Graham Field intensa 420 Series User manual

420-INS-LAB-RevA20
Read this manual before installing or operating your Examination Table.
Save this manual for future use.
420 SERIES EXAMINATION TABLE
MODELS 420 / 420-DW / 420-EO
INSTALLATION AND OPERATION MANUAL

420-INS-LAB-RevA20 2
CONTENTS
1 INTRODUCTION.............................................................................................................................. 3
INTENDED USE......................................................................................................................... 3
EQUIPMENT SYMBOL KEY...................................................................................................... 4
2 SAFETY PRECAUTIONS................................................................................................................ 5
WARNINGS................................................................................................................................ 5
3 FEATURES ...................................................................................................................................... 7
EXAM TABLE COMPONENTS.................................................................................................. 7
4 HANDLING PROCEDURES............................................................................................................ 8
UNPACKING .............................................................................................................................. 8
INSPECTION.............................................................................................................................. 8
STORAGE .................................................................................................................................. 8
DISPOSAL ................................................................................................................................. 9
5 INSTALLATION ............................................................................................................................. 10
MODELS 420-DW AND 420-EO: INSTALLATION ELECTRICAL REQUIREMENTS ............ 10
MODELS 420-DW AND 420-EO: ELECTROMAGNETIC INTERFERENCE .......................... 10
LEVELING THE EXAM TABLE ............................................................................................... 10
6 OPERATION ...................................................................................................................................11
EXAM TABLE BACK ANGLE RANGE.....................................................................................11
PATIENT LEGREST AND PROCEDURE TRAY...................................................................... 12
STIRRUP OPERATION............................................................................................................ 12
PELVIC TILT OPERATION....................................................................................................... 13
7 CLEANING AND MAINTENANCE ................................................................................................ 14
CLEANING............................................................................................................................... 14
MAINTENANCE ....................................................................................................................... 15
8 SPECIFICATIONS ......................................................................................................................... 16
9 LIMITED WARRANTY................................................................................................................... 17
10 INDEX ............................................................................................................................................ 19

420-INS-LAB-RevA20 3
1 INTRODUCTION
Congratulations on your purchase of the Intensa 420 Series Examination Table. The following
pages will provide you with important safety and operating instructions on the installation and
operation of the Examination Table, as well as maintenance and warranty information. Read this
manual carefully before operating your Examination Table and refer to it as often as needed.
Consult your authorized distributor and / or healthcare professional with any questions or
concerns regarding safe and effective techniques for operating your Examination Table.
This guide covers the use of the Intensa 420 Series Examination Table. Keep in mind that the basic
safety procedures included in this manual are to be used as a guide only. You may nd it necessary
to develop your own unique methods for safely utilizing the Examination Table. Again, consult
your healthcare professionals for their recommendations and never hesitate to ask for their
assistance.
Upon receipt of the Examination Table, inspect it closely to ensure that nothing is damaged,
there are no loose or broken parts, that all Examination Table parts are in the proper place, etc.
Immediately replace any worn or broken components. Your Examination Table should receive
maintenance on a regular schedule and should be inspected frequently for proper operation.
Contact Intensa at 1.336.884.4096 with any maintenance concerns.
Info: Before attempting to install the Examination Table, refer to the section titled
“INSTALLATION” contained elsewhere in this manual. Contact Intensa at 1.336.884.4096 if
additional assistance is needed.
INTENDED USE
The Intensa 420 Series Examination Table is intended to support patients during medical
examinations. During these exams, medical professionals use adjusting mechanisms to manipulate
and position the table to provide patient support and closer examination of a portion of or the
entire patient.
Contraindications for Models 420-DW and 420-EO
 Warning:Thisequipmentisnotsuitableforuseinthepresenceofhighammable
anesthetics or mixtures thereof and may result in serious injury or death.
Warning: This equipment is not suitable for use in the presence of a highly oxygenated
atmosphere and may result in serious injury or death.
Warning: When this equipment is in use and a cauterization or high frequency surgical
device is being used, the patient must be insulated from the metal table using a
nonconductive material. Failure to do so could result in electrical shocks or burns to the
patient.

420-INS-LAB-RevA20 4
EQUIPMENT SYMBOL KEY
Symbol Meaning
Refer to Manual
Shock Hazard
Protective Earth Ground
Shipping Orientation
Maximum Weight Capacity 500 lb (317 Kg) Evenly Distributed

420-INS-LAB-RevA20 5
2 SAFETY PRECAUTIONS
IMPORTANT: Before installing or using Examination Table, read and then follow the
following safety precautions and warnings. Failure to do so could result in serious
personal injury or damage to your Examination Table.
Always consult your healthcare professional to determine safe methods most suitable for your
individual abilities. Protect yourself, your attendant and Examination Table by having it serviced
regularly. If you experience any malfunction, contact Intensa Tech Support at 1.336.884.4096
immediately, as a hazardous condition could result, causing personal injury or damage to your
Examination Table.
Periodic inspection, adjustment and replacement of worn parts are necessary to provide years of
excellent service. Refer to CARE AND MAINTENANCE section of this manual.
Maintenance MUST be performed by qualied personnel ONLY.
Signicanceofsafetystatements
Note the following special statements, used throughout this manual, and their signicance:
DANGER: Indicates a potential hazard situation or unsafe practice that, if not avoided, will
result in death or serious personal injury.
WARNING: Indicates a potential hazard situation or unsafe practice that, if not avoided,
could result in death or serious personal injury.
CAUTION: Indicates a potential hazard situation or unsafe practice that, if not avoided,
could result in minor or moderate personal injury.
sNOTICE: Indicates a potential hazard situation or unsafe practice that, if not avoided, could
result in product or property damage.
Info: Provides application recommendations or other useful information to ensure that you get
the most from your product.
WARNINGS
WARNING: Important! Read and understand these instructions before assembling or
using the Intensa 420 Series Examination Table. If you do not understand any part of these
warnings, cautions or instructions, contact a healthcare professional for direction in the
use of this product. If the Intensa 420 Series Examination Table is not properly assembled,
personal injury and damage to the Examination Table could result.
WARNING: If components are damaged or missing, contact Intensa immediately.
DO NOT use substitute parts. Use only Intensa replacement parts. The use of non-Intensa
replacement parts could cause personal injury, property damage, and void the warranty.
 WARNING:UnauthorizedmodicationofyourExaminationTablecouldcausepersonal
injury, property damage, and void the warranty.
WARNING: The Intensa 420 Series Examination Table maximum weight capacity is 500 lb
(227 kg), EVENLY DISTRIBUTED. DO NOT exceed the maximum weight capacity.
WARNING: Intensa, Inc. assumes no responsibility for any damage or injury caused by
improper assembly or use of this product.
WARNING: Check all parts for shipping damage before using. In case of damage, DO NOT
USE the equipment. Contact the carrier or Intensa for further instructions.

420-INS-LAB-RevA20 6
 WARNING:UnauthorizedmodicationoftheExaminationTableortheuseofnon-Intensa
replacement parts may change the structure of the table and could create a hazardous
condition, which may result in serious injury and void the warranty.
WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate
(DEHP) which is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.p65warnings.ca.gov/furniture.
 WARNING:Intensa,Inc.specicallydisclaimsresponsibilityforanybodilyinjuryor
property damage which may occur during any use which does not comply with federal,
state or local laws or ordinances.

420-INS-LAB-RevA20 7
3 FEATURES
EXAM TABLE COMPONENTS
Back Angle
Adjustment Lever
Paper Roll Holder
Pelvic Tilt Bar
Legrest Pull-Out
Paper Cutter
Independent Procedure
Tray (foot pad need not
be removed to access
procedure tray)
Pull-Out Foot Step
Supports 800 lb (363 kg)
Pass Thru Drawers
Storage Drawers
Stirrups
Leveling Glides

420-INS-LAB-RevA20 8
4 HANDLING PROCEDURES
Lift Area Lift Area
UNPACKING
WARNING: This exam table, as shipped, can weigh as much as 330 lb (150 kg) — use
sufcientpersonneltoliftandremovetheexamtablefromtheshippingpalletfor
placementintonallocation.DONOTattempttoremovetheexamtablefromtheshipping
pallet or move it without assistance. Use proper lifting technique, and see illustration
above for proper lifting area; neglect of these procedures could result in serious injury.
sNOTICE: Do Not Use a knife or other sharp object to open packaging — damage could
occur to the exam table upholstery or surface.
1. Check for any obvious damage to the carton or its contents. If damage is evident, immediately
notify the carrier or Intensa.
2. Carefully remove the exam table from the shipping pallet.
INSPECTION
1. Examine the Examination Table for nicks, dents, scratches or other damage. If damage is
evident, immediately notify the carrier or Intensa.
2. Inspect all components.
3. If damage to any component is evident, immediately notify the carrier or Intensa.
STORAGE
Store the repackaged Examination Table in a dry area.

420-INS-LAB-RevA20 9
DISPOSAL
WARNING: During normal use of this product, it could become contaminated and may
present a biohazard to waste sites.
This product may contain substances that could be harmful to the environment if disposed
ofinplaces(landlls)thatarenotappropriateaccordingtolocallegislation.
 Attheendofthisproduct’susefullife,disposeofitinaccordancewithlocalrequirements,
or contact the manufacturer for advice. Recycle this product through your recycling facility
or dispose of it in accordance with local regulations.
We recommend disassembling and dividing the equipment and components into different
waste groups such as: metal, cable, electronic, recoverable resource and plastic for
recycling or combustion. Most plastic components are provided with a plastic types code
andbercontenttoaidsortingofplasticparts.

420-INS-LAB-RevA20 10
5 INSTALLATION
WARNING: Do Not Use Stirrups , Legrest Pull-Out or Upholstery to lift, move or slide the
table. Personal injury and damage to exam table could occur.
 WARNING:UnauthorizedmodicationoftheExaminationTablemaychangethestructure
of the table and could create a hazardous condition, resulting in serious injury or death.
MODELS 420-DW AND 420-EO: INSTALLATION ELECTRICAL REQUIREMENTS
Warning: Use 115 VAC, 60 Hz. Failure to do so may result in electrical shock and may cause
damage to the exam table.
Warning: The power cord and table must be set up for easy access and use, with no
obstructions for the table to be unplugged.
Warning: This table must only be connected to a main supply with protective earth.
Warning: When connecting equipment to a courtesy outlet, this creates a “Medical
Electrical System” which can result in a lowering of safety levels.
MODELS 420-DW AND 420-EO: ELECTROMAGNETIC INTERFERENCE
This product is designed and built to minimize electromagnetic interference with other devices. If
interference is noticed:
• Remove interfering device from the room.
• Plug exam table into an isolated circuit.
LEVELING THE EXAM TABLE
Leveling Glides
1. Locate Leveling Glides on Bottom of exam table base, shown above (six total).
2. Turn Leveling Glide counterclockwise to raise exam table.
3. Turn Leveling Glide clockwise to lower exam table.
