INTRODUCTION
3
TRACKMAN® CONNECTED |USER’S GUIDE
ACCESSORIES PART NUMBER
Tablet holder FB02201
Microplate holder FB02202
Chapter 1
INTRODUCTION
Congratulations on the purchase of your TRACKMAN® Connected, a tablet with
exclusive bench design accessories and applications to improve efficiency at the
bench, making traceability and pipetting more reliable, and faster.
Discover a new experience of connected pipetting. Prepare, run, and report your work
on the bench has never been so easy.
Parts Checklist
Take a moment to verify that the following items are in the box:
• SAMSUNG Galaxy Tab S3 with PipettePilot application
• Power adapter, 5V
• Tempered glass screen protector
• Tablet holder
• Microplate holder
• Microplate adapter
• Strip adapter
• Environment sensor
• Quick Start Guide
Accessories
Please contact your Gilson representative to order accessories.
NOTE

GETTING STARTED
4GETTING STARTED | TRACKMAN® CONNECTED
Chapter 2
GETTING STARTED
Assemble your Tablet Holder
For your comfort and a secure use of TRACKMAN Connected at the bench, a tablet
holder is provided. The use of the tablet holder is optional.
To use the tablet holder, Insert the smaller part of the tablet holder, into one of the
five slots of the larger part according to the inclination you need. According to your
personal comfort, you can choose one of the two tablet holder positions below.
Apply Screen Protector to Tablet
NOTICE
It is strongly recommended to install the screen protector provided before
use.
Two tempered glass screen protectors are included with TRACKMAN Connected.
Tempered glass is a type of safety glass processed by controlled thermal or chemical
treatments to increase its strength compared with normal glass.
The screen protector enables easy cleaning of the tablet and protection against
corrosive liquids.
Refer to the documentation supplied with the screen protector for more
information.
Figure 1
Both options of tablet holder assembly
A
B
A
B
A
B
NOTE

GETTING STARTED
5
TRACKMAN® CONNECTED |USER’S GUIDE
Start PipettePilot
The SAMSUNG Galaxy Tab S3 provided with TRACKMAN Connected is preloaded with
the PipettePilot application.
NOTE
The tablet user manual is available directly on the tablet.
Place your SAMSUNG Galaxy Tab S3 on the tablet holder and switch it on to access to
PipettePilot application.
PipettePilot works with any PIPETMAN M Connected pipette and can be used with
other pipette models with limited performance.
Please consult www.gilsonconnect.com.
A tutorial at the beginning of the application will explain the main steps to run your
experiment. The HELP section in PipettePilot menu explains all features of the
application.
Environment Sensor
The environment sensor is connected by Bluetooth® to the tablet. It measures
temperature, humidity, and pressure at bench and wirelessly send the data to the tablet
in order to track environment parameters during your experiments. The soft touch
color rubber on top of the environment sensor is a button.
Turn the environment sensor on by pressing gently on the purple side. The LED will
blink three times to indicate it is on.
When prompted by PipettePilot, connect the environment sensor to the tablet using
the Bluetooth® connection. Once turned on and connected, the environment sensor
will automatically begin monitoring temperature, humidity, and pressure.
> >
Figure 2
PipettePilot icon

GETTING STARTED
6GETTING STARTED | TRACKMAN® CONNECTED
The environment sensor user manual is available here.
Start Pipetting
Microplate holder
A microplate holder is provided to position your 96- or 384-well microplates on the
tablet.
When prompted by PipettePilot, remove the two white strips from the microplate
holder and then place it on the corresponding frame on the tablet. Follow the
application instructions.
Microplate adapter
A microplate adapter is provided for semi-skirted or non-skirted plates.
Place your microplate in the adapter.
Place the adapter in the microplate holder (refer to Figure 4).
Place the microplate holder on tablet when prompted by PipettePilot.
NOTE
Figure 3
Environment sensor
Figure 4
Microplate holder
1
2
Figure 5
Microplate adapter
3
To turn off the environment sensor, press and hold the purple side down for five
seconds. The LED will blink rapidly to indicate it is turned off.
NOTICE
Pressing the button with excessive force may damage the device.

GETTING STARTED
7
TRACKMAN® CONNECTED |USER’S GUIDE
Strip adapter
A strip adapter is provided for 8-tube strips.
Place your strip(s) in the adapter.
Place the adapter in the microplate holder (refer to Figure 4).
Place the microplate holder on tablet when required by PipettePilot.
Recommendations
Before beginning your experiment, take a few minutes to get organized and
ensure you have:
• an appropriate posture,
• the right material,
• the appropriate method,
• an organized workspace.
A good test is to see if you can rest your elbow comfortably on the work surface.
If not, your receptacle may be too low or too high. Find the right height.
1
2
3
Figure 6
Strip adapter

MAINTENANCE
8MAINTENANCE | TRACKMAN® CONNECTED
Chapter 3
MAINTENANCE
Battery
Environment sensor
The environment sensor battery can be changed by removing the two small PHILIPS 00
screws and removing the back battery cover.
The device takes a coin cell CR2032. It should be inserted so that the + side is facing
outwards. For more details, refer to the environment sensor user manual available
here.
The back battery cover may have small padding elements on the inside of it. If this is
the case, ensure the padding elements remain in place when putting the battery
cover back on.
You will know when the battery is properly inserted since it will blink three times and
then once every time the button is pushed. If the environment sensor blinks three
times every time the button is pushed, this is an indication the battery is not making a
good connection and will need to be reseated.
SAMSUNG Galaxy Tab S3
When your tablet runs out of battery, simply charge it with the power supply.
It is recommended to keep the tablet plugged in while running.
Do not try to open the SAMSUNG Galaxy Tab S3: the battery is not removable from
the device.
Decontamination
Accessories and screen protectors could be cleaned with a soft cloth or lint free tissue
dipped in distilled water, simple soap solution, ethanol, or DNA/RNAse remover.
NOTICE
Do not autoclave any TRACKMAN Connected components.
NOTE

REGULATORY COMPLIANCE
9
TRACKMAN® CONNECTED |USER’S GUIDE
Chapter 4
REGULATORY COMPLIANCE
SAMSUNG certifies that its SAMSUNG Galaxy Tab S complies with the
requirements indicated in the section "Settings' > "About tablet"
BlueMaestro® certifies that its environment sensor complies with the requirements
indicated in its specification section.
For more information, refer to the documentation supplied by the
manufacturers.
The WEEE symbol (crossed-out wheeled bin), according to the
European Directive 2012/19/EU, indicates separate collection for
WEEE – Waste of Electrical and Electronic Equipment.
Do not dispose electronic devices and their batteries in a household
bin, use the recycling path in place in your country.
NOTE

WARRANTY
10 WARRANTY | TRACKMAN® CONNECTED
Chapter 5
WARRANTY
Gilson warrants this device against defects in material under normal use and
service for a period of 12 months from the date of purchase.
This warranty shall not apply to devices which are subject to abnormal use and/
or improper or inadequate maintenance (contrary to the recommendations
given in the user’s guide), including, but not limited to devices which have been
subjected to physical damage, improper handling, or spillage or exposure to any
corrosive environment. This warranty shall also be void in the event devices are
altered or modified by any party other than Gilson or its designates. Gilson’s sole
liability under this warranty shall be limited to, at Gilson’s sole option, repair or
replacement of any defective components of pipettes or refund of the purchase
price paid for such devices.
THE FOREGOING WARRANTY IS EXCLUSIVE AND GILSON HEREBY DISCLAIMS
ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING ANY
WARRANTIES OF MERCHANTABILITY AND ANY WARRANTIES OF FITNESS
FOR A PARTICULAR PURPOSE, UNDER NO CIRCUMSTANCES SHALL GILSON
BE LIABLE FOR ANY CONSEQUENTIAL, PUNITIVE, INDIRECT OR INCIDENTAL
DAMAGES ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY.
Warranty for Non-Gilson Equipment
Contact your Gilson representative. Gilson will coordinate with the manufacturer
for handling warranty-related service. The warranties are those provided by the
manufacturer.

NOTES
