GME XRS-370C User manual

XRS-370C
COMPACT HIDEAWAY 80 CHANNEL UHF CB RADIO
ARTWORK SUMMARY
DRAWING # 45823-6
PART # 310545
JIRA REFERENCE GRA-1637
ECO # 8460
SUPPLIER WK
MPE #
INSTRUCTION MANUAL

XRS-370C
2
Copyright Notice.......................................................................2
Introduction .............................................................................6
Features ...................................................................................6
XRS Apps .................................................................................8
XRS Connect app ........................................................................ 8
XRS Location Services app ......................................................... 8
Pairing......................................................................................... 9
General Operation ..................................................................10
Front panel ............................................................................... 10
Rear Panel................................................................................. 10
Controller Microphone.............................................................. 11
General...................................................................................11
Power........................................................................................ 11
Auto Power-down..................................................................... 11
Volume...................................................................................... 12
Selecting Channels ................................................................... 12
Squelch ..................................................................................... 13
Adjusting the Squelch Level ..................................................... 13
Signal Meter ............................................................................. 13
Brightness................................................................................. 13
Transmitting ............................................................................. 14
Time-out Timer ......................................................................... 14
Busy Lockout ............................................................................ 15
Voice Scrambler........................................................................ 15
Beep Tone Volume.................................................................... 16
Dynamic Volume Control (DVC) ................................................ 16
COPYRIGHT NOTICE

XRS-370C 3
Selecting the Active Speaker.................................................... 17
Microphone Gain....................................................................... 17
Squelch Tail............................................................................... 17
Roger Beep ............................................................................... 18
Repeater and Duplex Mode...................................................... 18
Priority Channel ........................................................................ 19
Scanning ................................................................................20
Scan groups.............................................................................. 20
Programming the scan memories ............................................ 21
Auto skip................................................................................... 21
Dual Watch ............................................................................... 22
Open Scan................................................................................. 23
Selecting Open Scan................................................................. 23
Priority Scan ............................................................................. 24
Selecting Priority Scan.............................................................. 25
Network Scan (Net-Scan).......................................................... 26
Enabling Net-Scan .................................................................... 26
Using Net-Scan......................................................................... 27
Ending the Scan........................................................................ 27
CTCSS and DCS .......................................................................28
Choosing CTCSS or DCS ............................................................ 28
CTCSS tone set compatibility.................................................... 28
Enabling CTCSS/DCS on a channel (Silent mode) ..................... 29
Busy Lockout ............................................................................ 30
Monitor function....................................................................... 30
Selective Calling .....................................................................31
SelCall Identication Number ................................................... 31
SelCall naming ......................................................................... 31

XRS-370C
4
The Quiet mode ........................................................................ 32
Sending a SelCall ...................................................................... 32
Receiving a SelCall.................................................................... 32
Quiet mode ............................................................................... 33
Group Calling..........................................................................35
Programming and sending group calls .................................... 35
Call acknowledge in group mode ............................................. 36
Storing group call idents .......................................................... 36
Receiving group calls................................................................ 36
Menu Options.........................................................................37
Context menu examples........................................................... 37
Menu Table ............................................................................39
Receive-only channels (zones).................................................. 41
Select a Zone ............................................................................ 42
Edit a Zone Name ..................................................................... 42
Add Channels to a New Zone ................................................... 44
Edit Existing Channels in a Zone .............................................. 46
Bluetooth .................................................................................. 48
Programmable Buttons ............................................................ 49
Programming the XRS Button:................................................. 50
Programming the top button: .................................................. 51
Functions .................................................................................. 52
Radio Settings .......................................................................... 53
Scan Settings............................................................................ 55
Net-Scan ................................................................................... 56
SelCall ....................................................................................... 56
Making a SelCall ....................................................................... 57
Resending the last SelCall number........................................... 58

XRS-370C 5
Editing the contact name ......................................................... 58
Editing your radio’s own SelCall number ................................. 59
Adding a new contact to the SelCall memory.......................... 60
XRS Features..........................................................................61
Location Services...................................................................... 61
Voice Playback.......................................................................... 62
Active Mute .............................................................................. 64
Installation .............................................................................65
General...................................................................................... 65
Installation................................................................................ 65
Installing the cradle .................................................................. 66
Mounting the cradle ................................................................. 66
Fitting the radio........................................................................ 67
Removing the radio .................................................................. 67
Fitting the controller microphone ............................................ 68
DC power connection ............................................................... 68
Radio remains ON when the ignition switch is OFF................. 68
Radio turns ON and OFF with the ignition switch ................... 69
High voltage detection ............................................................. 69
Antenna connection ................................................................. 70
Noise suppression .................................................................... 70
Wiring ....................................................................................... 71
Frequency and Subtone Tables ................................................ 72
Specications .........................................................................75
Electrical ................................................................................... 75
Mechanical Specications and Connections ............................ 77

XRS-370C
6
INTRODUCTION
Your GME XRS-370C 80 channel radio is Australian designed and manufactured
and is the most advanced UHF Citizen Band radio available. It combines the very
latest in electronic hardware with the most up-to-date computer aided design
and manufacturing techniques to produce a super compact mobile radio with
outstanding specications, features and performance.
The XRS Connect speaker microphone with OLED display and front mounted
speaker provides clear sound and total control from the palm of your hand
allowing your radio to be mounted almost anywhere in your vehicle.
XRS Connect are the rst UHF CB radios with an app to congure and control the
radio. Visit gme.net.au/GETXRS for more information.
FEATURES
This section lists the various features available on your XRS Connect radio.
• Transmit (TX)
• Individually Programmable Duplex Function: User selectable
for only those individual channels in your area that have repeaters,
leaving the others free for use as extra simplex channels.
• Receive (RX)
• Squelch Tail:Can be switched o to eliminate the audible noise
burst normally heard when the Squelch closes.
• User Programmable Receive Channels: 8 zones of 50 channels
per zone for a total of 400 additional receive-only channels.
• Digital Signal-Strength Meter: Provides a numeric signal
strength indication in numbers from 0 to 9+.
• Scanning and memory functions
• Microprocessor Controlled Frequency Synthesiser: Allows
user programmable control of scanning, channel memories and
selected feature options.
• Programmable Scan Function: Scans the selected UHF CB
channels with Open, Priority and Network scan functions available.

XRS-370C 7
• Priority Channel: A user programmable Priority channel for
instant recall at the press of a key.
• Signal processing
• Digital Signal Processing (DSP): Measures, lters and
compresses standard analogue audio signals and converts them
into digital format. Allows advanced RF and audio processing
techniques to be applied to maximise the radio’s performance.
• Advanced Signal Management (ASM): Identies interference
caused by strong local signals on adjacent channels and prevents
these from opening your Squelch. ASM also minimises distortion
on reception by ne tuning the receiver frequency to match that of
the incoming signal.
• Dynamic Volume Control (DVC): Automatically compensates
for variations in received audio level to provide a constant audio
output level to the speaker.
• Privacy functions
• Voice Inversion Scrambler: When activated, scrambles your
voice so that communications are only intelligible to others using
the same scrambler technology.
• In-built CTCSS and DCS: User selectable Continuous Tone Coded
Squelch System and Digital Coded Squelch system provides silent
operation on individual channels.
• In-Built SelCall with Quiet Mode: Provides selective calling of
individuals or groups with fully user-adjustable 5-tone transmitted
SelCall Ident. Also allows alphanumeric naming of up to 20 Idents
for easier caller identication.
• Physical properties
• Over Voltage Protection: Special over voltage detection circuitry
protects the radio and warns of excessive voltage conditions on
the display.
• Rugged Construction: With die-cast chassis.
• User controls and interface
• Full Function Controller Microphone: Includes front mounted
speaker to channel clear audio towards the user.

XRS-370C
8
• OLED Display: Bright, high contrast, dot matrix OLED display is
readable under all lighting conditions.
For a more detailed description of all key functions, refer the ‘General Operation’
section.
XRS APPS
This section provides details about the XRS Connect and the XRS Location
Services apps.
To download the apps for iOS or Android:
1. Visit App Store or Google Play.
2. Based on your requirement, search for XRS Connect or XRS
Location Services.
XRS CONNECT APP
The XRS Connect app is the easy way to customize, update and maintain your
XRS Connect radio using Bluetooth.
• When your device is paired to the radio, select the Read from Radio
button to read your radio’s settings into the app.
• After you have congured your preferences in the app, select Write to
Radio to update your radio with your new settings.
For information on pairing your smart device with your XRS Connect radio, see the
‘Pairing’ section that follows.
XRS LOCATION SERVICES APP
The XRS Location Services app is used with the XRS Connect radio, and is
available for iOS and Android devices. It connects to the XRS Connect radio using
Bluetooth. The app allows users to share their location using the mobile device’s
GPS location. The location is broadcast by the radio at the end of a normal voice
transmission. The location cannot be shared by the app without being connected
to an XRS Connect radio.

XRS-370C 9
XRS Location Services transmits your geographic location as a supplementary
service to voice communication on CB channels. This feature complies with the
Radio Communications (Citizen Band Radio Stations) Class Licence 2015.
GME values your privacy, and does not collect any of your location data.
The location data is only stored within the XRS Location Services app and is
transmitted from your XRS Connect radio.
To use XRS Location Services, download the app to your mobile device and update
the radio rmware.
PAIRING
To pair your smart device with your XRS Connect radio:
1. Open the Radios section of the XRS Connect or XRS Location Services
app.
2. Press the +button to discover new radios.
If you don’t see your radio, swipe down to refresh the list.
3. Locate your radio in the list and tap the name of the radio to pair.
See the ‘Bluetooth’ section of this manual for information on secure
pairing.
4. If secure pairing is turned on;
In the radio’s Bluetooth menu, navigate to Pair and select it to put the
radio into ‘pair’ mode. You will be asked to conrm a security PIN on
both the mobile device and radio.
When successfully connected the icon on your radio should change to to
show that the Bluetooth pairing is successful.
Note: The Bluetooth wireless technology enabled connection between your smart
device and your XRS Connect radio must be made through the XRS Connect app.
You will not be able to pair your smart device to your XRS Connect radio using
the normal Bluetooth wireless technology enabled settings option on your smart
device.
The XRS Connect and XRS Location Services apps are compatible with iOS 10.0
and above and Android 5.0 and above.

XRS-370C
10
GENERAL OPERATION
FRONT PANEL
Microphone Socket
REAR PANEL
Extension Speaker
Socket
Antenna Socket
12V DC
Socket
