GME GX600A User manual

INSTRUCTION MANUAL
VHF MARINE RADIO
GX600A

SAFETY INFORMATION
The GX600A is a radio transmitting device.
 •Whentransmitting,keepanypartofyour
headorbodymorethan20cmfrom
theantenna.
 •Donottransmitnearelectricalblasting
equipmentorinexplosiveatmospheres.
 •Donotallowchildrentooperatearadio
transmitterunsupervised.
OPERATOR QUALIFICATIONS
AnypersoninAustraliaoperatingaVHFmarineradio
shouldpossesatleastaMarineRadioOperatorsVHF
CertificateofProficiency(MROVCP).Alternatively,operators
mayobtainaMarineRadioOperatorsCertificateof
Proficiency(MROCP),whichcoverstheoperationofboth
VHFandMF/HFequipment.
ManyTAFEsandmarineorganisationsoffercoursesleading
toexaminationfortheMROVCPandMROCPalthough
suchcoursesarenotcompulsory.Personswishingtoobtain
theMROVCPorMROCPshouldfirstpurchaseacopyof
theMaritimeRadioOperatorHandbookwhichisessential
readingforeveryboatownerinAustralia.
TheAustralianMaritimeCollege(AMC)providesthe
marineexaminationandcertificateserviceonbehalfofthe
AustralianCommunicationsandMediaAuthority(ACMA).
TheAMCcanprovidethedetailsoforganisationsand
individualsofferingcoursesandorconductingexams.
Forfurtherinformationvisit:www.amc.edu.au
INTRODUCTION
Congratulations.Youhavejustpurchasedoneofthemost
technicallyadvancedVHFmarineradiosintheworld.
TheGMEGX600AisaVHFFMradiodesignedtooperatein
the156–163MHzmarineband.TheGX600Ahasanumber
ofenhancedfeaturesincludingfullyuserprogrammable
ChannelScanning,DualWatchandTripleWatchfunctions
andtwoprogrammable‘Instant’channelmemories.
WithitscompactsizeandIP67designitcaneasilybe
installedintoalmostanypanelmountinglocationinyour
flybridgeorcabin.
TheGX600AistotallydesignedatourSydneyfacility
usingprecisionrobotsandthelatestmanufacturing
techniquesensuringaconsistentlyhighqualityresulting
inacommunicationssystemofextremereliabilityand
performance.
SAFETYINFORMATION......................................................2
OPERATORQUALIFICATIONS.............................................2
INTRODUCTION................................................................2
FEATURES.........................................................................3
RANGE.............................................................................3
MICROPHONE...................................................................3
CONTROLS........................................................................3
OPERATION......................................................................4
 Volumeon/off............................................................4
 Transmitting...............................................................4
Display.......................................................................4
 ChannelSelection......................................................4
 AdjustingtheSquelch................................................4
 Channel16Selection.................................................5
 SelectingChannelSets...............................................5
 DisplayBacklighting...................................................5
 High/LowPowerSelection..........................................5
 WorkingChannelMemories.......................................5
 DualWatchKey..........................................................6
 DualWatchFeatures..................................................6
 TripleWatchKey.........................................................6
 TripleWatchFeatures.................................................6
 Scanning....................................................................7
 ScanningFeatures......................................................7
INSTALLATION..................................................................8
 SelectingaLocation...................................................8
 InstallingtheUnit......................................................8
 DCConnections.........................................................9
 NoiseSuppression......................................................9
 GX600AWiring..........................................................9
SPECIFICATIONS.............................................................10
SCCONTRACTWARRANTYAGAINSTDEFECTS................11
BRANCHADDRESSES......................................................12
PLEASEREADTHISMANUALTHOROUGHLY
TOENSUREYOUGETTHEBESTFROMTHE
GX600A’SFEATURES.
CONTENTS
PAGE2 INSTRUCTIONMANUAL GX600A

GX600A INSTRUCTIONMANUAL PAGE3
FEATURES
 •CompactIP67Design
 •SelectableInternational,USA,andCanadian
ChannelSets
 •SelectableUSAWeatherChannels
 •DualWatchandTripleWatchwithProgrammable
PriorityChannel
 •10PrivateChannelsavailable
 •ProgrammableChannelScanning
 •SelectablePower25/1watt
 •TwoWorkingChannelMemories
 •AdjustableDigitalSquelch
RANGE
TherangeofVHFtransmissionsdependonantennaheight,
transmitterpowerandtheterrainoverwhichthesignals
pass.Shiptoshipcommunicationsshouldbepossible
overatleast8nauticalmilesanduptoabout27nautical
miles.Shiptoshorerangeswilloftenbegreaterduetothe
increasedheightoftheshoreantennaandcommunications
of25to50nauticalmilesarepossible.
MICROPHONE
CONTROLS
Channel Channel LCD Volume
 Down Up Display
Scan
Microphone
Speaker
PushtoTalk Downkey Upkey Squelch
CH16Key
Channel ChannelA ChannelB Lamp/ DualWatch/ Squelch
 16 Memory Memory Power TripleWatch

OPERATION
VOLUME ON/OFF
RotatetheVolumecontrolclockwisepastthe‘click’to
turntheGX600AON.Whilereceivingasignal,continueto
rotateclockwisetoincreasethesoundinthespeaker.
Rotatethecontrolfullycounterclockwisepastthe‘click’to
turntheGX600AOFFagain.
NOTE: Atminimumvolumesettingthereisstillsufcient
volumetobeheardinaquietcabinenvironment.
TRANSMITTING
Totransmit,pressthePushtoTalk(PTT)switchon
themicrophone.Holdthemicrophoneabout5–8cm
fromyourfaceandspeakatanormalvoicelevel.The
microphoneisquitesensitivesoitisnotnecessaryto
raiseyourvoiceorshout.ReleasethePTTwhenyou
havefinishedtalking.
Transmissiontimeiscontrolledbyatime-outtimer.Ifthe
PTTisheldformorethan90seconds,alowbeepwill
beheardandthetransmitterwillbedisabledtoprevent
accidentaljammingofthechannelfrequency.Toresetthe
timersimplyreleasethePTT.
NOTE: ThetransmitterisdisabledonCH70.IfthePTTis
pressedalowbeepwillbeheardandthePTTwill
beignored.
DISPLAY
CHANNEL SELECTION
Standard Marine Channels
Brieflypressthe keytostepupwardsonechannelorthe
keytostepdownwardsonechannel.Ahighbeepwillbe
heardateachpress.
The and keysarealsoduplicatedonthefrontof
themicrophone.
Pressandholdthe or keyfor1.5secondstoscroll
quicklyupwardsordownwardsthroughthechannelsata
rateof10channelspersecond.Whenthekeyisreleased
channelscrollingstops.
Weather Channels
TheUSweatherchannelsareavailableonlywhentheUSA
ChannelSethasbeenselected.Whenavailable,weather
channelsarenumbered01–10andareinsertedintothe
normalchannelsequencebelowmarinechannel01.They
areselectedintheusualwayusing or keys.Weather
channelsareidentifiedbytheWXicononthedisplay.
Private Channels
PrivatechannelscanbeprogrammedintotheGX600A
fororganisationsthathavebeenofficiallyallocated
specialfrequencies.Privatechannelsareprogrammedon
applicationbyyournearestGMEbranchoffice.Allrequests
forPrivatechannelprogrammingmustbesupportedby
ACMAdocumentation.
IfPrivatechannelshavebeeninstalledtheywillappearas
P0–P9aboveCH88.
ADJUSTING THE SQUELCH
ToopentheSquelch,brieflypressthe SQL key.Alowbeep
willbeheardandtheSquelchwillopen.Brieflypressthe
SQL keyagaintoclosetheSquelch.Ahighbeepwillbe
heardandtheSquelchwillberestoredtoitspresetlevel.
Setting the Squelch Preset Level
ThepresetSquelchlevelcanbeadjustedtosuitlocal
conditions.Ifyouareinanelectricallynoisylocationor
unwantedweaksignalskeepopeningtheSquelch,youcan
adjusttheSquelchsettingsothattheGX600Aremains
quiet.NotethatincreasingthepresetSquelchlevelwill
meanthatstrongersignalswillberequiredtoovercome
theSquelchandmayresultinmissedcallsfromweaker
signals.Thebestsettingistheminimumonerequiredto
keepthereceiverquiet.
Channel Transmit Busy Channel Scan Weather 
 Set   Number Memory
Triple Scan Dual ChannelSuffix Low
Watch Watch e.g.CH87A Power
PAGE4 INSTRUCTIONMANUAL GX600A

GX600A INSTRUCTIONMANUAL PAGE5
ToentertheSquelchsettingmode,pressandholdthe SQL
keyfor1.5secondsuntilahighbeepisheard.Thepresent
Squelchsettingwillbedisplayedindigitsfrom-0to-9with
-0beingunmutedand-9beingmaximumSquelch.While
inthismode,brieflypressthe or keystoincreaseor
decreasetheSquelchlevelrespectivelyasrequired.Press
the SQL keyagaintoexittheSquelchsettingmodeorwait
5secondsanditwillexitautomatically.Alowbeepwill
beheard.
CHANNEL 16 SELECTION
Brieflypressthe 16 keytoswitchstraighttoChannel16.
Allpreviouscontrolsettings(suchasscanningorlow
transmitterpower)willbecancelledandtheradiowillbe
restoredtonormaloperationwithhightransmit
powerselected.Pressthe 16 keyagaintoreturntothe
selectedchannel.
The 16 keyisalsoduplicatedonthefrontofthe
microphone.
SELECTING CHANNEL SETS
TheGX600AisprogrammedwiththreeChannelSets–
International,USAandCanada.TheseChannelSetssupport
variouschannelandfrequencyallocationsforotherpartsof
theworld.OnceyouhaveselectedtherequiredChannelSet
foryourlocation,youshouldnotneedtochangeitagain
unlessyouhavemovedtoanothercountry.
WhenusingtheGX600AinAustralia,the International
ChannelSetshouldbeselected.
To change the Channel Set
• SwitchtheGX600AOFF
• Pressandholdthe 16 keywhileturningtheGX600A
ONagain.
• Channel16willbeselectedandthepresentlyselected
ChannelSetwillflashonthedisplayas INT’L , USA
or CAN .
• Brieflypressthe 16 keytocyclethroughtheChannelSet
selectionsinthefollowingorder:
TheselectedChannelSetbecomesactiveimmediately.
• OncetherequiredChannelSetisselected,return
tonormaloperationbyeitherholdingthe 16 keyor
switchingtheGX600AOFFmomentarilyorwaiting20
secondsfortheChannelSetmodetotime
outautomatically.
NOTE: WhentheUSAChannelSetisselected,weather
channelsareaccessiblebelowChannel01.
DISPLAY BACKLIGHTING
TheLCDdisplayisbacklitforeasyviewingatnight.
Brightness Adjustment
TosetthebrightnessoftheLCDbacklighting,brieflypress
the LAMP key.Eachpresswillcyclethefollowinglamp
illuminationsettings.
HIGH/LOW POWER SELECTION
ToswitchbetweenHighandLowtransmitpower,pressand
holdthe 25/1W key.AhighbeepindicatesHighpower
(25watts)isselectedwhilealowbeepindicatesLow
power(1watt)isselected.Whenlowpowerisselected‘LO’
isdisplayed.
NOTE: SelectingChannel16automaticallyresetsthe
transmittertohighpower.
WORKING CHANNEL MEMORIES
TheGX600Ahastwodedicated‘workingchannel’
memoriescalledChannelAandChannelB.Theseallowyou
tostoreandrecalltwooften-usedworkingchannels.These
memoriesareaccessedusingkeyslabeled CHAN A and
CHAN B .ChannelAisalsousedasthePriorityChannel
fortheTripleWatchfunction(seefeaturedescriptionlater
inthismanual).Thesechannelmemoriesalsoallowfaster
channelswitchingacrossthebandthanwouldnormallybe
possibleusingthe or keys.E.gfromCH16toCH67.
Channel A
TostoreafrequencyinChannelA,selecttherequired
channelusingthe or keys,thenpressandholdthe
CHAN A keyfor1.5seconds.Thechannelnumberwillflash
thenahighbeepwillbeheardasthechannelisstored.
Channel B
TostoreafrequencyinChannelB,selecttherequired
channelusingthe or keys,thenpressandholdthe
CHAN B keyfor1.5seconds.Thechannelnumberwillflash
thenahighbeepwillbeheardasthechannelisstored.
To Recall Channel A or B
Brieflypressthe CHAN A or CHAN B keytoswitch
immediatelytothechannelstoredinthatmemory.Ifthe
radiowasscanningthescanwillbecancelled.
 Bright Dim Off
InternationalUSACanada

DUAL WATCH KEY (DW)
TheDualWatchfunctionisa2Channelscanfeaturewhere
theGX600AswitchesbetweenChannel16andanyother
selectedchannel.Thisallowsyoutomonitoraworking
orclubchannelwhilestillbeingabletoreceiveimportant
broadcastsonChannel16.
TousetheDualWatchfunction,selectyourpreferred
workingchannel–eitherbyusingthe or keys–orby
selectingoneofthestored CHAN A or CHAN B memories
-thenbrieflypressthe DW key.Ahighbeepwithbe
heardand‘DW’willappearonthedisplay.TheGX600A
willnowmonitortheselectedchannelANDChannel16
byalternatingequallybetweenthem.Onlytheworking
channelnumberisshownonthedisplaywhen
DualWatching.
TocancelDualWatching,brieflypressthe DW keyagain.
DUAL WATCH FEATURES
If a Signal Appears on Channel 16
TheradiowillswitchimmediatelytoChannel16andCH
16willbedisplayed.Atthispointtheselectedchannel
isnolongerbeingmonitoredbecauseChannel16has
priority.Duringthistimethe PTT maybepressedfornormal
transmissionson Channel 16 .OnceChannel16hasbecome
inactivefor5secondstheDualWatchfunction
willresume.
If a Signal Appears on the Selected Channel
ScanningwillpauseontheselectedchannelBUTChannel
16willcontinuetobemonitoredevery2seconds.During
thistimethe PTT maybepressedfornormaltransmissions
onthe selected channel (monitoringofChannel16ceases
whiletransmitting).Oncetheselectedchannelhasbecome
inactivefor5secondstheDualWatchfunctionwillresume.
To Transmit on the Selected Channel While Dual
Watching
Simplypressthe PTT. TheDualWatchfunctionwillpause
duringthetransmissionandremainpauseduntil5seconds
afterallactivityhasceasedonthechannel.DualWatchwill
thenresume.
To Transmit on Channel 16 While Dual Watching
Pressthe 16 keytoswitchtoChannel16.Dualwatchwill
becancelledandtheradiowillswitchstraighttoChannel
16.Nowpressthe PTT andtransmitintheusualway.When
yourconversationhasended,pressthe DW keytoresume
DualWatching.
To Change the Working Channel While Dual
Watching
WhileDualWatching,simplyselectanotherworking
channelbyeitherusingthe or keysorselectingone
ofthestored CHAN A or CHAN B memories.DualWatching
continuesonthenewlyselectedchannel.
TRIPLE WATCH KEY (TW)
TheTripleWatchfunctionisanextensionoftheDualWatch
feature.ItallowstheGX600AtomonitorChannel16,a
selectedchannelANDaPriorityChannel.Eachchannel
isscannedequallyforsignalswithprioritygivenfirstto
CH16,thenthePriorityChannelandlastlytheselected
channel.
WhenTripleWatchisselected,theTWiconisdisplayed
alongwiththeselectedchannelnumber.The‘priority’
channelistheonestoredinthe CHAN A memory.
TousetheTripleWatchmode,firstprogramyourPriority
Channel(thedefaultPriorityChannelis9)intothe CHAN A
memory,thenselectyourpreferredworkingchannelusing
the or keys.Nowpressandholdthe TW keyfor1.5
secondsuntilahighbeepisheard.‘TW’andtheselected
channelwillbedisplayed.
To Cancel Triple Watch
Either- Brieflypressthe TW keytoswitchtoDual
Watchmode.Ahighbeepwillbeheard
Or- Pressandholdthe TW keytoreturntonormal
operation.Alowbeepwillbeheard.
TRIPLE WATCH FEATURES
If a Signal Appears on Channel 16
TheradiowillswitchimmediatelytoChannel16andCH
16willbedisplayed.Atthispointtheselectedchanneland
thePriorityChannelarenolongerbeingmonitoredbecause
Channel16hashighestpriority.Duringthistimethe PTT
maybepressedfornormaltransmissionsonChannel16.
OnceChannel16hasbecomeinactivefor5secondsthe
TripleWatchfunctionwillresume.
If a Signal Appears on the Priority Channel
ScanningwillpauseonthePriorityChannelBUTChannel
16willcontinuetobemonitoredevery2seconds(the
selectedchannelisnotmonitored).Duringthistimethe
PTT maybepressedfornormaltransmissionsonthe
PriorityChannel(monitoringofChannel16ceaseswhile
transmitting).OncethePriorityChannelhasbecome
inactivefor5secondsTripleWatchwillresume.
PAGE6 INSTRUCTIONMANUAL GX600A

GX600A INSTRUCTIONMANUAL PAGE7
If a Signal Appears on the Selected Channel
ScanningwillpauseontheselectedchannelBUTChannel
16andthePriorityChannelwillcontinuetobemonitored
every2seconds.Duringthistimethe PTT maybe
pressedfornormaltransmissionsontheselectedchannel
(monitoringofChannel16andthePriorityChannelceases
whiletransmitting).Oncetheselectedchannelhasbecome
inactivefor5secondstheTripleWatchwillresume.
To Transmit on the Selected Channel While
Triple Watching
Simplypressthe PTT .TheTripleWatchfunctionwillpause
duringthetransmissionandremainpauseduntil5seconds
afterallactivityhasceasedonthechannel.TripleWatchwill
thenresume.
To Transmit on the Priority Channel While
Triple Watching
Brieflypressthe CHAN A key.ThePriorityChannelwill
thenbecometheselectedchannel.Nowpressthe PTT and
transmitintheusualway.Whenyourconversationhas
ended,re-selectyourselectedchannel.
To Transmit on Channel 16 While Triple Watching
Pressthe 16 key.Triplewatchwillbecancelledandthe
radiowillswitchstraighttoChannel16.Nowpressthe
PTTandtransmitintheusualway.Whenyourconversation
hasended,pressandholdthe TW keytoresumeTriple
Watching.
SCANNING
TheScanfunctionallowstheGX600Atoscanthrough
aseriesofuserselectedchannelslookingforactivity.
Scanningisdoneinanascendingsequenceatarateof10
channelspersecond.
Channelscanbeselectedandstoredforscanningfromany
oftheavailablechannels,includingweatherchannels(ifthe
USAchannelsetisselected)andprivatechannels(ifthey
areenabled).
NOTE: Thetransmitterisdisabledwhilescanning.Ifthe
PTT ispressed,alowbeepwillbeheardandthe PTT is
ignored.
To Store Channels for Scanning
Selecttherequiredchannelusingthe or keys,then
pressandholdthe SCAN keyfor1.5seconds.Thechannel
numberwillflash,ahighbeepwithbeheardand‘M’will
appearnexttothechannelnumber.
Repeattheprocesstoremoveapreviouslystoredchannel
fromthescanlist.Whenachannelisremovedalowbeepis
heardand‘M’disappearsfromthedisplayonthatchannel.
To Begin Scanning
Brieflypressthe SCAN key.TheGX600Awillscanupwards
throughthestoredchannelsat10channelspersecondand
thedisplaywillshowrapidlychangingchannelnumbers.
Ifasignalislocated,scanningwillpauseonthatchannel
andwillremainfor5secondsafterthesignalhasgone.
Scanningwillthenresume.
To Stop the Scan
Brieflypressthe SCAN keyagain.Theradiowillreturnto
thelastselectedchannel.
SCANNING FEATURES
If the Scan is Paused on a Busy Channel and you
Wish to Remain on That Channel
Brieflypressthe SCAN key.Scanningwillbecancelledand
theradiowillremainonthatchannel.Toresumescanning,
brieflypressthe SCAN keyagain.
If the Scan is Paused on a Busy Channel and you
Wish to Skip over that Channel
Brieflypressthe or key.Scanningwillresumewiththe
nextchannelinsequence.Asanalternative,pressingthe
SCAN keytwicewillgivethesameresult.
If the Scan is Paused on a Busy Channel and you
Wish to Transmit on that Channel
Simplypressthe PTT switch.Scanningwillbecancelledand
theradiowillremainonthatchannel.Note,ifthePTTis
pressedatanyothertimewhilescanning,alowbeepwill
beheardandthe PTT willbeignored.
To Switch Immediately to Channel 16
Brieflypressthe 16 key.Channel16willbeselected,
scanningwillbecancelledandtheradiowillberestoredto
normaloperationwithhightransmitterpowerselected.
To Switch Immediately to a Stored Working
Channel (CHAN A or CHAN B)
Brieflypressthe CHAN A or CHAN B key.Scanningwillbe
cancelledandtheradiowillswitchtothechannelstoredin
theselectedmemory.
Scanning Notes
1.Eachchannelsethasitsownindependentscanmemory.
E.g.ScanchannelsstoredundertheInternationalchannel
donotaffectthosestoredundertheUSAchannelset.
2.IftheGX600Aisswitchedoffwhileitisscanning,it
willresumescanningautomaticallywhenitisswitched
ONagain.

3.Aminimumof2channelsisrequiredinthescanmemory
beforescanningisallowed.Iftherearelessthat2
channels,pressingthe SCAN keywillgivealowbeep
andthescanwillbeignored.
4.Thefollowingkeys/functionsaredisabledwhilescanning:
•PTT
•25/1W
•Scanmemorystorage
Scanning with Dual Watch
IfDualWatchisselectedwhilescanning,Channel16willbe
insertedintothescaneveryalternatechannel.
Scanning with Triple Watch
IfTripleWatchisselectedwhilescanning,Channel16and
thePriorityChannel(storedinthe CHAN A memory)will
bothbeinsertedintothescan.
INSTALLATION
NOTE: YourGX600Aisdesignedforconnectionto
negativeearthelectricalsystemsonly.
SELECTING A LOCATION
Itisadvisabletospendalittletimeselectingthebest
locationforyourGX600A.Themountingbracketcanbe
rotatedabove,beloworbehindtheradioenablingtheradio
tobemountedinawiderangeoflocations.Inaddition,
usingtheoptionalflushmountingkit,theGX600Acan
bemounteddirectlyinapanelordashboard.
Upright or Overhead Mounting
Keep the following points in mind when choosing
a location.
• TheGX600AisdesignedtomeettheIP67specification
whichallowsfordirectwaterspray.However,we
recommendyouselectalocationthatwillminimise
excessiveexposuretowatersplashesorcontinuousrain.
• Selectalocationthatwontexposeyourradioto
continuousdirectsunlightwhichmaycauseoverheating.
• Ensurethatthelocationallowsafreeflowofairaround
theheatsinkonthebackoftheradio.
• Themicrophoneandallcontrolsshouldbereadily
accessibleandtheloudspeakereasilyheardfromthe
normalsteeringposition.Anextensionspeaker(SPK600)
canbeinstalledifrequired.
• Forbestresultsconnectthebatteryleadsdirectlytothe
vessel’sbattery.Ifyouneedtoextendthepowerleadsto
reachthebatteryuseheavyinsulatedautomotivewireof
atleast#10gauge.
• Componentsandcurrentsintheradiocreatemagnetic
fields.Toavoidinterferencetoshipscompassesor
autopilotsensors,theGX600Ashouldbemountedat
least300mmfromsuchequipment.
INSTALLING THE UNIT
Afterchoosingyourlocation,holdtheunitwiththe
mountingbracketattachedintothedesiredpositionand
markthelocationwithapencil.Removethemounting
bracketfromtheradioanddrillthemountingholes.Boltor
screwthebracketinplaceusinghardwaresuitableforthe
mountingsurface.Theunitissuppliedwithstainlesssteel
screws,however,ifthemountingsurfaceisunsuitablefor
screwsyoumayneedtoreplacethesewithstainlesssteel
bolts.Rememberthefixingsforoverheadmountedunits
mayhavetowithstandheavypoundingwhenthevesselis
inroughwaterorbeingtowedonatrailer.
PanelMounting
FlushMounting
(OptionalMK600ushmountingkitavailable)
PAGE8 INSTRUCTIONMANUAL GX600A
OverheadMounting
UprightMounting

GX600A INSTRUCTIONMANUAL PAGE9
DC CONNECTIONS
ConnecttheREDpowerleadtothePositive(+)sideofthe
batteryortoanaccessorypointinthevessel’sfusebox.
ConnecttheBLACKpowerleadtotheNegative(-)sideof
thebatteryortoagroundpointinyourvessel’sfusebox.
NOTE: TheREDpowerleadisttedwitha10ampfuse.If
thefuseblows,useonlyastandard10amp(3AGtype)fuse
asareplacement.Useofhigherratedfusesor‘slowblow’
typescouldresultindamagetoyourradiowhichwould
voidthewarranty.
Connecttheantennacabletotherearantennasocket
ontheradiousingaPL259coaxialconnector.
Ifrequired,anSPK600extensionspeakermaybe
installednearthesteeringpositionoroutsidethe
cabintoimprovethereceptionclarityinthoseareas.
TheSPK600isspecificallydesignedfortheGX600A
withawatertightconnectortomatchtheextension
speakersocketontherearoftheradio.
NOISE SUPPRESSION
TheinherentdesignofVHFFMradiosresultsinahigh
levelofresistancetoignitionandelectricalinterference.
Howeverinsomeinstallationsitmaybenecessaryto
takeadditionalstepstohelpreduceoreliminatenoise
interference.Duringinstallation,trytoroutetheDCbattery
leads,theantennaleadoranyaccessorywiresawayfrom
theenginecompartment,ignitionoralternatorwiring.Ifthe
noisecontinues,itmaybenecessarytofitasuppressionkit.
Contactyourlocalmarinedealerformoreinformation.
Similarly,iftheinterferenceyouareexperiencingisfrom
otherelectronicequipmentsuchasadepthsounder,tryto
keepthedepthsounder’sDCleadsandtransducercable
wellawayfromyourGX600A’swiring.
GX600A WIRING
DCPowerCable ExtensionSpeakerSocket
GimbalKnob
AntennaSocket
MountingBracket
Rear Panel Connections
ExtensionSpeaker
SPK600(optional)
VHFAntenna
10AmpFuse
Black- Red+
12Volt
Battery
GX600A

ELECTRICAL
General
Complies with: AS/NZS4415.2.2003
Frequency Range: 155–165MHz
Channel Spacing: 25kHz
Modulation: FM
Channels Sets: •International,USA,Canada
  •Private–10channels
  •USAweatherchannels
  •Customerweatherchannels
Supply Voltage: •12Voltnominal
  •10.5–15.6voltmax.range
  •Negativeearth
Frequency Stability: ±1.5kHzoverenvironment
extremes
Scan Speed: 100ms/channel
(10channels/sec)
Transmitter
Power Output: •High:25wattsmax
  •Low:1wattmax
Spurious Emissions: <-75dBc
Frequency Deviation: ±5kHzmax+20dBlimiting
@1kHz
Frequency Response: +6dBperoctave,
300Hz–3kHz,+1-3dB
Demodulated S/N: >50dBweighted
Current Consumption: •Highpower:<5amps
  •Lowpower:850mA
Receiver
IF Frequencies: •1st:21.4MHz
  •2nd:450kHz
Sensitivity: -121dBmfor12dBSINAD
unweighted
Squelch Sensitivity: Adjustable,10presetlevels
Spurious Rejection: >70dB
Intermodulation
Rejection: >75dB
Adjacent Channel
Rejection: >74dB
Blocking Rejection: >100dB
RF Bandwidth: <4MHz
Switching Bandwidth: >10MHz
Frequency Response: -6dBperoctavede-emphasis,
300Hz–3kHz,+1-3dB
Audio Output Power: •4wattsaverageintoexternal
4Ohmspeaker
  •2wattsaverageintointernal
speaker
Audio SN: >50dBweighted
Conducted Spurious
Emission: <-70dBm
Current Consumption: •Muted:<200mA
  •Fullvolume:700mA
MECHANICAL
Dimensions: 164(W)x65(H)x77(D)mm
Flush Mounting: 46mmpaneldepthminimum
Weight: 590grams
ENVIRONMENTAL
Temperature Range: -10°Cto+55°C
Vibration: MILSTD810E,
procedureI3.4.8
Solar Radiation: CaseUVstabilised
Water and Dust
Resistance: •IP67excludingexternal
cabling
Compass Safe Distance: 300mm
EXTERNAL CONNECTIONS
Microphone: 6pinsocket
DC Supply: 2pinsocket
External Speaker: 3.5mmphonolinesocket
SPECIFICATIONS
Specificationsaretypicalunlessotherwiseindicatedandmaybesubjecttochangewithoutnoticeorobligation.
PAGE10 INSTRUCTIONMANUAL GX600A

GX600A INSTRUCTIONMANUAL PAGE11
TThiswarrantyagainstdefectsisgivenbyStandard
CommunicationsPtyLtdACN000346814(We,us,our
orGME).Ourcontactdetailsaresetoutinclause2.7.This
warrantystatementonlyappliestoproductspurchasedin
Australia.PleasecontactyourlocalGMEdistributorfor
productssoldoutsideofAustralia.Localdistributordetailsat
www.gme.net.au/export.
1. Consumer guarantees
1.1Ourgoodscomewithguaranteesthatcannotbe
excludedundertheAustralianConsumerLaw.You
areentitledtoareplacementorrefundforamajor
failureandforcompensationforanyotherreasonably
foreseeablelossordamage.Youarealsoentitledto
havethegoodsrepairedorreplacedifthegoodsfail
tobeofacceptablequalityandthefailuredoesnot
amounttoamajorfailure.
1.2Totheextentweareable,weexcludeallother
conditions,warrantiesandobligationswhichwould
otherwisebeimplied.
2. Warranty against defects
2.1Thiswarrantyisinadditiontoanddoesnotlimit,
excludeorrestrictyourrightsundertheCompetition
andConsumerAct2010(Australia)oranyother
mandatoryprotectionlawsthatmayapply.
2.2Wewarrantourgoodstobefreefromdefectsin
materialsandworkmanshipforthewarrantyperiod
(seewarrantytable)fromthedateoforiginalsale(or
anotherperiodweagreetoinwriting).Subjecttoour
obligationsunderclause1.2,wewillatouroption,
eitherrepairorreplacegoodswhichwearesatised
aredefective.Wewarrantanyreplacementpartsforthe
remainderoftheperiodofwarrantyforthegoodsinto
whichtheyareincorporated.
2.3Totheextentpermittedbylaw,oursoleliabilityfor
breachofacondition,warrantyorotherobligation
impliedbylawislimited
  (a)inthecaseofgoodswesupply,toanyoneofthe
followingaswedecide-
   (i) thereplacementofthegoodsorthesupplyof
equivalentgoods;
   (ii)therepairofthegoods;
   (iii)thecostofrepairingthegoodsorofacquiring
equivalentgoods;
  (b)inthecaseofserviceswesupply,toanyoneofthe
followingaswedecide–
   (i) thesupplyingoftheservicesagain;
   (ii)thecostofhavingtheservicessuppliedagain.
2.4Forrepairsoutsidethewarrantyperiod,wewarrant
ourrepairstobefreefromdefectsinmaterialsand
workmanshipforthreemonthsfromthedateofthe
originalrepair.Weagreetore-repairorreplace(atour
option)anymaterialsorworkmanshipwhichweare
satisedaredefective.
2.5 Wewarrantthatwewillperformserviceswith
reasonablecareandskillandagreetoinvestigateany
complaintregardingourservicesmadeingoodfaith.
Ifwearesatisedthatthecomplaintisjustied,and
asoursoleliabilitytoyouunderthiswarranty(tothe
extentpermittedatlaw),weagreetosupplythose
servicesagainatnoextrachargetoyou.
2.6Tomakeawarrantyclaimyoumustbeforetheendof
theapplicablewarrantyperiod(seewarrantytable),
atyourowncost,returnthegoodsyouallegeare
defective,providewrittendetailsofthedefect,andgive
usanoriginalorcopyofthesalesinvoiceorsomeother
evidenceshowingdetailsofthetransaction.
2.7Sendyourclaimto:
StandardCommunicationsPtyLtd.
UnitB,22-24CollegeStreet,
Gladesville,NSW2111,Australia.
Tel:(02)98798888Fax:(02)98164722.
Email:[e-mail]
2.8Ifwedeterminethatyourgoodsaredefective,wewill
payforthecostofreturningtherepairedorreplaced
goodstoyou,andreimburseyouforyourreasonable
expensesofsendingyourwarrantyclaimtous.
3. What this warranty does not cover
3.1Thiswarrantywillnotapplyinrelationto:
  (a)goodsmodiedoralteredinanyway;
  (b)defectsanddamagecausedbyusewithnon
StandardCommunicationsproducts;
  (c)repairsperformedotherthanbyourauthorised
representative;
  (d)defectsordamageresultingfrommisuse,accident,
impactorneglect;
  (e)goodsimproperlyinstalledorusedinamanner
contrarytotherelevantinstructionmanual;or
  (f) goodswheretheserialnumberhasbeenremoved
ormadeillegal.
4. Warranty period
4.1WeprovidethefollowingwarrantyonGMEandKingray
products.Norepairorreplacementduringthewarranty
periodwillreneworextendthewarrantyperiodpast
theperiodfromoriginaldateofpurchase.
STANDARD COMMUNICATIONS WARRANTY AGAINST DEFECTS
PRODUCT TYPE WARRANTY
PERIOD
VHFmarinetransceivers 1year

Part Number: 310211 Drawing Number: 42244-5 GX600A

REAR VIEW
Cut Out 156 mm x 58 mm
6.0 Radius
Adhesive Backing Plate
Ensure that the location selected for in dash mounting is convenient
for the operator and that there is sufficient space behind the panel to
accommodate the body of the radio and allow a free flow of air.
Refer to page 13 of the Instruction Manual for more hints.
Once the most suitable location has been selected, mark and centre
punch the cross hair in each corner and drill a 12 mm diameter hole.
Mark a straight line from the outer edge of each hole to form a
rectangle. Cut to the inside edge of these lines.
Remove the backing paper from the metallic backing strips exposing
the self adhesive surface and fix them in position vertically at either end
of the hole on the rear side of the dashboard flush with the edge.
See figure 1
Place the GX600 through the hole. If the dashboard is subject to water
spray it may be beneficial to apply a thin bead of sealant to prevent
any water ingress between the body of the radio and
the dashboard.
The S/S brackets can now be fastened to the rear panel of the GX600
with the 4 S/S self tappers supplied. Note that the brackets can be
reverse mounted to allow for varying thicknesses of dashboards.
See figure 2
Insert the remaining metal-thread screws so that they bear down on
the two metallic backing strips and tighten until the GX600 is held
firmly in place.
Connect the power lead and antenna lead as illustrated in the
Instruction Manual.
Contents:
2 S/S brackets
2 adhesive backing strips
4 S/S self tapping screws
4 S/S metal-thread screws
MK600 IN DASH FITTING INSTRUCTIONS
Figure 2
Figure 1
✂
✂
✂
✂
58 mm
157 mm
TEMPLATE
D.N. 42261-3 P.N. 310226
HeadOffice: PO Box 96,Winston Hills, NSW2153,Australia
A division of Standard Communications Pty Ltd.

MK001B INSTALLATION - CUTTING TEMPLATE
66 mm 8 mm
2.5 mm
165 mm
10 mm Drill Bit
Mounting
Screw Clearance
8 mm Drill Bit
Mark and cut a hole 66 mm (h) by 165 mm (w), allowing for clearance of the two mounting screws holding the radio to the surround.
Use a 10 mm drill bit to form the radius of the corners and an 8 mm drill bit for the clearance of the mounting screws.

MK001W INSTALLATION - CUTTING TEMPLATE
66 mm 8 mm
2.5 mm
165 mm
10 mm Drill Bit
Mounting
Screw Clearance
8 mm Drill Bit
Mark and cut a hole 66 mm (h) by 165 mm (w), allowing for clearance of the two mounting screws holding the radio to the surround.
Use a 10 mm drill bit to form the radius of the corners and an 8 mm drill bit for the clearance of the mounting screws.
