GOAL ZERO GUIDE10 User manual

Power portable electronic devices
directly from the USB output port.
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Install batteries in correct orientation.
3. Turn on and use.
4. Recharge from any GOAL ZERO NOMAD solar panel or USB power source.
Get to know your gear
Technical Specs
How to use your gear
Getting Started
HANG IT
PROTECT IT
LIGHT IT
Sturdy hanging wire provides
convenient storage options.
Batteries are housed securely
behind a transparent door.
Equipped with a bright LED flashlight
which never needs replacing.
Mini-USB port 5V, 0.5A max (2.5W)
Inputs
Usage
Outputs
General
Weight w/ batteries 0.4 lbs (0.18 kg)
Dimensions 2.5x4x0.75 in (6x10x2 cm)
Warranty 12 months
Certifications FCC and CE
Optimal operating temp. 32-104ºF (0-40ºC)
Charges from the following: Approx. charge time:
Any USB power source 8-10 hours
GOAL ZERO NOMAD 3.5 (solar port) 6-8 hours
GOAL ZERO NOMAD 7 (solar port) 2-4 hours
Batteries 4x AA or AAA** NiMH cells
USB standard port 5.0V, 0.5A max (2.5W)
Flashlight 100mW white LED, 100+ hours*
Battery capacity 10 Wh*, use only NiMH cells
Life-span hundreds of cycles*
Shelf Life 12 months*
*When using GOAL ZERO NiMH rechargeable low self-discharge AA cells.
** AAA cells require an adapter, which is free upon request. Contact GOAL ZERO
directly to request one.
Internal
Power switch
Turn to ‘on’ to enable output; turn to the to turn on flashlight.
See legend below.
Power LED
Indicates power and charging state. See power legend below.
LED power legend: Power switch legend:
USB output port
Accepts any standard USB cable for charging USB devices. To
use, turn GUIDE 10 to ‘on.’
LED Flashlight
100+ hours of light per charge. Never needs replacing. Turn on
with power switch.
Solar charging port
Recharge from GOAL ZERO NOMAD 7 or NOMAD 3.5 solar panels.
Mini-USB charging port
Recharge from USB sources, like a computer.
USE IT
GUIDE 10
BATTERY PACK

Output Ports
Frequently Asked Questions
Comes With:
Compatible With:
What batteries can be used?
• Any AA or AAA NiMH batteries can be used and recharged.
• We do not recommend other types of batteries.
• 4 same-sized batteries MUST be charged at once, but not all batteries need to be empty.
How do I charge?
• From Solar: Use GOAL ZERO NOMAD 3.5 or NOMAD 7 with solar charge cable for fast charging.
• From USB: Use any USB power source, such as a computer or any GOAL ZERO power pack.
Is it waterproof?
No, but it is weather-resistant. Care should be taken to shield it from direct sunlight
and the elements. Unexpected rain storms probably won’t harm it.
How is it protected?
Usage is plug-and-play. The built-in battery management system prevents over-charging and over-discharging
of batteries. The USB output will only supply the amount of power needed.
USB mini charging cord
Solar charging cord
4-pack of GOAL ZERO rechargeable AA batteries (in most kits)
CONTACT US:
Toll Free: 888.794.6250
14864 Pony Express Road
Bluffdale, UT, 84065
WWW.GOALZERO.COM
We proudly support Tifie Humanitarian
WWW.TIFIE.ORG
USER GUIDE
• Fill out your warranty
• Watch demo video
• Download this manual
Hand-held USB devices, like:
Cell phone, Smart phone
GPS, MP3 player
GOAL ZERO products:
NOMAD solar panels
LUNA, BOLT, BLAZE lights
GUIDE 10
BATTERY PACK
