Goodwe Pytes E-BOX Series Manual

Installation and configuration manual
With GOODWE
Pytes Lithium Battery
E-BOX series
With GOODWE Energy Storage Inverter
GW-BP/SBP/GW-ES/EM

2
CONTENTS
BOM LIST...............................................................................................3
HOW TO INSATLL..................................................................................5
1. Power Cable Connection.....................................................................5
2. Communication Cable Connection......................................................7
3. Set The DIP Switch.............................................................................7
4.Start up the system ..............................................................................8
5.Connect to smart phone.......................................................................8
6.Change the battery setting of the inverter...........................................11
7.Check the battery SOC ......................................................................15

3
BOM LIST
Before installation, you should prepare following items.
Item
Remarks
Quantity
Power Cable
(DC)
☐Conductor cross-section: 50 mm²
to 95 mm²
☐Cable diameters: 14 mm to 25 mm
☐Only copper cables may be used.
☐The DC cables must be sized for
the maximum battery voltage and the
maximum battery current (see battery
manufacturer documentation).
Depends on the number of
batteries and the
connection method
CAN Cable
CAN communicationTerminal (RJ45
port) follow CAN protocol, to output
batteries information
1
Twist Pair Cable
For Ethernet Connection between PC
and Inverter
1
PC (Personal
Computer)
Provide for oneself
1
Battery
48100R / 48100C / 4850
Depends on the number of
batteries and the
connectionmethod
Inverter
Goodwe GW-BP/SBP/GW-ES/EM
1

4
Definition of RJ45 Port Pin for BMS is as follow.
Click here to tell the version of 48100R you have.
CAN port definition
Version of 48100R
Pin number of com. cable
A version
B and C version

5
Power cable connection
communication cable
connection
Connet with smartphone
Change the battery
setting of the inverter
System monitoring
Check the battery soc
And System monitoring
HOW TO INSATLL
Set the ADD switch
Start up the system

6
Ba t tery +
Battery-
1. Power Cable Connection
Step.1
Open the cap of the Goodwe inverter.
Step.2
Strip cable coat, revealing 10mm length of metal core. Use special
crimper to compress battery terminal tightly.
Pic 1.1.1
Step.3
Connect battery terminal onto inverter .
Pic 1.1.2

7
CAN
2. Communication Cable Connection
Open the cap and connect the other end of the cable to the battery
communication port as shown in pic 1.2.1. (Ensure the correct sequence
of wires inside the communication cable)
Make sure which communication port to use.
Pic 1.2.1
Pic 1.2.2
3. Set The DIP Switch
Set the ADD switch as shown in graphic 1

8
Version of 48100R
ADD setting
A and B version
C version
Pic 1.2.3
4. Start up the system
Start up the inverters and batteries.
5. Connect to smart phone
Step.1
Download the app PV master from the app store.
Pic 2.2.1

Step.9
9
Start the APP then connect to the solar-WIFI ,password is 12345678.
Pic 2.2.2

Step.
10
10
The BMS status will be showed on the interface if the connection
between battery and inverter is correct.
Pic 2.2.3

11
6. Change the battery setting of the inverter
※CAUTION:If you want more details about the batteries settings，
please check the operating manual of inverters.
Step1.
Choose the Basic settings in settings icon. The Installer login passwordis：
goodwe2010.
Pic 3.1.1 Pic 3.1.2

Step.
12
12
Select your safety settings and opertation mode.
Pic 3.1.3 Pic 3.1.4

Step.
13
13
Select battery model to default(lithium 100Ah)，restart the inverter.
(If your battery model is 48100C,you can choose LBS051200A-A02)
Pic 3.1.5

14
You can also choose self define to define the settings yourself.
Pic 3.1.6

15
7. Check the battery SOC
Now you can monitor your plant in the PV master interface.
Pic 3.2.1
