Safety introduction 1
Preparation before use 3
Safety precautions 4
Installation instructions
Installation diagram 5
Select the installation locations 6
Indoor unit installation 7
Outdoor unit installation 13
Air purging 12
Maintenance 15
Protection 16
Troubleshooting 17
Identification of parts 18
Indoor unit 18
Outdoor unit 18
Display introduction 19
Remote controller operating instructions. See" remote controller
instructions".
EN

-1-
1. To guarantee the unit work normally, please read the manual carefully before
installation, and try to install strictly according to this manual.
2. Do not let air enter the refrigeration system or discharge refrigerant when moving
the air conditioner.
3. Properly ground the air conditioner into the earth.
4. Check the connecting cables and pipes carefully, make sure they are correct and
firm before connecting the power of the air conditioner.
5. There must be an air-break switch.
6. After installing, the consumer must operate the air conditioner correctly
according to this manual, keep a suitable storage for maintenance and moving
of the air conditioner in thefuture.
7. Fuse of indoor unit: T3.15A 250VAC or T5A250VAC. Please refer to the screen
printing on the circuit board for the actual parameters, which must be consistent with
the parameters on the screen printing.
8. The installation instructions for appliances that are intended to be
permanently connected to fixed wiring and have a leakage current that may
exceed 10 mA, must state that the installation of a residual current device
(RCD) having a rated residual operating current not exceeding 30 mA is
advisable.
9. Warning: Risk of electric shock can cause injury or death: Disconnect all
remote electric power supplies before servicing.
10. The maximum length of the connecting pipe between the indoor unit and
outdoor unit should be less than 5 meters. It will affect the efficiency of the air
conditioner if the distance longer than that length.
11. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
12. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children must not play with the appliance. Cleaning and user
maintenance must not be made by children without supervision.
13. The batteries in remote controller must be recycled or disposed of
properly. Disposal of Scrap Batteries --- Please discard the batteries as sorted
municipal waste at the accessible collectionpoint.
14. If the appliance is fixed wiring, the appliance must be fitted with means
for disconnection from the supply mains having a contact separation in all
poles that provide full disconnection under over voltage category III
conditions, and these means must be incorporated in the fixed wiring in
accordance with the wiring rules. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
EN

-2-
15. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
16. The appliance must be installed in accordance with national wiring
regulations.
17. The air conditioner must be installed by professional or qualified persons.
18. The appliance must not be installed in the laundry.
19. Regarding to installation, please refer to section “Installation
instructions”.
20. Regarding to maintenance, please refer to section “Maintenance”.
EN

-3-
When charging refrigerant into the system, make sure to charge in liquid state, if
the refrigerant of the appliance is R410A. Otherwise, chemical composition of
refrigerant R410A inside the system may change and thus affect performance of
the air conditioner.
According to the character of refrigerant (R410A, the value of GWP is 2088),
the pressure of the tube is very high, so be sure to be careful when you install
and repair the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
The air conditioner must be installed by a professional engineer.
The temperature of refrigerant circuit will be high, please keep the
interconnectioncable away from the copper tube.
Before using the air conditioner, be sure to check and preset as the following.
Remote Controller presetting
Each time after the remote control is replaced with new batteries or is energized, remote control auto
presetting heat pump. If the air conditioner you purchased is a Cooling Only one, heat pump remote
controller can also be used.
Back-light function (optional)
Hold down any button of the remote controller for about 2 seconds, the back-light will be turned on.
It will be turned off automatically after about 10 seconds.
Auto Restart Presetting
The air conditioner has Auto-Restart function.
You can set or cancel this function when the air conditioner is running.
Hold down the emergency button (ON/OFF) for a few seconds, this function will be set if you
hear beep twice. If you just hear beep once, this function will be canceled.
This appliance is made of recyclable or re-usable material. Scrapping must be carried out in compliance with
local waste disposal regulations. Before scrapping it, make sure to cut off the mains cord so that the
appliance cannot be re-used.
For more detailed information on handling and recycling this product, contact your local authorities who
deal with the separate collection of rubbish or the shop where you bought the appliance.
SCRAPPING OF APPLIANCE
This appliance is marked according to the European Directive 2012/19/EC, Waste Electrical and
Electronic Equipment (WEEE).
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmentally safe recycling.
Note
Preset
EN

-4-
Symbols in this Use and Care Manual are interpreted as shown below.
Be sure not to do.
Pay attention to such a situation.
Grounding is essential.
Warning: Incorrect handling could
cause a serious hazard, such as death,
serious injury, etc.
Use correct power supply in
accordance with the rating plate
requirement. Otherwise, serious
faults or hazard may occur, or a
fire may break out.
Keep the power supply circuit
breaker or plug from dirt.
Connect the power supply cord
to it firmly and correctly, lest an
electric shock or a fire break out
due to insufficient contact.
Do not use the power supply
circuit breaker or pull off the plug
to turn it off during operation.
This may cause a fire due to
spark, etc.
It is harmful to your health ifthe cool
air reaches you for a long time. It is
advisable to let the airflow be
directed to the entire room.
Prevent the air flow from reaching
the gas burners andstove.
Do not touch the operation buttons
when your hands are wet.
Never insert a stick or similar obstacle
to the unit. Since the fan rotates at high
speed, this may cause an injury.
Do not repair the appliance by yourself.
If this is done incorrectly, it may cause
an electric shock, etc.
Do not put any objects on the outdoor
unit.
ON
OFF
SMART MODE
TEMP.
SUPER FAN SPE E D
TEMP.
FEEL SLEE P
It is the user's responsibility to
make the appliance be grounded
according to local codes or
ordinances by a licensed
technician.
CLOCK TIM ER ON TIMER OFF
QUIET DI MM ER ECON O MY
Turn off the appliance by remote
control first before cutting off
power supply if malfunction occurs.
Do not knit, pull or press the power
supply cord, lest the power supply cord
be broken. An electric shock or fire is
probably caused by a broken power
supply cord.
ON
OFF
ON
OFF
EN

-5-
Distance from wall
should be over 50mm
Distance from ceiling
should be over 200 mm
Distance from the obstacle
should be over 3000mm.
Distance from the wall
should be over 50mm
Distance from floor should be
over 2500mm.
Distance from the obstacle
should be over 500mm.
Air intake distance from
the wall should be
over 250mm
Air intake distance from the wall
should be over 250mm
Above figure is only a simple presentation
of the unit, it may not match the external
appearance of the unit you purchased.
Installation must be performed in accordance with
the national wiring standards by authorized personnel only.
over 250mm
Installation diagram
EN

-6-
Location for Installing Indoor Unit
Where there is no obstacle near the air outlet and air can be
easily blown to every corner.
Where piping and wall hole can be easily arranged.
Keep the required space from the unit to the ceiling and wall
according to the installation diagram on the previous page.
Where the air filter can be easily removed.
Keep the unit and remote controller 1m or more away from
television, radio etc.
Keep as far as possible from fluorescent lamps.
Do not put anything near the air inlet to obstruct it from air
absorption.
Install on a wall that is strong enough to bear the weight of the unit.
Install in a place that will not increase operation noise and vibration.
Keep away from direct sunlight and heating sources. Do not place
flammable materials or combustion apparatuses on top of the unit.
Location for Installing Outdoor Unit
Where it is convenient to install and well ventilated.
Avoid installing it where flammable gas could leak.
Keep the required distance from the wall.
The pipe length between indoor and outdoor unit should be not
more than 5 meters in factory default status, but it can go up to
maximum 15 meters with additional refrigerant charge.
Keep the outdoor unit away from greasy dirt,
vulcanization gas exit.
Avoid installing it by the roadside where there is a risk of
muddy water.
A fixed base where it is not subject to increased operation
noise.
Where there is not any blockage of the air outlet.
Avoid installing under direct sunlight, in an aisle or sideway,
or near heat sources and ventilation fans. Keep away from
flammable materials, thick oil fog, and wet or uneven places.
Model
Max. allowed pipe length
without additional
refrigerant (m)
Limit of pipe
length (m)
Limit of Elevation
Difference H (m)
Required amount of
additional refrigerant (g/m)
2kW~5,3kW
5
15
5
20
6kW~7,3kW
5
15
5
30
8,8kW~10kW
5
15
5
40
If the height or pipe length is out of the scope of the table, please consult the dealer.
EN

-7-
1. Installing the Mounting Plate
Decide an installing location for the mounting plate according to the indoor unit location and piping direction.
Keep the mounting plate horizontally with a horizontal ruler or dropping line.
Drill holes of 32mm in depth on the wall for fixing the plate.
Insert the plastic plugs to the hole, fix the mounting plate with tapping screws.
Inspect if the mounting plate is well fixed. Then drill a hole for piping.
Tapping screw
Mounting plate
Note: The shape of your mounting plate may be different from the one above, but the installation method is similar.
Note: As the above figure shows, the six holes matched with tapping screw on the mounting plate must be used to
fix the mounting plate, the others are prepared.
2. Drill a Hole for Piping
Decide the position of hole for piping according tothe
location of mounting plate.
Drill a hole on the wall. The hole should tilt alittle
downward toward outside.
Install a sleeve through the wall hole to keep the wall
tidy and clean.
3. Indoor Unit Piping Installation
Put the piping (liquid and gas pipe) and cables through the wall hole from outside or put them through
from inside after indoor piping and cables connection complete so as to connect to outdoor unit.
Decide whether to saw the unloading piece off in accordance with the piping direction (as shown below).
Piping direction
trough
Unloading
piece
1
Saw the unloading piece
off along the trough
4
3 Note: When installing the pipe at the directions
1,2 or 4, saw the corresponding unloading piece
2 off the indoor unit base.
After connecting piping as required, install the drain hose. Then connect the power cords. After connecting,
wrap the piping, cords and drain hose together with thermal insulation materials.
Indoor unit installation
EN

-8-
Piping Joints Thermal Insulation:
Wrap the piping joints with thermal
insulation materials and then wrap
with vinyl tape.
Piping Thermal Insulation:
a. Place the drain hose under thepiping.
b. Insulation material uses polythene foam over 6mm inthickness.
Note: Drain hose is prepared by user.
Drain pipe should point downward for easy drain flow.
Do not arrange the drain pipe twisted, sticking out or wave
around, do not immerse the end of it in water.
If an extension drain hose is connected to the drain pipe,make
sure to thermal insulated when passing along the indoorunit.
When the piping is directed to the right, piping, power
cord, and drain pipe should be thermal insulated and
fixed onto the back of the unit with a piping fixer.
Base
Piping fixer
Base
drain
hose
large
pipe
small
pipe
Piping fixer
Base
drain
hose
large
pipe
small
pipe
Hook here
A. Insert the pipe fixer to the slot. B. Press to hook the pipe fixer onto the base.
EN
Note: The unit of 5,3kW
#
,7kW
#
,10,5kW is bigger than the unit of 5,3kW
#
,7kW
#
,10,5kW

-9-
4. Connecting of the Cable
Indoor Unit
Connect the power connecting cord to the indoor unit
by connecting the wires to the terminals on the control
board individually in accordance with the outdoor unit
connection.
Note: For some models, it is necessary to remove the cabinet to
connect to indoor unit terminal.
Outdoor Unit
1). Remove the access door from the unit by loosening
the screw. Connect the wires to the terminals on the
control board individually as the following.
2). Secure the power connecting cord onto the control
board with cable clamp.
3). Reinstall the access door to the original position
with the screw.
4) Use a recognized circuit breaker for 7kW model or
above between the power source and the unit.
A disconnecting device to adequately disconnected all
supply lines must be fitted.
Caution:
1. Never fail to have an individual power circuit specifically for the air conditioner. As for the method of
wiring, refer to the circuit diagram posted on the inside of the access door.
2.Confirm that the cable thickness is as specified in the power source specification.
3.Check the wires and make sure that they are all tightly fastened after cableconnection.
4. Be sure to install an earth leakage circuit breaker in wet or moist area.
Cable Specifications
Capacity
(kW)
Power cord
Power connecting cord
Power connecting cord1
Main
power
supply
Type
Normal cross
-sectionalarea
Type
Normal cross
-sectionalarea
Type
Normal cross
-sectionalarea
1,5 ~ 3,8
H05VV-F
0.75~1.5mm
2
X3
H07RN-F
H05RN-F
1.5mm2X3
0.75~1.0mm2X3
H05RN-F
0.75mm2X2
(Heat-pump)
Toindoor
4,1 ~ 7
H05VV-F
1.5~2.5mm2X3
H07RN-F
1.5~2.5mm2X3
H05RN-F
0.75mm2X2
(Heat-pump)
Toindoor
5,3 ~ 8,8
H05VV-F
1.5~2.5mm2X3
H07RN-F
1.5~2.5mm2X4
H05RN-F
0.75mm2X2
(Heat-pump&Optional)
Toindoor
5,3 ~ 8,8
H07RN-F
2.5mm2X3
H05RN-F
H07RN-F
1.0mm2X3
1.0mm
2
X4Cooling only
H05RN-F
0.75mm2X3
(Heat-pump)
To outdoor
7 ~ 10,6
H07RN-F
2.5~4.0mm2X3
H05RN-F
H07RN-F
0.75mm
2
X4
1.0mm
2
X4
H05RN-F
0.75mm
2
X2
(Heat-pump&Optional)
To outdoor
7 ~ 10,6
H07RN-F
1.5mm2X5
H05RN-F
0.75mm2X4
H05RN-F
0.75mm2X2
(Heat-pump)
To outdoor
The cord may be different from the list above. It may be used as the next list. And it can be larger.
0-6A, use 0.75mm2 or 18AWG. 0-10A, use 1mm2 or 16AWG. 0-16A, use 1.5mm2 or 14AWG.
0-20A, use 2.5mm2 or 14AWG. 0-25A, use 2.5mm2 or 12AWG. 0-32A, use 4mm2.
Front
panel
Terminal
(inside)
Cabine
t
Indoor
unit
Chassi
s
Access door
Terminal(ins
ide)
Outdoor unit
Thefiguresinthismanualarebasedonthe
external viewofastandardmodel.
Consequently,theshape may differ from that of
theairconditioneryouhave selected.
EN

-10-
Wiring Diagram
Warning: Before obtaining access to terminals, all supply circuits must be disconnected.
Note: All the wires may be of different colors. The indicators ‘1L 2L 3L’ may be ‘4 5 6’ or others.
And the terminal may be different from the material object.
1,5kW~7kW Model
For above models, the power supply is connected from indoor unit.
For these models, the ground wire may be connected to the electric box directly.
5,3kW~8,8kW Model
For above models, the power supply is connected from indoor unit.
For these models, the ground wire may be connected to the electric box directly.
5,3kW~8,8kW Model
For these models, the power supply is connected from outdoor unit, with a circuit breaker.
EN

-11-
Warning: Before obtaining access to terminals, all supply circuits must be disconnected.
Note: All the wires may be of different colors. The indicators ‘1L 2L 3L’ may be ‘4 5 6’ or others.
And the terminal may be different from the material object.
7kW~10,6kW Model
For these models, the power supply is connected from outdoor unit, with a circuit breaker. All
the wires may be different colors.
Defrost cable (for heat-pump air conditioner only, and it`s an optional part)
After connection, the defrost wire should be well wrapped with a wrapping tape and the
connector should be put inside the unit.
Overheat protection or high-pressure protection cable (it`s an optional part)
After connection, the wire should be well wrapped with a wrapping tape and the connector
should be put inside the unit.
Ionizer (The ionizer is an optional part)
After connection, the ionizer will work automatically.
EN

-12-
1.Install Drain Port and Drain Hose (for heat-pump model only)
The condensate drains from the outdoor unit when the unit operates
in heating mode. In order not to disturb your neighbor and protect
the environment, install a drain port and a drain hose to direct the
condensate water. Just install the drain port and rubber washer to
the chassis of the outdoor unit, then connect a drain hose to the
port as the right figure shown.
2. Install and Fix Outdoor Unit
Fix with bolts and nuts tightly on a flat and strong floor.
If installed on the wall or roof, make sure to fix the supporter well to prevent it
from shaking due to serious vibration or strong wind.
3. Outdoor Unit Piping Connection
Remove the valve caps from the 2-way and 3-way valve.
Connect the pipes to the 2-way and 3-way valves separately according to the required torque.
4. Outdoor Unit Cable Connection (see previous page)
The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the
compressor. After connecting the indoor and outdoor units, release air and moisture from the refrigerant
cycle using a vacuum pump, as shown below.
Note: To protect the environment, be sure not to discharge the refrigerant to the air directly.
Outdoor unit installation
Air purging
Drain hose
(prepared by user)
Rubber pad (optional)
Place under the leg pedestal
EN

-13-
How to Purge Air Tubes:
(1). Unscrew and remove caps from 2 and 3-way valves.
(2). Unscrew and remove cap from service valve.
(3). Connect vacuum pump flexible hose to the service valve.
(4). Start vacuum pump for 10-15 minutes until reaching a vacuum of 10 mm Hg absolutes.
(5). With vacuum pump still running, close the low-pressure knob on vacuum pump manifold. Then
stop vacuum pump.
(6). Open 2-way valve 1/4 turn, then close it after 10 seconds. Check tightness of all joints using
liquid soap or an electronic leak detector.
(7). Turn 2 and 3-way valves stem to fully the valves. Disconnect vacuum pump flexible hose.
(8). Replace and tighten all valve caps.
EN

-14-
Dangerous!
Electric
shock!
Front panel maintenance
Cut off the power supply
Turn off the appliance
first before disconnecting
from power supply.
a
Grasp position "a" and
pull outward to remove the
front panel. a
Wipe with a soft
and dry cloth.
Use soft moisture cloth Use a dry and
to clean if the front panel soft cloth to
is very dirty; clean it.
Never use volatile substance
such as gasoline or polishing
powder to clean the appliance.
Never sprinkle water onto the
indoor
unit
Reinstall and shut the front panel.
Reinstall and shut the front panel by
pressing position "b" downward.
b b
Air filter maintenance
Stop the appliance, cut off the
power supply and remove the air
filter.
1
2
3
1.Open the front panel.
2.Press the handle of the filter gently
from the front.
3.Grasp the handle and slide out the filter.
Clean and reinstall the air filter.
If the dirt is conspicuous,
wash it with a solution of
detergent in lukewarm water.
After cleaning, dry well in
shade.
Close the front panel again.
Clean the air filter every two weeks
if the air conditioner operates in an
extremely dusty environment.
It is necessary to clean the air filter
after using it for about 100 hours.
EN

-15-
Operating condition
The protective device maybe trip and stop the appliance in the cases listed below.
*For Tropical (T3) Climate condition models, the temperature point is 55℃instead of 43℃.
The temperature of some products is allowed beyond the range. In specific situation, please consult the dealer.
If the air conditioner runs in COOLING or DRY mode with door or window opened for a long time when
relative humidity is above 80%, dew may drip down from the outlet.
Noise pollution
Install the air conditioner at a place that can bear its weight in order to operate more quietly.
Install the outdoor unit at a place where the air discharge and the operation noise would not annoy
your neighbors.
Do not place any obstacles in front of the air outlet of the outdoor unit lest it increases the noise level.
Features of protector
1. The protective device will work at following cases.
Restarting the unit at once after operation stops or changing mode during operation, you need to wait for
3 minutes.
Connect to power supply and turn on the unit at once, it may start 20 seconds later.
2. If all operation has stopped, press ON/OFF button again to restart. Timer should be set again if it has
been canceled.
Features of HEATING mode
Preheat
At the beginning of the HEATING operation, the airflow from the indoor unit is discharged 2-5 minutes later.
Defrost
In HEATING operation, the appliance will defrost (de-ice) automatically to raise efficiency.
This procedure usually lasts 2-10 minutes. During defrosting, fans stop operation.
After defrosting completes, it returns to HEATING mode automatically.
Note: Heating is NOT available for cooling only air conditioner models.
HEATING
Outdoor air temperature is over 24oC
Outdoor air temperature is below -7oC
Room temperature is over 27oC
COOLING
Outdoor air temperature is over *43oC
Room temperature is below 21oC
DRY
Room temperature is below 18oC
EN

-16-
The following cases may not always be a malfunction, please check it before asking for service.
Trouble
Does not run
Analysis
If the protector trip or fuse is blown.
Please wait for 3 minutes and start again,
protector device may be preventing unit to work.
.
If batteries in the remote controller exhausted.
If the plug is not properly plugged.
No cooling or
heating air
Is the air filter dirty?
Are the intakes and outlets of the air
conditioner blocked？
Is the temperature set properly？
Ineffective control
If strong interference (from excessive static
electricity discharge, power supply voltage
abnormality) presents, operation will be
abnormal. In such case, disconnect from
the power supply and connect back 2-3
seconds later.
Does not operate
immediately don't run
Changing mode during operation, 3 minutes
will delay.
Peculiar odor
This odor may come from another source
such as furniture, cigarette etc., which is
sucked in the unit and blows out with the air.
A sound of
flowing water
Caused by the flow of refrigerant in the
air conditioner, not a trouble.
Defrosting sound in heating mode.
Cracking sound is
heard
The sound may be generated by the expansion
or contraction of the front panel due to change
of temperature.
Spray mist from
the outlet
Mist appears when the room air becomes
very cold because of cool air discharged
from indoor unit during COOLING or DRY
operation mode.
The compressor indicator (red) lights on
constantly, and indoor fan stops.
The unit is shifting from heating mode to defrost.
The indicator will turn off within ten minutesand
return to heating mode.
EN

-17-
Identification of parts
Front Panel
Air Intake
Display Panel
Emergency Panel
Air Outlet
Vertical Adjustment
Louver
HorizontalAdjustment
Louver
Air Filter
Remote Controller
Air Intake
Pipes and Power
Connection Cord
Drain Hose
Note: Condensate water drains
at COOLING or DRY operation.
Air Outlet
Indoor unit
Outdoor unit
EN
The figures in this
manual are based on the
external view of a
standard model.
Consequently, the shape
may differ from that of
the air conditioner you
have selected.
