Graco Magnum SR7 Instruction Manual

Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001
311984A
Operation
SR7 Airless Sprayer
- For portable spray applications of architectural paints and coatings -
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this
manual. Save these instructions.
ti9193a
ti9208a
Model: 261810, Series A
Specifications
This equipment is not intended for use with flammable or
combustible materials used in places such as cabinet shops
or other “factory” or fixed locations. If you intend to use this
equipment in this type of application, you must comply with
NFPA33 and OSHA requirements for the use of flammable
and combustible materials.
ti9338a
Maximum Working Pressure: 3000 psi (21 MPa, 207 bar)
Includes:
Gun: SG10
Hose: 1/4 inch x 35-ft. (6.4 mm x 11 m)
Dispense Rate: 0.31 gpm (1.17 lpm)
The manual provided with this
sprayer contains
English, Español and Français.
Visit our website;
http://MAGNUM.Graco.com

Warnings
2311984A
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. Refer
back to these warnings. Additional, product specific warnings may be found throughout the body of this manual
where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent
fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static arc).
• Sprayer generates sparks. When flammable liquid is used in or near the sprayer or for flushing or
cleaning, keep sprayer at least 20 feet (6 m) away from explosive vapors.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.
• Ground equipment and conductive objects in work area. Read Grounding instructions.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment
until you identify and correct the problem.
• Keep a fire extinguisher in the work area.
ELECTRIC SHOCK HAZARD
Improper grounding, setup, or usage of the system can cause electric shock.
• Turn off and disconnect power cord before servicing equipment.
• Use only grounded electrical outlets.
• Use only 3-wire extension cords.
• Ensure ground prongs are intact on sprayer and extension cords.
• Do not expose to rain. Store indoors.
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like just
a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Engage trigger lock when not spraying.
• Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning,
checking, or servicing equipment.

Warnings
311984A 3
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. Read Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. Read Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco
replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your Graco distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or overbend hoses or use hoses to pull equipment.
• Comply with all applicable safety regulations.
• Keep children and animals away from work area.
• Do not operate the unity when fatigued or under the influence of drugs or alcohol.
PRESSURIZED ALUMINUM PARTS HAZARD
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids
containing such solvents in pressurized aluminum equipment. Such use can cause serious chemical
reaction and equipment rupture, and result in death, serious injury, and property damage.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDS’s to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic
fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eye wear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
•Gloves
• Hearing protection
WARNING

Installation
4311984A
Installation
Grounding and Electric
Requirements
Sprayer must be grounded. Grounding reduces the risk
of static and electric shock by providing an escape wire
for electrical current due to static build up or in the event
of a short circuit.
• The 120 Vac sprayers
require a 120 Vac, 60
Hz, 15A circuit with a
grounding receptacle.
• The 230 Vac sprayers
require a 230 Vac, 50
Hz, 10A circuit with a
grounding receptacle.
• Never use an outlet that is not grounded or an
adapter.
• Do not use the sprayer if the
electrical cord has a damaged
ground prong.
• Only use an extension cord with
an undamaged 3-prong plug.
Recommended extension cords
for use with this sprayer:
• 50 ft (15.0 m) 16 AWG (1.0 mm2)
• 100 ft (30.0 m) 14 AWG (1.5 mm2)
Spray gun:ground through connection to a properly
grounded fluid hose and pump.
Fluid supply container:follow local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface such as concrete. Do not place the pail on a
nonconductive surface, such as paper or cardboard,
which interrupts grounding continuity.
Grounding the metal pail: connect a ground wire to the
pail by clamping one end to pail and other end to ground
such as a water pipe.
Maintaining grounding conti-
nuity when flushing or reliev-
ing pressure: hold metal part of
the spray gun firmly to the side
of a grounded metal pail, then
trigger the gun.
Thermal Overload
Motor has a thermal overload switch to shut itself down
if overheated. If unit overheats, allow approximately 45
minutes for unit to cool. Once cool, switch will close and
unit will restart.
WLD
WLD
Smaller gauge or longer extension cords may
reduce sprayer performance.
To reduce risk of injury from motor starting unexpect-
edly when it cools, always turn power switch OFF if
motor shuts down.
ti9207a

Component Identification
311984A 5
Component Identification
A Power Switch Turns sprayer ON and OFF.
B Prime/Spray Valve • PRIME position (pointing down) directs fluid to prime tube.
• SPRAY position (pointing forward) directs pressurized fluid to paint
hose.
• Automatically relieves system pressure in overpressure situations.
C Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid pressure
in pump, hose and spray gun.
C1 Setting Indicator To select function, align symbol on pressure control knob with setting indi-
cator, page engage trigger lock.
D Pump fluid outlet fitting Threaded connection for paint hose.
EInstaClean™fluid filter • Filters fluid coming out of pump to reduce tip plugging and improve
finish.
• Self cleans only during pressure relief.
FPower-Piston™Pump (behind Easy
Access door)
Pressurizes fluid and delivers it to paint hose. Easy Access door permits
quick removal of outlet valve.
G suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Sample Spray Shield Introduces benefits of a spray shield. Blocks paint from surfaces you do
not want to spray.
L Inlet screen Prevents debris from entering pump.
M Storage compartment Provides onboard storage for spray tips and/or tools.
N Quick Release Latch Collapses handle for compact or hanging storage.
P Roller tray/Gun holder/Hose wrap Removable tray can also be used to clean paint roller.
R Paint hose Transports high-pressure fluid from pump to spray gun.
Q Roller attachment Used with spray gun to apply coating directly to surfaces.
S Airless spray gun Dispense fluid through spray tip or roller attachment.
T Tip guard Reduces risk of fluid injection injury.
U Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and controls fluid
flow according to hole size.
• Reverse unclogs plugged tips without disassembly.
V Gun trigger safety lever (page 7) Prevents accidental triggering of spray gun.
WSpillGuard™Tray Protective tray to set sprayer and paint pail on during operation.
X Practice spray board Instructs user on how to perform basic spraying techniques and provides
surface to practice techniques prior to spraying surfaces.
Y Power Flush attachment Connects garden hose to suction tube for power flushing water-base flu-
ids.
Z Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.

Component Identification
6311984A
/&&
/.
N
J
W
M
R
S
T
U
A
B
C
E
D
F
G
L
H
P
Q
X
ti9951a
ti9950a
ti9208a
ti9213a
ti9338a
ti9312a
Y
C1
Z
ti9257a
ti9763a
V

Operation
311984A 7
Operation
Trigger Lock
Always engage the trigger lock when you stop spraying
to prevent the gun from being triggered accidentally by
hand or if dropped or bumped.
Pressure Relief Procedure
Follow this Pressure Relief Procedure whenever you
stop spraying and before cleaning, checking, servicing,
or transporting equipment.
1. Turn power switch OFF and unplug
power cord.
2. Turn Prime/Spray valve to
PRIME to relieve pressure.
3. Hold gun firmly to side
of pail. Trigger the gun
to relieve pressure.
4. Engage trigger lock.
If you suspect the spray tip or hose is clogged or that
pressure has not been fully relieved after following the
steps above, VERY SLOWLY loosen tip guard retaining
nut or hose end coupling to relieve pressure gradually,
then loosen completely. Clear hose or tip obstruction.
Read Unclogging Spray Tip, page 10.
ti8923a
Trigger Locked Trigger Unlocked
ti8922a
WLD
Leave Prime/Spray valve in the PRIME position
until you are ready to spray again.
ti9346a
ti9207a
ti8908a ti8923a
TIA
Pressure Control Knob Settings
High Pressure
Spray
Low Pressure
Spray
Prime/
Clean
Rolling
To select function, align symbol on pressure control knob with setting indicator on sprayer.

Setup
8311984A
Setup
1. Unscrew tip and guard assembly
from gun.
2. Uncoil hose and connect one
end to gun.Use two
wrenches to tighten securely.
3. Connect other end of hose
to sprayer.
4. Turn OFF power switch.
5. Turn Pressure Control Knob all
the way left (counter-clock-
wise) to minimum pressure.
Prime and Flush Storage Fluid
Before you use your sprayer for the first time or begin a
new spraying project, you need to prime the sprayer and
flush the storage fluid out of the sprayer.
Oil- or Water-based Materials
1. Make sure power switch is
OFF and sprayer is unplugged.
If hose is already connected, make sure connec-
tions are tight.
ti9204a
ti9203a
ti9351a
WLD
ti9344a
• When spraying water-based materials, flush
the system thoroughly with water.
• When spraying oil-based materials, flush the
system thoroughly with mineral spirits or com-
patible, oil-based flushing solvent.
• To spray water-based materials after spray-
ing oil-based materials, flush the system thor-
oughly with water first. The water flowing out of
prime tube should be clear and solvent-free
before you begin spraying the water-based
material.
• To spray oil-based materials after spraying
water-based materials, flush the system thor-
oughly with mineral spirits or a compatible
oil-based flushing solvent first. The solvent
flowing out of the prime tube should not contain
any water.
• When flushing with solvents, ground pail and
gun. Read Grounding and Electric Require-
ments, page 4.
• To avoid fluid splashing back on your skin or
into your eyes, always aim gun at inside wall of
pail.
WLD

Setup
311984A 9
2. Separate prime/prime tube
(smaller) from suction tube (larger).
3. Place prime tube in waste pail.
4. Submerge suction tube in
water or flushing solvent.
5. Turn Prime/Spray Valve to
PRIME.
6. Plug sprayer in a grounded outlet.
7. Turn power switch ON.
8. Align setting indicator with
Prime/Clean setting on pressure
control knob until pump starts,
page 7.
9. When sprayer starts pumping, flushing solvent and
air bubbles will be purged from system. Allow fluid to
flow out of prime tube, into waste pail for 30 to 60
seconds.
10. Turn power switch OFF.
11. Transfer suction tube to paint
pail and submerge suction
tube in paint.
12. Turn power switch ON.
13. When you see paint coming
out of prime tube:
a. point gun into waste pail,
b. unlock gun trigger lock,
c. pull and hold gun trigger,
d. turn Prime/Spray valve to
SPRAY.
14. Continue to trigger gun into waste pail until you see
only paint coming out of gun.
15. Release trigger. Engage trigger
lock.
16. Transfer prime tube to paint pail
and clip prime tube to suction
tube.
17. If spraying, install tip and guard on gun, page 10
and see Spraying Techniques, page 10.
If rolling, roller setup and Rolling Techniques, begin
on page 14.
TIA
ti9652a
ti9651a
ti9346a
TIA
ti9343a • Motor stopping indicates pump and hose are
primed with paint.
• If motor continues to run the sprayer is not
properly primed. To reprime repeat step 8.
WLD
ti9653a
TIA
ti8922a
ti9345a
ti8923a

Setup
10 311984A
Install Tip and Guard
1. Engage trigger lock.
2. Verify tip and guard parts are assembled in order as
shown below.
3. Screw tip and guard assembly on
gun. Tighten retaining nut.
Spraying Techniques
Preventing Excessive Tip Wear
• Spray should be atomized (evenly distributed, no
gaps at edges). Start at low pressure setting,
increase pressure a little at a time until you see a
good spray pattern, without tails.
• Spray at lowest pressure that atomizes paint.
• If maximum sprayer pressure is not enough for a
good spray pattern, tip is too worn. See Reversible
Spray Tip Selection Chart, page 12.
Adjust Spray Pressure
This sprayer is set up for most airless spraying applica-
tions. Details on tip selection, tip wear, coat thickness,
etc. are provided on page 11.
Align setting indicator with function symbol on Pressure
Control knob, page 7.
• Turning knob to right (clockwise), increases
pressure at gun.
• Turning it left (counter-clockwise), decreases
pressure.
• General spraying instructions are provided in
Getting Started with Basic Spraying Techniques
section of this manual, page 13.
ti8923a
retaining nut
black rubber gasket and
guard
tip
ti8911a
metal seat
TIA
Use tip to align seat
in guard.Tip must be pushed
all the way into guard
ti9574a
ti9255a
If tails persist when spraying at the highest
pressure, a smaller tip is needed or the material
may need to be thinned.
Motor only runs when gun is triggered. Sprayer is
designed to stop pumping when gun trigger is
released.
GOOD
SPRAYPATTERN
TAILSGAPS
ATEDGES
PRESSURE
TOOLOW
TIA

Setup
311984A 11
Unclogging Spray Tip
To avoid fluid splashback:
• Never pull gun trigger when arrow-shaped handle is
between SPRAY and UNCLOG positions.
• Tip must be pushed all the way into guard.
1. To UNCLOG tip obstruction, lock
trigger lock.
2. Point arrow-shaped handle back-
ward to UNCLOG position.
3. Aim gun at piece of scrap or cardboard.
4. Unlock trigger lock. Pull trigger to
clear clog.
5. When obstruction is cleared, lock
trigger lock and rotate
arrow-shaped handle back to
SPRAY position.
Point the arrow-shaped handle on the spray tip forward
to SPRAY and backward to UNCLOG obstructions.
Tip Selection
Selecting Tip Hole Size
Tips come in a variety of hole sizes for spraying a range
of fluids. Your sprayer includes an 0.015 in (0.38 mm) tip
for use in most spraying applications. Use the following
table to determine the range of recommended tip hole
sizes for each fluid type. If you need a tip other than the
one supplied, see the Reversible Tip Selection Chart
on page 12.
HINTS:
• As you spray, the tip wears and enlarges. Starting
with a tip hole size smaller than the maximum will
allow you to spray within the rated flow capacity of
the sprayer.
• Maximum tip hole size supported by the sprayer is
0.017 in. (0.43 mm).
ti8923a
ti9048a
to8922a
ti9049a
Coatings
Tip Hole Size Stains Enamels Primers Interior
paints Exterior paints
0.011 in. (0.28 mm) ✔
0.013 in. (0.33 mm) ✔✔✔✔
0.015 in. (0.38 mm) ✔✔✔✔
0.017 in. (0.43 mm) ✔✔✔

Setup
12 311984A
Choosing the Correct Tip for the
Job
Consider coating and surface to be sprayed. Make sure
you use best tip hole size for that coating and best fan
width for that surface.
Tip Hole Size
Tip hole size controls flow rate - the amount of paint that
comes out of the gun.
HINTS:
• Use larger tip hole sizes with thicker coatings and
smaller tip hole sizes with thinner coatings.
• Maximum tip hole sizes supported by sprayer is
0.017 in. (0.43 mm).
• Tips wear with use and need periodic replacement.
Fan Width
Fan width is the size of the spray pattern, which deter-
mines the area covered with each stroke. Narrower fans
deliver a thicker coat, and wider fans deliver a thinner
coat.
HINTS:
• Select a fan width best suited to the surface being
sprayed.
• Wider fans allow provide better coverage on broad,
open surfaces.
• Narrower fans provide better control on small, con-
fined surfaces.
Understanding Tip Number
The last three digits of tip number (i.e.: 221413) contain
information about hole size and fan width on surface
when gun is held 12 in. (30.5 cm) from surface being
sprayed.
Reversible Tip Selection Chart
Example: For an 8 to 10 in. (203 to 254 mm) fan width
and 0.013 (0.33 mm) hole size, order Part No. 221413.
Tip Part
No.
Fan Width 12 in.
(305 mm) from
surface Hole Size
221311 6 - 8 in.
(152 - 203 mm)
0.011 in.
(0.28 mm)
221411 8 - 10 in.
(203 - 254 mm)
0.011 in.
(0.28 mm)
221313 6 - 8 in.
(152 - 203 mm)
0.013 in.
(0.33 mm)
221413 8 - 10 in.
(203 - 254 mm)
0.013 in.
(0.33 mm)
221415 8 - 10 in.
(203 - 254 mm)
0.015 in.
(0.38 mm)
221515 10 - 12 in.
(254 - 305 mm)
0.015 in.
(0.38 mm)
221417 8 - 10 in.
(203 - 254 mm)
0.017 in.
(0.43 mm)
221517 10 - 12 in.
(254 - 305 mm)
0.017 in.
(0.43 mm)
TIA
First digit when doubled
= approximate
fan width 413 tip has
8-10 in.
fan width
413 tip has a
0.013 in.
hole size
Last two digits = tip hole size in thousands of an inch

Getting Started With Basic Techniques
311984A 13
Getting Started With Basic Techniques
Use the Practice Spray Board to practice these basic spraying techniques before you begin spraying the surface.
• Hold gun 12 in. (30 cm) from surface and aim
straight at surface. Tilting gun to direct spray angle
causes an uneven finish.
• Flex wrist to keep gun pointed straight. Fanning gun
to direct spray at angle causes uneven finish.
Triggering Gun
Pull trigger after starting stroke. Release trigger before
end of stroke. Gun must be moving when trigger is
pulled and released.
Aiming Gun
Aim tip of gun at bottom edge of previous stroke, over-
lapping each stroke by half.
Spray Shield
Use Sample Spray Shield to help shield ceilings and floor
boards from spray. The Sample Spray Shield is intended
to introduce you to the benefits of a spray shield. Visit
your local paint supplier for larger spray shield solutions.
1. Apply a layer of masking tape
approximately 4 inches wide to
edge of spray shield. Change tape
when paint starts to accumulate
on spray shield.
2. Grasp shield firmly through han-
dle grip with one hand.
3. When spraying, use shield
to prevent paint from getting
on ceiling or adjoining walls.
4. Move the spray shield as
you move the gun to protect
surface.
TIA
12 in.
(30 cm)
even
finish
thick
thin
uneven
finish
TIA
even finish thin thick thin
TIA
TIA
tape
ti9313a
ti9573a

Rolling
14 311984A
Rolling
Setup
• Follow Priming instructions, beginning on page 8,
prior to assembling roller.
1. If installed, remove tip and guard assembly from
gun.
2. Make sure gasket is in place in bottom of roller
frame.
3. Attach pressure roller
assembly to gun.
4. Rest roller on flat surface
and align gun with roller.
Tighten nut with wrench
while keeping gun and roller
aligned.
5. Turn Pressure Control Knob to
ROLL.
6. Unlock gun trigger safety. Trigger
gun. Roll surface until paint is
fully dispersed on roller. This may
take a minute.
7. Increase pressure only if triggering gun does not
supply enough paint for your rolling speed.
8. Whenever you stop painting, relieve pressure,
page 7 and elevate roller end of extension tube to
prevent paint from draining out.
9. Flush the pump, gun and pressure roller immedi-
ately after each use to prevent paint from drying in
the pressure roller and damaging it. See Shutdown
and Cleaning, beginning on page 16.
ti9339a
ti9650a
• Trigger gun briefly only when you need more
paint.
• The best operating pressure is the lowest pres-
sure that provides an even paint supply to the
roller. This typically does not exceed 300 psi
(2.1 MPa, 21 bar).
ti8922a

Rolling
311984A 15
Rolling Techniques
1. Rolling vertically, roll out
the letter “M”.
2. Cross roll, horizontally,
to spread paint.
3. Finish with light, verti-
cal strokes until the entire area
has been covered evenly.
Ceilings, Walls and Woodwork
1. Ceilings: Using a paint
brush, apply a starting row of
paint approximately the width
of your paint brush where the
walls and ceiling meet.
2. With the roller apply paint to
the ceiling, working the short
way of the room and applying
as wide a strip as possible.
1. Walls and Woodwork:
Using a brush, paint
woodwork first. Apply a
starting row of paint
approximately the width of
the paint brush around the
woodwork and where the walls meet the ceiling.
2. With the roller, apply paint
to the walls, following the
Rolling Techniques,
page 15.
tiFig2
tiFig3
tiFig4
tiFig5
tiFig6
tiFig7
tiFig8

Shutdown and Cleaning
16 311984A
Shutdown and Cleaning
Pail Flushing
1. Relieve pressure, page 7.
2. If you used a spray gun, remove tip and guard
assembly from gun and place in flushing fluid.
If you used a roller, leave roller assembly attached
to gun.
3. Lift suction tube and prime tube from paint pail. Let
them drain into paint pail for a while.
4. Separate prime tube (smaller) from
suction tube (larger).
5. Place waste and paint pails
side by side.
6. Place prime tube in waste pail.
7. Submerge suction tube in
water or flushing solvent.
8. Turn Pressure Control knob to
Prime/Clean setting.
9. Turn power switch ON.
10. Flush until approximately 1/3 of the flushing fluid is
emptied from the pail.
11. Turn power switch OFF.
12.
a. If you used a spray gun only,
continue Pail Flushing, Step
13.
b. If you used a roller follow roller cleanup instruc-
tions beginning on page 18.
• For short term shutdown periods (overnight to
two days) refer to Short Term Storage, page 22.
• For flushing after spraying oil-based coatings,
use compatible oil-based flushing fluid or min-
eral spirits. Read Priming and Flushing Storage
Fluid, page 8.
• For flushing after spraying water-based coat-
ings, use water. Read Priming and Flushing
Storage Fluid, page 8 or Power Flush, page 19.
TIA
ti9726a
ti9652a
ti9651a
ti9718A
TIA
WLD

Shutdown and Cleaning
311984A 17
13. To preserve paint in hose:
a. Point gun into paint pail.
b. Unlock gun trigger lock.
c. Pull and hold gun trigger.
d. Turn Prime/Spray valve to
SPRAY.
e. Turn power switch ON.
f. Continue to hold gun trigger until you see paint
diluted with flushing fluid starting to come out of
gun.
14. While continuing to trigger
gun, quickly move gun to
redirect spray into waste
pail. Continue triggering
gun into waste pail until
flushing fluid dispensed
from gun is relatively clear.
15. Stop triggering gun. Engage
trigger lock.
16. Turn power switch OFF.
17. Clean InstaClean Fluid Filter, page 21.
18. Fill unit with Pump Armor™storage fluid. Read Long
Term Storage, page 22.
19. Clean gun fluid filter
(d) with water or
flushing solvent and
a brush every time
you flush the system.
Replace gun filter if
damaged.
20. Clean tip and guard with
water or flushing solvent. A
soft brush can be used to
loosen and remove dried on
material if needed.
21. Wipe paint off outside of gun using a soft cloth
moistened with water or flushing solvent.
Step 13 is for returning paint in hose back to paint
pail. One 50-ft hose holds approximately 1-quart
(1-liter) of paint.
ti8922a
ti9345a
TIA
ti9725a
4
ti8923a
WLD
dti9257a
ti9671a

Shutdown and Cleaning
18 311984A
Cleaning Roller
1. Relieve Pressure, page 7.
2. Remove roller cover (a) and core (b) from roller
frame (c) as follows:
a. Using your thumb, press clip (d) to release roller
and core into waste pail.
b. Remove cap (e) from core (b).
c. Remove roller cover (a) from core (b).
3. Clean roller cover, cap and core with water or a
compatible flushing solvent for oil-based materials.
4.
a. Place roller frame in paint pail. Be sure holes in
roller frame are facing inside paint pail.
b. Unlock gun trigger lock.
c. Pull and hold gun trigger.
d. Turn Prime/Spray valve to
SPRAY.
e. Turn power switch ON.
5. Move roller frame to waste pail. Trigger gun to flush
hose, roller frame and gun.
6. Continue triggering gun until flushing fluid is gone
from pail.
7. Stop triggering gun. Engage
trigger lock.
8. Turn power switch OFF.
9. Clean InstaClean Fluid Filter, page 21.
10. Fill unit with Pump Armor™storage fluid. Read Long
Term Storage, page 22.
11. Clean gun fluid filter
(d) with water or
flushing solvent and
a brush every time
you flush the system.
Replace gun filter if
damaged.
12. Wipe paint off outside of gun using a soft cloth
moistened with water or flushing solvent.
Step 4 is for returning paint in hose back to paint
pail.
a
b
c
e
d
ti9370a
ti8922
a
ti9345a
TIA
ti8923a
WLD
d
ti9257a

Shutdown and Cleaning
311984A 19
Power Flush
Power flushing is a faster method of flushing. It can only
be used after spraying water-based coatings.
1. Relieve pressure, page 7.
2. If you used a spray gun, remove tip and guard
assembly from gun and place in flushing fluid.
If you used a roller, leave roller assembly attached
to gun.
3. Place waste and paint pails
side by side.
4. Lift suction tube and prime tube from paint pail. Let
them drain into paint for a while.
5. Place suction and prime tube in waste pail.
6. Turn pressure control knob to
Prime/Clean setting.
7. Screw power flush attachment
to garden hose. Close valve.
8. Turn on water. Open valve. Rinse
paint off suction tube, prime tube
and inlet screen.
9. Turn lever to close power flush attachment.
10. Unscrew inlet screen from suction
tube. Place inlet screen in waste pail.
11. Connect garden hose to suction tube
with Power Flush attachment. Leave
prime tube in waste pail.
12. Turn power switch ON.
13. Open lever on Power Flush
attachment.
14. Circulate water through sprayer, into waste pail, for
20 seconds.
15. Turn power switch OFF.
16.
a. If you used a spray gun only,
continue Power Flushing, Step
17.
b. If you used a roller follow roller cleanup instruc-
tions beginning on page 18.
ti9726a
ti9718a
ti94143a
ti9527a
TIA
TIA
TIA
TIA
OPEN
WLD

Shutdown and Cleaning
20 311984A
17. To preserve paint in hose:
a. Point gun into paint pail.
b. Unlock gun trigger lock.
c. Pull and hold gun trigger.
d. Turn Prime/Spray valve to
SPRAY.
e. Turn power switch ON.
f. Continue to hold gun trigger until you see paint
diluted with water starting to come out of gun.
18. While continuing to trigger
gun, quickly move gun to
redirect spray into waste
pail. Continue triggering gun
into waste pail until water
coming out of gun is
relatively clear.
19. Stop triggering gun. Engage
trigger lock.
20. Turn power switch OFF.
21. Turn off garden hose. Close
Power Flush attachment.
22. Unscrew Power Flush attachment
from suction tube.
23. Clean InstaClean Fluid Filter.
24. Fill unit with Pump Armor™storage
fluid. Read Long Term Storage,
page 22.
25. Clean gun fluid filter
(d) with water or
flushing solvent and
a brush every time
you flush the system.
Replace gun filter if
damaged.
26. Clean tip and guard with
water or flushing solvent. A
soft brush can be used to
loosen and remove dried on
material if needed.
27. Wipe paint off outside of gun using a soft cloth
moistened with water or flushing solvent.
Step 17 is for returning paint in hose back to paint
pail. One 50-ft (15-m) hose holds approximately
1-quart (1-liter) of paint.
ti8922a
ti9345a
TIA
ti9745a
ti8923a
WLD
ti9413a
TIA
dti9257a
ti9671a
