golmar ART 4TH/G+ User guide

ART 4TH/G+
ART 4TH/G+ V01 REV.0122|ENGLISH
INSTALLER MANUAL

CATEGORY 1_HEADERCATEGORY 2_HEADER
2Footer Infos
IP G+ ART 4TH/G+
2
www.golmar.es
INDEX
1. Safety cautions and warnings...................................................................................................................................... 3
2. Specications ................................................................................................................................................................ 3
3. Device description........................................................................................................................................................ 3
3.1. Jumper description.............................................................................................................................................. 4
4. Device installation........................................................................................................................................................ 4
5. Initial conguration ..................................................................................................................................................... 5
6.Web Client...................................................................................................................................................................... 5
6.1. Settings.................................................................................................................................................................. 6
6.2. SIP Servers............................................................................................................................................................ 6
6.3. About..................................................................................................................................................................... 7
7. Settings........................................................................................................................................................................... 7
7.1. Address.................................................................................................................................................................. 8
7.2. Privacy................................................................................................................................................................... 8
7.3. Guard..................................................................................................................................................................... 8
7.4. Devices.................................................................................................................................................................. 9
7.5. SIP.......................................................................................................................................................................... 9
7.6. Password ............................................................................................................................................................... 9

3
ART 4TH/G+ IP G+
www.golmar.es
Handset.
Speaker.
- TCP/IP video intercom system.
- Installation over existing Ethernet netwrok (D4L-G+/POE switches are required) or in its own structure by means of bre or UTP
cable category 5 or higher.
- Up to 98 blocks for each installation.
- Up to 19 indoor panels for each block.
- Up to 799 apartments for each block.
- Up to19 general guard units for each installation and 9 for each block.
- Up to 32 ONVIF cameras.
2. SPECIFICATIONS
e installation and setup of this equipment must be done by an authorized installer.
- e current regulations oblige to protect the power supply by means of a thermal magnetic circuit breaker.
- All the installation conduits must distance at least 40 cm from any other installation.
- In regards of the power supply FA-G+:
- Do not tight with excessive strength the screws of the terminal block at FA-G+ power supply.
- Install the power supply in a dry and secure area, protected against water drops.
- Avoid placing the power supply close to heating sources, humid or dusty areas.
- Do not cover the power supply ventilation openings area to assure air ow circulation.
- To prevent damages, the power supply has to be strongly mounted. Use a DIN rail 46277 (8 DIN) to x it.
- To avoid an Electrical shock, do not remove the protection cover and do not manipulate the cables connected to the power terminals.
1. SAFETY CAUTIONS AND WARNINGS
3. DEVICE DESCRIPTION
- Front side:
SPOE
48V
FPOE
18V
GND
12V
GND
SA
HZ-
HZ+
PSF-16211
PPT
2149L
EP-286SG
2050
MOC
18V 18V
48V 48V
HZ-
HZ+
GND
SA
GND
12V
- Back side:
Microphone.
RJ45 connector.
HZ(*)
(*) Refers to the apartment door bell..
12V local supply connector.
Auxiliary sounder
connector.
Supply voltage selector
jumper.
Capacitive touch buttons.

4
ART 4TH/G+IP G+
www.golmar.es
4. DEVICE INSTALLATION
1- Avoid exposing the monitor to backlighting from light
sources for optimal picture quality:.
1,65m máx
1,45m máx
1,85m máx
16-03-2020 Mon
View Intercom Events Settings
11:24
2- Place the top of the monitor at a height of 1,65m for a correct
viewing of the screen:
1,65m máx
16-03-2020 Mon
View Intercom Events Settings
11:24
Monitor location
Necessary elements to complete an installation:
• FA-G+power supply for each 8 devices (door panels, monitors…).
• Do the distribution to the dierent devices through 4 distributed outputs D4L-G+/PoE distributors, or using 48V standard
PoE switches.
• Choose 6502/G+ door panels, or a composition of modules for the Nexa panel to be able to register units in it and set the video
intercom system.
• Add ART 7/G+/PCM DUAL POE y ART 7W/G+/PCM DUAL POE video units if you want the apartment unit has a PCM/G+
private call panel.
• In case of a daisy-chain distribution of the devices (IN/OUT), use DCP/G+ injectors with the FA-DC48/G+ power supply and
Ethernet DCS/G+ switches in monitors.
Use the bracket so that the monitor is at the above mentioned
height.
Place it on a at surface that allows a good t of the bracket to
the wall for a correct viewing of the screen:
3.1. Jumper description
SPOE
48V
FPOE
18V
GND
12V
GND
SA
HZ-
HZ+
GND
We will be able to choose which supply will be necessary for the correct operation of the device through the jumper located in the back side of the
monitor in the following way:
48 Vstandard PoE (default position).
e device is ready to receive 48V from a standard PoE switch.
18 V.
e device will be ready to receive 18V from a D4-L-G+/PoE or from
an Ethernet DCS/G+ switch.
SPOE
48V
FPOE
18V
GND
12V
GND
SA
HZ-
HZ+
GND

5
ART 4TH/G+ IP G+
www.golmar.es
6. WEB CLIENT
We can access the web client to do changes in the conguration or to congure its network parameters manually entering the device
IP address in our web browser. If the device still having default settings, the IP addrees we must enter will be 10.0.0.254. If the device is
already congured we must enter the IP address that the system automatically assigned or we manually assigned.
Type the IP address in the web browser:
GO
10.0.14.9
Search
GO
10.0.14.9
Search
Log in the Web Client: we password to access is 888999.
5. INITIAL CONFIGURATION
Once connected the monitor to the installation, this will automatically starts and will show an initial conguration screen on which we must set
the following parameters concerning to the phisical location of the monitor in the installation:
Monitor
#20
558
1
#
Configuración inicial ~ Initial config
EnglishIdioma ~ Language
Edificio ~ Block
Vivienda ~ Apartment
Up to a maximum of 6 apartment
units for each apartment..
Block where the apartment is
located..
Apartment number.
Save set conguration..
Menu navigation buttons.

6
ART 4TH/G+IP G+
www.golmar.es
e following describes the initial screen of the Web Client for the ART 4TH/G+ monitor:
If we don’t remember the IP address that we assigned to the monitor, we can search for IP address in the network through search
programs as “IP Search Tool”.
Sip Server
About

APARTMENT UNIT

Network
 10.0.7.105
 255.0.0.0
Gateway 10.0.0.1
Server IP 10.0.14.9

 1
 5
 1
 1
 1



About the device.
SIP.settings
Settings.
Monitor language.
Dialing code
length.
Block number.
Apartment address.
Apartment unit
number.
Available languages. Manual assignment of
network parameters.
6.1. Settings
6.2. SIP Servers
In the SIP servers section we will be able to include the device in the registered PABX telephone switchboard in the management panel
to be able to make and receive calls through an extension assigned to the monitor from SIP devicess which are included in the system.
L
Name
SERVER LIST
Apply
Enabled

SERVER INFORMATION
Delete
1
2
3
4
5
6
7
8
9
10
11
grandstream-
10.0.128.8
5060
IP Address
Port
User
Password
Transmission mode*
*Transmission mode
0 IP - 1 to 30 SIP Servers
1000
*****
1
grandstream
Transmission port
Normally is the 5060.
Created user and
password in the PABX

7
ART 4TH/G+ IP G+
www.golmar.es
7. SETTINGS
In this section of the manual we will see with detail the system settings. If you want to see other type of settings which we can access
with the monitor, see the user manual of the 4.3” ART 4TH/G+ monitor that you will nd in the “Downloads” tab in the website of the
product.
When pressing on system settings, in the monitor will appear a screen on which you must enter the installer password to access the
system settings. e installer password by default is: 2718.
Once you have access the system settings menu, the next screen will appear:
System settings
To return the monitor settings to factory values, we must press on the icon located on the bottom right in the second system settings
screen. It will appear the following screen and we must conrm the restore to factory values of the monitor settings.
Reset
Reset system settings ?
6.3. About
Sip Server
About
Se�ngs
MCU 1.00
Firmware 1.01
Hardware VER.B
Server IP 10.0.14.9
Apartment address
Monitor unit
10.0.7.105
Return to factory settings.Reboot the device. Uopdate FW version.
System settings
****
Access to the 2nd system settings screen.

8
ART 4TH/G+IP G+
www.golmar.es
7.1. Address
Block number
Address
Apartment address
Monitor unit
#2
558
1
#
0
# #
In this section we will be able to modify the monitor address. If we change the physical address of the monitor, it will also change its
network parameters. ese can be assigned automatically by the system again or manually accessing the previously explained screen
pressing on the icon. We would ll in the elds in the same way as in the beginning but changing the data which have changed.
7.2. Privacy
Preview video sources
Automatic snapshot
Privacy
Automatic erasing
In the privacy section we can enable or disable the preview of the door panel and CCTV IP cameras images which are registered in the
system. It is also possible to manage the automatic snapshot when there is a call from the door panel and the automatic erasure of these
images when the 30 days period set is overpassed.
7.3. Guard
Direct call button
Block number
Guard
Unit address
#20
558
With regard to the guard unit settings, we will be able to set to which address we will call when we press the direct call to the guard icon
from the main screen of the monitor.

9
ART 4TH/G+ IP G+
www.golmar.es
7.6. Password
To nish with the system settings menu, we will emphasise in the “Password” section which allows us to change the password to access
the system settings of the monitor.
# #
Password
6543
Enter new password
****
7.4. Devices
Devices
20
Lift control
Floor number
Link to access control
Staircase light
In the “Devices” section we will be able to enable, if it were available to us, the panel of one call line PCM/G+. We will also be able to
enable the li control from the main screen of the monitor and link it with the access control to, in case of an openning presenting the
keys on the RFID reader of the entry panel, activate the li on the respective oors of the panel and the apartment.
