OPERATIONMANUAL
GTVC14N14DVD
14"(34cm)COLOURTELEVISION
WITHDVD PLAYER
HELPLINEPHONENUMBER08708 7 3 0 0 80
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:391

2
INSTALLATION
LOCATEthe receiverinthe roomwheredirectlightdoesnotstrikethe screen.Totaldarkness
orareflection on the picturescreen can causeeyestrain.Soft and indirectlighting is
recommended forcomfortableviewing.
ALLOWenough spacebetween the receiverand the wall topermitproperventilation.
AVOIDexcessivewarmlocationstopreventpossibledamage tothe cabinetorcomponent
failure.
CONNECTION
ThisTV/DVDPlayershouldonlybe connected toan AC230V~50Hzmainselectricalsupply.
AUTOMATICDEGAUSSING
All colortelevision receiversaresensitivetomagneticinfluences,usuallycaused byeither
moving the receiverfromone placetoanotherorusing certainelectricalappliancesnearthe
receiver.Thisresidualmagnetismasitiscalled,sometimescausesdistortion whichgivesrise
to"blotchy"areasofcolorinthe picture.Toavoidtheseeffectsthe receiverincorporatesan
automaticdegaussing circuitwhichoperatesforashortwhileimmediatelyeachtimethe
receiverisswitched on using the mainsswitch.Thiscircuitremovesanyresidualmagnetism
inthe metalpartsofthe picturetube and thereforeensuresthateachtimethe receiveris
switched lifelike.If the setismoved orfaced inadifferentdirection,the mainsswitchmustbe
switched off atleast10 minutesinorderthatthe automaticdegaussing circuitoperatesproperly.
CAUTION:TOREDUCETHERISKOFELECTRICSHOCK.DONOTREMOVE COVER(OR
BACK).
NOUSERSERVICEABLEPARTSINSIDE.REFERSERVICINGTOQUALIFIEDSERVICEPERSON-
NEL.
The graphicsymbolson the back coverofthe setmean the following:
WARNING:
•To reduce therisk offireorelectricshock,do notexpose thisappliance torain
ormoisture.
•Theapparatusshall notbeexposedtodripping orsplashing and thatno objects
filledwithliquids,suchas vases,shall beplacedon theapparatus.
•Themainsplug isusedas thedisconnectdevice,thedisconnectdevice shall
remainreadilyoperable.
The lightning flashwitharrowhead symbolwithinan equilateraltriangleisintended to
alertthe usertothe presenceofuninsulated "dangerousvoltage"withinthe product's
enclosurethatmaybe ofsufficientmagnitude toconstitutearisk ofelectricshock to
persons.
The exclamation pointwithinan equilateraltriangleisintended toalertthe usertothe
presenceofimportantoperating and maintenance(servicing)instructionsinthe literature
accompanying the appliance.
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:392

3
CAUTION
Nevertamperwithanycomponentsinside yourset, oranyotheradjustmentcontrolsnot
mentioned inthismanual.All television receiversarehigh voltage instruments.YourPICTURE
TUBE ishighlyevacuated.If broken,glass fragmentswill be violentlyexpelled.Scratching,
shipping orundue pressureisdangerousand shouldbe avoided.When you clean up dustor
stick orawaterdrop on the PICTURETUBE FACEorCABINET,the powercordshouldbe pulled
outfromthe wall then wipe the receiverwithadrysoft cloth.All "inside work"on yourreceiver
shouldbe performed onlybythe ProfessionalServicePersonnel.
DANGER
Manufactured underlicensefromDolbyLaboratories“Dolby”,”ProLogic”and the double-D
symbolaretrademarks ofDolbyLaboratories.Confidentialunpublished works.©1992-1997
DolbyLaboratories,lnc.All rightsreserved.
Invisiblelaserradiation when open
and interlock fai led ordefeated.
avoiddirectexposuretolaserbeam.
LASERSAFETY
Thisunitemploys an opticallaserbeamsysteminthe CD
mechanism,designed withbuiltinsafeguards.Donotattempt
todisassemble,refertoqualified servicepersonnel.
Exposuretothisinvisiblelaserlightlightbeammaybe harmful
tothe human eye.
THISISACLASS-1LASERPRODUCT.USE OFCONTROLS,
ORADJUSTMENTSORPROCEDURES OTHERTHANTHOSE
SPECIFIEDHEREIN,MAY RESULTINHAZARDOUS
LASERLIGHTBEAMEXPOSURE.
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:393

4
Instructionson environmentprotection
Donotdisposeofthisproductinthe usualhouseholdgarbage atthe end ofitslife
cycle;hand itoveratacollection pointforthe recycling ofelectricaland electronic
appliances.The symbolon the product, the instructionsforuseorthe packing will
informaboutthe methodsfordisposal.
The materialsarerecyclableasmentioned initsmarking.Byrecycling,material
recycling orotherformsofre-utilization ofoldappliances,you aremaking an
importantcontribution toprotectourenvironment.
Pleaseinquireatthe communityadministration forthe authorized disposallocation.
Thisproductincorporatescopyrightprotection technologythatisprotected byU.S.patents
and otherintellectualpropertyrights.Useofthiscopyrightprotection technologymustbe
authorized byMacrovision,and isintended forhomeand otherlimited viewing usesonly
unless otherwiseauthorized byMacrovision.Reverseengineering ordisassemblyis
prohibited.
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:404

5
IMPORTANTSAFEGUARDS
PREFITTEDMAINSPLUGS
Foryou convenienceamainsplug hasbeen fitted tothisappliance.Foryoursafetyplease
observethe following information.
1.Shouldthe fuseinthe plug fall removethe plug fromthe wall socketand replacethe fuse
witha3AmpASTAapproved toBS 1362 fuse.
2.Neverusethe plug withoutthe fusecoverfitted.Replacementfusecoversareavailable
fromyourdealerormostelectricalretail outlets.
3. If the mainsplug isoutoff the cable,rewirethe replacementplug inaccordancewith
instruction giveinthismanual.
4.CAUTION:Underno circumstancesshouldthe discarded plug be inserted intothe mains
socket. Topreventashock hazardcarefullydisposeofthe discarded plug.
Donotleavethe plug lying around wherechildren mightsee it.
WARNING:Topreventfireorshock hazarddo notexposethisunittorainormoisture.
CAUTION:
DANGEROUSVOLTAGES EXISTINSIDETHISUNITDONOTREMOVE COVER(OR
BACK).
NOUSERSERVICEABLEPARTSINSIDEREFERSERVICINGTOQUALIFIEDSERVICE
PERSONNEL.DISCONNECTFROMMAINSSUPPLYWHENNOTINUSE.
Thiswiresinthismainslead arecoloured in
accordancewiththe following wiring codes:
Blue................................... Neutral
Brown...................................Live
Thiswiresinthismainslead mustbe connected to
the terminalsinthe plug asfollows:
Blue Wire........................... NorBlack
BrownWire..........................LorRed
Onlya3Ampfuseshouldbe fitted inthe plug ora5Ampfuseatthe distribution board.
WARNING:UNDERNOCIRCUMSTANCES MUSTTHELIVE ORNEUTRALWIRES BE
CONNECTEDTOTHEEARTHTERMINALINA3-PINMAINSPLUG.
Thissymbolmeansthatthisunitisdoubleinsulated.Anearthconnection isnot
required.
HELPLINEPHONENUMBER08708 730080
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:405

6
LOCATIONOFCONTROL
1.Speaker
2.PowerButton
3.PowerIndicator
4.RemoteSensor
5.ChannelButtons
6.TV/AV/DVDButton
7.Open Button
8.PlayButton
9.Stop Button
10.VolumeButtons
11.DVDDoor
12.FrontAudio(R)Input(AV2)
13.FrontAudio(L)Input(AV2)
14.FrontVideo Input(AV2)
15.Earphone Jack
16.75 ohmAntenna Socket
17.Scartconnector(AV 1)
18.AudiodigitalOutSocket(ForDVDonly)
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:406

7
LOCATIONOFCONTROLS
1.Open/CloseButton
2.Sleep button
3.PP Button
4.NumericButtons
5.P+Buttons
6.Programbutton
7.Menu Button
8.Volume-Button
9.DisplayButton
10.PlayButtons
11.Stop Button
12.FastForwardButton
13.FastBackwardButton
14.Direction Buttons(UpDownLeft Right)
15.DVDMenu Button
16.EnterButton
17.Setup Button
18.SearchButton
19.AngleButton
20.TeletextStop Button
21.TeletextIndexButton
22.TeletextconcealButton
23.TVSystem/TeletextCancelButton
24.FastTeletextdirectPage Button/Menu direct
Page button
25.StandbyButton
26.Recall Button
27.MuteButton
28.+10/TwoDigitalprogramButton
29.TV/AV Button
30.TV/DVDButton
31.Volume+Button
32.P-Buttons
33.Audio(DVD)/ST/D/I/II(TV)Button(ForNicam/
A2stereo version only)
34.Pause/Step Button
35.PreviousButton
36.NextButton
37.RepeatButton
38. Repeat A-B Button
39. Slow Button
40. Clear Button
41. DVD Subtitle Button
42. DVD Zoom Button
43. Txt Mode/SwapButton
44. Teletext Time Display Button
45. Teletext /TV Mode Button
46. Teletext Enlarge Button
47. Teletext Mix Mode Button
BATTERYINSTALLATION
•Inserttwopcs "AAA";"R03"batteriesasillustrated and replacethe batterycover.
•Corrosion,oxidation,battery-leakage and anyothergradually acidicdefectofthisnature
will invalidatethe guarantee.
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:407

8
OPERATINGTHETELEVISIONRECEIVER
ConnectyourTVaerialtothe aerialinputsocketlocated on the back ofthe TV.
Pushthe MainPowerSwitch,PowerIndicatorwill be illuminated.Afterafewsecondsthe TV
screen will lightup.Shouldwhitedotsappearon the screen the TVwill requiretuning intothe
availableTVstationsinyourarea.
Pre-setting theTVstationsintotheMemory
(Note:Presettuning canonlybecarriedoutinTVMode)
1.TUNE
•Press the MENU button fourtimestoselectthe TUNE
mode asshowinFIG.1
•Press the “P+/P-”button toselectthe SOUND then
press “V+/V-”button tochange the desired sound
systemBGorI.
AUTOSEARCH
•Press the “P+/P-”button toselectthe AUTOSEARCH
asshowninFIG.2
•Press the “V+/V-”button tostartthe automatic
scanning processes,the scanning starting fromVHF
toUHFand the TVstationswill automaticstoreinto
memoryasshowninFIG.3
•When scanning iscompleted,the setwill tune to
lowestprogramand showlowestprogramnumber
on the screen.
•If wanttostop autosearchfunction topress MENU button.
FIG.1
TUNE
AUTOSEARCH
SEARCH
BAND VHF-L
FINETUNE
COLOUR AUTO
SOUND I
SKIPOFF
PROGRAM1
FIG.2
TUNE
AUTOSEARCH
SEARCH
BAND VHF-L
FINETUNE
COLOUR AUTO
SOUND I
SKIPOFF
PROGRAM1
FIG.3
AUTOSEARCH
VHF-L
-|||||||||| +
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:408

9
OPERATINGTHETELEVISION
SEARCH(Manual)
1)Press the “P+/P-”button toselectthe PROGRAM.
then press the “V+/V-”button ornumericbutton to
selectthe desired Programnumber.
2)Press the “P+/P-”button toselectthe BAND.then
press the “V+/V-”button toselectVHF-L,VHF-Hand
UHF.
3) Pressthe“ P+/P-”button toselectthe COLOUR then
press “V+/V-”button tochange the desired colour
systemAUTO,PAL,N3.58,N4.43,SECAM.
4)Press the “P+/P-”button toselectthe SOUND then
press “V+/V-”button tochange the desired sound
systemBGorI.
5)Press the “P+/P-”button toselectthe SEARCH then press the “V+/V-”button tostartthe
station search.The TVscreen will showthe tuning and when the firststation received is
located,the tuning will stop and stored automatically.Repeatsteps1,2,3,4tosearchthe
nextTVstation.asshowninFIG.4,FIG.5.
•If wanttostop search(manual)funtion topress MENU button.
Notes:
•If ghost/noisy stationshavebeen stored when using the AUTOSEARCH method these
stationscan be removed fromthe channellistbyentering the SKIPMode showninthe TUNE
menu.Press the “V+/V-”button and change the OFF statetoON.Press the MENU button to
returntonormalviewing.The unwanted station will be removed fromthe channellistwhen
you change TVchannelsand cannotbe viewed.
•The SKIPPEDstation can be restored byreentering the TUNEmenu and changing the SKIP
ONstatustoOFF.
•Toexitthe TUNEmode press MENU button twotimes.
FIG.5
SEARCH
VHF-L
-|||||||||| +
TUNE
AUTOSEARCH
SEARCH
BAND VHF-L
FINETUNE
COLOUR AUTO
SOUND I
SKIPOFF
PROGRAM1
FIG.4
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:409

10
OPERATINGTHETELEVISION
2.PICTURE
•Press the MENU button toselectthe PICTUREmode
asshowinFIG.6.
•Press the “P+/P-”button toselectthe BRIGHTNESS/
COLOUR/CONTRAST/SHARPNESS/HUE
•Press the “V+/V-”button toadjustthe desired level,
The stepscan be adjustfrom0~63.
•HUEitemforNTSCsystemonly,the levelsetting can
be adjustfrom“-31”to“+31”.
•Toexitthe PICTUREmode press the MENU button
fivetimes.
3.SOUND
•Press the MENU button twotimestoselectthe SOUND
mode asshowinFIG.7
•Press the “V+/V-”button toadjustthe levelofthe
Volume.The levelsetting can be adjustfrom“0”to
“63”.
•Toexitthe SOUND mode press the MENU button four
times.
4.SETUP
LANG.
•Press the MENU button three timestoselectthe
SETUPmode,asshowninFIG.8
•Press the “P+/P-”button toselectthe LANG.then
press the “V+/V-”button toselectthe desired
language ENGLISH,RUSSIAN,DUTCH,ITALIAN,
GERMAN,FRENCH,SPANISH,PORTUGUESE,
ARABIC,FARSI, orTURKISH.
BLUEBACK
•Press the “P+/P-”button toselectthe BLUEBACKand press the “V+/V-”button toadjustthe
blue Back-ground ONorOFF.
•Toexitthe SETUPmode press the MENU button three times.
BRIGHTNESS 32
COLOUR 32
CONTRAST32
SHARPNESS 32
HUE0
FIG.6
SOUND
VOLUME10
FIG.7
SETUP
LANG.ENGLISH
BLUEBACKON
FIG.8
(GTVC14N14DVD)UOC+CT908S ib 060509.p65 2006/5/9, 下午 02:4010
