Gorenje Classico BO73CLI User manual

Instructions for Use
GB IE MT

425514
We sincerely thank you for your purchase. We
believe you will soon find ample evidence that
you can really rely on our products. To make the
use of the appliance easier, we attach these
comprehensive instruction manual.
The instructions should aid you in getting familiar with
your new appliance. Please, read them carefully before
using the appliance for the first time.
In any case, please make sure the appliance was supplied
to you undamaged. Should you identify and transport
damage, contact your sales representative or the regional
warehouse from where the product was delivered. You
will find the telephone number on the receipt or delivery
report. We wish you a lot of pleasure with your new
household appliance.
The connection should be carried out in compliance
with the instructions in the section “Connection to the
power mains”, and the relevant eective regulations and
standards. This should only be performed by a qualified
technician.
The rating plate indicating the basic information on the
appliance is attached to the edge of the oven and it is
visible when you open the oven door.
Instructions for
connection
Rating plate
Dear customer!
3
ELECTRIC OVEN

425514
IMPORTANT - READ BEFORE USING THE APPLIANCE..........................................5
Safety percautions........................................................................................................................5
Warnings............................................................................................................................................6
Appliance purpose .......................................................................................................................6
APPLIANCE DESCRIPTION ............................................................................................7
Cooling fan .......................................................................................................................................8
Control lamps..................................................................................................................................8
Program timer.................................................................................................................................8
THE OVEN ......................................................................................................................... 9
Before using the oven for the first time.............................................................................9
Important warnings......................................................................................................................9
Electronic program timer........................................................................................................ 10
Setting the time of day ............................................................................................................ 10
Oven operation without timer settings............................................................................10
Oven operation with program timer settings .................................................................11
Setting the minute minder.......................................................................................................12
Displaying the setting................................................................................................................12
Deleting a setting.........................................................................................................................12
Operating the oven .................................................................................................................... 13
The oven may be operated in the following modes .................................................. 14
Shelf levels (depending on the model) ............................................................................ 16
Telescopic pull-out guides (depending on the model) .............................................17
Oven accessories (depending on the model)................................................................17
FOOD PREPARATION.................................................................................................... 18
Baking pastry ................................................................................................................................ 18
Cooking / roasting meat......................................................................................................... 23
Grilling and browning............................................................................................................... 25
Preservation .................................................................................................................................. 28
Defrosting ...................................................................................................................................... 29
CLEANING AND MAINTENANCE...............................................................................30
Cleaning ........................................................................................................................................... 31
Maintenance (depending on the model)........................................................................ 32
Replacing appliance parts .....................................................................................................34
SPECIAL WARNINGS AND ERROR REPORTING ................................................... 36
Important ....................................................................................................................................... 36
INSTRUCTIONS FOR INSTALLATION AND ............................................................. 38
CONNECTION................................................................................................................. 38
Important warnings................................................................................................................... 38
Installation...................................................................................................................................... 38
Electrical connection................................................................................................................ 39
TECHNICAL CHARACTERISTICS ................................................................................ 41
Rating plate.................................................................................................................................... 41
4
TABLE

425514
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
metal capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age shall
be kept away unless continuously supervised.
• WARNING: Danger of fire: do not store items on the
cooking surfaces.
• Only use the temperature probe recommended for this
oven.
• WARNING: Ensure that the appliance is switched o
before replacing lamp to avoid the possibility of electric
shock.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
• Do not use steam cleaners or high-pressure cleaners to
clean the cooking hob, as this may result in an electric
shock.
• The appliance is not intended to be controlled by external
timers or special control systems.
5
IMPORTANT - READ BEFORE USING THE
APPLIANCE
Safety percautions

425514
• The appliance may only be connected to the power mains by an authorized service
technician or expert.
• Tampering with the appliance or non-professional repair thereof may result in risk of severe
injury or damage to the product. Any repairs may only be carried out by an authorized
service technician or expert.
• If the power cords of appliances located near this appliance are caught in the oven door,
they can be damaged, which may in turn result in a short circuit. Therefore, keep the power
cords of other appliances at a safe distance.
• The appliance is intended solely for cooking. Do not use it for any other purpose, e.g. for
room heating. Do not place empty cookware on the cooking zones.
• Be particularly careful when cooking food in the oven. Due to high temperatures, baking
trays, baking sheets, the grid and the oven interior walls become very hot. Always use oven
mitts.
• Do not line the oven walls with aluminium foil and do not place baking trays or other
cookware on the oven bottom. Aluminium foil would prevent air circulation in the oven,
hinder the cooking process, and ruin the enamel coating.
• Appliance operation is safe with and without tray guides.
• Oven door become very hot during operation. A third glass is installed or additional
protection to reduce the temperature of the outside surface (only with some models).
• Oven door hinges may be damaged if overloaded. Do not place heavy cookware on the
open oven door and do not lean against the door while cleaning the oven. Before cleaning
the oven, remove the oven door (see chapter »Removing and re-installing the oven door«).
Do not stand or sit on the open oven door (children!).
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be
caused by inappropriate waste handling of thisproduct. For more detailed information
about recycling of this product, please contact your local city oce, your household
waste disposal service or the shop where you purchased the product.
The appliance is intended for conventional preparation of
food in households and should not be used for any other
purpose. Individual options of use are comprehensively
described in this instruction manual.
Appliance purpose
6
Warnings

425514
The figure represents one of the appliance models.
Since a group of appliances to which these instructions
apply, have dierent features, the instruction manual
may describe functions and equipment that may not be
available in your appliance.
1. Control panel
2. Oven door handle
3. Oven door
1On/O knob and oven operation mode
selection knob
2Program timer (only with some models)
3Temperature selection knob / dial
4Oven control light. This light it lit while
the oven is heating up; when the set
temperature is reached, it goes o (only
featured in some models)
7
APPLIANCE DESCRIPTION

425514
(only with some models)
The appliance features a built-in cooling fan which cools
the appliance housing and control panel.
Red lamp
The red lamp is lit when heaters in the oven are operating;
when the selected temperature is reached, the lamp goes
o.
Backlit knob dials
(only with some models)
The dial of an activated knob is lit when a function is
selected. Appliances with this feature do not have the
yellow control lamp.
Setting the time of day is requisite for the use of the
appliance. Oven operation is only possible once the time
of day has been set.
Cooling fan
Control lamps
Program timer
8

425514
• Remove all accessories from the oven and clean them with
warm water and a conventional detergent. Do not use
abrasive cleaning aids.
• When the oven is heated up for the first time, a specific
odor of a “new appliance” will be discharged; therefore,
ventilate the room thoroughly while the oven heats up.
• Use dark, black silicon coated or enamel coated baking
trays, as these transmit the heat particularly well.
• Only preheat the oven if specifically stated in the recipe or
in the instruction tables herein.
• Heating up an empty oven uses a lot of energy; therefore,
a lot of power is saved if several types of pastry are cooked
consecutively, as the oven is already heated up.
• Approximately ten minutes before the anticipated end
of the cooking process, the oven may be turned o.
This way, you will save some power and make use of the
accumulated heat.
• Note: When cooking is completed, the cooling fan will
stop operating. If you leave the dish in the oven, steam
could evaporate from it and condense on the front panel
and the oven door. In order to prevent condensation, set
the program selector switch to the »light« position. Thus,
the cooling fan will continue to operate and cool the oven,
preventing the accumulation of condensate.
Before using the oven
for the first time
Important warnings
9
THE OVEN

425514
• Select the time settings by consecutively pressing the
(A) knob. Selected symbol will flash on the display.
Rotate the (A) knob to set the function and press to
confirm. Clock hands will automatically move to time
display. The set symbols will remain lit.
• Each time you press the (A) knob, this will be confirmed
by a short acoustic signal.
• Press and hold the (A) knob for 2 seconds to delete the
set function.
• If the time display symbol (4) is flashing (after
connecting the appliance for the first time or following
a power failure), press the (A) knob and hold it for two
seconds until the flashing stops.
• Then select the time display (4) by consecutively
pressing the (A) knob. Time display will flash when
selected.
• Rotate the (A) knob to set the time.
• Confirm the setting by pressing the (A) knob again.
If nothing is pressed, the setting will be stored
automatically after a few seconds.
• After connecting the appliance to the power mains for
the first time or after a power supply failure, time display
symbol (4) will flash.
Setting the time of day
Oven operation without
timer settings
AFunction selection knob
1Oven delayed start
2End oven operation
3Minute minder
4Time display
5Clock
10
ELECTRONIC
PROGRAM TIMER

425514
• In order for the oven to operate, press the (A) knob and
hold it for two seconds. Time display will stop flashing.
• The oven can be used without restrictions if no timer
settings are made.
Program timer can be used to program oven operation in
two ways:
• Setting the stop time - the oven will stop operating at
the preset time.
• Setting delayed start - the oven will automatically start
and stop operating at a preset time.
Setting the stop time
This mode allows you to set the time at which you wish
the oven to stop operating. The longest possible setting is
15 hours from the current time.
• Check if the clock is set accurately to current time.
• Select the (2) symbol by consecutively pressing the (A)
knob until the symbol starts to flash.
• Rotate the (A) knob to set stop time.
• Confirm the setting by pressing the (A) knob again.
Clock hands will move to time display. The oven stop
symbol will light up.
• Switch on the oven (use the oven knobs to set the
operating mode and temperature). The oven will start t
operate at the set time and stop and the selected stop
time.
• When the clock reaches the selected stop time, the
oven will be switched o, which will also be indicated by
an intermittent acoustic signal. The acoustic signal can
be switched o by pressing the (A) knob; otherwise, it
will switch o automatically after 1 minute. The symbol
(2) will flash. To continue cooking, press the (A) knob
and hold it for 2 seconds, and set a new cooking time if
necessary.
Setting the delayed start
This mode allows you to specify the time when the oven
should start to operate (cooking start time) and the time
when you wish the cooking process to stop (end time).
Stop time may be delayed by a maximum of 12 hours
relative to the current time of day; cooking duration may
be set to a maximum of 3 hours.
• Check if the clock is set accurately to current time.
• Setting the start time: Select the (1) symbol by pressing
the (A) knob. Rotate the (A) knob to set the start time
Oven operation with
program timer settings
11

425514
and confirm it by pressing the (A) knob. The symbol for
the end of operation will start to flash (2).
• Set the stop time: Rotate the (A) knob to set the stop
time and confirm it by pressing the (A) knob.
• The clock hands will turn to clock display. Symbols (1)
and (2) will be lit up.
• The timer will wait for the start of the cooking process.
• Set the oven – use the oven knobs to set the operating
mode and temperature.
• The oven will start to operate at the start time, and stop
operating at the stop time.
• When the clock reaches the selected stop time, the
oven will be switched o, which will also be indicated by
an intermittent acoustic signal. The acoustic signal can
be switched o by pressing the (A) knob; otherwise, it
will switch o automatically after 1 minute. The symbol
(2) will flash. To continue cooking, press the (A) knob
and hold it for 2 seconds, and set a new cooking time if
necessary.
The clock can also be used as a minute minder which will
sound an alarm upon expiry of a set amount of time.
The minute minder can only be selected when the
program timer is not programmed or in use.
• Select the (3) symbol by consecutively pressing the (A)
knob until the symbol starts to flash.
• Rotate the (A) knob to set the time when you wish the
minute minder to sound the alarm. The longest possible
setting is 3 hours.
• Confirm the setting by pressing the (A) knob again.
Clock hands will automatically turn to lock display and
the symbol (3) will be lit up.
• When the time you set runs out, an intermittent acoustic
signal will be sounded. The acoustic signal can be
switched o by pressing the (A) knob and holding it
for 2 seconds; otherwise, it will switch o automatically
after 1 minute.
Whenever a timer function is set, you may check it by
pressing the (A) knob. The clock hands will briefly move to
the set value and then return to display the current time.
Delete the setting by pressing the (A) knob and holding it
for 2 seconds. The symbol of the deleted function will be
switched o.
Setting the minute
minder
Displaying the setting
Deleting a setting
12

425514
On/o and operation mode knob.
Note: When using the operation mode Large grill
or Grill , set the temperature selection knob to the
position indicated , as appropriate for these two
operation modes.
The oven is operated by the on/o and operation mode
selection knob and the temperature setting knob / dial.
Operating the oven
13

425514
Oven lighting
With some models, there are two interior lighting lamps:
one on the upper part of the back wall, and the other,
additional lamp on middle of the right side wall. Oven
lighting can be selected independently, without selecting
another function. With all other modes of operation,
the oven lighting is turned on automatically when the
operation mode is selected.
Upper / lower heater
The heaters on the upper and lower side of the oven
radiate heat uniformly and evenly into the oven interior.
Pastry and meat can be cooked on one shelf level only.
Large grill
With this operation mode, the upper heater and the infra
heater are activated simultaneously. The infra heater
installed on the oven interior ceiling radiates heat directly.
To boost the heating eect or to make optimal use of
the entire area of the oven grid, the upper heater is also
activated. This operation mode is appropriate for cooking
smaller chunks of meat, such as steaks, roasts, chops, ribs,
etc.
Grill
Only the infra heater is activated (which also operates,
along with the upper heater, in the Large grill mode).
This mode is appropriate for grilling smaller quantities of
toasted sandwiches, grill sausages, or simply for toasting
bread.
Grill & fan
With this operation mode, the infra heater and the fan are
activated simultaneously. It is appropriate for grilling meat
and large chunks of meat or poultry on one shelf level.
Also appropriate for cooking food au gratin or browning.
The oven may be
operated in the
following modes
14

425514
Hot air and lower heater
With this operation mode, the lower heater and the hot air
fan operate simultaneously. This is particularly convenient
for making pizza. Also ideal for moist or heavy pastry,
fruit cakes made of leavened dough, short pastry, or
cheesecakes.
Hot air
With this operation mode, the round heater and the fan
operate simultaneously. The fan at the oven back wall
causes the hot air to circulate constantly around a roast
of pastry. This operation mode is appropriate for roasting
meat and making pastry on several shelves simultaneously.
Cooking temperature should be set lower than with
conventional operation modes.
Defrosting
With this mode, the air is circulating without any heater
being turned on. Only the fan is in operation. This is used
for slow defrosting or thawing of frozen food.
Lower heater and fan
With this operation mode, the lower heater and the fan
operate simultaneously. Used for baking low leavened
dough and preserving fruit and vegetables. Use the first
shelf position from the bottom and shallow rather than
deep baking trays to allow the warm air circulate around
the upper side of the dish as well.
Upper and lower heater plus the fan
The upper and the lower heater operate simultaneously. The
fan enables uniform circulation of hot air in the oven. The
system is suitable for making all kinds of pastry, for defrosting
food, and drying fruit and vegetables. Before placing food
into the preheated oven, wait for the signal lamp (heater
operation lamp) to go o for the first time. For best results,
cook on a single shelf level only; with cooking on two levels
simultaneously, the results are somewhat inferior. The oven
must be preheated. Use the second and fourth shelf level
(from the bottom). The temperature should be set lower than
with conventional heating combinations.
15

425514
Lower heater / Aqua Clean
The heat is only radiated by the heater installed in the
bottom of the oven. Select this operation mode when
you wish to bake / cook the bottom side of the dish more
thoroughly (e.g. for moist pastry with fruit filling). Set
the temperature with the temperature selection knob /
dial. The lower heater can be used for cleaning the oven.
Details are given in the “Cleaning and maintenance”
section.
• Accessories (grid, shallow and deep baking tray) can be
inserted into the oven at four levels.
• Please note that the shelf levels are always referred
to by consecutive numbers starting from the bottom
(particular shelf levels are described in the cooking
tables below)
• The guides may be drawn, wire, or telescopic
(depending on the appliance model). Telescopic (pull-
out or, retractable) guides are installed for the second,
third, and fourth level. In case of wire guides, the grid
and the trays should always be inserted into the leading
slot formed by adjacent wire profiles.
Shelf levels (depending
on the model)
16

425514
Telescopic (pull-out or, retractable) guides are installed
for the second, third, and fourth level. They are installed
on the left and right side wall of the oven interior at three
levels.
Pull-out levels consist of (depending on the model):
- three guides that can be pulled out partially,
- one guide that can be pulled out completely and two
that can be pulled out partially, or
- three guides that can be pulled out completely.
Telescopic pull-out guides and other parts of oven
accessories will heat up! Use a kitchen glove or
similar protection when handling them.
• To insert the grid, baking tray, or drip tray, first pull out
the telescopic guides of the desired level.
• Place the grid or the shallow or deep baking tray on the
pull-out guides and push it into the oven with your hand.
Close the oven door only when the telescopic guides
have been fully retracted.
The grid onto which the container with food, or the food
directly, is placed.
A safety stop is fitted on the grid and on the
guides. To pull out the grid, lift it slightly when it
hits the stop.
Shallow baking tray is only intended for baking pastry and
cakes.
Deep baking tray is intended for baking meat and moist
pastry; it is also intended as a drip tray.
Unless you are using the grill, or the deep baking
tray is used only as a drip tray when spit-roasting,
the deep tray should not be inserted into the first
guide.
Telescopic pull-out
guides (depending on
the model)
Oven accessories
(depending on the
model)
17

425514
• For baking pastry, use the , or . mode of
operation. (Oven operation with the selected mode, or
system, depends on the appliance model).
• When baking pastry, always remove the fat filter.
Instructions
• When baking pastry, always observe the instructions on
the shelf / guide level, temperature, and cooking time
indicated in the pastry baking table. Do not be prejudiced
by experience you may have with other ovens. The values
indicated in the cooking table are defined and checked
especially for this particular oven.
• If the baking table does not specifically address a
particular type of pastry, see the information for a
similar type of pastry.
Baking pastry with upper and lower heater
• Bake the pastry at one level only.
• Upper / lower heater combination is particularly
appropriate for baking various types of pastry, bread,
and meat.
• Use dark-colored baking trays. Light-colored trays
reflect the heat, which leads to poorer cooking
(browning) results. Always place the models on the grid.
If you are using the supplied baking tray, remove the
grid.
• Preheating will shorten the cooking time. Place the
dish into the oven only when the selected temperature
has been reached, i.e. when the control lamp (heater
operation lamp) goes o for the first time.
Baking pastry with hot air
Baking pastry with hot air is particularly convenient
when you wish to bake on several shelf / guide levels
simultaneously, especially when preparing bite-size pastry
in shallow trays. Preheating is recommended, and the
use of the second and third guide level. This mode is also
appropriate for moist pastry and fruit cakes (in this case,
bake on a single level only).
• The temperature is normally set lower than when baking
with the upper/lower heater combination (see also the
pastry baking table).
• Various types of pastry can be baked simultaneously, if
the required temperature is at least approximately the
same for all.
• Baking time can vary, even for equal baking trays. When
Baking pastry
18
FOOD PREPARATION

425514
baking in several baking trays simultaneously – on two
or even three levels, baking time for each tray can e
dierent. You may have to remove one of the trays
sooner (normally, this would be the uppermost tray.
• If possible, prepare bite-size pastry, such as cupcakes,
in the same thickness and height. Unevenly sized pastry
will be unevenly browned!
• When baking several types of pastry simultaneously,
there will be a significant amount of vapor in the oven,
resulting in accumulation of condensate on the oven
door.
Tips on baking pastry
Is the pastry completely done?
Use a wooden stick to pierce the pastry at the highest
point. If there are no traces of dough when the stick is
removed, the pastry is done. Turn o the oven and use the
remaining accumulated heat.
The pastry has collapsed
Check the recipe. Next time, use less liquid. Observe the
instructions on mixing / kneading time, especially when
using small household appliances.
The pastry is too light-colored
Next time, use a dark-colored baking tray, place the tray
one guide level lower, or turn on the lower heater towards
the end of the cooking process.
The pastry with a moist filling (e.g. cheesecake) is not
completely done
Next time, reduce the temperature and extend the cooking
time.
Notes on the pastry baking table:
• Two values are indicated for temperature, lower and
upper. Initially, set the lower temperature; if the pastry is
not brown enough, increase the temperature next time.
• Cooking times are given as an estimate and may vary
subject to a number of circumstances.
• The value printed in bold in the temperature table
indicates the most appropriate operating mode for a
particular type of pastry.
• The indication * means that the oven should be
preheated with the corresponding operating mode
selected.
• When using baking paper, make sure it is resistant to
high temperature.
19

425514
Pastry baking table for combined upper and lower heater or hot air operating mode -
when cooking on one level only
Type of pastry Guide
(from the
bottom)
Temperature
(°C)
Guide
(from the
bottom)
Temperature
(°C)
Cooking
time
(minutes)
Sweet pastry
Marble cake, ring cake 1 160-170 1 150-160 50-70
Rectangle-shaped cake 1 160-170 1 150-160 55-70
Cake made in cake tin 1 160-170 2150-160 45-60
Cake tin cheesecake 1 170-180 2 150-160 65-85
Fruit cake, short pastry 1 180-190 2160-170 50-70
Fruit cake with dressing 1 170-180 2160-170 60-70
Sponge cake* 1 170-180 2 150-160 30-40
Cake with icing 2 180-190 2 160-170 25-35
Fruit cake, mixed dough 2 170-180 2 150-160 45-65
Cherry cake 2 180-200 2 150-160 35-60
Sponge cake roll* 2 180-190 2 160-170 15-25
Leavened dough cake 2 160-170 2 150-160 25-35
Hefezopf (leavened dough) 2 180-200 2 160-170 35-50
Christmas cake 2 170-180 2 150-160 45-70
Apple pie 2 180-200 2 170-180 40-60
Oven-baked donuts 1 170-180 2 150-160 40-55
Savory pastry
Quiche Lorraine 1 190-210 2 170-180 50-65
Pizza* 2 210-230 2 190-210 25-45
Bread 2 190-210 2 170-180 50-60
Buns* 2 200-220 2 180-190 30-40
Bite-size pastry
Short pastry – cookies * 2 160-170 2 150-160 15-25
Merengue * 2 160-170 2 150-160 15-28
Leavened dough 2 180-190 2 170-180 20-35
Pu pastry 2 190-200 2 170-180 20-30
Choux pastry (cream filled) 2 180-190 2 180-190 25-45
Soués
Rice soué 1 190-200 2 180-190 35-50
Fresh cheese soué 1 190-200 2 180-190 40-50
Frozen pastry
Apple, cheese pie 2 180-200 2 170-180 50-70
Cheesecake 2 180-190 2 160-170 65-85
Pizza 2 200-220 2 170-180 20-30
French fries for oven * 2 200-220 2 170-180 20-35
Croquettes 2 200-220 2 170-180 20-35
Note: Guide number refers to the grid onto which smaller baking trays or cake tins are
placed, and to shallow baking tray. The deep baking tray should not be inserted into the
first guide.
20
