
January A
February B
March C
April D
May E
June G
July H
August J
September K
October L
November M
December N
Good Laboratory Practice (GLP) Compliance
The serial number is engraved on the body of the pipette.
It provides unique identification of your pipette and the
manufacturing date.
MyPIPETMAN Select and
MyPIPETMAN Enterprise
serial number type:
MY 524 A A
Model Random
Number
Month Year
MyPIPETMAN serial
number type:
The barcode on the box
and the Certificate of
Conformity provides
traceability of your
pipette.

3
MyPIPETMAN®|QUICK GUIDE
QUICK GUIDE | MyPIPETMAN®
Description
Figure 1
MYPIPETMAN® single channel and multichannel model
components
Color-coded
push button
Locking system
Tip ejector
button
Color ring
Connecting nut
Tip ejector
Ejector lock
Ejector clip
Tip holder
Cover
Single channel Multichannel
Customizable
handle
Colored
window

4QUICK GUIDE | MyPIPETMAN®
MYPIPETMAN® SINGLE CHANNEL
Vol.
(µL)
Maximum Permissible Errors
Gilson ISO 8655
Systematic
Error
(µL)
Random
Error
(µL)
Systematic
Error
(%)
Random
Error
(%CV*)
Systematic
Error
(µL)
Random
Error
(µL)
Systematic
Error
(%)
Random
Error
(%CV*)
MyPIPETMAN P2 with D10 and DL10 Tips
0.2
0.5
1
2
± 0.024
± 0.025
± 0.027
± 0.030
≤0.012
≤0.012
≤0.013
≤0.014
± 12.0
± 5.0
± 2.7
± 1.5
≤6.0
≤2.4
≤1.3
≤0.7
± 0.08
± 0.08
± 0.08
± 0.08
≤0.04
≤0.04
≤0.04
≤0.04
± 40.0
± 16.0
± 8.0
± 4.0
≤20.0
≤8.0
≤4.0
≤2.0
MyPIPETMAN P10 with D10 and DL10 Tips
1
5
10
± 0.025
± 0.075
± 0.100
≤0.012
≤0.030
≤0.040
± 2.5
± 1.5
± 1.0
≤1.2
≤0.6
≤0.4
± 0.12
± 0.12
± 0.12
≤0.08
≤0.08
≤0.08
± 12.0
± 2.4
± 1.2
≤8.0
≤1.6
≤0.8
MyPIPETMAN P20 with D200 Tips
2
10
20
± 0.10
± 0.10
± 0.20
≤0.030
≤0.050
≤0.060
± 5.0
± 1.0
± 1.0
≤1.5
≤0.5
≤0.3
± 0.2
± 0.2
± 0.2
≤0.1
≤0.1
≤0.1
± 10.0
± 2.0
± 1.0
≤5.0
≤1.0
≤0.5
MyPIPETMAN P100 with D200 Tips
10
50
100
± 0.35
± 0.40
± 0.80
≤0.10
≤0.12
≤0.15
± 3.5
± 0.8
± 0.8
≤1.0
≤0.24
≤0.15
± 0.8
± 0.8
± 0.8
≤0.3
≤0.3
≤0.3
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN P200 with D200 Tips
20
100
200
± 0.50
± 0.80
± 1.60
≤0.20
≤0.25
≤0.30
± 2.5
± 0.8
± 0.8
≤1.0
≤0.25
≤0.15
± 1.6
± 1.6
± 1.6
≤0.6
≤0.6
≤0.6
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN P1000 with D1000 Tips
100
500
1000
± 3.0
± 4.0
± 8.0
≤0.6
≤1.0
≤1.5
± 3.0
± 0.8
± 0.8
≤0.6
≤0.2
≤0.15
± 8.0
± 8.0
± 8.0
≤3.0
≤3.0
≤3.0
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN P5000 with D5000 Tips
500
2500
5000
± 12
± 15
± 30
≤3
≤5
≤8
± 2.4
± 0.6
± 0.6
≤0.6
≤0.2
≤0.16
± 40
± 40
± 40
≤15.0
≤15.0
≤15.0
± 8.0
± 1.6
± 0.8
≤3.0
≤0.6
≤0.3
MyPIPETMAN P10mL with D10mL
1000
5000
10000
± 30
± 40
± 60
≤6
≤10
≤16
± 3.0
± 0.8
± 0.6
≤0.6
≤0.2
≤0.16
± 60
± 60
± 60
≤30.0
≤30.0
≤30.0
± 6.0
± 1.2
± 0.6
≤3.0
≤0.6
≤0.3
*CV means Coefficient of Variation
Specifications
MyPIPETMAN is a high-quality pipette that has excellent
accuracy and precision, especially when used with PIPETMAN®
DIAMOND Tips. The data given in the “Gilson Maximum
Permissible Errors” table below was obtained using PIPETMAN
DIAMOND Tips. These values are guaranteed only when genuine
PIPETMAN DIAMOND Tips are used.
NOTE
The data given in this table conform to
the ISO 8655-2 standard. With a precise
pipetting technique, the P2 model can be
used to aspirate volumes as low as 0.1 μL
and the P10 model as low as 0.5 μL.

5
MyPIPETMAN®|QUICK GUIDE
QUICK GUIDE | MyPIPETMAN®
MYPIPETMAN® MULTICHANNEL MODELS
Maximum Permissible Errors
Vol.
(µL)
Gilson ISO 8655
Systematic
error
(µL)
Random
error
(µL)
Systematic
error
(%)
Random
error
(%CV*)
Systematic
error
(µL)
Random
error
(µL)
Systematic
error
(%)
Random
error
(%CV*)
MyPIPETMAN P8x10 & MyPIPETMAN P12x10 with D10 and DL10 Tips
0.5
1
5
10
± 0.08
± 0.08
± 0.20
± 0.20
≤0.04
≤0.05
≤0.10
≤0.10
± 16.0
± 8.0
± 4.0
± 2.0
≤8.0
≤5.0
≤2.0
≤1.0
± 0.24
± 0.24
± 0.24
± 0.24
≤0.16
≤0.16
≤0.16
≤0.16
± 48.0
± 24.0
± 4.8
± 2.4
≤32.0
≤16.0
≤3.2
≤1.6
MyPIPETMAN P8x20 & MyPIPETMAN P12x20 with D10L and D200 Tips
2
10
20
± 0.10
± 0.20
± 0.40
≤0.08
≤0.10
≤0.15
± 5.0
± 2.0
± 2.0
≤4.0
≤1.0
≤0.75
± 0.4
± 0.4
± 0.4
≤0.2
≤0.2
≤0.2
± 20.0
± 4.0
± 2.0
≤10.0
≤2.0
≤1.0
MyPIPETMAN P8x200 & MyPIPETMAN P8x200 with D200 Tips
20
100
200
± 0.50
± 1.00
± 2.00
≤0.25
≤0.40
≤0.50
± 2.5
± 1.0
± 1.0
≤1.25
≤0.4
≤0.25
± 3.2
± 3.2
± 3.2
≤1.2
≤1.2
≤1.2
± 16.0
± 3.2
± 1.6
≤6.0
≤1.2
≤0.6
MyPIPETMAN P8x300 & MyPIPETMAN P12x300 with D300 Tips
20
30
150
300
± 1.00
± 1.00
± 1.50
± 3.00
≤0.35
≤0.35
≤0.60
≤1.00
± 5.0
± 3.3
± 1.0
± 1.0
≤1.75
≤1.17
≤0.4
≤0.33
± 8.0
± 8.0
± 8.0
± 8.0
≤3.0
≤3.0
≤3.0
≤3.0
± 40.0
± 26.67
± 5.33
± 2.67
≤15.0
≤10.0
≤2.0
≤1.0
*CV means Coefficient of Variation
Setting the Volume
The volume of liquid to be aspirated is set using the volume
display. The dials are colored either black or red to indicate the
position of the decimal point, depending on the model (refer to
Figure 2 on page 6).
MODEL
COLOR OF VOLUMETER NUMBERS
BLACK RED INCREMENT
MyPIPETMAN SINGLE CHANNEL
MyPIPETMAN P2 µL 0.01 µL 0.002 µL
MyPIPETMAN P10 µL 0.1 µL 0.02 µL
MyPIPETMAN P20 µL 0.1 µL 0.02 µL
MyPIPETMAN P100 µL - 0.2 µL
MyPIPETMAN P200 µL - 0.2 µL
MyPIPETMAN P1000 0.01 mL mL 0.002 mL
MyPIPETMAN P5000 0.01 mL mL 0.002 mL
MyPIPETMAN P10mL mL 0.1 mL 0.02 mL
MyPIPETMAN MULTICHANNEL
MyPIPETMAN P8x10 µL 0.1 µL 0.02 µL
MyPIPETMAN P12x10 µL 0.1 µL 0.02 µL
MyPIPETMAN P8x200 µL - 0.2 µL
MyPIPETMAN P12x200 µL - 0.2 µL
MyPIPETMAN P8x300 µL - 0.2 µL
MyPIPETMAN P12x300 µL - 0.2 µL

6QUICK GUIDE | MyPIPETMAN®
Simple Ratchet
For pipettes mounted with a simple ratchet,
select the volume by turning the push button
(refer to Figure 3).
3-Position Locking System
For pipettes equipped with a 3-position locking
system, turn the selector to your desired
position (refer to Figure 4).
Free volume selection position
1. Turn the selector to the left until the
cursor reaches the unlocking 1.
2. Select the volume by turning the push
button.
Light click volume selection position
1. Turn the selector until the cursor
reaches the middle 2.
2. Select the volume by turning the push
button.
NOTE
When selecting the
volume, you will hear
click sounds, allowing
for more precise
settings.Use these
sounds for final fine
volume selection.
1
5
P2
1.25 µL
2
0
7
5
P10
7.5 µL
1
2
5
P20
12.5 µL
P100
0
7
5
75 µL
P200
1
2
5
125 µL
P1000
0
7
5
0.75 mL
P5000
1
2
5
1.25 mL
P10mL
0
7
5
7.5 mL
0
7
5
x10
7.5 µL
1
2
5
x20
12.5 µL
x200
1
2
5
125 µL
x300
1
2
5
125 µL
Multichannel
model
Single channel
model
Figure 2
Dial colors by model
Figure 3
Simple rachet
Figure 4
3-position
locking system

7
MyPIPETMAN®|QUICK GUIDE
QUICK GUIDE | MyPIPETMAN®
NOTE
To ensure good performance, always lock
the pipette before pipetting by selecting
the locking icon.
32
1
Figure 5
Tip ejector dual
position adapter
and extension for
P2L and P10L
Short collar
tips
Long collar
tips
180°
Fitting the Tip Ejector Adapter
Single Channel Models
AFor P2 and P10 pipettes equipped with a
stainless-steel tip ejector, a dual-position
adapter is required to fit and eject DL10 tips
(long tips) and D10 tips (short tips).
To fit the adapter for short and long tips
(refer to Figure 5):
1. Pull the adapter down from the
stainless steel tip ejector.
2. Turn the adapter 180°.
3. Refit the adapter so that the end of the
stainless steel tip ejector engages the
shorter or longer slot of the adapter.
BFor P2 and P10 pipettes equipped with a
plastic tip ejector, a dual-position adapter
is required to fit and eject D10 tips (short
tips).
To fit a tip ejector extension
(refer to Figure 5):
1. Slide the extension over the tip holder.
2. Push the extension firmly onto the
end of the tip ejector until it clicks into
place.
To remove a tip ejector extension:
1. Gently twist the adapter.
2. Pull it away from the pipette.
To fit To remove
Secure Pipetting
After selecting your volume, turn the selector to the right until
the cursor reaches the locking 3for secure pipetting.
B
A

8QUICK GUIDE | MyPIPETMAN®
Fitting the Tips
It is recommended to use PIPETMAN DIAMOND Tips with
MyPIPETMAN for optimum performance. These tips are
made from pure polypropylene. Plastic tips are for a single
application and should be disposed of after use—please do not
clean for reuse.
Single Channel Models
To fit a new PIPETMAN DIAMOND Tip, push the tip holder
into the tip using a slight twisting motion to ensure a firm and
airtight seal.
PIPETMAN DIAMOND Tip
Compatibility for Single Channel Models
P2, P10 D10, DL10, DF10ST, DFL10ST
P20 D200, DF30ST
P100 D200, DF100ST
P200 D200, D300, DF200ST, DF300ST
P1000 D1000, D1200, DF1000ST, DF1200ST
P5000 D5000
P10mL D10mL
4
1
2 3
Multichannel Models
For P8x10 and P12x10 models, according to the tip used, either
D10 or DL10, you may have to fit the ejector adapter. Long
collar tips can be inserted without it.
1. Remove the tip ejector, keep both ejector locks
depressed 1, and then pull the tip ejector down 2.
2. Fit the ejector adapter 3and click it to the tip ejector.
3. To refit the tip ejector, gently re-insert the tip ejector
vertically into the rails of the ejector support 4.
NOTE
Long tips can be used without tip ejector
adapter.

9
MyPIPETMAN®|QUICK GUIDE
QUICK GUIDE | MyPIPETMAN®
Multichannel Models
PIPETMAN DIAMOND Tips: TIPACK AND TOWERPACK
PIPETMAN DIAMOND tips are best fitted with the
ROCKY RACK technique, invented by Gilson, available
only in our TIPACK and TOWERPACK.
PIPETMAN DIAMOND Tip
Compatibility for Multichannel Models
P8x10, P12x10 D10*, DL10, DF10ST,
DFL10ST
P8x20, P12x20 DL10, D200, DFL10ST,
DF30ST
P8x200, P12x200 D200, D300,
DF200ST, DF300ST
P8x300, P12x300 D200, D300,
DF200ST, DF300ST
*Using an ejector adapter, you can adapt a
D10 tip (refer to page 8).
Pre-Wetting the Tips
Pre-wetting the tips before pipetting helps prepare the tips
for the best pipetting performance. Ideally, the pre-wet
includes both immersing the tip in the liquid and performing
one pipetting step.
Pre-wetting the tips helps ensure that volumes that you pipette
will achieve accuracy and precision within specifications.
Aspirating
1. Press the push button to the first stop (this corresponds
to the set volume of liquid).
2. Hold the pipette vertically and immerse the tip in the
liquid.
3. Release the push button slowly and smoothly to the top
position to aspirate the set volume of liquid.
4. Wait one second and then withdraw the pipette tip from
the liquid. You may wipe any droplets away from the
outside of the tip using a medical wipe. However, if you do
so, take care to avoid touching the tip’s orifice.
Figure 6
ROCKY RACK
technique

10 QUICK GUIDE | MyPIPETMAN®
Dispensing
1. Place the end of the tip against the inside wall of the
recipient vessel (at an angle of 10° to 40°).
2. Press the push button slowly and smoothly to the first
stop.
3. Wait for at least a second, then press the push button to
the second stop to expel any residual liquid from the tip.
Keep the push button pressed fully, and while removing
the pipette, draw the tip along the inside surface of the
vessel.
4. Release the push button smoothly. Eject the tip by
pressing firmly on the tip ejector button.
Second stop
First stop
Aspirate DispensePrepare Purge Home
Rest Position
Ejecting the Tips
To avoid touching used tips, hold the pipette over the waste
container and press the tip ejector push button.
Cleaning and Decontamination
MyPIPETMAN pipettes are designed so that the parts normally
in contact with liquid contaminants can easily be cleaned and
decontaminated.
MyPIPETMAN can be sterilized by steam autoclaving at
121°C (252°F),1 bar relative pressure for 20 minutes without
disassembly for maximum convenience as well as protection
from contamination.

11
MyPIPETMAN®|QUICK GUIDE
QUICK GUIDE | MyPIPETMAN®
For further information, please refer to MyPIPETMAN User’s
Guide LT801622 available on www.gilson.com.
NOTE
For pipettes equipped with the 3-position
locking system, turn the selector to the left
until the cursor reaches the autoclaving
icon.
Maintenance
Routine maintenance will help keep your pipette in good
condition, ensuring a continued high level of performance.
For further information, please refer to MyPIPETMAN User’s
Guide LT801622 available on www.gilson.com.
NOTICE
Gilson recommends maintenance and
calibration at least annually, more
frequently as needed, depending on use.
Warranty
Gilson warrants this pipette against defects in material under
normal use and service for a period of three years from the date
of purchase.
This warranty shall not apply to pipettes which are subject to
abnormal use and/or improper or inadequate maintenance
(contrary to the recommendations given in the user’s guide),
including, but not limited to pipettes which have been subjected
to physical damage, improper handling, spillage or exposure to
any corrosive environment, abuse misuse or misapplication, or
from ordinary wear and tear (including seal and O-rings). This
warranty shall also be void in the event pipettes are altered
or modified by any party other than Gilson or its designates.
Gilson’s sole liability under this warranty shall be limited to,
at Gilson’s sole option, repair or replacement of any defective
components of pipettes or refund of the purchase price paid for
such pipettes.
Routine cleaning, control, and recalibration are not covered
under the warranty. The replacement of wearing parts such as
seals, O-rings, broken pistons assembly, and broken tip holders
are not covered under the warranty.
NOTICE
Yearly routine maintenance is highly
recommended to keep your pipette in
good condition, ensuring a continued high
level of performance.
THE FOREGOING WARRANTY IS EXCLUSIVE AND GILSON
HEREBY DISCLAIMS ALL OTHER WARRANTIES, WHETHER
EXPRESS OR IMPLIED, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY AND ANY WARRANTIES OF FITNESS
FOR A PARTICULAR PURPOSE, UNDER NO CIRCUMSTANCES
SHALL GILSON BE LIABLE FOR ANY CONSEQUENTIAL,
PUNITIVE, INDIRECT OR INCIDENTAL DAMAGES ARISING OUT
OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY.

LT801608/A | ©2019 Gilson, Inc. All rights reserved.
gilson.com/contactus
LT801608/B | ©2022 Gilson, Inc. All rights reserved.
