Graham Field Lumex LCMP100 User manual

LCMP100 : PUMP, SELECT SERIES CONVERTIBLE
MATTRESS SYSTEM; OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE USE
LCMP100-INS-LAB-RevB19 1
SAFETY GUIDELINES - PLEASE READ BEFORE USE
WARNING: Important: Read and understand these instructions before using the
pump. Ensure that the pump is used as described in the following paragraphs before
use. If you do not understand any part of these warnings, cautions or instructions,
contact a healthcare professional for direction in the use of this product. If the pump
is not properly used, personal injury and/or property damage could result.
WARNING: If components are damaged or missing, contact your GF authorized
distributor immediately. DO NOT use substitute parts.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or
injury caused by improper installation, assembly or use of this product.
INTENDED USE
The Lumex Select Series Convertible Mattress System Pump is designed to aid in the
treatment and prevention of pressure ulcers while optimizing user comfort.
OPERATION
 DANGER:DONOTusethepumpinthepresenceofammablematerialsor
chemicals. This could cause an explosion.
DANGER: There are no serviceable parts in the pump. DO NOT attempt to open it;
electric shock could result.
WARNING: Read the user manual included with the mattress system before using the
pump, and refer to it if you have questions about this product's use.
1. Place the pump on a at horizontal surface or suspend it on the end of bed frame with
the built-in hanger.

LCMP100-INS-LAB-RevB19 2
1.770.368.4700
Information contained herein is subject to change.
The most current and complete product information can be found on our website.
www.grahameld.com
© 2017, GF Health Products, Inc. All Rights Reserved.
Lumex is a trademark of GF Health Products, Inc.
GF Health Products, Inc. is an ISO 13485 Certied Company.
Manufactured for GF Health Products, Inc.
Made in Taiwan
2. Place the air mattress on top of the bed mattress. Ensure the air mattress lies completely
at without any kinks. Place "FOOT END" of air mattress toward foot end of bed.
3. Connect air hoses to pump and air mattress — hose ends with ttings connect to air
mattress. Ensure air hoses are not kinked and will not be pinched by any articulated bed
mechanisms.
4. Ensure green Power switch is in the OFF position, then plug pump into a properly
grounded wall outlet. (Verify power to this outlet is not controlled by a wall switch).
5. Press green Power switch to the ON position. Air will begin to ow into mattress.
6. Yellow LED illuminated indicates that air pressure is low and air mattress is not fully
inated; the green LED will automatically illuminate when proper air pressure has been
reached and the air mattress is ready for patient placement.
Info: Each time the air mattress is inflated, set the Comfort Control Knob pressure to
"MAX.", after which the user can adjust the mattress to desired firmness.
MAINTENANCE AND CLEANING
Refer to user manual included with mattress system for this information.
