INSTRUCTIONS–PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
Back Pressure Valve
300 psi (21 bar, 2.1 MPa) Maximum Inbound Pressure
180 psi (12.4 bar, 1.24 MPa) Maximum Regulated Pressure
Model 205122, Series C
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
DThis equipment is for professional use only.
DRead all instruction manuals, tags, and labels before operating the equipment.
DUse the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
DDo not alter or modify this equipment. Use only genuine Graco parts and accessories.
DCheck equipment daily. Repair or replace worn or damaged parts immediately.
DDo not exceed the maximum working pressure of the lowest rated component in your system. This
equipment has a 300 psi (21 bar, 2.1 MPa) maximum inbound pressure and a 180 psi (12.4 bar,
1.24 MPa) maximum regulated pressure.
DUse fluids and solvents which are compatible with the equipment wetted parts. Refer to the Tech-
nical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
DComply with all applicable local, state, and national fire, electrical, and safety regulations.
PRESSURIZED EQUIPMENT HAZARD
Spray from the gun, hose leaks, or ruptured components can splash fluid in the eyes or on the skin
and cause serious injury.
DDo not stop or deflect leaks with your hand, body, glove or rag.
DTighten all fluid connections before operating the equipment.
DFollow the Pressure Relief Procedure on page 2 whenever you: are instructed to relieve pres-
sure; stop spraying; clean, check, or service the equipment; and install or clean the spray nozzle.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
eCOPYRIGHT 1994, GRACO INC.
Graco Inc. is registered to ISO 9001

3066402
Pressure Relief Procedure.
WARNING
PRESSURIZED EQUIPMENT HAZARD
The system pressure must be manually relieved to
prevent the system from starting or spraying accidentally.
To reduce the risk of an injury from accidental spray from
the gun, splashing fluid, or moving parts, follow the
Pressure Relief Procedure whenever you:
Dare instructed to relieve the pressure,
Dstop spraying,
Dcheck or service any of the system equipment,
Dor install or clean the spray nozzle.
1. Shut off the power to the pump. If you are using an air–
powered pump, open the bleed–type master air valve.
2. Trigger the gun.
3. Relieve the line pressure by turning the adjusting screw
(26) counterclockwise until there is no spring pressure.
Installation
This valve is used in a circulating system to regulate the back
pressure to spray guns and to maintain the proper circulating
pressure throughout the system.
The valve is adjustable to control fluid pressure in a circulat-
ing system from 0 to 180 psi (0 to 12.4 bar, 0 to 1.24 MPa).
CAUTION
To prevent damage to the diaphragm, the hard carbide seat
and stem, and other sensitive parts, handle the valve care-
fully.
Install the valve in the return line of the spray guns, down-
stream from the last gun. See Fig. 1. Connect the return line
to the 3/8 npsm(m) inlet (22) and the 3/8 npsm(f) outlet (11).
Be sure the connections match the direction of fluid flow in
the line. See Fig. 2.
Fig. 1
AB
C
D
E
F
04521
Fig. 2 04520
11
22
Operation
The back–pressure valve controls pressure in the fluid
return–line. Adjust the pump pressure and the back–pressure
valve for the best combination of spraying pressure and fluid
circulation.
To adjust the back–pressure valve, loosen the locknut (27)
and insert the hex key wrench (7) into the socket on the
adjusting screw (26). Turn the screw clockwise to increase
pressure in the return line. Turn the screw counterclockwise
to decrease pressure in the return line. Lock in the adjust-
ment by tightening the locknut (27).
NOTE: Always check and adjust the back pressure valve if
you make changes to the system such as a change of fluids,
the length of the lines, and the number of spray guns.
Flush the valve with a compatible solvent whenever the rest
of the system is being flushed. Fully open the valve before
flushing by turning the adjustment screw counterclockwise.
Always use the lowest possible pressure when flushing.
Service
NOTE: Clean and check the valve regularly to maintain it in
good working condition. Refer to the Parts drawing on page
3.
1. Remove the valve from the system.
2. Disassemble the pressure gauge (5) and the tube (16)
from the inlet adapter (22). Remove the inlet adapter and
the outlet union (11) from the housing (25).
3. Unscrew the cap (28) from the housing (25). Remove the
adjusting screw (26) and the locknut (27).
4. Remove the spring plate (15) and the spring (13).
5. Loosen the cap nut (4). Disassemble the diaphragm and
its related parts (2,10, 18, 19, 20, 21).
CAUTION
Be careful not to damage the valve seat (1) or stem (2)
which are made of hard carbide.

306640 3
Service
6. Remove the valve seat (1) and the gasket (9) from the
housing (25).
7. Clean all the parts with a compatible solvent. Check the
parts for wear or damage. Replace worn or damaged
parts.
8. Assemble the valve seat (1) and the gasket (9) into the
housing (25). Torque to 70–80 in–lb (8–9 N.m).
9. Assemble the diaphragm and the related parts as shown
in the parts drawing. Torque the cap nut (4) to 27–33
in–lb (3.1–3.7).
10. Install the spring (13) and the spring plate (15).
11. Screw the cap (28) onto the housing (25). Torque to
115–125 in–lb (13–14 N.m). Reinstall the locknut (27)
and the adjusting screw (26) into the cap (28).
12. Assemble the inlet adapter (22) and the outlet union (11)
into the housing.
13. Assemble the gauge (5) to the pressure tube (16). Use a
thread sealant to ensure a good seal. Install the tube and
the gauge into the inlet adapter (22).
14. Install the valve in the system.
Parts
1
3
2
04519
26
27
28
15
13
4
10
18
20
21 19
2
1
9
11
25
5
16
22
7
1
2
3
Torque to
115–125 in–lb
(13–14 N.m)
Torque to
27–33 in–lb
(3.1–3.7 N.m)
Torque to
70–80 in–lb
(8–9 N.m)
4
4
“AIRSIDE”
marking facing
down
Ref.
No. Part No. Description Qty.
1n236893 SEAT, valve 1
2n236894 STEM, valve 1
4 100529 NUT, hex, cap, 5/16–18 1
5n187876 PRESSURE GAUGE, 0–300 psi
(0–21 bar, 0–2.1 MPa) pressure range 1
7 101976 WRENCH, hex key, 3/8” 1
9n189817 GASKET, copper 1
10n154789 GASKET, copper 1
11 155665 UNION, 3/8 npt(m) x
3/8 npsm(f) swivel 1
13 157796 SPRING, compression 1
15 160180 PLATE, spring 1
16 160745 TUBE, fluid gauge 1
18n189816 PLATE, backup 1
19n177430 GASKET, valve 1
20n177432 DIAPHRAGM PLATE, support 1
21n177431 DIAPHRAGM 1
22 162265 INLET ADAPTER, 3/8–18 npsm(m),
3/8–18 npt(m), 1/4–18 npt(f) 1
25 162811 VALVE HOUSING 1
26 112844 ADJUSTING SCREW, 1/2–20 x
1–5/8 inch long 1
27 100111 LOCKNUT, 1/2–20 1
28 189815 REGULATOR CAP 1
nKeep these spare parts on hand to reduce down time.
Graco Phone
Number
TO PLACE AN ORDER, contact your Graco distributor, or
call this number to identify the distributor closest to you:
1–800–328–0211 Toll Free
Manual Change
Summary
Assembly
Changed Part Status Ref No. Part No. Name
205122
Series to C Old New
Old
New
1
1
5
5
212030
236893
101180
187876
Seat
Seat
Gauge
Gauge
Maximum inbound fluid pressure is increased to 300 psi (21
bar, 2.1 MPa).

3066404
Technical Data
Maximum inbound fluid pressure 300 psi (21 bar, 2.1 MPa). .
Regulated pressure range 0–180 psi (0–12.4 bar, 1.24 MPa)
Valve orifice diameter 0.156 inch (3.96 mm). . . . . . . . . . . . . . .
Approximate maximum
flow capacity 2 gpm (7.6 liter/min). . . . . . . . . . . . . . . . . . . . . .
Wetted parts 303 stainless steel, plated steel. . . . . . . . . . . . . .
brass, tungsten carbide, buna–N impregnated
nylon, PTFE, elastomer treated cellulose fiber
Dimensions
Height (A) 7 inch (178 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Width (C) 5 inch (127 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid inlet (B) 3/8 npsm(m). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid outlet (D) 3/8 npsm(f). . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diameter (E) 2.44 inch (51.28 mm). . . . . . . . . . . . . . . . . . . . . . .
04520
A
B
C
DE
