Graco XTR 7 User manual

312145K
EN
Instructions, Parts
XTR™5 and XTR™7
Airless Spray Gun
For use with protective coating materials.
XTR 5
5000 psi (35 MPa, 345 bar) Maximum Working Pressure
XTR 7
7250 psi (50 MPa, 500 bar) Maximum Working Pressure
See page Parts, page 14, for model information.
Important Safety Instructions
Read all warnings and instructions in this
manual and in your sprayer instruction
manual before using the equipment. Save
all instructions.
Important Medical Information
Read the medical alert card provided with
the gun. It contains injection injury
treatment information for a doctor. Keep it
with you when operating the equipment.
ti5045b
II 2 G Ex h T6 Gb

2312145K
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . . 6
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
System Requirements . . . . . . . . . . . . . . . . . . . . . . . 7
Gun Trigger Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Spray Tip Installation . . . . . . . . . . . . . . . . . . . . . . . 8
RAC Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Flat Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adjusting Spray Pattern . . . . . . . . . . . . . . . . . . . 9
Cleaning Tips/Clearing Clogs . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning and Replacing Filter . . . . . . . . . . . . . . 10
Cleanup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Trigger Removal . . . . . . . . . . . . . . . . . . . . . . . . 11
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Test Gun Before Using . . . . . . . . . . . . . . . . . . . 12
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
XTR5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
XTR7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Technical Specifications . . . . . . . . . . . . . . . . . . . . 19
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 20
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 20

Warnings
312145K 3
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks.
When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this
manual where applicable.
WARNING
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like
just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not spray without tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or solvent
flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well-ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.

Warnings
4312145K
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PRESSURIZED ALUMINUM PARTS HAZARD
Use of fluids that are incompatible with aluminum in pressurized equipment can cause serious chemical
reaction and equipment rupture. Failure to follow this warning can result in death, serious injury, or
property damage.
• Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or
fluids containing such solvents.
• Do not use chlorine bleach.
• Many other fluids may contain chemicals that can react with aluminum. Contact your material supplier
for compatibility.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled or
swallowed.
• Read Safety Data Sheets (SDSs) for handling instructions and to know the specific hazards of the
fluids you are using, including the effects of long-term exposure.
• When spraying, servicing equipment, or when in the work area, always keep work area well-ventilated
and always wear appropriate personal protective equipment. See PERSONAL PROTECTIVE
EQUIPMENT warnings in this manual.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
BURN HAZARD
Equipment surfaces and fluid that is heated can become very hot during operation. To avoid severe
burns:
• Do not touch hot fluid or equipment.
WARNING

Warnings
312145K 5
RECOIL HAZARD
Gun may recoil when triggered. If you are not standing securely, you could fall and be seriously injured.
PERSONAL PROTECTIVE EQUIPMENT
Always wear appropriate personal protective equipment and cover all skin when spraying, servicing
equipment, or when in the work area. Protective equipment helps prevent serious injury, including
long-term exposure; inhalation of toxic fumes, mists or vapors; allergic reaction; burns; eye injury and
hearing loss. This protective equipment includes but is not limited to:
• A properly fitting respirator, which may include a supplied-air respirator, chemically impermeable
gloves, protective clothing and foot coverings as recommended by the fluid manufacturer and local
regulatory authority.
• Protective eyewear and hearing protection.
WARNING

Pressure Relief Procedure
6312145K
Pressure Relief
Procedure
Follow the Pressure Relief Procedure whenever
you see this symbol.
1. Engage the trigger lock.
2. Shut off the pump.
3. Disengage the trigger lock.
4. Hold a metal part of the gun firmly to a grounded
metal pail. Trigger the gun to relieve pressure.
5. Engage the trigger lock.
6. Open the fluid drain valve over a waste container
(see System Requirements, page 7). Leave drain
valve open.
If pressure is not fully relieved:
• Spray tip is clogged. For RAC tip, see Cleaning
Tips/Clearing Clogs, page 9. For flat tip, slowly
loosen tip guard retaining nut to relieve pressure.
Remove and clean the tip.
• Hose is clogged. Slowly loosen hose end coupling
to relieve pressure. Clean the hose obstruction.
Grounding
Check your local electrical code and pump or sprayer
manual for detailed grounding instructions.
Spray gun: ground through connection to a properly
grounded fluid hose and pump.
Fluid hose: use only electrically conductive hoses with
a maximum of 500 ft. (150 m) combined hose length to
ensure grounding continuity. Check electrical resistance
of hoses. If total resistance to ground exceeds 29
megohms, replace hose immediately.
Fluid supply container: follow local code.
Object being sprayed: follow local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface. Do not place the pail on a nonconductive
surface, such as paper or cardboard, which interrupts
grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the spray
gun/dispense valve firmly to the side of a grounded
metal pail, then trigger the gun/valve.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing
fluid and moving parts, follow the Pressure Relief
Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes to
ignite or explode. Grounding provides an escape wire
for the electric current.

System Requirements
312145K 7
System Requirements
• Install a bleed-type master air valve on a pneumatic
pump air supply line to relieve air trapped between
this valve and pump after air regulator is shut off.
Trapped air can cause the pump to cycle
unexpectedly.
• Install a fluid drain valve between the pump and gun
to relieve pressure in displacement pump, hose, and
gun. Triggering to relieve pressure may not be
sufficient. See the Pressure Relief Procedure,
page 6.
Gun Trigger Lock
To prevent injury when the gun is not in use, always
engage the gun’s trigger lock if unit is being shut
down or left unattended. A wallet-sized warning card
with important injection treatment information is
included with the gun. Additional cards are available
at no charge. Provide a card to all operators.
The trigger lock must move freely, and easily snap
into the locked position. If the trigger lock is damaged
or movement is restricted, replace with new trigger kit
(16) immediately.
ti5049b ti5048b
Trigger Locked
(no spray)
Trigger Unlocked
(spray)

Spray Tip Installation
8312145K
Spray Tip Installation
RAC Tip
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Snap gasket (20b) on fluid seal (20a). Use tool (A)
to insert gasket and seal into housing, seal first. Tip
the tool to remove it when seal is in place.
3. Install tip cylinder (20c) as shown. Turn 90°
counterclockwise to spray position, so the arrow
faces forward. Install assembled RAC onto spray
gun.
Flat Tip
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Insert tip (32) and gasket (30) into back of guard
(31).
3. Install the guard over the end of the gun.
To avoid serious injury from skin injection, do not put
your hand in front of the spray tip when installing or
removing the spray tip and tip guard.
YES
NO
ti10635c
20b 20a
A
ti10636b
20c
31
32
30
ti10051a

Operation
312145K 9
Operation
1. Connect a grounded fluid hose.
2. Without spray tip attached, flush the pump. Use the
lowest pressure possible.
3. Prime. Refer to the sprayer manual.
4. Follow the Pressure Relief Procedure, page 6.
5. Install the spray tip and tip guard.
6. RAC tips only: In spray position, arrow on tip
cylinder (20c) faces forward.
7. Hold the gun perpendicular and approximately 12
inches (304 mm) from the surface. Wear gloves if
the fluid temperature exceeds 110°F (43°C).
8. Move the gun first, then pull the gun trigger to spray
onto test paper.
a. Adjust the fluid pressure until spray is
completely atomized.
b. If adjusting the pressure does not give a good
spray pattern, follow Pressure Relief
Procedure, page 6, then try another tip size.
9. Trigger the gun full-open or full-close.
Adjusting Spray Pattern
The spray tip orifice and spray angle determine pattern
coverage and size. When you need more coverage, use
a larger spray tip rather than increasing fluid pressure.
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Loosen tip guard retaining nut.
3. Align the guard horizontally to spray a horizontal
pattern. Align guard vertically to spray a vertical
pattern.
4. Tighten the nut.
Cleaning Tips/Clearing Clogs
NOTE: Clean the tip guard at the end of each workday.
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Clean the spray tip.
a. RAC tips: Rotate tip 180° so arrow on tip
cylinder (20c) faces backward. Disengage the
trigger lock. Trigger the gun into a pail or onto
the ground to remove clog. Engage the trigger
lock. Rotate tip 180° back to spray position.
b. Flat tips: Remove tip and clean with a
solvent-soaked brush.
3. If the RAC tip is still clogged:
a. Shut off sprayer and disconnect power source.
b. Open the fluid drain valve (see System
Requirements, page 7) to relieve pressure.
c. Remove and clean the spray tip.
20c
ti11482a
20c
ti11483a

Maintenance
10 312145K
Maintenance
Flushing
Flush the pump and gun before fluid can dry in it. If
available, use flushing procedure provided in your pump
manual instead of this procedure.
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Remove the spray tip and guard from gun. Clean
with solvent.
3. Put the pump intake in a grounded pail of
compatible solvent.
4. Start the pump at its lowest pressure.
5. Disengage trigger lock, then trigger the gun into the
paint pail. When solvent appears, release trigger.
6. Trigger the gun into solvent pail. Circulate fluid until
the system is thoroughly flushed.
7. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
Cleaning and Replacing Filter
(Not applicable for XTR510, XTR706, and
17V677)
1. Follow the Pressure Relief Procedure, page 6.
Engage the trigger lock.
2. Disconnect the trigger guard from the gun body by
pushing up on the guard hook and pulling it out of
the notch.
3. The trigger guard beneath the gun handle can then
be used as a wrench to loosen the nut.
4. When the alignment notches are no longer
engaged, use your hand to twist the handle and
remove it from the gun head.
5. Remove the filter.
6. Clean the filter using a soft brush.
7. Replace the filter.
8. Apply a light coating of grease to the threads and
then attach.
9. Use the trigger guard to tighten the nut.
10. Reattach the trigger guard to the gun.
Cleanup
Flush the gun after each work shift and store in a dry
location. Do not leave the gun or any parts in water or
cleaning solvents.
Failure to clean or replace the filter or damaged
handle bore can result in serious injury.
Before performing any maintenance on the gun, read
all warnings in this manual and relieve pressure.
ti5052a
ti5054a
