Graco PROX17 User manual

Electric Airless Sprayer
OWNERS MANUAL
X5, X7, ProX17, ProX19, ProX21
3A3208B
EN
IMPORTANT SAFETY INSTRUCTIONS
Read all warnings and instructions in this manual and related manuals. Be familiar with the
controls and the proper usage of the equipment. Save these instructions.
Not approved for use in explosive atmospheres or hazardous locations.
For portable airless spraying of architectural paints and coatings.
3A3208B
EN
Not approved for use in explosive atmospheres or hazardous locations.
For portable airless spraying of architectural paints and coatings.
Important Safety Instructions
Read all warnings and instructions in this manual, related manuals, and on the unit.
Be familiar with the controls and the proper usage of the equipment. Save these
instructions.
FIRE AND EXPLOSION HAZARD
X5/X7 Models:
•Use only non-flammable or water-based materials, or non-flammable paint thinners. Do not use
materials having flash points lower than 100° F (38° C). This includes, but is not limited to, acetone,
xylene, toluene, or naphtha. For more information about your material, request Safety Data Sheet
(SDS) from the supplier.
•Spraying flammable or combustible materials in a factory or fixed location must comply with NFPA
33 and OSHA 1910.94(c) requirements in the USA and with all similar local regulations in other
countries.

Before You Spray
23A3208B
Before You Spray
Review Warnings for Important Safety Information
Important! Read carefully and practice good safety habits.
Review Manual & Watch Videos
Scan QR code for Operational Video or go to
magnum.graco.com/magop
Related Manuals
Gun: 312830 (SG)
ProXChange™ Pump: 3A3172 (ProX only)
Models
3000 psi (207 bar, 20.7 MPa) Maximum Working Pressure
VAC Model Stand (Series) Cart (Series)
120
USA
X5 262800 (E)
17K437 (A)
X7 262805 (D)
ProX17 17G177 (A)
17K438 (A) 17G178 (A)
ProX19 17G179 (A) 17G180 (A)
17K439 (A)
ProX21 17G181 (A) 17G182 (A)
110474
Certified to
CAN/CSA
C22.2 No. 68
Conforms to
UL 1450

Warnings
43A3208B
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this
equipment. The exclamation point symbol alerts you to a general warning and the hazard
symbols refer to procedure-specific risks. When these symbols appear in the body of this
manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols
and warnings not covered in this section may appear throughout the body of this manual
where applicable.
GROUNDING
This product must be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This product is
equipped with a cord having a grounding wire with an appropriate grounding plug. The plug
must be plugged into an outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
•Improper installation of the grounding plug is able to result in a risk of electric shock.
•When repair or replacement of the cord or plug is required, do not connect the grounding
wire to either flat blade terminal.
•Thewirewithinsulation having an outer surface that is greenwithor without yellow stripes
is the grounding wire.
•Check with a qualified electrician or serviceman when the grounding instructions are not
completely understood, or when in doubt as to whether the product is properly grounded.
•Do not modify the plug provided; if it does not fit the outlet, have the proper outlet installed
by a qualified electrician.
•This product is for use on a nominal 120V circuit and has a grounding plug similar to the
plugs illustrated below.
•Only connect the product to an outlet having the same configuration as the plug.
•Do not use an adapter with this product.
Extension Cords:
•Useonlya3-wireextensioncordthathasagroundingplugandagroundingreceptaclethat
accepts the plug on the product.
•Make sure your extension cord is not damaged. If an extension cord is necessary use 12
AWG (2.5mm2) minimum to carry the current that the product draws.
•An undersized cord results in a drop in line voltage and loss of power and overheating.
ti3509b
Conductor Size Length
AWG (American Wire Gauge) Metric Maximum
16 1.5 mm225 ft. (8 m)
12 2.5 mm250 ft. (15 m)

Warnings
3A3208B 5
FIRE AND EXPLOSION HAZARD
Flammablefumes,suchassolventandpaintfumes,inworkareacanigniteorexplode.Tohelp
prevent fire and explosion:
X5/X7 Models:
•Donotsprayorcleanwithmaterialshavingflashpointslowerthan100°F(38°C).Useonly
non-flammable or water-based materials, or non-flammable paint thinners. For complete
information about your material, request the Safety Data Sheet (SDS) from the material
distributor or retailer.
•Do not spray combustible materials near an open flame or sources of ignition such as
cigarettes, motors, and electrical equipment.
•Do not spray combustible liquids in a confined area.
ProX Models:
•Donot sprayflammableorcombustiblematerialsnearanopenflameor sourcesofignition
such as cigarettes, motors, and electrical equipment.
•Do not spray flammable or combustible liquids in a confined area.
All Models:
•Paint or solvent flowing through the equipment is able to result in static electricity. Static
electricity creates a risk of fire or explosion in the presence of paint or solvent fumes. All
parts of the spray system, including the pump, hose assembly, spray gun, and objects in
and around the spray area shall be properly grounded to protect against static discharge
andsparks.UseGraco conductive or grounded high-pressure airless paintsprayerhoses.
•Verify that all containers and collection systems are grounded to prevent static discharge.
Do not use pail liners unless they are anti-static or conductive.
•Connect to a grounded outlet and use grounded extensions cords. Do not use a 3-to-2
adapter.
•Do not use a paint or a solvent containing halogenated hydrocarbons.
•Keep spray area well-ventilated. Keep a good supply of fresh air moving through the area.
•Sprayer generates sparks. Keep pump assembly in a well ventilated area a least 20 feet
(6.1 m) from the spray area when spraying, flushing, cleaning, or servicing. Do not spray
pump assembly.
•Do not smoke in the spray area or spray where sparks or flame is present.
•Do not operate light switches, engines, or similar spark producing products in the spray
area.
•Keep area clean and free of paint or solvent containers, rags, and other flammable
materials.
•Know the contents of the paints and solvents being sprayed. Read all Safety Data Sheets
(SDSs) and container labels provided with the paints and solvents. Follow the paint and
solvents manufacturer’s safety instructions.
•Fire extinguisher equipment shall be present and working.

Warnings
63A3208B
SKIN INJECTION HAZARD
High-pressuresprayisabletoinjecttoxinsintothebodyandcauseseriousbodily injury. In the
event that injection occurs, get immediate surgical treatment.
•Do not aim the gun at, or spray any person or animal.
•Keephandsandotherbodyparts away fromthedischarge.Forexample,do not trytostop
leaks with any part of the body.
•Always use the nozzle tip guard. Do not spray without nozzle tip guard in place.
•Use Graco nozzle tips.
•Usecautionwhencleaningandchangingnozzletips.Inthecasewherethenozzletipclogs
while spraying, follow the Pressure Relief Procedure for turning off the unit and relieving
the pressure before removing the nozzle tip to clean.
•Equipment maintains pressure after power is shut off. Do not leave the equipment
energized or under pressure while unattended. Follow the Pressure Relief Procedure
when the equipment is unattended or not in use, and before servicing, cleaning, or
removing parts.
•Check hoses and parts for signs of damage. Replace any damaged hoses or parts.
•Thissystemiscapableofproducing3000psi.UseGracoreplacementpartsoraccessories
that are rated a minimum of 3000 psi.
•Always engage the trigger lock when not spraying. Verify the trigger lock is functioning
properly.
•Verify that all connections are secure before operating the unit.
•Know how to stop the unit and bleed pressure quickly. Be thoroughly familiar with the
controls.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
•Always wear appropriate gloves, eye protection, and a respirator or mask when painting.
•Do not operate or spray near children. Keep children away from equipment at all times.
•Do not overreach or stand on an unstable support. Keep effective footing and balance at
all times.
•Stay alert and watch what you are doing.
•Do not operate the unit when fatigued or under the influence of drugs or alcohol.
•Do not kink or over-bend the hose.
•Do not expose the hose to temperatures or to pressures in excess of those specified by
Graco.
•Do not use the hose as a strength member to pull or lift the equipment.
•Do not spray with a hose shorter than 25 feet.
•Do not alter or modify equipment. Alterations or modifications may void agency approvals
and create safety hazards.
•Makesureallequipmentisrated and approvedfortheenvironmentinwhichyou are using
it.
ELECTRIC SHOCK HAZARD
This equipment must be grounded.Improper grounding, setup, or usage of the system can
cause electric shock.
•Turn off and disconnect power cord before servicing equipment.
•Connect only to grounded electrical outlets.
•Use only 3-wire extension cords.
•Ensure ground prongs are intact on power and extension cords.
•Do not expose to rain. Store indoors.

Warnings
3A3208B 7
PRESSURIZED ALUMINUM PARTS HAZARD
Useoffluidsthatareincompatiblewithaluminuminpressurizedequipment can cause serious
chemical reaction and equipment rupture. Failure to follow this warning can result in death,
serious injury, or property damage.
•Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents.
•Do not use chlorine bleach.
•Many other fluids may contain chemicals that can react with aluminum. Contact your
material supplier for compatibility.
MOVING PARTS HAZARD
Moving parts can pinch, cut, or amputate fingers and other body parts.
•Keep clear of moving parts.
•Do not operate equipment with protective guards or covers removed.
•Pressurized equipment can start without warning. Before checking, moving, or servicing
equipment, follow the Pressure Relief Procedure and disconnect all power sources.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin,
inhaled, or swallowed.
•Read MSDSs to know the specific hazards of the fluids you are using.
•Store hazardous fluid in approved containers, and dispose of it according to applicable
guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury,
including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective
equipment includes but is not limited to:
•Protective eyewear, and hearing protection.
•Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
CALIFORNIA PROPOSITION 65
ThisproductcontainsachemicalknowntotheStateofCaliforniatocausecancer,birthdefects
or other reproductive harm. Wash hands after handling.

ProX17: 17G177, 17K438, ProX19: 17G179
40 3A3208B
ProX17: 17G177, 17K438, ProX19: 17G179
Stand Sprayer Parts
Ref. Torque
140-160 in-lb (16-18 N•m)
30-35 in-lb (3.5-4.0 N•m)
110-120 in-lb (12-14 N•m)
45-55 in-lb (5-6 N•m)
1
2
3
4
1
1a
24
3
7
9
10
10a
27
10b
9
12
13
56
8
14
15
15a
16
17
19
20
45
21
22
22
23
24
25
37
36
35
34
39
38
35
40
6
32
ti27198a
31
30
18
See page 48.
12
3
4
3
2
2
2

ProX17: 17G177, 17K438, ProX19: 17G179
3A3208B 41
17G177, 17K438, 17G179 Stand Sprayer Parts List
Ref. Part Description Qty.
1 KIT, repair, motor,
120V includes 1a
17K285 ProX17 1
17F756 ProX19 1
1a 287770 FAN 1
2 17J863 KIT, gear and yoke 1
3 17J173 CORD, power 1
4 17J864 KIT, yoke 1
6 117493 SCREW, mach, hex,
washer head 1
7 17J874 KIT, pump complete 1
8 17J865 SHIELD, motor, blue
includes 9 and labels 1
9 118444 SCREW, mach, hwhd
10-24 x 0.5 in. 3
10 17J866 COVER,frontincludes
9, 10a, 10b, 12, 14 1
10a 128551 CABLE, jumper, PC 1
10b 17F262 COVER, wire 1
12 115478 SCREW, mach, Torx,
pan hd 4
13 15J803 SWITCH, bracket 1
14 17F233 COVER, pump,
locking 1
15 17J867 KIT, control board
120V includes 15a, 16 1
15a 119276 FUSE, 12.5A slow
blow 1
16 117501 SCREW, plastite 1
17 24Y329 KIT, switch, repair
includes 13 1
18 115498 SCREW, mach, slot,
hex whd 1
19 17G328 PLATE, motor mount 1
20 16D686 KIT, right leg 1
21 16D687 KIT, left leg 1
22 260212 SCREW, hwh, thread
forming 8
23 15J599 CAP, tube 2
24 276864 HANDLE, sprayer 1
25 116139 GRIP, handle 1
27 LABEL, front
17J031 ProX17 1
17J033 ProX19 1
30 247340 HOSE, cpld, 1/4 in. x
50 ft 1
31 GUN, spray, SG3
243012 Models 17G177,
17G179 1
246506 Models 17K438, 1
32 115099 WASHER, hose 1
34 244035 DEFLECTOR, barbed 1
35 115489 CLAMP, drain tube 2
36 195084 TUBE, drain 1
37 24V074 KIT, tube, suction
includes34,35,36,38,
39, 40
1
38 116295 CLAMP, tube 1
39 195400 CLIP, spring 2
40 288716 KIT, strainer 1
45 17H422 CUP, suction/drain 1
5617J027 LABEL, warning 1
57222385 CARD, medical alert
(not shown) 1
60 3A3526 GUIDE,Magnumquick
guide, English (not
shown)
1
60a 3A3528 GUIDE,Magnumquick
guide, Spanish (not
shown)
1
61 115648 VALVE, power flush
(not shown) 1
62 244168 FLUID, pump armor, 8
oz (not shown) 1
64 17K631 TAG, hang, tip (not
shown) 1
17L305 KIT, conversion,
lacquer, stand (sold
separate)
ReplacementDangerand Warninglabels,
tags, and cards are available at no cost.
Ref. Part Description Qty.
