GRAPHTEC CE6000-120AP User manual

USER’S MANUAL
MANUAL NO.CE60AP-UM-153
CUTTING PLOTTER
CE6000-120AP
www.delinit.by

i
TO ENSURE SAFE AND CORRECT USE
•To ensure the safe and correct use of your plotter, read this manual thoroughly prior to use.
•After reading this manual, keep it in a handy location for quick reference as necessary.
•Do not allow small children to touch the plotter.
•The following describes important points for safe operation. Be sure to observe them strictly.
Conventions Used in This Manual
To ensure the safe and accurate use of the plotter as well as to prevent human injury and property damage, the safety
precautions provided in this manual are ranked in the three categories described below. Their display and meaning is as
following. Be sure to gain a full understanding of the meaning of them before reading the Manual.
DANGER
This category provides information that, if ignored, is highly
likely to cause fatal or serious injury to the operator.
WARNING
This category provides information that, if ignored, is likely to
cause fatal or serious injury to the operator.
CAUTION
This category provides information that, if ignored, could cause
injury to the operator or damage to the plotter.
Description of Safety Symbols
The symbol indicates information that requires careful attention
(including warnings). The specific point requiring attention is described by
an illustration or text within or next to the symbol.
The symbol indicates an action that is prohibited. Such prohibited
action is described by an illustration or text within or next to the symbol.
The symbol indicates an action that must be performed. Such
imperative action is described by an illustration or text within or next to the
symbol.

ii
Safety Precautions
WARNING
Do not touch the moving parts such as rollers and
tool carriage while cutting or plotting is in progress.
•Such action may result in injury.
No touching
Be sure to ground the earth terminal.
•If the plotter is not grounded, the operator could suffer an
electric shock in the event of current leakage.
Ground the Plotter
Keep your hands, hair, etc., away from the rollers or
moving parts such as the carriage even if the plotter is
stopped, as it may suddenly start moving when data is
received.
•Such action may result in injury.
No touching
Do not disassemble, repair, or remodel the plotter.
•Such action may cause electric shock or a fire hazard due to
current leakage.
•Contact with the high-voltage parts within the plotter may
cause electric shock.
•If the plotter requires repairs, contact your sales
representative or nearest Graphtec vendor.
No disassembly
Do not connect the plotter to a non-rated power
supply.
•Such action may cause electric shock or a fire hazard due to
current leakage.
Prohibited
Do not use the plotter in a location where it will be
exposed to water, rain, or snow.
•Such action may cause electric shock or a fire hazard due to
current leakage.
Avoid water Beware of
electrical shock
If the plotter generates smoke, overheats, emits a
strange odor, or otherwise functions abnormally, do
not continue using it. Turn off the power and unplug
the power cord from the electrical socket.
•Use of the plotter in such a condition may result in a fire
hazard or electric shock.
•After confirming that smoke is no longer being emitted,
contact your sales representative or nearest Graphtec vendor
for repairs.
•Never attempt to perform repairs yourself.
Repair work by inexperienced
personnel is extremely dangerous.
Prohibited
Do not allow dust or metal scraps to adhere to the
power plug.
•Such action may cause electric shock or a fire hazard due to
current leakage.
Prohibited Beware of
electrical shock

iii
Safety Precautions
WARNING
CAUTION
Do not use the power cord if it is damaged.
•Use of a damaged cord may result in electric shock or a fire
hazard due to current leakage.
•Replace the power cord with a new one.
Unplug the power
cord from the socket
Be careful when handling the cutter blade.
•Touching the blade with your bare hand may cause injury.
•Do not touch the cutter blade while cutting is in progress.
No touching
Do not use or store the plotter in a location exposed
to direct sunlight or the direct draft of an air
conditioner or heater.
•Such locations may impair the
performance of the plotter.
Prohibited
Do not use the plotter in an excessively dusty or
humid location.
•Such locations may impair the performance of the plotter.
Prohibited
Do not place any receptacle containing water or
other fluid on top of the plotter.
•Fluid falling inside the plotter may cause electric shock or a
fire hazard due to current leakage.
Avoid water Beware of
electrical shock
Do not use the plotter in a location subject to
excessive mechanical vibration or electrical noise.
•Such locations may impair the performance of the plotter.
Prohibited
When disconnecting the power cord or interface
cable, do not pull on the cord/cable.
•Such action will damage the cord/cable, resulting in a fire
hazard or electric shock.
Prohibited
If water or foreign matter enters the plotter,
discontinue use. Turn off the power and unplug the
power cord from the electrical socket.
•Use of a damaged cord may result in electric shock or a fire
hazard due to current leakage.
•Contact your sales representative or nearest Graphtec vendor
for repairs.
Unplug the power
cord from the socket

iv
Safety Precautions
CAUTION
Do not clean the plotter using volatile solvents such
as thinner or benzene.
•Such action may impair its performance.
Prohibited
Do not place the plotter on an incline, areas subject
to many vibrations, or other unstable locations.
•If the plotter falls, it may sustain damage.
Do not place magnetic cards, diskettes or similar
items in the vicinity of the tool carriage.
•The magnetic force may destroy the data on the magnetic
cards or diskettes.
Prohibited
Run a test cut when cutting media with unknown
condition settings.
•Running a cut operation with incorrect setting values may
cause a large overload to the blades and device or a system
breakdown.
Do not attempt to lubricate the cutting-plotter
mechanisms.
•Such action may cause it to break down.
Prohibited
Provide sufficient space around the plotter so that
it does not strike any objects in its vicinity during
cutting.
•Such contact may cause misalignment in cutting or plotting.
No touching
When using the cutter, take care not to extend the
blade more than necessary.
•An overly extended blade will damage the cutting mat and
adversely affect the cutting quality.
When using indoor lighting such as fluorescent or
other electrical lamps, provide a distance of at least
one meter between the plotter and the light source.
•Close proximity of such a light source may cause the sensor
to malfunction and prevent proper size detection of the media.
Move the tool carriage slowly when moving it
manually in order to load the medium or for other
reasons.
•Moving it quickly may damage the plotter.
Prohibited

I
Preface
Thank you for choosing a Graphtec CE6000-120AP plotter. The CE6000-120AP plotters employ a digital
servo drive system to achieve high-speed and high-precision cutting. In addition to cutting with any
perforation pattern, the CE6000-120AP plotter can also be used as a pen plotter. To ensure high cutting
quality and optimal productivity, be sure to read this User's Manual thoroughly prior to use.
Notes on this Manual
(1) No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or
by any means, without the prior written permission of Graphtec Corporation.
(2) The product specifications and other information in this manual are subject to change without notice.
(3) While every effort has been made to provide complete and accurate information, please contact your
sales representative or nearest Graphtec vendor if you find any unclear or erroneous information or wish
to make other comments or suggestions.
(4) Not with standing the stipulations in the preceding paragraph, Graphtec Corporation assumes no liability
for damages resulting from either the use of the information contained herein or the use of the product.
Registered Trademarks
All names of companies, brands, logotypes, and products appearing in this manual are the trademarks or
registered trademarks of their respective companies.
Copyright
This User's Manual is copyrighted by Graphtec Corporation.
Instruction Manual
The Instruction Manual is included as a PDF on the CD-ROM, and gives detailed explanations on the
operation of this machine.

II
Special Precautions on Handling Blades
Sharp cutter blades are used with this plotter. Handle the cutter blades and holders with care to prevent
bodily injury.
Cutter Blades
Cutter blades are very sharp. While handling a cutter blade or cutter pen, be careful to avoid cutting your
fingers or other parts of your body. Promptly return used blades to the cutter case provided.
Blade tip
When the case is completely filled, discard the used blades together with the case.
Cutter Pens
The tip consists of a sharp blade. Be sure not to extend it too far. Moreover, when you are not using the
cutter pen, make sure that the blade is fully retracted.
Cutter blade
After Mounting the Cutter Pen
After the power has been turned on, and during operation, do not touch the pen tip. It is dangerous.

III
After Turning on the Plotter
During the course of turning on the plotter, be sure to observe the following precautions. The tool carriage
and loaded media may suddenly move during the cutting operation, immediately afterward and when setting
the plotter's functions. Keep hands, hair, clothing and other objects out of the vicinity of the tool carriage, grit
rollers and loaded media. To prevent operator injury and poor cutting results, be careful not to allow hands,
hair, clothing or other foreign objects to become entangled with the tool carriage or loaded media while the
plotter is operating.
During a plotting or cutting operation, do not touch the gears, rollers, or other moving parts.
Please be careful not to get your fingers pinched or stuck on the gears, rollers, or other moving parts when
loading the medium.
Machine Caution Label
The machine's Caution Label is located on the top cover. Be sure to observe all the cautions on the label.
About the words and phrases in this text
• In this instruction manual, the word "plot" refers to operating the machine and using either the plotting pen
or the cutter pen to cut.
• In this instruction manual, the word "media" refers to paper, roll, or sheet media.

IV
Prior to use
• Be sure to read the attached TO ENSURE SAFE AND CORRECT USE prior to use. Otherwise, it may
cause an unexpected accident or fire.
Notes on the basket
If the supplied basket is not used, problems in cutting quality may occur. Be sure to use the basket.
Notes on the paper (media)
Please use the paper (media) in accordance with the following precautions.
• The paper is sensitive to temperature and humidity, and can start to stretch or contract immediately upon
removal from the roll. Cutting/plotting the media immediately after taking it off causes it to stretch and may
blur or cause deviations in the images.
• Please make sure to store the paper at the same environment (temperature/humidity) as this machine.
• Please always line up the edge of the paper.
Misalignment may cause skewing and mis-cuts.
• About the end of the roll media and the paper roll.
The cutting or plotting may differ depending on how the roll media ended or how the paper roll was stopped.
• About the paper roll.
This machine uses rolls with an internal diameter of 3 inches, or 76.2 mm. Mis-cuts or plotting deviations
may occur if the paper roll is warped or has a larger internal diameter.
• Please make sure to use the Paper Exposure Time and Number of Pre Feeds settings.
The media can start to stretch or contract after it is taken off the roll. Changes in temperature and/or humidity
affect the paper's contractibility and saturation time, and may cause mis-cuts or plotting deviations.
To prevent this from occurring, this machine is preset for Paper Exposure Time at 180 seconds, and
Number of Pre Feeds at 2. For details on how to change these settings, see "Setting Paper Exposure Time"
and "Setting the Number of Pre Feeds" in Section 4.
• Using the thin media (70 g/m2)
When the cutting speed is too fast, the media deviations may occur. Reduce the cutting speed to use the
thin media.
Especially, please reduce the cutting speed in low humidity environment.

V
Operating environment
With regard to changes in the operating environment, we guarantee the precision of our products under the
following conditions:
• The paper used is Graphtec brand for this machine.
• The Paper Ready Time and Number of Pre Feeds are the manufactures settings of 180 seconds and 2
times.
• There are no changes in the storage temperature and humidity levels.
• If there are changes, the repeatable accuracy is equivalent to 0.1 mm per degree Celsius or 0.3 mm per
10% Relative humidity.
• The paper is re-set after 5 consecutive page cuts.
• Each page is removed from the basket after cutting.
• Connection of a ground wire is required.
* When the ground wire is not connected, the machine may be affected by static electricity.
When using the machine without connecting a ground wire, there may be adversely affected in the cutting
results. Make sure that the machine is grounded.
WARNING
The United States Federal Communications Commission has specified that the following notice must be
brought to the attention of users of this product.
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
USE SHIELDED CABLES
To comply with FCC Class A requirements, all external data interface cables and connectors must be
properly shielded and grounded. Proper cables and connectors are available from GRAPHTEC’s authorized
dealers or manufacturers of computers or peripherals. GRAPHTEC is not responsible for any interference
caused by using cables and connectors other than those recommended or by unauthorized changes or
modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to
operate the equipment.

VI
To use a media wider than 1,119 mm
When using the left grit roller, set the push roller to the position of 2 mm from the right edge (A in the figure
below).
Depending on the media size, adjust the position of the push roller of the long right grit roller.
Push roller
Media
2mm
Grit roller (Right-side longer)Grit roller (Left)
Adjust
(A)
Notes on the left grit roller
The left grit roller is not available in all locations.
It's not possible to set the right edge of the grit roller to a size greater than 8 mm. (There is a stopper.)
Please set the push roller to the position between 2 mm and 8 mm from the right edge of the grit roller.
Push roller
Grit roller
8 mm or more
Media
Push roller
Grit roller
2 mm to 8 mm
Media
OK NG
Notes on the crosscut
When setting the push roller to the left grit roller, the length of the crosscut will be as follows.
Please note the position you want to set the media.
• When the position to set the push roller is 2 mm to 4 mm or less from the right edge of the grit roller, the
crosscut from the left edge of the push roller will be 15 mm.
Push roller
Grit roller
2 mm to 4 mm or less
15 mm
Media
• When the position to set the push roller is 4 mm or more to 8 mm from the right-side of the grit roller, the
crosscut from the left-side of the push roller is 10 mm.
Push roller
Grit roller
4 mm or more to 8 mm
10 mm
Media

VII
Selecting a Power Cable
Be sure to refer to the following tables if you wish to use a cable other than the one supplied as an
accessory.
Table 1. 100 V to 120 V Power Supply Voltage Range
Plug Configuration Plug Type Supply Voltage
Selector Settings
Reference
Standards Power Cable
North America
125 V
10 A
100/120 V
ANSI C73.11
NEMA 5-15
UL498/817/62
CSA22.2
NO.42/21/49
UL Listed
Type SJT
No.18AWG × 3
300 V, 10 A
Table 2. 200 V to 240 V Power Supply Voltage Range
Plug Configuration Plug Type Supply Voltage
Selector Settings
Reference
Standards Power Cable
Europe
250 V
10 A
200 V
CEE(7)VII
IEC320
CEE13
TYPE: H05VV-F
3 × 1.0 mm2
UK
250 V
5 A
200 V
BS1363
BS4491
BS6500
TYPE: H05VV-F
3 × 1.0 mm2
Australia
250 V
10 A
200 V
AS3112
AS3109
AS3191
TYPE: OD3CFC
3 × 1.0 mm2
North America
250 V
15 A
200 V
ANSI C73.20
NEMA 6-15
UL 198.6
UL Listed
Type SJT
No.18AWG × 3
300 V, 10 A
Switzerland
250 V
6 A
200 V
SEV1011
SEV1004
SEV1012
TYPE: H05VV-F
3 × 0.75 mm2
China
250 V
6 A
200 V
GB15934
GB2099.1
GB1002
GB/T 5023.5
TYPE: H05VV-F
3 × 1.0 mm2

C-1
CONTENTS
TOENSURESAFEANDCORRECTUSE...........................................i
SafetyPrecautions.............................................................ii
Preface......................................................................I
NotesonthisManual .........................................................I
RegisteredTrademarks........................................................I
Copyright...................................................................I
InstructionManual ...........................................................I
SpecialPrecautionsonHandlingBlades............................................II
CutterBlades ...............................................................II
CutterPens.................................................................II
AfterMountingtheCutterPen ..................................................II
AfterTurningonthePlotter .....................................................III
MachineCautionLabel ........................................................III
Aboutthewordsandphrasesinthistext...........................................III
Priortouse..................................................................IV
Notesonthebasket...........................................................IV
Notesonthepaper(media).....................................................IV
Operatingenvironment......................................................... V
WARNING .................................................................. V
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT .. V
USESHIELDEDCABLES ...................................................... V
Touseamediawiderthan1,119mm..............................................VI
SelectingaPowerCable ...................................................... VII
Chapter 1 Product Summary
1.1 CheckingtheAccessories...............................................1-2
Accessories ..............................................................1-2
1.2 Nomenclature.........................................................1-3
FrontView..........................................................1-3
RearView..........................................................1-4
1.3 Assembling ..........................................................1-5
Components of stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Componentsofbasket......................................................1-5
Attachingamediaguide..............................................1-11
1.4 ConnectingtotheComputer ............................................1-12
Chapter 2: Preparing to Cut
2.1 PreparationofCutterPlunger.............................................2-2
CutterPlungerNomenclature...........................................2-2
StructureofCutterPlunger.............................................2-2
AdjustingtheBladeLength...................................................2-2
BladeApplicationandFeatures .........................................2-3
2.2 AttachingaTool.......................................................2-4
Attachingacutterplunger..............................................2-4
Removingthecutterplunger............................................2-5
Attachingapen......................................................2-6
Removingapen .....................................................2-6

C-2
2.3 LoadingMedia(Paper)..................................................2-7
LoadingRollMedia...................................................2-7
LoadingSheetMedia ................................................2-14
2.4 AligningthePushRollers...............................................2-16
AligningthePushRoller ..............................................2-16
WhenFeedingLong-axisMedia(atexceeds2meters)............................2-16
WhenFeedingLong-axisMedia (atleast2meters) ..............................2-17
Touseapaperwiderthan1,119mm ..........................................2-17
Forminimumwidthmedia...................................................2-17
ChangingtheHold-downForce ........................................2-18
Switching ...............................................................2-18
2.5 AbouttheDefaultScreen...............................................2-19
2.6 ConnectingtothePower...............................................2-20
2.7 HowtoUseControlPanel..............................................2-21
ControlKeys .......................................................2-21
MenuKeys.........................................................2-21
IndicatorLamp......................................................2-22
ReadingtheScreen(LCD) ............................................2-22
DefaultScreen(ReadyScreen) ..............................................2-22
ContentsofOperationfromMenuScreen.................................2-24
Simplemenu.............................................................2-24
Normalmenu ............................................................2-24
ContentsofOperationfrom[COND/TEST]Key ............................2-25
2.8 SettingFeedingMethod................................................2-26
2.9 Automediatransferandcrosscut........................................2-28
2.10 SelectingToolCondition ...............................................2-29
SelectingToolCondition....................................................2-29
SettingtheToolCondition.............................................2-30
SettingtheTool.....................................................2-31
Setting Condition No.1 (Pen plunger specific) ...................................2-31
SettingforConditionNo.2toNo.8(Forcutterplunger) ............................2-32
SettingtheSpeed...................................................2-34
SettingtheForce....................................................2-35
SettingtheAcceleration ..............................................2-36
AdjusttheBladeLength ..............................................2-37
2.11 SettingCutLinePattern................................................2-38
2.12 RunningCuttingTests.................................................2-41
CuttingTest........................................................2-41
ConfirmtheResultsoftheCuttingTest...................................2-42
AdjustmentofOffset.......................................................2-42
AdjustmentforCuttingOut..................................................2-42
AdjustmentWhenUsingPlottingPen..........................................2-42
2.13 AboutSimplemenu...................................................2-43
2.13.1 SettingPageLength(Simplemode)......................................... 2-44
2.13.2 Settingthenumberofprefeeds(Simplemenu)................................ 2-46
2.13.3 Userselectionsettings(Simplemenu)........................................2-47
2.13.4 SettingRS-232Cinterface(Simplemenu) .................................... 2-49
ChangingandsavingtheRS-232Cinterfacesettings............................ 2-49
2.13.5 DisplayLengthUnitSettings(LengthUnit)(Simplemenu)........................ 2-52

C-3
Chapter 3: Basic Operations
3.1 RaiseorLowertheTool.................................................3-2
3.2 MovetheToolCarriageandMedia ........................................3-3
MoveinStepsManually ...............................................3-3
ContinuouslyMoveManually............................................3-3
SettingofStepMovementDistance ......................................3-4
MoveAwaytheToolCarriage...........................................3-5
ChangetheCuttingCondition(ConditionNo.) ..............................3-6
Reset(Reverttotheinitialstatewhenthepowerwasturnedon.)................3-6
3.3 SettingtheOriginPoint .................................................3-7
WhenCoordinateAxesRotationareSet...................................3-8
WhenCoordinateAxesareRotatedAfterOriginPointisSet...................3-8
SettingOriginPointWhenHP-GLisSet...................................3-9
3.4 SettingtheCuttingDirection ............................................3-10
3.5 StopCutting.........................................................3-12
PauseandResumeCutting ...........................................3-12
StopCutting........................................................3-13
Chapter 4: Convenient Functions
4.1 SettingsforCutting ....................................................4-2
SettingCuttingArea ..................................................4-2
SettingCuttingWidth(EXPAND).........................................4-4
SettingLengthofthePage.............................................4-5
Settingthenumberofprefeeds .........................................4-7
SettingpaperReadytime..............................................4-8
Settingthespacerear.................................................4-9
4.2 Copy(DuplicateCutting) ...............................................4-11
WhenMediaChangemodeisoff.............................................4-11
WhenMediaChangemodeison.............................................4-14
4.3 PanelCutting........................................................4-16
4.4 Settingacrosscut....................................................4-18
4.5 Settingacut(F_CUT)forFcommand.....................................4-19
4.6 Settingaforceforcrosscut.............................................4-20
Chapter 5: Manual Position Adjust
5.1 OutlineofManualPositionAdjust .........................................5-2
Alignmentregistrationmark.............................................5-2
Exampleofaxisadjustment ............................................5-2
5.2 AdjustingcoordinateAxes...............................................5-3
Settingthestartpoint .................................................5-3
Chapter 6: Setting Regarding Cutting Quality
6.1 Tocutthecornerofthickmediasharply ....................................6-2
OutlineofTANGENTIALMODE .........................................6-2
SettingtheTangentialMode............................................6-3
SettingLengthoftheOvercut...........................................6-4
SettingoftheInitialDownForce.........................................6-6
6.2 SettingtheStepPass...................................................6-7
6.3 SettingtheOffsetAngle.................................................6-8

C-4
6.4 SettingtheDistanceAdjust.............................................6-10
6.5 SettingInitialBladeControlPositionAdjust.................................6-12
6.6 SettingsforOFFSETFORCE ...........................................6-14
6.7 BladeWearDetection .................................................6-15
CheckingtheWearRate..............................................6-15
BLADEWEARDETECT..............................................6-16
SETBLADEGROUP(bladeweargroupsettings) ..........................6-17
BLADEWEARSETUP(Bladewearfactorsettings).........................6-18
CLEARB.WEARVALUE(estimateddistancemethod)......................6-20
6.8 Adjustthespacebetweentools1and2 ...................................6-22
Chapter 7: Settings Regarding Cutting Time
7.1 SortingtheCuttingData.................................................7-2
7.2 PerformAutomaticPreFeedWhenCutDataisReceived.......................7-4
7.3 PerformAutomaticPreFeedWhenMediaisSet(InitialFeed)...................7- 6
7.4 SettingFeedSpeedforPreFeed .........................................7-8
7.5 SettingtheToolUpSpeed..............................................7-10
7.6 SettingtheToolUpMove...............................................7-12
Chapter 8: Setting Regarding Interface
8.1 SettingInterface.......................................................8-2
USBInterface .......................................................8-2
RS-232CInterface....................................................8-2
InterfaceSettingMenu ................................................8-2
ConnectingwithRS-232C..............................................8-3
Settinguserselection.......................................................8-3
Switchingtheuserselectionsetting............................................8-4
Changing and saving the RS-232C interface setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-5
8.2 Settingaseparator.....................................................8-8
GP-GLSeparator.....................................................8-8
HP-GL Separatorr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
8.3 Settingatimeout .....................................................8-11
Chapter 9: Settings Regarding Operation Environment
RelatedtoMenuDisplay...............................................9-2
DisplayLanguageSetting(LANGUAGESELECTION) .............................9-2
DisplayLengthUnitSettings(LENGTHUNIT)....................................9-3
RelatedtoSensor....................................................9-4
Enabling/DisablingtheMediaSensors(MEDIASENSOR) ..........................9-4
Enabling/DisablingthePushRollerSensors(PUSHROLLERSENSOR)...............9-5
RelatedtoPlotterEnvironment..........................................9-6
FanSuctionSetting(FANPOWER)............................................9-6
Enabling/DisablingtheBeepSetting(BEEPFORKEYOPERATION)..................9-7
Chapter 10: Settings of Controls from Computer
RelatedtoCommandProcessing.......................................10-2
SettingtheCommand(COMMAND)...........................................10-2
PriorityofToolConditionSelection(CONDITIONPRIORITY).......................10-3

C-5
RelatedtoGP-GLCommand ..........................................10-4
SettingtheStepSize(GP-GLSTEPSIZE)......................................10-4
Enabling/Disablingthe':'and';'Commands(COMMAND':',';')..................10-5
Moving the Pen While Raised or Lowered in Response to the 'W' Command (COMMAND 'W') ....10-6
RelatedtoHP-GLCommand...........................................10-7
ModelIDResponse(HP-GLMODELEMULATED)...............................10-7
Circle-CommandResolutionSetting(CIRCLERESOLUTION)......................10-8
Chapter 11: Maintenance
11.1 DailyMaintenance....................................................11-2
DailyMaintenance...................................................11-2
StoringthePlotter...................................................11-2
11.2 ReplacingCutterBlade ................................................11-3
11.3 CleaningtheCutterPen................................................11- 4
11.4 CutterPlungerExchange...............................................11-5
Chapter 12: Troubleshooting
12.1 Troubleshooting......................................................12-2
WhenthePlotterDoesNotOperateAfterTurningthePowerOn...............12-2
WhenItDoesNotWorkRight..........................................12-3
WhentheCuttingResultisNotGood....................................12-5
ErrorMessagesinGP-GLCommandMode...............................12-6
ErrorMessagesinHP-GLCommandMode...............................12-7
AXISErrorMessages................................................12-9
OtherErrorMessages...............................................12-10
CautionMessage ..................................................12-12
12.2 PrintingtheSettingofthePlotter........................................12-13
12.3 CreatingTestPattern.................................................12-15
12.4 ConfirmtheCuttingData..............................................12-17
12.5 CuttingaCUTDEMO.................................................12-19
12.6 Self Diagnostic Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-21
Appendix
A.1 Main Specifications ....................................................A-2
A.2 Supplies.............................................................A-3
Supplies ................................................................ A-3
A.3 ExternalDimensions ...................................................A-4
CE6000-120AP........................................................... A-4
A.4 MenuTree ...........................................................A-5
SimpleMenu............................................................. A-5
NormalMenu ............................................................ A-6
A.5 InitialSetting.........................................................A-11
SimpleMenu.............................................................A-11
NormalMenu ............................................................A-11
INDEX .......................................................................I-1

1-1
Chapter 1 Product Summary
This chapter explains how to connect this device your computer.
PRODUCT SUMMARY
1.1 Checking the Accessories
1.2 Nomenclature
1.3 Assembling
1.4 Connecting to the Computer

1-2
Accessories
Item Q'ty Item Q'ty
Power cable 1 pc USB cable 1 pc
CD
• Various software
• User's Manual (pdf)
2 pcs SETUP MANUAL,
TO ENSURE SAFE AND CORRECT USE
Cutter Blade Manual
1 of
each
Cutter holder (PHP33-CB09N-HS) 1 pc Cutter blades 1 pc
Oil-based ballpoint pen plunger (PHP34-BALL) 1 set Oil-based ballpoint pen (KB700-BK-1P) 1 pc
Media Cutter 1 pc Media guide
* Packaged with the stand.
1 set
Stand 1 set
*Other software data may be added later.
1.1 Checking the Accessories

1-3
Front View
Marking mat
Cutting groove
Tool carriage
Pen holder
Cutter holder
Control panel
Media set lever Pen station
USB interface connector
RS-232C interface connector
Push roller
Media flange
Grit roller position guide
Grit roller
Stock shaft
Media guide
Media sensor
Media stopper
Control panel...........................Used to access various plotter functions.
Push rollers .............................Rollers that push the media against the grit rollers.
Grit rollers................................Metallic rollers with a file-like surface that feed the media back and forth.
Media sensors .........................The front sensor is used to sense the leading edge of the media. The rear
sensor is used to sense the trailing edge of the media.
Tool carriage ............................Moves the cutter-pen or plotting pen across the media during cutting or
plotting.
Cutter holder ...........................Holds the cutter in position while moving up and down.
Pen holder................................Holds the pen in position while moving up and down.
Pen station...............................Fixes the pen in position before use.
Grit roller position guide ........Stickers on the front of the Y rail and the rear side of the top cover that show
the position of each grit roller. Use these alignment marks as an aid in locating
the Push rollers.
Marking mat .............................The oil-base ballpoint moves above this and does the cutting/plotting.
Cutting groove.........................Use this groove when using the media cutter.
Media set lever ........................Used to raise or lower the Push rollers during the loading or unloading of
media.
1.2 Nomenclature
