Graco Fusion CS Series User manual

Instructions
Fusion™CS
For plural component, impingement mix air purge spray gun with ClearShot™Liquid
technology. For professional use only.
For use with non-flammable foam and polyurea. Not for use in explosive atmospheres.
3500 psi (24.5 MPa, 245 bar) Maximum Fluid Working Pressure
80-130 psi (0.56-0.9 MPa, 5.6-9.0 bar) Air Inlet Pressure Range
200° F (94° C) Maximum Fluid Temperature
See page 4 for model information.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
TI11323a
312666W
EN

2312666W
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Models/Mix Chamber Selection Guide . . . . . . . . . 4
Round Pattern Guns . . . . . . . . . . . . . . . . . . . . . . 4
Flat Pattern Guns . . . . . . . . . . . . . . . . . . . . . . . . 5
Wide Round Pattern Gun . . . . . . . . . . . . . . . . . . 6
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Important Isocyanate (ISO) Information . . . . . . . . 9
Material Self-ignition . . . . . . . . . . . . . . . . . . . . . 10
Keep Components A and B Separate . . . . . . . . 10
Moisture Sensitivity of Isocyanates . . . . . . . . . . 10
Foam Resins with 245 fa Blowing Agents . . . . . 10
Changing Materials . . . . . . . . . . . . . . . . . . . . . . 11
ClearShot Liquid . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overall View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Piston Safety Lock . . . . . . . . . . . . . . . . . . . . . . . . 13
Remove Front Cover . . . . . . . . . . . . . . . . . . . . . . . 14
Loss of Air Pressure . . . . . . . . . . . . . . . . . . . . . . . 14
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 17
Optional Hose Position . . . . . . . . . . . . . . . . . . . . . 18
Flat Spray Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Variable Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Change Variable Flow Adjustment Knob . . . . . 20
ClearShot Liquid Cartridge Installation/Removal 22
Install ClearShot Liquid Cartridge . . . . . . . . . . . 22
Remove ClearShot Liquid Cartridge . . . . . . . . . 23
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 23
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Supplied Tool Kit . . . . . . . . . . . . . . . . . . . . . . . . 24
Keep Gun Clean . . . . . . . . . . . . . . . . . . . . . . . . 24
As Needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Daily . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Weekly to Monthly . . . . . . . . . . . . . . . . . . . . . . . 24
Flush Gun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Clean Outside of Gun . . . . . . . . . . . . . . . . . . . . 25
Clean or Replace Front Cover and Retainer . . . 25
Clean Breather Plug . . . . . . . . . . . . . . . . . . . . . 25
Clean Fluid Manifold . . . . . . . . . . . . . . . . . . . . . 26
Adjust Fluid Valve Packings . . . . . . . . . . . . . . . 26
Clean Mix Chamber Nozzle . . . . . . . . . . . . . . . 27
Clean Passages . . . . . . . . . . . . . . . . . . . . . . . . 28
Clean Impingement Ports . . . . . . . . . . . . . . . . . 28
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . 33
Cutaway View . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . 35
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Remove Front End . . . . . . . . . . . . . . . . . . . . . . 35
Attach Front End . . . . . . . . . . . . . . . . . . . . . . . . 36
Mix Chamber and Side Seal Assemblies . . . . . 37
Check Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Piston . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Air Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Mix Chamber Kits . . . . . . . . . . . . . . . . . . . . . . . 49
Flat Tip Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
O-ring Repair Kits . . . . . . . . . . . . . . . . . . . . . . . 51
Check Valve Filter Screen Kits . . . . . . . . . . . . . 52
Drill Bit Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Stainless Steel Side Seal Kit . . . . . . . . . . . . . . . 55
Polycarballoy Side Seal Kits . . . . . . . . . . . . . . . 55
Flat Pattern Stud Wall Kits . . . . . . . . . . . . . . . . . 55
Gun Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Lubricant for Gun Rebuild . . . . . . . . . . . . . . . . . 55
Flushing Manifold . . . . . . . . . . . . . . . . . . . . . . . 55
Fluid Inlet Cover . . . . . . . . . . . . . . . . . . . . . . . . 55
Gun Cleaning Kit . . . . . . . . . . . . . . . . . . . . . . . . 55
ClearShot Liquid Cartridges . . . . . . . . . . . . . . . 55
Solvent Flush Canister Kit . . . . . . . . . . . . . . . . . 56
Solvent Flush Pail Kit . . . . . . . . . . . . . . . . . . . . . 56
Tip Cleanout Tool . . . . . . . . . . . . . . . . . . . . . . . 56
Circulation Manifold . . . . . . . . . . . . . . . . . . . . . . 56
Fusion AP Manifold Adapter . . . . . . . . . . . . . . . 56
Gun and Palm Grips . . . . . . . . . . . . . . . . . . . . . 57
Handle Replacement Kit . . . . . . . . . . . . . . . . . . 57
Repair Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Technical Specifications . . . . . . . . . . . . . . . . . . . . 59
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 60
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 60

Related Manuals
312666W 3
Related Manuals
The following manuals are for accessories
used with the Fusion CS spray gun. Visit
www.graco.com for the most current manual
revisions.
Manual
in
English
Description
309572 Power-Lock™ Heated Hose,
Instructions - Parts Manual
309963 Solvent Flush Kits, Instructions -
Parts Manual
313058 256566 Circulation Manifold Kit,
Instructions - Parts Manual
313121 256569 TP100 Kit and 256570
Stud Wall Foam Kit, Instructions -
Parts Manual
313129 256526 Cleanout Tool Kit,
Instructions - Parts Manual
3A6242 Clearshot™ Liquid Refill Kit,
Instructions - Parts Manual

Models/Mix Chamber Selection Guide
4312666W
Models/Mix Chamber Selection Guide
Round Pattern Guns
Table 1: Round Pattern Gun Flow Rate
Mix Chamber
Gun Kit,
Series Part
Impingement
Port Size
in. (mm)
Equivalent
Size
Seal
Material
CS20RD, B RD2020 0.020 (0.50) -000 SST
CS00RD, B RD0000 0.029 (0.70) -00 SST
CS01RD, B RD0101 0.042 (1.00) -01 SST
CS02RD, B RD0202 0.052 (1.30) -02 SST
CS03RD, B RD0303 0.060 (1.50) -03 SST
--- RD4747 0.047 (1.19) --- SST
FLOW RATE in gpm (lpm)*
PRESSURE in psi (MPa, bar)
5.0
(18.9)
4.0
(15.1)
3.0
(11.4)
1.0
(3.8)
2.0
(7.6)
0
RD0101(01)WD0101*
RD0000(00)WD0000*
500
(3.5, 35)
1000
(6.9, 69)
1500
(10.3, 103)
2000
(13.8, 138)
2500
(17.4, 172.4)
3000
(20.7, 207)
3500
(24.1, 241)
* To calculate flow in lb/min, multiply gpm rate by 10. Example: 2 gpm x 10 = 20 lb/min.
RD0303(03)WD0303
*Accessory WD (wide pattern) mix chambers are available. See page 49.
RD0202(02)
RD2020(000)WD2222*
RD4747,WD0202

Models/Mix Chamber Selection Guide
312666W 5
Flat Pattern Guns
Mix Chamber Flat Tip
Gun Kit,
Series Part
Impingement
Port Size in. (mm)
Equivalent
Size Part
Pattern Size
in. (mm)
Orifice Size
in. (mm)
CS20F1, B FL2020 0.020 (0.50) -000 FT0424 8-10 (203-254) 0.024 (0.61)
CS20F2, B FL2020 0.020 (0.50) -000 FT0438 8-10 (203-254) 0.038 (0.97)
CS00F1, B FL0000 0.029 (0.70) -00 FT0424 8-10 (203-254) 0.024 (0.61)
CS00F2, B FL0000 0.029 (0.70) -00 FT0438 8-10 (203-254) 0.038 (0.97)
CS00F3, B FL0000 0.029 (0.70) -00 FT0624 12-14 (305-356) 0.024 (0.61)
CS00F4, B FL0000 0.029 (0.70) -00 FT0638 12-14 (305-356) 0.038 (0.97)
CS00F5, B FL0000 0.029 (0.70) -00 FT0838 16-18 (406-457) 0.038 (0.97)
CS00F6, B FL0000 0.029 (0.70) -00 FT0848 16-18 (406-457) 0.048 (1.22)
CS01F1, B FL0101 0.042 (1.00) -01 FT0424 8-10 (203-254) 0.024 (0.61)
CS01F2, B FL0101 0.042 (1.00) -01 FT0438 8-10 (203-254) 0.038 (0.97)
CS01F3, B FL0101 0.042 (1.00) -01 FT0624 12-14 (305-356) 0.024 (0.61)
CS01F4, B FL0101 0.042 (1.00) -01 FT0638 12-14 (305-356) 0.038 (0.97)
CS01F5, B FL0101 0.042 (1.00) -01 FT0838 16-18 (406-457) 0.038 (0.97)
CS01F6, B FL0101 0.042 (1.00) -01 FT0848 16-18 (406-457) 0.048 (1.22)
CS02F1, B FL0202 0.052 (1.30) -02 FT0424 8-10 (203-254) 0.024 (0.61)
CS02F2, B FL0202 0.052 (1.30) -02 FT0438 8-10 (203-254) 0.038 (0.97)
CS02F3, B FL0202 0.052 (1.30) -02 FT0624 12-14 (305-356) 0.024 (0.61)
CS02F4, B FL0202 0.052 (1.30) -02 FT0638 12-14 (305-356) 0.038 (0.97)
CS02F5, B FL0202 0.052 (1.30) -02 FT0838 16-18 (406-457) 0.038 (0.97)
CS02F6, B FL0202 0.052 (1.30) -02 FT0848 16-18 (406-457) 0.048 (1.22)

Models/Mix Chamber Selection Guide
6312666W
Table 2: Flat Pattern Gun Flow Rate
Wide Round Pattern Gun
FLOW RATE in gpm (lpm)*
PRESSURE in psi (MPa, bar)
2.25
(8.55)
3.0
(11.4)
0.75
(2.85)
1.5
(5.7)
0
FL0101withFTXX38tip
FL0000withFTXX38tip
500
(3.5, 35)
1000
(6.9, 69)
1500
(10.3, 103)
2000
(13.8, 138)
2500
(17.4, 172.4)
3000
(20.7, 207)
3500
(24.1, 241)
* To calculate flow in lb/min, multiply gpm rate by 10. Example: 2 gpm x 10 = 20 lb/min.
FL0202withFTXX48tip
FL2020withFTXX24tip
Mix Chamber
Pattern Diameter at
24 in. (610 mm) to
Target
in. (mm)
Equivalent Flow to
Mix Chamber Size
Reference Part No.
Gun Kit,
Series Part
Impingement
Port Size
in. (mm)
Equivalent
Size
CS22WD, B WD2222 0.022 (0.56) N/A 8-9 (203-229) 4.5 lb/min at 1000 psi
CS00WD, B WD0000 0.028 (0.71) -00 15 (381.0) RD0000
CS01WD, B WD0101 0.039 (0.99) -01 16 (406.4) RD0101
CS02WD, B WD0202 0.046 (1.17) -02 18 (457.2) RD0202
CS03WD, B WD0303 0.057 (1.45) -03 18 (457.2) RD0303

Warnings
312666W 7
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this
equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol
refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific
warnings may be found throughout the body of this manual where applicable.
WARNING
PERSONAL PROTECTIVE EQUIPMENT
Always wear appropriate personal protective equipment and cover all skin when
spraying, servicing equipment, or when in the work area. Protective equipment helps
prevent serious injury, including long-term exposure; inhalation of toxic fumes, mists or
vapors; allergic reaction; burns; eye injury and hearing loss. This protective equipment
includes but is not limited to:
• A properly fitting respirator, which may include a supplied-air respirator, chemically
impermeable gloves, protective clothing and foot coverings as recommended by
the fluid manufacturer and local regulatory authority.
• Protective eyewear and hearing protection.
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get
immediate surgical treatment.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Engage trigger lock when not spraying.
•FollowPressure Relief Procedure in this manual, when you stop spraying and
before cleaning, checking, or servicing equipment.
BURN HAZARD
Equipment surfaces and fluid that’s heated can become very hot during operation. To
avoid severe burns, do not touch hot fluid or equipment. Wait until equipment/fluid has
cooled completely.

Warnings
8312666W
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or
explode. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric
lamps, and plastic drop cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when
flammable fumes are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail.
• If there is static sparking or you feel a shock, stop operation immediately. Do not
use equipment until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest
rated system component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See
Technical Specifications in all equipment manuals. Read fluid and solvent
manufacturer’s warnings. For complete information about your material, request
MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with
genuine manufacturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and
hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PRESSURIZED ALUMINUM PARTS HAZARD
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents in pressurized aluminum equipment. Such
use can cause serious chemical reaction and equipment rupture, and result in death,
serious injury, and property damage.
WARNING

Important Isocyanate (ISO) Information
312666W 9
Important Isocyanate (ISO) Information
Isocyanates (ISO) are catalysts used in two component materials.
Isocyanate Conditions
Spraying or dispensing fluids that contain isocyanates creates potentially harmful mists, vapors, and atomized
particulates.
• Read and understand the fluid manufacturer’s warnings and Safety Data Sheet (SDS) to know specific
hazards and precautions related to isocyanates.
• Use of isocyanates involves potentially hazardous procedures. Do not spray with this equipment unless you
are trained, qualified, and have read and understood the information in this manual and in the fluid
manufacturer’s application instructions and SDS.
• Use of incorrectly maintained or mis-adjusted equipment may result in improperly cured material.which
could cause off gassing and offensive odors. Equipment must be carefully maintained and adjusted
according to instructions in the manual.
• To prevent inhalation of isocyanate mists, vapors and atomized particulates, everyone in the work area
must wear appropriate respiratory protection. Always wear a properly fitting respirator, which may include
a supplied-air respirator. Ventilate the work area according to instructions in the fluid manufacturer’s SDS.
• Avoid all skin contact with isocyanates. Everyone in the work area must wear chemically impermeable
gloves, protective clothing and foot coverings as recommended by the fluid manufacturer and local
regulatory authority. Follow all fluid manufacturer recommendations, including those regarding handling of
contaminated clothing. After spraying, wash hands and face before eating or drinking.
• Hazard from exposure to isocyanates continues after spraying. Anyone without appropriate personal
protective equipment must stay out of the work area during application and after application for the time
period specified by the fluid manufacturer. Generally this time period is at least 24 hours.
• Warn others who may enter work area of hazard from exposure to isocyanates. Follow the
recommendations of the fluid manufacturer and local regulatory authority. Posting a placard such as the
following outside the work area is recommended:
TOXIC FUMES
HAZARD
DO NOT ENTER DURING
SPRAY FOAM APPLICATION
OR FOR ___ HOURS AFTER
APPLICATION IS COMPLETE
DO NOT ENTER UNTIL:
DATE:
TIME:
____________
____________

Important Isocyanate (ISO) Information
10 312666W
Material Self-ignition
Keep Components A and B
Separate
Moisture Sensitivity of
Isocyanates
Exposure to moisture (such as humidity) will
cause ISO to partially cure, forming small,
hard, abrasive crystal that become suspended
in the fluid. Eventually a film will form on the
surface and the ISO will begin to gel,
increasing in viscosity.
NOTE: The amount of film formation and rate
of crystallization varies depending on the blend
of ISO, the humidity, and the temperature.
Foam Resins with 245 fa
Blowing Agents
Some foam blowing agents will froth at
temperatures above 90°F (33°C) when not
under pressure, especially if agitated. To
reduce frothing, minimize preheating in a
circulation system.
Some materials may become self-igniting if applied
too thick. Read material manufacturer’s warnings
and Safety Data Sheet (SDS).
Cross-contamination can result in cured material in
fluid lines which could cause serious injury or
damage equipment. To prevent cross-contamination:
•Never interchange component A and component
B wetted parts.
• Never use solvent on one side if it has been
contaminated from the other side.
NOTICE
Partially cured ISO will reduce performance and the
life of all wetted parts.
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere. Never
store ISO in an open container.
• Keep the ISO pump wet cup or reservoir (if
installed) filled with appropriate lubricant. The
lubricant creates a barrier between the ISO and
the atmosphere.
• Use only moisture-proof hoses compatible with
ISO.
• Never use reclaimed solvents, which may contain
moisture. Always keep solvent containers closed
when not in use.
• Always lubricate threaded parts with an
appropriate lubricant when reassembling.

ClearShot Liquid
312666W 11
Changing Materials
ClearShot Liquid
NOTICE
Changing the material types used in your equipment
requires special attention to avoid equipment damage
and downtime.
• When changing materials, flush the equipment
multiple times to ensure it is thoroughly clean.
• Always clean the fluid inlet strainers after flushing.
• Check with your material manufacturer for
chemical compatibility.
• When changing between epoxies and urethanes
or polyureas, disassemble and clean all fluid
components and change hoses. Epoxies often
have amines on the B (hardener) side. Polyureas
often have amines on the B (resin) side.
Read material MSDS to know specific
hazards and precautions related to
ClearShot Liquid.

Overall View
12 312666W
Overall View
Key:
A A Side Fluid Valve (ISO)
B B Side Fluid Valve (RESIN) (not shown)
C Front Cover Retainer
D Air Line Quick Coupler
E Breather Plug
F Fluid Housing (under cover)
H Handle
L Piston Safety Lock/Flow Selector Knob
M Gun Fluid Manifold
N Mix Chamber Nozzle
P Optional Fluid Inlets (A Side Shown)
R ClearShot Liquid Cartridge
S Fluid Inlet Swivels (A Side Shown)
T Trigger
UFrontCover
V Gun Air Whip Hose
WAirValve
X Variable Flow Adjustment Knob
Y Manifold Check Valve/Inlet Screen Housing
FIG. 1
TI11324a
A
P
T
M
H
L
D
V
W
U
N
S
C
F
E
R
X
Y

Grounding
312666W 13
Grounding
Check your local electrical code and
proportioner manual for detailed grounding
instructions.
Ground the spray gun through connection to a
Graco-approved grounded fluid supply hose.
Piston Safety Lock
Engage piston safety lock whenever you stop
spraying to avoid accidental triggering.
Engage
To engage piston safety lock, push knob in
and turn clockwise. If engaged, gun will not
actuate.
Disengage
To disengage piston safety lock, push knob in
and turn counterclockwise until it pops out.
There will be a gap between knob and gun
body.
FIG. 2
Engaged
TI11326a
FIG. 3
Disengaged
TI12240a

Remove Front Cover
14 312666W
Remove Front Cover
1. Follow Pressure Relief Procedure, page
17.
2. Ensure fluid valves A and B are closed
before turning front cover retainer (C).
Loss of Air Pressure
In event of loss of air pressure, gun will
continue to spray. To shut off gun, do one of
the following:
• Push in piston safety lock, see page 13.
• Close fluid valves A and B.
FIG. 4
TI11327a
A
C
FIG. 5
TI11327a
A

Setup
312666W 15
Setup
1. Close fluid valves A and B.
2. Connect A (ISO) and B (RESIN) fluid hoses
to fluid manifold.
3. Purge air from fluid lines using feed pump
pressure only (less than 500 psi (3.5 MPa,
35 bar)).
a. Ensure fluid valves are closed. Open
fluid manifold check valves 2 to 2-1/2
turns.
b. Open fluid valves and wait for all air to
bleed from fluid hoses.
c. Close fluid valves and retighten fluid
manifold check valves.
4. Engage piston safety lock, page 13.
5. Install ClearShot Liquid cartridge. See
ClearShot Liquid Cartridge
Installation/Removal, page 22.
6. Connect gun air whip hose (V) air valve (W)
to main air hose. Assemble fluid manifold
(M) to gun by hand, and then tighten bolt.
7. Connect air line to quick coupler (D). Turn
on air. Open air valve (W). Air should flow
from nozzle (N).
8. Apply layer of lubricant over front cover of
gun and front cover retainer, or use gun
cover to prevent overspray buildup and
ease disassembly.
FIG. 6
FIG. 7
TI11328a
TI11329a
FIG. 8
FIG. 9
TI11337a
TI11331a
N
W
D
V
M

Shutdown
16 312666W
9. Disengage piston safety lock, page 13.
10.Trigger gun to check for full mix chamber
travel and to prime ClearShot Liquid dosing
pump. See ClearShot Liquid Cartridge
Installation/Removal, page 22.
11.Engage piston safety lock, page 13.
12.Turn on proportioner.
13.Open B (RESIN) fluid valve. Then open A
(ISO) fluid valve.
14.Disengage piston safety lock, page 13.
15.Test spray onto cardboard. Adjust pressure
and temperature to get desired results.
16.The gun is now ready to spray.
Shutdown
Overnight Shutdown
1. Follow Pressure Relief Procedure, page
17.
2. See Maintenance, page 24.
FIG. 10
FIG. 11
FIG. 12
TI12240a
TI11326a
TI11333a
FIG. 13
FIG. 14
CAUTION
Air supply is required for gun actuation. Do
not disconnect gun air supply until fluid
pressure is relieved, page 17.
TI12240a
TI11334a

Pressure Relief Procedure
312666W 17
Pressure Relief Procedure
1. Engage piston safety lock, page 13.
2. Close fluid valves A and B. Leave air valve
(W) open.
3. Disengage piston safety lock, page 13.
4. Trigger gun onto cardboard or into waste
container to relieve pressure.
5. Engage piston safety lock, page 13.
FIG. 15
CAUTION
Air supply is required for gun actuation. Do
not disconnect gun air supply until fluid
pressure is relieved.
FIG. 16
TI11326a
TI11327a
A
W
FIG. 17
FIG. 18
Fluid in the hose and proportioner is still under
pressure. Follow the Pressure Relief Procedure
in the proportioner manual.
To relieve pressure in the hose manifold after the
gun is removed, place the fluid manifold over
containers, facing away from you. Ensure fluid
valves are closed. Very slowly open fluid
manifold check valves 2 to 2-1/2 turn. Under high
pressure, fluid will spray sideways from the fluid
ports.
TI12240a
TI11336a
TI11337a

Optional Hose Position
18 312666W
Optional Hose Position
Fluid inlet swivel fittings point to rear. If
desired, these positions can be changed so
hoses point downward.
1. Follow Pressure Relief Procedure, page
17. Also relieve system pressure, see
proportioner manual.
2. Disconnect air (D) and remove fluid
manifold (M).
3. Disconnect fluid hoses from inlet swivels
(A, B). Remove fluid valve assemblies.
Remove plugs from optional inlets (P).
4. Apply thread sealant to plugs (1e), elbows
(35), and male threads of fluid valve
assemblies. Install elbows (35) in optional
inlets, facing down. Install fluid valve
assemblies in elbows. Be sure to install A
fluid assembly in A side. Install plugs where
swivels had been. Torque all parts to
235-245 in-lb (26.6-27.7 N•m).
5. Connect A and B hoses to A and B swivels.
6. Attach fluid manifold. Connect air. Return
gun to service.
CAUTION
To prevent cross-contamination of gun’s
wetted parts, do not interchange A
component (isocyanate) and B component
(resin) parts.
FIG. 19
TI11330a
M
D
FIG. 20
FIG. 21
TI11329a
A
B
P
TI12085a
1e

Flat Spray Tips
312666W 19
Flat Spray Tips
1. Follow Pressure Relief Procedure, page
17.
2. Unscrew and remove front cover retainer
(C).
3. Remove front cover (U) and o-ring (2b).
Inspect o-ring.
4. Remove tip retainer (46) and tip (21).
Inspect o-ring (47).
5. Remove fluid housing (F). Loosen A and B
side seals. Slide flat mix chamber (14) out
rear of fluid housing.
NOTE: If tip is stuck, pry off with small screw-
driver or pull off with pliers. Tip is hardened to
resist damage.
6. To clean, soak tip in compatible solvent.
Clean gently with tip cleanout tool 15D234;
page 56 for details of tool.
7. Reassemble in reverse order.
a. Insert mix chamber (14) from rear of
fluid housing.
b. Tighten A and B side seals on fluid
housing.
c. Assemble o-ring (47), tip (21), and tip
retainer (46) to front of mix chamber
(14).
8. Reposition tip horizontally or vertically, or
install different tip size.
NOTE: Tips marked on back with last three
digits of part number. See Flat Tip Kits, page
50.
9. Reinstall fluid housing (F) to handle.
10.Reinstall front cover (U) and front cover
retainer (C).
FIG. 22
C
U
F
TI12087a
14
47
21
46
FIG. 23
TI12088a
TI2648a

Variable Flow
20 312666W
Variable Flow
Operation
NOTE: The variable flow feature is designed to
provide immediate adjustment between a full
flow pattern (determined by mix chamber size)
and a user defined reduced flow pattern.
Reduced Flow
To spray a reduced flow pattern, push in and
turn flow selector knob to variable flow
position. See FIG. 25.
Full Flow
To return to a full flow pattern, push in and turn
flow selector knob to full flow position. See FIG.
25.
Change Variable Flow
Adjustment Knob
1. Turn air valve (W) OFF.
2. Turn flow selector knob to variable flow
position. See FIG. 25.
FIG. 24
TI12240a
Safety
Stop/Flow
Selector
Knob
Variable
Flow
Adjustment
Knob
FIG. 25
TI11345a
Safety
Stop/Flow
Selector
Knob
Variable
Flow
Adjustment
Knob
OFF
Full Flow
Variable
Flow
