2960B: BARIATRIC TRAPEZE:
ASSEMBLY AND OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE USE
2960B-INS-LAB-RevF17 1
Info: The most current version of these instructions can be found online at www.
grahamfield.com.
SAFETY GUIDELINES - PLEASE READ BEFORE USE
WARNING: Important: Read and understand these instructions before installing or
using the 2960B Bariatric Trapeze. Ensure that the Trapeze is installed as described
in the following paragraphs before use. If you do not understand any part of these
warnings, cautions or instructions, contact a healthcare professional for direction in
the use of this product. If the Trapeze is not properly installed, personal injury and/or
property damage could result.
 WARNING:Thexedtrapeze,whenusedinconjunctionwithabed,canassistan
individual weighing up to 600 lb.
WARNING: If components are damaged or missing, contact your GF authorized
distributor immediately. DO NOT use substitute parts.
WARNING: Notice for California Customers- California Proposition 65 WARNING:
This product contains a chemical known to the State of California to cause cancer
and reproductive or developmental harm.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or
injury caused by improper installation, assembly or use of this product.
INTENDED USE
The 2960B Bariatric Trapeze is intended to assist in repositioning oneself in bed.
WARNING: The Trapeze is intended to be used ONLY as an assistive device — that is,
to enable patients to more easily and safely reposition themselves. It is not intended
to bear entire body weight.
ASSEMBLY
TrapezeAssembly-RefertoPictureonNextPage
Tools needed: 9/16" wrench, blade screwdriver

2960B-INS-LAB-RevF17 2
1. Use screwdriver to remove the screw, labeled in
picture at lower right, at top end of trapeze arm.
2. Slide bracket onto trapeze arm with chains
downward as shown at lower right.
3. Adjust bracket to desired position; use the
T-screw on top of the bracket to tighten it.
Ensure bracket is secure.
4. Reinstall screw at top end of trapeze arm; use
screwdriver to tighten.
5. Assemble four 3/8" x 1 1/8" hex bolts, lock
washers, and at washers from the hardware
bag as shown in Assemble Bolts, Washers at
upper right.
6. Align the trapeze arm holes with the trapeze
post insert threaded holes and slide the arm
over the insert as shown in Install Trapeze Arm
on Post.
7. Install the four bolts and washers in the trapeze
arm, nger tight, as shown in Assemble
Trapeze Arm to Post.
8. Align the outer surfaces of the trapeze arm and
trapeze post and tighten all eight bolts securely.
Info: The trapeze is now ready to be installed
on the trapeze base (instructions follow).
Trapeze-Base Assembly - Refer to Trapeze
Illustration at Right
Info: The spacers that come with the base glides
are only needed when using the floor stand
and Patriot LX bed. They will increase the
clearance.
1. Place the two base legs on the oor parallel to
each other with leveling glides on the oor as
shown.
2. Attach the A-frame to the base legs: Slide the
A-frame legs down over the upright posts that
project upward from the base legs. Slide the
locking pins through both base legs and A-frame
legs. Slide loops over ends of locking pins.
3. Install clamps on A-frame as shown; use the
thumbscrews on both sides of the clamps to
tighten them. Ensure that clamps are secure on A-frame.
4. Install trapeze post in both clamp center tubes; adjust trapeze to desired height, ensuring
that it passes completely through both center clamps. Use the wing nuts on clamp
center tubes to tighten clamps. Ensure that trapeze post is secure in clamps.
trapeze
base
trapeze
post
trapeze
arm
bracket
screw
chain
triangle
bolts,
trapeze arm
bolts,
trapeze post
clamp
2960B Bariatric Trapeze
Assemble Bolts, Washers
Install Trapeze
Arm on Post
Assemble Trapeze
Arm to Post

2960B-INS-LAB-RevF17 3
TRAPEZE OPERATION
WARNING: Before use, ensure that trapeze is correctly and securely assembled, and
that all clamps and fasteners are tight.
WARNING: The trapeze is intended to be used ONLY as an assistive device — that is,
to enable patients to more easily and safely reposition themselves. It is not intended
to bear entire body weight.
MAINTENANCE AND CLEANING
WARNING: During use, ensure trapeze components are securely fastened at all
times.
Cleaning
Use a soft cloth, dampened with water and a mild NON-ABRASIVE detergent (household
cleaner, soapy water, or hospital grade disinfectant), to clean the trapeze.
LIMITED WARRANTY
SCOPE OF WARRANTY
GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair
components, at GF’s sole discretion, that are defective in material or workmanship under normal use and
service. All warranties are conditioned upon the proper use of the products strictly in accordance with good
commercial practice and applicable GF instructions and manuals, including proper use and maintenance. To
the extent that a component is warranted by a third party, GF conveys all of its rights under that warranty
to the original purchaser, to the extent permitted. This limited warranty shall only apply to defects that are
reported to GF’s customer service team within the applicable warranty period and which, upon examination
by GF or its authorized representative, prove to be a warranty item. This limited warranty is not transferable.
Within the guidelines set forth in this document, this product is warranted for three (3) years. The applicable
warranty period shall commence from date of shipment to the original customer, unless there is an expiration
date on the component in which case the warranty shall expire on the earlier of warranty period or the
expiration date.
OBTAINING WARRANTY SERVICE
This limited warranty shall only apply to defects that are reported to the Distributor from whom the Customer
purchased the product within the applicable warranty period. If there is not a Distributor, you must contact
GF directly by calling 1-770-368-4700, sending a fax request to 1-770-368-2386, or by e-mailing a request to
cs@grahameld.com. Specic directions will be provided by the Customer Service Representative. Failure to
abide by the specic directions will result in denial of the warranty claim.
EXCLUSIONS
The warranty does not cover and GF shall not be liable for the following:
1) Defects, damage, or other conditions caused, in whole or in part, by misuse, abuse, negligence, alteration,
accident, freight damage, tampering or failure to seek and obtain repair or replacement in a timely manner;
2) Products which are not installed, used, or properly cleaned and maintained as required in the ofcial
manual for the applicable product;
3) Products considered to be of a non-durable nature including, but not limited to: casters, lters, fuses,
gaskets, lubricants, and charts;
4) Accessories or parts not provided by GF;
5) Charges by anyone for adjustments, repairs, replacement parts, installation or other work performed upon
or in connection with such products which are not expressly authorized in writing, in advance, by GF;
6) Any labor or shipping charges incurred in the replacement part installation or repair;
7) Costs and expenses of regular maintenance and cleaning; and
8) Representations and warranties made by any person or entity other than GF.

2960B-INS-LAB-RevF17 4
1.770.368.4700
Information contained herein is subject to change.
The most current and complete product information can be found on our website.
www.grahameld.com
© 2006, GF Health Products, Inc. All Rights Reserved.
Lumex and Graham-Field are trademarks of GF Health Products, Inc.
GF Health Products, Inc. is an ISO 13485 Certied Company.
Manufactured for GF Health Products, Inc.
Made in Taiwan
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED. GF MAKES NO IMPLIED WARRANTIES OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IF ANY MODEL OR SAMPLE WAS SHOWN
TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO ILLUSTRATE THE GENERAL TYPE
AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT THE PRODUCT WOULD NECESSARILY
CONFORM TO THE MODEL OR SAMPLE IN ALL RESPECTS. THIS WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT OF THE DEFECTIVE PARTS. GF SHALL NOT BE LIABLE FOR AND HEREBY DISCLAIMS ANY
DIRECT, SPECIAL, INDIRECT, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT
LIMITED TO: DAMAGES FOR LOSS OF PROFITS OR INCOME, LOSS OF USE, DOWNTIME, COVER, OR EMPLOYEE
OR INDEPENDENT CONTRACTOR WAGES, PAYMENTS AND BENEFITS.
The warranties contained herein contain all the representations and warranties with respect to the subject
matter of this document, and supersede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and represents that it has not relied on any
representation, assertion, guarantee, warranty, collateral contract or other assurance, except those set out in
this document.
For additional information on this product or this warranty, please contact a GF Customer Service
Representative.
NOTES:
1) Additional terms and conditions may apply.
2) Freight claims must be notated on the appropriate shipping documents and must be made with immediacy.
International, federal and state regulations govern specic requirements for freight claims. Failure to abide
by those regulations may result in a denial of the freight claim. GF will assist you in ling the freight claim.
3) Claims for any short shipment must be made within three (3) days of the invoice date.
