Installation
GRACO INC.ąP.O. BOX 1441ąMINNEAPOLIS, MNą55440-1441
Copyright 2004, Graco Inc. is registered to I.S. EN ISO 9001
T-Max 405 Bag Rollert
Model 248517, Series A
309976 Rev.B
‘
Read warnings and instructions in 309973
309978. . . . . . .
309973. . . . . . .
Parts
3099762
Mount Bag Roller on Sprayer
1. Remove bag roller from crate.
2. Fig. 1. Install bag roller assembly on T-Max 405
sprayer handle with four screws (15).
3. Install crank handle assembly (A) with ring detent
pin (11).
ti4175a
15
11
A
Fig. 1
Operation
1. Fig. 2. Feed bottom of bag (B) into bag roller. Turn
crank handle assembly (13) enough to start to pull
bag through rollers. Cut off top of bag.
2. Fig. 2. Turn crank handle assembly (A) and
squeeze the contents of bag into texture hopper.
Fig. 2
B
A
ti4169a
309976 3
Parts
910 1311 12 14
ti4168a
15
87465321
17
18
20
REF
NO. PART NO. DESCRIPTION QTY REF
NO. PART NO. DESCRIPTION QTY
1 110637 SCREW, shc, 10–24 x .375 2
2 15C680 PLATE, cover 1
3 15C547 GEAR, roller 2
4 100643 SCREW, cap, shc 2
5 15C690 BLOCK, gears mounting 1
6 118468 BEARING, sleeve 4
7 15C685 ROLLER, top 1
8 15C923 BRACE, bag roller 1
9 15C684 ROLLER, bottom 1
10 15C688 BLOCK, rollers mounting 1
11 118558 PIN, ring detent 1
12 15C487 ARM, crank 1
13 15C681 HANDLE, crank 1
14 118519 SCREW, shoulder, shc 1
15 115138 SCREW, cap, hex hd 4
17 15D636 RACK, bag 1
18 15D949 TOOL, multi-purpose 1
20 100086 WASHER, plain 4
3099764
Graco Warranty
Graco warrants all equipment listed in this manual which is manufactured by Graco and bearing its name to be free from defects in
material and workmanship on the date of sale to the original purchaser for use. With the exception of any special extended or limited
warranty published by Graco, Graco will, for a period of 12 months from the date of sale, repair or replace any part of the equipment
determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in
accordance with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by
faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or
substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of
Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture,
installation, operation or maintenance or structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for
verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The
equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect
in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and
transportation.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other
remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any
other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within 2 years of the date
of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD
BUT NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, gas engines,
switches, hose, etc.), are subject to the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable
assistance in making any claim for breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment
hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract,
breach of warranty, the negligence of Graco, or otherwise.
FOR GRACO CUSTOMERS SPEAKING FRENCH, SPANISH AND PORTUGUESE
The parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings
entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English.
POUR LES CLIENTS DE GRACO PARLANT FRANÇAIS
Les parties reconnaissent avoir convenu que la rédaction du présent document, ainsi que tous les documents, avis et procédures
judiciaires exécutés, donnés ou intentés à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées,
sera en anglais.
PARA CLIENTES DE GRACO DE HABLA ESPAÑOLES
Las partes reconocen que han requerido que el presente documento, al iqual que todos los documentos, notificaciones y
procedimientos legales en que se incurra conforme a esta infomación o en relación indirecta o directa con la misma, sea redactado en
inglés.
PARA CLIENTES DE LÍNGUA PORTUGUESA DA GRACO
As partes confirmam que solicitaram que o presente documento, assim como todos os demais documentos, notas e processos legais
inseridos, atribuídos ou instituídos de acordo com o mesmo ou relacionados direta ou indiretamente a este documento, fossem
redigidos em inglês.
ADDITIONAL WARRANTY COVERAGE
Graco does provide extended warranty and wear warranty for products described in the “Graco Contractor Equipment Warranty
Program”. Graco Phone Number
TO PLACE AN ORDER, contact your Graco distributor, or call 1–800–690–2894 Toll Free, to identify the distributor closest to you.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Sales Offices: Minneapolis
International Offices: Belgium, Korea, Hong Kong, Japan
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
http://www.graco.com
PRINTED IN U.S.A. 309976 4/2004, Revised 5/2004
