Gorenje BC637E13X Operating and maintenance manual

DETAILED
INSTRUCTIONS FOR
USE OF ELECTRIC
BUILT-IN COOKER
www.gorenje.comwww.gorenje.com
GB IE MT
517671_en.indd 1517671_en.indd 1 17. 10. 2020 09:31:4417. 10. 2020 09:31:44

We thank you for your
trust and the purchase of our
appliance.
This detailed instruction manual is
supplied to make the use of this
product easier. The instructions
should allow you to learn about your
new appliance as quickly as possible.
Make sure you have received an
undamaged appliance. If you do find
transport damage, please contact the
seller from which you purchased the
appliance, or the regional warehouse
from which it was supplied. The
telephone number can be found on
the invoice or on the delivery note.
Instructions for installation and
connection are supplied on a
separate sheet.
Instructions for use are also available
at our website:
www.gorenje.com / < http://www.
gorenje.com />
Important information
Tip, note
517671_en.indd 2517671_en.indd 2 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

3
517671
CONTENTS
INTRODUCTION
PREPARING THE
APPLIANCE FOR
THE FIRST USE
COOKING STEPS
MAINTENANCE
& CLEANING
TROUBLE-
SHOOTING
4 IMPORTANT SAFETY INSTRUCTIONS
5 Before connecting the appliance
6 ELECTRIC BUILT-IN COOKER
10 Control unit
12 Technical specifications
13 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
14 COOKING HOB
16 STEPS OF THE COOKING PROCESS (1–6)
16 Step 1: SWITCHING ON AND SETTINGS
17 Step 2: CHOOSING THE COOKING SYSTEM
19 Step 3: CHOOSING THE SETTINGS
22 Step 4: SELECTING ADDITIONAL FUNCTIONS/EXTRAS
24 Step 5: STARTING THE COOKING PROCESS
24 Step 6: SWITCHING OFF THE OVEN
25 DESCRIPTIONS OF SYSTEMS (COOKING MODES) AND COOKING
TABLES
41 MAINTENANCE & CLEANING
42 Cleaning the glass ceramic surface
44 Conventional oven cleaning
45 Using the aqua clean function to clean the oven
46 Removing and cleaning wire and telescopic extendible guides
47 Installing the catalytic inserts
48 Removing and inserting the oven door
51 Removing and inserting the oven door glass pane
52 Replacing the bulb
53 TROUBLESHOOTING TABLE
54 DISPOSAL
517671_en.indd 3517671_en.indd 3 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

4
517671
IMPORTANT SAFETY
INSTRUCTIONS
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM
FOR FUTURE REFERENCE.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept away
unless continuously supervised.
WARNING: Accessible parts may become hot during use. Young
children should be kept away.
During use the appliance becomes hot. Care should be taken to
avoid touching heating elements inside the oven.
Only use the temperature probe recommended for use in
this oven.
WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass/ the glass of hinged lids of the hob
(as appropriate), since they can scratch the surface, which may
result in shattering of the glass.
517671_en.indd 4517671_en.indd 4 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

5
517671
Do not use steam cleaners or high pressure cleaners to clean the
appliance as this may result in an electric shock.
Means for disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules.
The appliance must not be installed behind a decorative door in
order to avoid overheating.
The appliance is intended for household use.
Do not use it for any other purpose, such as
room heating, drying of pets or other animals,
paper, fabrics, herbs etc. As this may lead to
injury or fire hazard.
The appliance may only be connected to
the power mains by an authorized service
technician or expert. Tampering with the
appliance or nonprofessional repair thereof
may result in risk of severe injury or damage
to the product.
If the power cords of other appliances
located near this appliance are caught in the
oven door, they may be damaged, which may
in turn result in a short circuit. Therefore, keep
the power cords of other appliances at a safe
distance.
Do not line the oven walls with aluminium
foil and do not place baking trays or other
cookware on the oven bottom. Aluminium
foil would prevent air circulation in the oven,
hinder the cooking process, and ruin the
enamel coating.
Oven door become very hot duringoperation.
A third glass is installed for extra protection,
reducing the temperature of the outside
surface (only with some models).
Oven door hinges may be damaged when
under excessive load. Do not place heavy
pans on open oven door and do not lean
against open oven door when cleaning the
oven cavity. Never stand on the open oven
door and do not let children to sit on it.
Do not lift the appliance by holding it by the
door handle.
Appliance operation is safe with and without
tray guides.
Make sure the vents are never covered or
obstructed in any other way.
BEFORE CONNECTING THE APPLIANCE
Carefully read the instructions for use before connecting
theappliance. Repair or any warranty claim resulting from
incorrect connection or use of the appliance shall not be covered
by the warranty.
517671_en.indd 5517671_en.indd 5 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

6
ELECTRIC BUILT-IN COOKER
(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON
THE MODEL)
Door
Guides –
cooking
levels
4
3
2
1
Control unit
Door switch
Door handle
517671
The figure represents one of the built-in appliance models. Since the appliances for which
these instructions were drawn up may have different equipment, some functions or
equipment may be described in the manual that may not be present in your appliances.
PUSH-PULL KNOB
Slightly push the knob until it pops out; then, rotate it.
After each use, rotate the knob back to the "off" position and push it back in. The
push-pull knob can only be pushed back when the switch is in the "off" position.
517671_en.indd 6517671_en.indd 6 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

7
517671
CONTROL LIGHT
Yellow light
The yellow light is on whenever any appliance function is activated.
When a function is selected, the dial of the selected knob will be lit up. These appliances
do not have a yellow light (only with some models).
Oven lighting will be switched on automatically when the cooking system is selected.
WIRE GUIDES
The wire guides allow preparation of the food on four levels (please note that the levels/
guides are counted from the bottom up).
Guides 3 and 4 are intended for grilling.
TELESCOPIC PULL-OUT GUIDES
Telescopic pull-out guides may be fitted for the 2nd, 3rd, and 4th level.
Pull-out guides can be partly or fully extendible.
OVEN DOOR SWITCH
The switch deactivates oven heating and the fan when the oven door is opened during the
cooking process. When the door is closed, the switch turns the heaters back on.
COOLING FAN
The appliance is fitted with a cooling fan that cools the housing and the appliance control
panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues to operate for a short while in
order to cool the oven.
OVEN EQUIPMENT AND ACCESSORIES
GLASS BAKING DISH is used for cooking
with all oven systems. It can also be used as
a serving tray.
The GRID is used for grilling or as support
for a pan, baking tray or baking dish with
the food.
There is a safety latch on the grid.
Therefore, lift the grid slightly at the front
when pulling it out from the oven.
517671_en.indd 7517671_en.indd 7 17. 10. 2020 09:32:2317. 10. 2020 09:32:23

8
517671
The SHALLOW BAKING SHEET is used for
baking pastry and cakes.
The DEEP BAKING TRAY is used for roasting
meat and baking moist pastry. It can also be
used as a drip tray.
Never place the deep baking tray in the
first guide during the cooking process, except
when grilling food or using the roasting spit
and you are only using the deep tray as a drip
tray.
As baking accessories heat up, their
form may change. This does not affect
their functionality and their original form
will be restored when they cool down.
The grid or the tray should always be
inserted into the groove between the two
wire profiles.
With telescopic extendible guides, first pull
out the guides of one level and place the
grid or the baking tray onto them. Then,
push them in with your hand as far as they
will go.
Close the oven door when the
telescopic guides are retracted all the way
into the oven.
2
3
4
517671_en.indd 8517671_en.indd 8 17. 10. 2020 09:32:2417. 10. 2020 09:32:24

9
517671
CATALYTIC INSERTS prevent the spraying
fat from sticking to sides of the oven cavity.
The ROTISSERIE (meat skewer) is used
for roasting meat. The set consists of a
skewer support, skewer with screws, and a
removable handle.
The appliance and some of the accessible parts tend to heat up
during cooking. Use oven mitts.
517671_en.indd 9517671_en.indd 9 17. 10. 2020 09:32:2517. 10. 2020 09:32:25

10
CONTROL UNIT
(DEPENDING ON THE MODEL)
1COOKING ZONE
KNOB, REAR
LEFT 2COOKING
ZONE KNOB,
FRONT LEFT 4COOKING
SYSTEM
SELECTOR KNOB
3LIGHT – The
light is on
whenever any
appliance function
is activated.
5a CHILD LOCK
KEY
5bVALUE DEC-
REASE KEY
5c CLOCK
AND TIMER
SELECTOR KEY
NOTE:
Symbols of cooking systems may be located on the knob or on the front panel
(depending on the appliance model).
517671
517671_en.indd 10517671_en.indd 10 17. 10. 2020 09:32:2617. 10. 2020 09:32:26

11
6TEMPERATURE
KNOB 7COOKING ZONE KNOB, FRONT
RIGHT 8COOKING ZONE
KNOB, REAR
RIGHT
5eSTART/STOP
KEY
5d VALUE INC-
REASE KEY
NOTE:
The keys will respond better if you touch them with a larger area of your fingertip. Each
time you press a key, a short acoustic signal will be sounded.
517671
517671_en.indd 11517671_en.indd 11 17. 10. 2020 09:32:2617. 10. 2020 09:32:26

12
517671
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
3.5 kW
xxxxxx
SER. Nr: XXXXXX
ART. Nr:
max
TN XXXXX
Pn :
TYPE:
XXXXXX
220-240V ~
220V-240V, 50/60Hz
The rating plate indicating the basic
information about the appliance is located
at the edge of the oven and it is visible
when the oven door is opened.
517671_en.indd 12517671_en.indd 12 17. 10. 2020 09:32:2617. 10. 2020 09:32:26

13
517671
BEFORE USING THE APPLIANCE
FOR THE FIRST TIME
If your hob has a glass ceramic surface, clean it with a damp cloth and some washing-
up liquid. Do not use aggressive cleaners, such as abrasive cleaners that could cause
scratches, abrasive dishwashing sponges, or stain removers.
Upon receiving the appliance, remove all parts, including any transport equipment, from
the oven.
Clean all accessories and utensils with warm water and regular detergent. Do not use any
abrasive cleaners.
When the oven heats up for the first time, the characteristic smell of a new appliance will
be emitted. Ventilate the room thoroughly during the first operation.
517671_en.indd 13517671_en.indd 13 17. 10. 2020 09:32:2617. 10. 2020 09:32:26

14
517671
COOKING HOB
GLASS CERAMIC COOKING SURFACE
- The heating zone will quickly reach the set power or temperature, while the area around
the hot cooking zones will remain cook.
- The hob is resistant to temperature changes.
- The hob is also impact-resistant. Even if the cookware is placed onto the hob roughly,
the hob will not be damaged.
- Using the glass ceramic hob as a storage area may result in scratches or other damage
to it.
- Do not use aluminium or plastic cookware on hot cooking zones. Do not place any
plastic objects or aluminium foil on the glass ceramic hob.
- Do not use the glass ceramic hob if it is cracked or broken. If a sharp object falls on
the hob, the hob may break. The consequences of such occurrence may be visible
immediately or only after a while. If any visible crack appears in the hob, immediately
cut o the power supply to the appliance.
CONTROL OF THE TWO-RING COOKING
ZONE:
The area of the two-ring cooking zone
can adapt to the size and the form of your
cookware.
To activate the larger heating zone, rotate
the cooking zone knob as far as it will go
(a click will be heard), then set the desired
power level.
RESIDUAL HEAT INDICATOR
Every cooking zone has a signal light that
lights up when the cooking zone is hot.
When the cooking zone cools down, the
signal light goes out. The residual heat
indicator may also light up if a hot pot or
pan is placed on a cool cooking zone.
517671_en.indd 14517671_en.indd 14 17. 10. 2020 09:32:2617. 10. 2020 09:32:26

15
517671
- Use quality cookware with flat and stable
bottom.
- Pan bottom and cooking zone diameters
should be the same.
- Tempered glass cookware with special
ground bottom may be used on the
cooking zones if its diameter fits that
of the cooking zones. Cookware with
larger diameter may crack due to thermal
tension.
- Make sure the pot or pan is in the middle
of the cooking zone.
- When using a pressure cooker, keep an eye on it until the right pressure is reached.
First, set the cooking zone to maximum power; then, following the pressure cooker
manufacturer's instructions, use the relevant sensor to decrease the cooking power at
the right time.
- Make sure there is enough liquid in the pressure cooker, or any other pot or pan. Due to
overheating, using an empty pot on the cooking zone may result in damage to both the
pot and the cooking zone.
- When using special cookware, observe the manufacturer's instructions.
ENERGY SAVING TIPS
- Diameter of the pot and pan bottoms should match the diameter of the cooking zone. If
the pot or pan is too small, a part of the heat will be lost, and the cooking zone may be
damaged.
- If the cooking process allows, use a lid.
- Cookware should be suitably sized given the amount of food. When you cook a small
amount of food in a large pot or pan, more energy is lost.
- If a dish takes a long time to cook, use a pressure cooker.
- Vegetables, potatoes etc. may be cooked in a smaller amount of water. The food will
cook just as well, as long as the pot is tightly closed with a lid. After bringing the water
to a boil, reduce the heat to a level that just suces to maintain a slow simmer.
TIPS REGARDING YOUR COOKWARE
517671_en.indd 15517671_en.indd 15 17. 10. 2020 09:32:2717. 10. 2020 09:32:27

16
1Set the clock by touching the and keys, and confirm the setting by
touching the key.
If you press and hold the value
adjustment key, the rate at which the set
value is being changed will increase.
CHANGING THE CLOCK SETTING
Clock settings may be changed when no timer function is activated. To set the current
time (clock), touch the CLOCK key several times to select the symbol.
517671
STEPS OF THE COOKING
PROCESS (1–6)
STEP 1: SWITCHING ON AND SETTINGS
After connecting your appliance or after an extended power outage, 12:00 will flash on
the display and the symbol will light up .
Set the time of day.
SETTING THE CLOCK
517671_en.indd 16517671_en.indd 16 17. 10. 2020 09:32:2717. 10. 2020 09:32:27

17
SYSTEM DESCRIPTION SUGGESTED
TEMPERATURE °C
COOKING SYSTEMS
RAPID PREHEAT
Use this function if you wish to heat the oven to the desired
temperature as quickly as possible. This function is not
appropriate for cooking food. When the oven heats up to the
desired temperature, the heating process is completed.
160
UPPER AND BOTTOM HEATER
The heaters in the bottom and in the ceiling of the oven
cavity will radiate heat evenly into the oven interior. Pastry or
meat can only be baked/roasted at a single height level.
200
TOP HEATER
Only the heater on the oven cavity ceiling will radiate heat
onto the food. Use it to brown the upper side of your dish
(final browning).
180
BOTTOM HEATER
Only the heater on the bottom of the oven cavity will radiate
heat. Use this heater to brown the lower side of the dish.
180
GRILL
Only grill heater, a part of the large grill set, will operate.
This system is used for grilling a smaller amount of open
sandwiches or beer sausages, and for toasting bread.
220
LARGE GRILL
The upper heater and the grill heater will operate. The heat
is radiated directly by the grill heater installed in the oven
ceiling. To boost the heating effect, the upper heater is
activated as well.
This combination is used for grilling a smaller amount of
open sandwiches, meat or beer sausages, and for toasting
bread.
220
GRILL WITH FAN
Grill heater and the fan will operate. This combination is used
to grill meat and to roast larger chunks of meat or poultry at
a single height level. It is also appropriate for dishes au gratin
and for browning to a crispy crust.
170
TOP HEATER AND FAN
The top (upper) heater and the fan will operate. Use this
system to roast larger chunks of meat and poultry. It is also
suitable for dishes au gratin.
170
Rotate the knob (left and right) to select the cooking system (see
program table, depending on the model).
Settings can also be changed during the cooking process.
517671
STEP 2: CHOOSING THE COOKING SYSTEM
517671_en.indd 17517671_en.indd 17 17. 10. 2020 09:32:2817. 10. 2020 09:32:28

18
517671
SYSTEM DESCRIPTION SUGGESTED
TEMPERATURE °C
HOT AIR AND BOTTOM HEATER
The bottom heater, the round heater, and the hot air fan
will operate. This is used to bake pizza, moist pastry,
fruitcakes, leavened dough and shortcrust on several levels
simultaneously.
200
HOT AIR
Round heater and the fan will operate. The fan installed
in the back wall of the oven cavity makes sure the hot air
constantly circulates around the roast or pastry. This mode
is used for roasting meat and baking pastry at several levels
simultaneously.
180
BOTTOM HEATER AND FAN
This is used for baking leavened but low-rising pastry and for
preserving fruit and vegetables.
180
TOP AND BOTTOM HEATER WITH FAN
Both heaters and the fan are activated. The fan allows even
circulation of hot air inside the oven. It is used for baking
pastry, for defrosting, and for drying fruit and vegetables.
180
PLATE WARMER
Use this function to reheat your dinnerware (plates, cups)
before serving food in it to keep the food warm longer.
60
GENTLEBAKE 1)
This feature allows gentle, slow, and even baking that leaves
the food soft and juicy. It is suitable for roasting meat,
cooking fish, and baking pastry on a single rack.
Set the temperature in the range from 140 to 220°C.
180
DEFROSTING
The air circulates with no heaters activated. Only the fan will
be activated. This is used to slowly thaw frozen food.
-
AQUA CLEAN
Only the bottom heater will radiate heat. Use this function to
remove stains and food residues from the oven. The program
takes 30 minutes.
70
1) It is used for determining the energy efficiency class pursuant to the EN 60350-1
standard.
In this mode, the actual temperature in the oven is not displayed due to a special
appliance operation algorithm and use of residual heat.
517671_en.indd 18517671_en.indd 18 17. 10. 2020 09:32:2917. 10. 2020 09:32:29

19
Rotate the knob to set the desired
TEMPERATURE.
When using the oven system with the
large grill and grill, set the temperature
knob to position .
After switching on the appliance by touching the START key, the temperature icon is
displayed on the display unit.
To switch on the appliance, press the START key and hold it for a while – about 1
second.
517671
STEP 3: CHOOSING THE SETTINGS
ADJUSTING THE COOKING TEMPERATURE
517671_en.indd 19517671_en.indd 19 17. 10. 2020 09:32:3117. 10. 2020 09:32:31

20
Setting the cooking time
In this mode, you can define the duration of oven operation
(cooking time). Set the desired cooking time. First set the minutes,
then the hours. Icon and cooking time are displayed on the display
unit.
Setting the delayed start
In this mode, you may specify the duration of the cooking process
(cooking time) and the time when you wish the cooking process to
stop (end time). Make sure the clock is accurately set to current time.
Example:
Current time: noon
Cooking time: 2 hours
End of cooking: 6 pm
First set the OPERATION DURATION (2 hours). Touch the CLOCK
button twice to select the END OF OPERATION. The display
automatically shows a flashing sum of the time of day and duration of
operation of the oven (14:00).
Set the time for the end of baking (18:00)
Press START to start the cooking process. The timer will wait for the
time to start the cooking process and the symbol will be lit up. The
oven automatically switches on (at 4 pm) and stops operating and the
selected time (at 6 pm).
Timer function display
517671
TIMER FUNCTIONS
First rotate the COOKING SYSTEM SELECTOR KNOB; then, set the temperature.
Touch the TIMER key several times to select the desired timer function.
The icon for the selected timer function will light up and the adjustable cooking start/end
time will flash on the display.
Press START to start the cooking process. ELAPSED COOKING TIME will be displayed.
517671_en.indd 20517671_en.indd 20 17. 10. 2020 09:32:3217. 10. 2020 09:32:32
