Goodwe EM Series User manual

340-00053-00
Franciscusdreef 42C
3565AC Utrecht
Google playiOS App Store

6 CEI Auto Test introduction
7
10
12
11
4.6
4.7
4.8 DRED Connection
4.9 Earth Fault Alarm
18
19
24
25
27
14
14
14
13
15
16
4.10
20
9 Trouble shooting
4.12 special backup application 15

1 Introduction
Before using the inverter, please read all instructions and cautionary markings on the unit and this manual. Store the manual where
it can be accessed easily.
The EM series inverter of Jiangsu GoodWe Power Supply Technology Co. Ltd. (hereinafter referred to as GoodWe) strictly conforms to
related safety rules in design and test.
Safety regulations relevant to the location shall be followed during installation, operation and maintenance.
Improper operation may have a risk of electric shock or damage to equipment and property.
01
2 Important Safety Warning
02
Caution!
Failure to observe a warning indicated in
this manual may result in injury.
Danger of high voltage and electric shock!
Danger of hot surface!
Components of the product can be recycled.
This side up; the package must always be
transported, handled and stored in such a way
that the arrows always point upwards.
No more than six (6) identical packages may
be stacked on each other.
The EM series inverters (hybrid) are bidirectional which apply to PV system with battery to store energy.
Energy produced by the PV system is used to optimize self-consumption; excess energy is used to charge the batteries, and then feed
into the public grid when the PV energy is adequate,
When PV energy output is insufficient to support connected loads, the system automatically discharge energy from the batteries if
battery capacity is abundant. If the battery energy is insufficient to meet own consumption requirements, electricity will be drawn
from the public grid.
EM series inverter is design for both indoor and outdoor use.The
Figure 1-1 Basic hybrid PV system overview
2.1 Symbols
Product should not be disposed as
household waste.
CE Mark
Keep dry; the package/product must be
protected from excessive humidity and must be
stored under cover.
Signals danger due to electrical
shock and indicates the time (5
minutes) to allow after the
inverter has been turned off and
disconnected to ensure safety in
any installation operation.
The package/product should be handled
carefully and never be tipped over or slung.
2.2 Safety
● Installation, maintenance and connection of inverters must be performed by qualified personnel, in compliance with local electrical
standards, wiring rules and the requirements of local power authorities and/or companies (for example : AS 4777 and AS/NZS
3000 in Australia).
● To avoid electric shock, DC input and AC output of the inverter must be terminated at least 5 minutes before performing any
installation or maintenance.
● The temperature of some parts of the inverter may exceed 60℃ during operation. To avoid being burnt, do not touch the inverter
during operation. Let it cool before touching it.
● Ensure children are kept away from inverters.
● Do not open the front cover of the inverter. Apart from performing work at the wiring terminal (as instructed in this manual),
touching or changing components without authorization may cause injury to people, damage to inverters and annulment of the
warranty.
● Static electricity may damage electronic components. Appropriate method must be adopted to prevent such damage to the
inverter; otherwise the inverter may be damaged and the warranty annulled.
● Ensure the output voltage of the proposed PV array is lower than the maximum rated input voltage of the inverter; otherwise the
inverter may be damaged and the warranty annulled.
● When exposed to sunlight, the PV array generates dangerous high DC voltage. Please operate according to our instructions, or it
will result in danger to life.
● PV modules should have an IEC61730 class A rating.
● If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
● Completely isolate the inverter before maintaining. Completely isolate the inverter should ：Switch off the DC switch, disconnect
the PV terminal, disconnect the battery terminal, and disconnect the AC terminal.
● Prohibit to insert or pull the AC and DC terminals when the inverter is running.
● In Australia, the inverter internal switching does not maintain the neutral integrity, neutral integrity must be addressed by external
connection arrangements like the example proposed in the diagram 4.10.
● In Australia, the output of backup side in switchbox should be labeled 'main switch UPS supply', the output of normal load side in
switchbox should be labeled 'main switch inverter supply'.
Refer to the operating instructions

03 04
Figure 3.3-1
Mounting location should be selected based on the following aspects:
● The installation method and mounting location must be suitable for the inverter's weight and
dimensions.
● Mount on a solid surface.
● Select a well ventilated place sheltered from direct sun radiation.
● Install vertically or tilted backward by max 15°. The device cannot be installed with a sideways tilt. The connection area must point
downwards. Refer to Figure 3.3-1.
3.3 Selecting The Mounting Location
●
● For the convenience of checking the LED lights and possible maintenance activities, please install the inverter at eye level.
● Inverters should NOT be installed near inflammable and explosive items. Any strong electro-magnetic equipment should be kept
away from installation site.
● Product label and warning symbol shall be clear to read after installation.
● Please avoid direct sunlight, rain exposure, snow lay up when install.
In order to achieve optimal performance, the ambient temperature should be lower than 45 °C.
Direct Sunlight Rain Exposure Snow Lay up
No direct sunlight No Rain Exposure No Snow Lay up
3.1 Packing List
3 Installation
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the
following items inside of package:
Max
15°
Wall-mounted
Bracket×1
Inverter×1Positive DC Plug×2
or
Negative DC Plug×2
or
Battery cover × 1
EzMeter & CT × 1
Battery terminal × 2
User Manual×1
User
manual
Quick Installation Guide×1Wi-Fi Configuration×1
Wi-Fi
Configuration
Instruction
of
Fast
Installation
Expansion Bolts×6Hexagon head
screw × 2 Pan head screw × 6
Waterproof terminal × 2
3.2 Product Overview
1 2 3 4 5 6
7
1.
2. Battery input terminals
3. Wi-Fi Box port
4. Communication port
5. Back-Up port
6. On-Grid port
7. DC Switch (Optional)
8. LED Lable
8
PE terminal × 1
● Don’t connect EM series in the following ways:
①Back-up port should not be connected to grid;
②Back-up port should not be connected in parallel;
③The single PV panel string should not be connected to two or more inverters.
① ② ③
PV PV
Load
Back-Up On-Grid Back-Up Back-Up
PV input terminals
2
EzManage Instruction ×1
EzManage
Instruction

T
oB attery
To Battery communication cable
To EzMeter communication cable
House Grid
200mm 200mm
Both sides 200mm

Figure 4.1-3
Negative connector
Positive connector
Inverter
Special tools are used to stitching
MC4 series AMPHENOL series
Limit buckle can't
crimping the wire
63
The terminal can be connected to earth wire.

Note:
GW5048-EM
GW3648-EM
GW3048-EM
2300VA 25A/30mA
1
1.5
GW5048-EM
GW3648-EM
GW3048-EM
Installation instruction of WIELAND series please refer to Figure 4.3.3-1.
Figure 4.3.3-1
Single capacitive loadpower 0.7kVA,

BMS port is used for communication with lithium battery and can be used for both CAN and RS485 communication
protocol.
RS485 port is used for communication with expansion devices.
There are two pre-made cables connect to EM inverter, one cable is 3m which is marked "To Battery" should be connected
to Li-battery communication port, the other cable is 10m which marked "To EzMeter" should be connected to EzMeter.If
not use the battery communication and EM inverter is installed outside，please take out the "To Battery" cable by remove
the communication cover, then put the communication cover back and install the waterproof terminal.
The“To Meter”communication cable attached on inverter can be extended to max 100m, but for "to battery" cable, we do
not suggest any extension.
BMS
NC
GND-S
NC
CANL
485_B2
CANH
NC
485_A2
RS485
NC
NC
485_B1
485_A1
485_B1
NC
NC
Color
Orange/white
Orange
Green/white
Blue
Blue/white
Green
Brown/white
Brown
Lithium Battery
④④
To Battery
House Grid
House Grid
inverter's on grid part
485_A1

4.7 Wi-Fi Reset & Reload
Wi-Fi Reset & Reload only apply to WiFi connection problem, such as 'can't find the inverter WiFi signal' or 'WiFi configuration problem'.
Wi-Fi Reset means restarting the Wi-Fi module.
Wi-Fi Reload means making the Wi-Fi module to the default factory setting.
● press the touch switch, then LED Wi-Fi displays Once a second flicker, Wi-Fi reset is Short (about 1s)
successful. Refer to Figure 4.7-1.
●Long press(more than 3s) the touch switch, then Wi-Fi reload is successful.Refer to Figure 4.7-1.
4.8 DRED Connection
1.DRED connection is only available for Australia and New Zealand
2.Supported DRM command:DRM0,DRM1,DRM2,DRM3.DRM4,DRM5,DRM6,DRM7,DRM8
4.10 System Connection Diagram for Australia
Switch Board
Grid
Back-Up
Goodwe EM series
Hybrid Inverter L
N
Solar
array
48V
Battery
L
N
PE
RCD
RCD
L
Main
Switch
E-N
Link
Normal Loads
N
PE E
L
N
PE
Grid
Ezmeter
Back-Up
Loads
PE
N
RS-485
4.9 Earth Fault Alarm
7
4.8-1
13 14
NOTE：
6-pin terminal is used to make connection to DRED device. If DRED device is not available, please keep it
not connected.
Pull out the 6-pin terminal from the socket in the cabinet and take off the resistor which is fixed in it. Cable should be connected as
Figure4.8-1.
123456
4.11 Off-grid System Connection Diagram
Switch Board
Grid
Back-Up
Goodwe EM series
Hybrid Inverter L
N
Solar
array
48V
Battery
L
N
PE
RCD
L
EARTH
Back-Up
Loads
PE
N

EM Series inverter has no LCD screen, it can be controlled via the APP software
(EzManage). For iOS System, please go to AppStore to search for "EzManage", then
download and install it. For Android System, please go to google play to search for
"EzManage", then download and install it. Besides, it can be also installed by scanning
the QR code on the back cover of this manual .
When EM hybrid inverter is working, please use mobile devices to select the SSID of
inverter (Factory defaults is Solar - Wi-Fi, and initial password is 12345678. If any
questions, please refer to Wi-Fi Configuration). After accessing inverter's Wi-Fi network,
you can open the App then configure and monitor the EM system.
5 EzManage Illustration
4.12 Special Back-up Connection
If need maintainance on EM, then just switch SP3T to position 3 as shown above. Thus the loads will be supplied by grid (loads
supply will not be cut off).
Back-up On-grid
The PV Auto Test function of CEI is integrated in EzManage App. For the detailed operation of this function, please check
instructions on EzManage App.
6 CEI Auto Test/Power limit function Introduction
15 16
1
2
3
SP3T 1:Loads is supplied from back-up side
2:Loads is not powered
3:Loads is supplied from grid side
7 LED Lights Illustration
SYSTEM BACK-UP COM BATTERY GRID ENERGY Wi- FAULTFi
ON = SYSTEM IS READY
BLINK = SYSTEM IS STARTING UP
OFF = SYSTEM IS NOT OPERATING
ON = BACK-UP IS READY / POWER AVAILABLE
OFF = BACK-UP IS OFF / NO POWER AVAILABLE
ON = BATTERY IS CHARGING
BLINK 1 = BATTERY IS DISCHARGING
BLINK 2 = BATTERY IS LOW / SOC IS LOW
OFF = BATTERY IS DISCONNECTED / NOT ACTIVE
ON = GRID IS ACTIVE AND CONNECTED
BLINK = GRID IS ACTIVE BUT NOT CONNECTED
OFF = GRID IS NOT ACTIVE
ON = CONSUMING ENERGY FROM GRID / BUYING
BLINK 1 = SUPPLYING ENERGY TO GRID / ZEROING
BLINK 2 = SUPPLYING ENERGY TO GRID / SELLING
OFF = GRID NOT CONNECTED OR SYSTEM NOT OPERATING
ON = Wi-Fi CONNECTED / ACTIVE
BLINK 1 = Wi-Fi SYSTEM RESETTING
BLINK 2 = Wi-Fi ROUTER PROBLEM
BLINK 4 = Wi-Fi SERVER PROBLEM
OFF = Wi-Fi NOT ACTIVE
ON = FAULT HAS OCCURRED
BLINK = OVERLOAD OF BACK-UP OUTPUT / REDUCE LOAD
OFF = NO FAULT
SYSTEM
BACKUP-
COM
BATTERY
GRID
ENERGY
Wi-Fi
FAULT
INDICATOR EXPLANATION
STATUS
Green Blue Yellow RedGreen Blue Blue Yellow
ON=BMS AND METER COMMUNICATION OK
BLINK1= METER COMMUNICATION OK, BMS COMMUNICATION FAIL
BLINK2= BMS COMMUNICATION OK, METER COMMUNICATION FAIL
OFF= BMS AND METER COMMUNICATION FAIL
You can set Power limit function by EzManage APP. For the detailed operation of this function, please check
instructions on EzManage App.

8 Work Modes
EM series inverters have the following main work modes based on different conditions:
Mode1：
Energy produced by the PV system priority for local load,
excess energy is used to charge the battery, finally
remaining is delivered to the grid.
Mode2：
If there is no PV, battery energy is used for local load
first, the grid also can supply when the battery capacity
is not enough.
Mode3：
If the grid is fault or there is no grid, the system can still
work, PV and batteries supply energy for local load.
Mode4：
The battery can be charged by the grid, time and power
of battery charging can be set up flexibly.
9 Trouble shooting
Q/A and Trouble Shooting on EM
(+/-) not reversed
PLEASE CHECK THE FOLLOWING ITEMS AT THE FIRST INSTALLATION, MAKE SURE EVERYTHING IS FINE. OR PLEASE
STOP INVERTER SYSTEM TILL EVERY THING CONFIRMED FINE OR CONTACT GOODWE.
Checking Items Checking Description
Check items before EM
start-up
Battery connection Confirm the connection between EM
and battery : polarity ( +/-) not reversed
PV INPUT connection Confirm the connection between EM and PV panels : polarity(+ /-) n
ot reversed
AC OUTPUT Connection power Back-up to loads : polarity
Confirm ON-GRID connected to and
grid
(+/-)not reversed
EzMeter / CT connection Make sure EzMeter & CT connected between house loads and grid. and follow
the House→Grid direction sign on CT.
Checking items when start up system
CT & EzMeter
connection direction
BMS Communication
Checking details：
1. Check if the COM led on EzMeter triple blinking or not.
2. Or connect Solar-Wifi, check in EzManage App (“Parameters”) if
EzMeter COM state is “OK” or not.
If COM led does not blink, or show “NG” on App, then please check
the connection between EzMeter and EM, like:
1. RJ45 port broken or not;
2. communication cable looses or broken?
3. EzMeter should connect to EM RS485 port.
If everything is Ok, but problem still there, please contact GoodWe
after-sales services.
EzMeter
Communication
check
NOTE: do not need check if it is Lead-acid battery.
For lithium battery, please check following:
Connect Solar-Wifi, check on EzManage APP (Parameter >>> Battery) if
BMS status shows “BMS Communication OK” or not.
If APP BMS Status on APP says“BMS Communication Failure”, please
reboot EM. if problem is still there, please check further:
a. check on EzManage APP (Basic Setting) if Battery type is right what you
have or not, if not right, please set it right in “Basic Setting”
b. Connection between battery and EM is OK or not;
c. communication cable looses or broken?
d. RJ45 port/cables broken or not;
If everything is Ok, but problem still there, please contact GoodWe after-
sales services.
1. Turn off PV and open Loads, check if R-P led is solid or not.
If “R-P” not solid, please check
a. if CT or EzMeter connected in a wrong direction (the arrow on
EzMeter & CT should point to grid);
b. if connection between EzMeter and CT (port 1 and 4 on EzMeter) is
OK or not.
If both are OK but problem still there, please contact GoodWe after-sales
services.
17 18

Problems During Operation
Problems Solutions
Battery settings on APP
1. For Lithium battery:
connect Solar-Wifi, check on EzManage APP (Parameter >>>
Battery) if Battery Mode is right what you have or not, if not right,
please set it right in “Boost settings”
2. For lead-acid battery:
All the settings should comply with the parameter of the battery
(GoodWe do not suggest the settings for lead-acid batteries)
1. Make sure the voltage of battery is higher than 48V, otherwise
battery cannot start EM up.
If battery voltage is OK, but problem still there, please contact
GoodWe after-sales services.
EM not start up with ONLY
battery connected
EM not start up with ONLY
PV connected
1. Make sure the voltage of PV is higher than 125V;
If everything is OK, but problem still there, please contact GoodWe
after-sales services.
There is no discharge or
output from EM without PV
or PV Power lower than
Load Power
Check items:
1. Communication between EM and EzMeter is OK or not;
2. Make sure Meter power is higher than 150W?
a. EM/battery will not discharge continuously unless Meter Power is
higher than 150W;
b. If Meter Power is higher than 150W, but EM/Battery still not
discharge, then please check Ezmeter & CT connection and
direction;
1. Make sure SOC is higher than 1-DOD ;
Or if battery discharged to below 1-DOD, than battery will only
discharge again when SOC charged to 20%+(1-DOD)/2 and SOC
>105%-DOD(if need battery discharge immediately, customer can
restart the system)
2. Check on APP if it is set as charge time, during charge time,
battery will not discharge (battery will charge preferentially during
coincident time of charge/discharge)
If everything is OK, but problem still there, please contact GoodWe
after-sales services.
EM/Battery not charge when
PV＞P-load
Check items:
1. Check if charge voltage is properly set
2. Check if it is set as only charge time.
3. Check if battery is fully charged or not, or battery voltage reach
“charge voltage” or not.
If everything is OK, but problem still there, please contact GoodWe
after-sales services.
Big Power fluctuation on
Battery charge/discharge Check items
Q/A (Questions and Answers)
Big Power fluctuation on Battery
charge/discharge
Check items
1. Check if there is a fluctuation on load power;
2. Check if there is a fluctuation on PV power on GoodWe Portal.
If everything is OK, please contact GoodWe after-sales Services.
Check items:
1. Make sure BMS communication OK. if not, please try to restart
EM, and check the connection (for lithium battery);
2. Check if EzMeter & CT connected in the right position and to
right direction as on the user manual;
3. Check if total load power is much higher than PV power, or
check if Pgrid on GoodWe Portal is always below 0W.
If PV power is stable but problem still exist, please contact GoodWe
services.
1. Battery does not charge
About Out-Put Power Limit
Cannot see Solar-wifi signal
on mobile devices
Battery change between
Charge/discharge continually.
Check items:
1. Make sure battery settings are saved successfully;
2. Check if there is a fluctuation on PV power on GoodWe Portal
If PV power is stable but problem still exist, please contact GoodWe
services.
Questions Answers
“Battery Activate” unction
Only use battery when grid is
OFF
On Portal, SOC has a sudden
jump up to 95%?
1. Can set on APP the max out-put power to grid;
2. If Out-put Power Limit set as 0W, then there might still have max
100W to grid.
1. Open or close it on EzManage APP;
2. Used to activate battery when battery is discharged empty;
3. Only used when there is no battery charge.
1. On APP, Open off-grid output function and backup function;
2. Set charge time as 00:00-23:59, discharge time as default
1. Happened on Lead-acid battery or when BMS communication NG on
lithium battery;
2. if battery charge current keep lower than floating charge current set
on APP for 30mins, SOC will be reset to 95% compulsively;
Battery cannot charge to
100%
1. For LG battery, it will stop charge at SOC 95%. It is about LG battery,
normal.
2. Battery will also stop charge when battery voltage reaches charge
voltage set on EzManage APP.
1. Solar-wifi signal will disappear when EM connected to internet; if
need change settings, can connect to customers’ router to change.
2. If cannot see wifi signal when not connect to router, then please try
to reload wifi (refer to EM user Manual)
3. If still cannot find wifi signal, then restart EM(disconnect everything
including battery and PV/AC
If cannot find Solar-wifi after all these try, please contact GoodWe after-
sales services.
19 20

Cannot save settings on
EzManage APP
1. Make sure you connected solar-wifi (make sure no other devices
connected) or router (if connected Solar-wifi to router) and on home
page shows connection OK.
2. Make sure EM under waiting mode (on APP) before you change any
settings on EzManage APP ---- disconnect grid/load/battery, only leave
PV connected and then restart EM till see work mode as wait on APP.
If all these try does not help, please contact GoodWe services.
1. For lithium battery, please make sure BMS
communication OK;
2. Please check if battery voltage is lower than discharge voltage
set on APP
3. Make sure no short-cut on Battery connection side.
Battery switch trip
Lithium battery connection
Limitation on Backup Loads
NO-ALLOWED connection
For connection of Ezconverter/battery and EM, please refer to battery
connection SOP, chose right battery brand and fill in battery capacity
manually.
1. For Inductive Loads (like Air conditioner/wash machine/drill), the max
power for each load should be lower than1.5KAV , total power lower
than 2.5KVA
2. For Capacitive Loads, the total max power should be lower than 3KVA
1. Back-up side connected to grid; or backup side connect parallel;
2. Battery connected to grid;
3. One PV string connect to 2 or more PV inputs
Battery configuration
1. Lithium battery must connect BMS communication;
2. Nominal voltage for Lead-acid battery is 48V, max charge
voltage 60V;
3. For example, serial connection of 4*12V 100Ah lead-acid
battery, the capacity will still be 100Ah.
An error message will be displayed on the APP if a fault occurs.
Table 8-1 is the Description of Error Message
10 Error Messages
Table 8-1
Error message
Utility Loss
Fac Failure
PV Over Voltage
Over Temperature
Isolation Failure
Ground I Failure
Relay-Check Failure
DC Injection High
EEPROM R/W Failure
SPI Failure
DC Bus High
AC HCT Failure
GFCI Failure
Vac Failure
Battery Over Temperature
Battery Under Temperature
Battery Cell Voltage Differences
Battery Over Total Voltage
Battery Discharge Over Current
Battery Charge Over Current
Battery Under SOC
Battery Under Total Voltage
Battery Communication Fail
Battery Output Short
Description
Grid disconnected
Grid frequency no longer within permissible range
Overvoltage at DC input
Overtemperature on the case
Ground insulation impedance is too low
Overhigh ground leakage current
Relay self-checking failure
Overhigh DC injection
Memory chip failure
Internal communication failure
Overhigh BUS voltage
Output current sensor failure
Detection circuit of ground leakage current failure
Grid voltage no longer within permissible range
Battery Over Temperature
Battery Under Temperature
Li-Ion Battery Cell Voltage Differences
Li-Ion Battery Over Total Voltage
Battery Discharge Over Current
Battery Charge Over Current
Battery Capacity Low
Battery Under Total Voltage
Battery Communication Fail
Battery Output Short
Over Load Back-up Output Over Load

11 Technical Parameters
IEC62109-1&-2, IEC62040-1
EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4, EN61000-3-2, EN61000-3-3
17
347*432*145mm
Max Battery efficiency
Protection
Residual current monitoring unit
Anti-islanding protection
DC switch(PV)
AC over current protection
Insulation monitoring
Certifications&Standards
Grid regulation
Safety
EMC
General Data
Dimensions (W*H*D)
Weight (kg)
Mounting
Ambient temperature range
Relative humidity
Max. operating altitude
Protection degree
Cooling
Noise emision(dB)
Display
Communication
Integrated
Integrated
Integrated (optional)
Integrated
Integrated
Wall bracket
-25~60°C
0~95%
4000m（> 3000m derating）
IP65
Nature convection
<25
LED, APP
RS485;CAN;WiFi
Model
VDE-AR-N 4105, AS4777.2, VDE0126-1-1, G83/G59, CEI 0-21,G100
94.5%
Model
MC4/ Phoenix/ Amphenol(Optional)
GW3048-EM
3900
3000
100~500
125
11
1
1
48
50
50 (configurable)
>=50 (depending requirement)
3-stage adaptive with maintenance
60 (configurable)
included(Li-Ion)
integrated
integrated
GW3648-EM
4600
5500
11/11
2(can parallel)
2
Lead-acid or Li-Ion
50/60Hz; 230Vac
45~55Hz/55~65Hz; 180~270Vac
<3%
0.8 leading~0.8 lagging
Single phase
Solar
Max. allowed PV Power (W)
Nominal DC power (W)
Max. DC voltage (V)
MPPT voltage range (V)
Start feeding voltage (V)*
Max. DC current (A)
No. of DC connectors
No. of MPPTs
DC connector
Battery
Battery Type
Norminal Voltage (V)
Max Discharge Current (A)
Max Charge Current (A)**
Battery capacity (Ah)***
Charging curve
Max Charge voltage (V)
Battery temperature compensation
Battery voltage sense
Current shunt
AC Output Data (On-grid)
Norminal AC power(VA)
Max. AC power(VA)
Max. AC current(A)
Norminal AC output
AC output range
THDi
Power factor
Grid connection
GW5048-EM
6500
4000
550
3000 5000****
3680
3000 5000****
3680
13.6 22.8****
16
AC Output Data (Back-up)
AC output (Back-up)
Max. AC current(A) 10
230Vac ±2%, 50Hz (60Hz Optional)±0.2%, THDv<3%(linear load),Single phase
GW3048-EM GW3648-EM GW5048-EM
16
*: When there is no battery connected, Solar Start feeding voltage need more than 200V.
**: For lead-acid battery, default charge current is 0.15C, which is can be configurable up to 0.5C and cannot
exceed 50A.
For Li-Ion battery, charge current follows the command of BMS which doesn't exceed 50A.
***: Under off-grid mode,then battery capacity should be more than 100 Ah.
****: 4600VA for VDE-AR-N4105, 21.7A for Australia and New Zealand
***** : Can be reached only if PV power is enough.
DC overcurrent protection(A) 13.8 13.8/13.8
Battery overcurrent protection(A) 63
AC overcurrent protection(A) 20 25 32
Back-up overcurrent protection(A) 16
DC overvoltage category Category II
AC overvoltage category Category II
97.6%
>97%
Efficiency
Max. efficiency
Euro efficiency
Norminal AC power(VA) 2300
Peak power(VA)*****
MPPT adaptation efficiency 99.9%
3500, 10sec
23 24

12 Certificates
59
Note
Overvoltage category definition
Category I : applies to equipment connected to a circuit where measures have been taken to reduce transient overvoltage to a
low level.
Category II : applies to equipment not permanently connected to the installation. Examples are appliances, portable tools and
other plug-connected equipment;
Category III: applies to fixed equipment downstream of and including, the main distribution board. Examples are switchgear
and other equipment in an industrial installation;
Category IV: applies to equipment permanently connected at the origin of an installation (upstream of the main distribution
board). Example are electricity meters, primary overcurrent protection equipment and other equipment connected
directly to outdoor open lines.
Environment category definition
Outdoor : the ambient air temperature is -20~50°C, Relative humidity range is 4 % to 100 %, applied to PD3
Indoor unconditioned: the ambient air temperature is -20~50°C, Relative humidity range is 5 % to 95%,applied to PD3
Indoor conditioned: the ambient air temperature is 0~40°C, Relative humidity range is 5 % to 85%,applied to PD2
Pollution degree definition
Pollution degree 1: No pollution or only dry, non-conductive pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution occurs. Occasionally, however, a temporary conductivity caused by
condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or, dry, non-conductive pollution occurs which becomes conductive due to
condensation which is expected.
Pollution degree 4: Persistent conductive pollution occurs, for example, the pollution cause by conductive dust, rain and snow.
Moisture
parameters
Level
Temperature Range
Humidity Range
3K3
0~+40℃
5%~85%
4K2
-33~+40℃
15%~100%
4K4H
-20~ +55°C
4%~100%
Moisture location category definition
G100 IEC62109-1 IEC62109-2 CEI 0-21 VDE0126-1-1 VDE-AR-N 4105
25
