GME g-radio GR300BT User manual

INSTRUCTION MANUAL

2 INSTRUCTION MANUAL GR300BT
CONTENTS
INTRODUCTION ...................................................................................................... 3
FEATURES............................................................................................................... 3
SUPPLIED WITH....................................................................................................... 3
OPTIONAL ACCESSORIES......................................................................................... 3
COMPLIANCE ......................................................................................................... 4
LISTENING TO FM IN YOUR BOAT ............................................................................ 4
CONTROLS.............................................................................................................. 4
OPERATION ............................................................................................................ 5
On/Off............................................................................................................. 5
Clock............................................................................................................... 5
Key beeps........................................................................................................ 6
Adjusting the sound ........................................................................................ 6
Mute ............................................................................................................... 7
Loudness......................................................................................................... 7
Display backlighting ........................................................................................ 7
Local/DX mode................................................................................................ 8
Tuning for stations .......................................................................................... 8
Stereo/Mono mode.........................................................................................10
Bluetooth®operation ..................................................................................10
Auxiliary audio input......................................................................................12
INSTALLATION ...................................................................................................... 12
Selecting a location........................................................................................12
Installing the unit...........................................................................................13
DC connections..............................................................................................14
Speakers ........................................................................................................14
Antenna installation.......................................................................................15
SPECIFICATIONS ................................................................................................... 16
Standard Communications Warranty Against Defects.............................................. 17
Wireless Technology
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Standard Communications Pty Ltd is under license. Other trademarks and trade
names are those of their respective owners.

GR300BT INSTRUCTION MANUAL 3
INTRODUCTION
Congratulations on purchasing your GR300BT marine radio.
For simplicity and performance, the GME GR300BT is the entertainment unit of
choice where space is limited. Using either the included gimbal mounting bracket
or an optional flush mounting kit, the flexibility and size of the GR300BT is
suited to vessels where there is insufficient space to install a conventional marine
entertainment system.
Powerful yet compact, the GR300BT combines an AM/FM radio with Bluetooth®
audio streaming that can be paired with any Smartphone, tablet or compatible
device. A front face Lanson speaker maintains audio clarity and minimises distortion.
For higher output power and full stereo sound, a pair of external speakers can be
connected using the included speaker adaptor cables.An auxiliary input socket allows
direct audio connection to media players that don’t support Bluetooth® streaming.
To ensure lasting performance, the GR300BT is waterproof to IPX7* and is UV
stabilised to maintain the finish expected of a GME radio.
FEATURES
•Compact design with bracket or flush
mounting options
•Ingress protection to IPX7* (excludes
external connectors)
•4 bands (AM1, AM2, FM1, FM2)
•4 preset frequency memories per band
•Bluetooth®connectivity with
music streaming
•Simple push button controls.
•Front panel ‘monitor’ speaker
•FM stereo reception
•Large white backlit display with
‘dim’ feature
•Bass, treble and balance controls
•Built-in clock
•Over voltage and reverse
polarity protection
•Static discharge protection at
antenna input
•Auxiliary audio input
•Available in black or white
*Refer: www.gme.net.au
SUPPLIED WITH
•2 x extension speaker leads
– 3.5 mm mini jack
•Mounting bracket, hardware
•DC supply lead
•Instruction manual
•Cabin Cover
OPTIONAL ACCESSORIES
In-dash flush mounting kits –
MK002W/B, MK008W/B, MK011W/B,
MK100W/B
Rear flush mount kit – MK600
Choose from a range of GME antennas
Choose from a range of GME speakers
Cabin cover – CVR032W/B
Auxiliary input interface cable – LE74

4 INSTRUCTION MANUAL GR300BT
COMPLIANCE
This device complies with AS/NZS 61000.6.3:2007.
This device complies with part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.
LISTENING TO FM IN YOUR BOAT
The majority of FM broadcasts are music programs. Compared with AM signals, FM
signals have a wider dynamic range, are relatively immune to noise and provide
virtually distortion free music reproduction. However, because of the nature of FM
signals and the fact that FM stations are usually positioned for shore based reception,
reception in a moving boat may be accompanied by problems.
FM programs are broadcast for local reception and may not be heard satisfactorily at
distant locations. To enjoy FM programs at their best, it is important that you tune to
a station that is broadcasting in your locality.
FM signals can reflect from solid objects such as buildings or hills. If these reflected
signals are received along with signals that are arriving directly from the transmitter,
they may mix together to produce what is known as ‘multipath distortion’. This
distortion is heard as noise. Often, moving as little as one metre from your position
will correct this problem.
FM signals travel in straight lines. Because the signals are reflected from or absorbed
by large solid objects, a signal ‘shadow’ may be present behind the object which may
result in poor reception in that area.
CONTROLS
Front Panel
Control Knob
Preset Memories Display Options Select Frequency Up Power/Light
Speaker LCD Band Auto Music Source
Search
Frequency Down Mute
1
2
3
4
SEL
DIS
S
R
C
AMS
BND
AM - FM RADIO
G•RADIO
MUT
AUX

GR300BT INSTRUCTION MANUAL 5
LCD Display
FM Bands AM Bands
Frequency and Status Auxiliary Input
OPERATION
ON/OFF
To switch the GR300BT ON, briefly press the key.
To switch the GR300BT OFF, press and hold the key.
Note: When the GR300BT is switched off, it will remember the last state it was set to
and return to that state when switched back on.
CLOCK
When the GR300BT is switched off, the LCD will (by default) display the time for as
long as the power remains connected. When the GR300BT is switched on, the LCD
will normally display the radio settings, but can be manually switched between the
radio and the clock. To toggle the display between the radio and the clock, briefly
press the DIS key.
Note: If any of the radio function keys are pressed while the LCD is in clock mode,
the LCD will temporarily switch back to the radio display to allow you to make
adjustments and set stations and frequencies. The LCD will then return to the clock
mode after a few seconds.
Setting the Time
1. Briefly press the DIS key to switch to the clock display.
2. Hold the DIS key until the ‘Hours’ flash.
3. Rotate the Control Knob left or right to adjust the hours. Rotate right to step
forward or left to step backwards.
4. Once the Hours have been set, briefly press the DIS key. The ‘Minutes’ will flash.
5. Rotate the Control Knob to adjust the minutes. Rotate right to step forward or
left to step backwards.
6. Briefly press the DIS key again to exit and display the time.
Local/DX
Loudness
Stereo
kHz
MHz
Auto Music Search
Preset Memories
Treble
Bass
Balance AUX

6 INSTRUCTION MANUAL GR300BT
Note: The time setting will be retained as long as the 12V power source remains
connected. If the 12V power source is disconnected, the time setting will be lost and
will need to be readjusted once the power is restored.
Selecting 12 or 24 Hour Mode
1. Press and hold the SEL key. ‘CL XX’ is displayed where XX is the clock setting.
2. Rotate the Control Knob left or right to make your selection.
(i) Select ‘CL 24’ to display a 24 hour clock.
(ii) Select ‘CL 12’ to display a 12 hour clock.
(iii) Select ‘CL OF’ to disable the time display whenever the GR300BT is switched
off (the time display is still available when the GR300BT is switched on).
The radio will return to the normal display after a few seconds
Note: If the 12 hour clock option is selected, ‘A’ for AM or ‘P’ for PM will be displayed
directly above the time.
KEY BEEPS
The GR300BT normally provides a confirmation beep whenever a key is pressed.
If preferred, the beep can be disabled. To disable the beep;
1. Press and hold the SEL key. ‘CL XX’ is displayed where XX is the clock setting.
2. Briefly press SEL again to access the Beep setting. ‘BEEP’ is displayed.
3. Rotate the Control Knob left or right to enable or disable the key beep.
(i) Select ‘BEEP’ to enable the key beeps.
(i) Select ‘OFF’ to disable the key beeps.
The radio will return to the normal display after a few seconds
ADJUSTING THE SOUND
Volume
During normal use the Control Knob will default to the volume mode.
To adjust the volume, rotate the Control Knob to the right to increase the volume or
to the left to decrease the volume. The volume level is displayed on the LCD in values
from 0 (min) to 30 (max)
Bass
To adjust the Bass, briefly press the SEL key until the icon is displayed. Rotate
the Control Knob to the right to increase the Bass or to the left to decrease the
Bass. The selected setting will be displayed on the LCD in values from -10 (min) to
+10 (max). For a flat bass response, select 0.

GR300BT INSTRUCTION MANUAL 7
Treble
To adjust the Treble, briefly press the SEL key until the icon is displayed. Rotate
the Control Knob to the right to increase the Treble or to the left to decrease the
Treble. The selected setting will be displayed on the LCD in values from -10 (min) to
+10 (max). For a flat treble response, select 0.
Balance
The balance setting adjusts the audio balance between the left and right speaker.
NOTE: The Balance setting is only available in the SEL menu when stereo speakers
are connected to the external speaker sockets. When listening on the internal speaker,
the Balance option will not be available.
To adjust the Balance, briefly press the SEL key until the icon is displayed.
Rotate the Control Knob to the right to adjust the balance towards the right
speaker. The Balance setting will be displayed in values of R1 to R9. Rotate the
Control Knob to the left to adjust the balance towards the left speaker. The balance
setting will be displayed in values of L1 to L9. A setting of 0 indicates the balance is
set equally between both speakers.
MUTE
The Mute feature allows the radio’s sound to be temporarily disabled without
affecting any other settings. This is useful when making calls on your two way radio or
mobile phone or during a local conversation where the radio sound is distracting.
To mute the radio, briefly press the MUT key. The audio will be temporarily muted and
no sound will be heard from the speaker(s). While the sound is muted, ‘MUTE’ will
flash on the display.
To cancel the Mute selection and restore the sound to its previous level, briefly press
the MUT key again.
LOUDNESS
The Loudness function provides an additional Bass boost to compensate for the
human ear’s inability to track these frequencies at low volume settings.
To enable the Loudness function, briefly press the SEL key until ‘LOUD’ is displayed
then rotate the Control Knob to switch the ‘LOUD’ icon on or off. When the
Loudness setting is enabled the ‘Loud’ icon remains visible on the display.
DISPLAY BACKLIGHTING
The brightness of the display backlight can be dimmed for night time viewing or can
be completely switched off.
To adjust the display brightness, briefly press the key. Each press will cycle the LCD
backlight through Off, Dim or Bright settings.
OFF DIM BRIGHT

8 INSTRUCTION MANUAL GR300BT
LOCAL/DX MODE
The Local/DX mode controls the receiver’s sensitivity. The GR300BT can be set to high
sensitivity for long distance reception (DX) or low sensitivity for local reception (LOC).
Selecting Local mode when using the AMS feature will help to reduce the strength
of distant weaker stations allowing only the stronger local stations to be stored in
memory.
To switch the Local mode on or off, briefly press the SEL key repeatedly until ‘LOC’
is displayed. Rotate the Control Knob right or left to enable or disable Local mode.
When enabled, the ‘LOC’ icon is visible on the display. If the ‘LOC’ icon is not visible,
the radio is in the DX mode.
When the GR300BT returns to the normal display mode, ‘LOC’ will be displayed if
Local mode is selected. If ‘LOC’ is not visible then DX mode is selected.
TUNING FOR STATIONS
Selecting USA or European Receiver Standards
The GR300BT supports USA and European standards for AM and FM frequency
bands. Australia and New Zealand conform to the European standard which is the
GR300BT’s default setting. Owners in the USA should select the USA standard.
To switch between standards, press and hold the BND key for 4 seconds.
The GR300BT will briefly display ‘E’ at the top of the LCD for European or ‘U’ for USA.
The ‘E’, ‘U’ symbol will disappear after a few seconds.
The differences between the European and USA bands are listed below.
COUNTRY BAND FREQUENCY STEP
European FM 87.5 – 108 MHz ± 100 kHz
AM 522 – 1620 kHz ± 9 kHz
USA FM 87.5 – 108 MHz ± 100 kHz
AM 530 – 1710 kHz ± 10 kHz
Select a Frequency Band
The GR300BT has 4 selectable frequency bands labelled AM1, AM2, FM1 and FM2.
Each band has 4 memories providing a total of 8 AM and 8 FM stations to be stored
for easy retrieval.
To select the desired frequency band briefly press the BND key. Each press will
advance to the next band in the sequence and the corresponding icon , ,
or will appear on the display to confirm your selection.
Manually Tuning the Frequency
Briefly press the or key to step upwards or downwards in frequency. The
frequency will be displayed on the LCD at each key press.

GR300BT INSTRUCTION MANUAL 9
Scanning for Stations
Press and hold the or key to automatically scan for stations in the direction
selected. The scanning will stop when a station is found and the frequency will be
displayed.
Memory Keys
The GR300BT has 4 preset memory keys which allow up to 4 frequencies to be stored
and recalled within each band. Because there are two identical AM bands and two
identical FM bands, this allows 8 AM and 8 FM preset memories.The memories can
be stored manually or automatically.
Manually Locating and Storing Station Frequencies in the Preset Memories
1. Press the BND key repeatedly to select the required band.
2. Briefly press the or key to manually step through the frequencies or press and
hold the or key to automatically scan for the next station.
3. Once the required station is tuned, press and hold one of the four memory keys.
‘Preset X’ will be displayed when X is the memory number selected (1, 2, 3or 4).
Repeat the steps above to store other frequencies into the preset memories.
NOTE: When tuning stations, if the selected frequency has already been stored,
the preset memory number will be displayed whenever that frequency is selected.
Recalling Stations from the Preset Memories
Select the required band (AM1, AM2, AM3 or AM4) then briefly press the desired
memory key. The GR300BT will switch to the frequency stored in that memory and the
selected memory number will be displayed (e.g. Preset 2).
Automatic Music Search (AMS)
The AMS feature allows the GR300BT to search the selected AM or FM band for
stations and automatically store the first eight stations into the station memories.
Scanning will start at the lowest frequency in the band and scan upwards storing
stations as they are located.
NOTE: To store only the strongest stations, select ‘Local’ mode before scanning.

10 INSTRUCTION MANUAL GR300BT
To store AM stations using AMS
1. Briefly press the BND to select AM1 or AM2.
2. Hold the AMS key until the radio starts scanning for stations.The ‘AMS’ icon will
appear and stations will be stored into memory locations 1 – 4 in the AM1 band.
The radio will then switch to the AM2 band and any further stations will be stored.
3. When the scan has completed, the radio will switch to the AM1 band and play the
station stored in Memory location 1 (‘Preset 1’ will be displayed).
4. Briefly press other memory keys or select the AM2 band to hear stations stored into
other memories.
To store FM stations using AMS
1. Briefly press the BND to select FM1 or FM2.
2. Hold the AMS key until the radio starts scanning for stations.The ‘AMS’ icon will
appear and stations will be stored into memory locations 1 – 4 in the FM1 band.
The radio will then switch to the FM2 band and any further stations will be stored.
3. When the scan has completed the radio will switch to the FM1 band and play the
station stored in Memory location 1 (‘Preset 1’ will be displayed).
4. Briefly press other memory keys or select the FM2 band to hear stations stored into
other memories.
Note: To cancel the AMS function while searching, briefly press the or key.
STEREO/MONO MODE
The Stereo/Mono function can be selected for the FM band when the external stereo
speakers are attached. If the GR300BT is only operating from the internal speaker,
Stereo/Mono selection is not available.
To switch between Mono and Stereo FM modes, briefly press the SEL key until
‘MONO’ or ‘ST’ is displayed. Rotate the Control Knob to select the required option.
For normal stereo listening on the FM bands, select stereo. If the FM station is weak
and noisy, select Mono to disable stereo detection and improve the quality of the
reception. When Stereo is selected and a stereo signal is being received, the ‘ST’ icon
is displayed. When Mono is selected, there is no indication on the display.
Bluetooth®OPERATION
Bluetooth®is a short range wireless system used to transfer data between devices.
Using Bluetooth®, your smart phone or Bluetooth®enabled portable media player
is able to stream music wirelessly to your GR300BT.
Note: The GR300BT supports music streaming only. It does not support the making
or receiving of telephone calls.
