Gree FP-51XD-E User manual

FP-51XD-E
FP-51XDS-E
FP-51XDM-E
FP-51XDSM-E
FP-68XD-E
FP-68XDS-E
FP-68XDM-E
FP-68XDSM-E
Applicable Models :
Change for life
Cassette Type Fan Coil Unit
Thank you for choosing commercial or household air conditioners.
Please read this Owner’s Manual carefully before operation and retain it for
future reference.
If you have lost the Owner's Manual, please contact the local agent or visit www.
gree.com or send an email to [email protected] for the electronic version.
Commercial or Household Air Conditioners
Owner's Manual(Original Instruction)

User Notice
This appliance is intended to be used by expert or trained users in shops, in light industry and
on farms, or for commercial or household use by lay persons.
Installing the unit in the following places may cause malfunction. If it is unavoidable,please
consult the local dealer:
1.The place with strong heat sources,vapors, flammable or explosive gas,or volatile objects
spread in the air.
2.The place with high-frequency devices (such as welding machine,medical equipment).
3.The place near coast area.
4.The place with oil or fumes in the air.
5.The place with sulfureted gas.
6.Other places with special circumstances.
7.Do not use the unit in the immediate surroundings of a laundry a bath a shower or a swimming
pool.
DISPOSAL: This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved.Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.

Contents
1 Safety cautions����������������������������������������������������������������������������������������������� 2
1.1 Important notices........................................................................................... 2
1.2 Safety requirements for electric appliances................................................... 2
1.3 Earthing requirements ................................................................................... 3
1.4 Others............................................................................................................ 3
2 Notices for use������������������������������������������������������������������������������������������������ 3
2.1 Working principle for cooling ......................................................................... 3
2.2 Working principle for heating......................................................................... 3
2.3 Anti-cool-wind function................................................................................... 4
2.4 Anti-heat-wind function .................................................................................. 4
3 Name and function of parts��������������������������������������������������������������������������� 4
4 Installation of the Cassette Type FCU ���������������������������������������������������������� 5
4.1 Schematic diagram of installation spaces ..................................................... 5
4.2 Selection of the installation location of the FCU............................................ 5
4.3 Important notice............................................................................................. 6
4.4 Dimension of ceiling opening and location of the hoisting screw ................. 6
4.5 Hanging preparations .................................................................................... 7
4.6 Installing drainage hose................................................................................. 8
4.7 Installation connecting the pipes ................................................................... 8
4.8 Connection of the motorized valve ............................................................... 9
4.9 Electrical wiring............................................................................................ 10
4.10 Bolting the grille assembly to the body...................................................... 11
4.11 Wireless unit connection wire wiring.......................................................... 11
4.12 Installing/removing the intake grille ........................................................... 12
4.13 Test operation ............................................................................................ 12
5 Troubleshooting ������������������������������������������������������������������������������������������� 14
6 Parameters of the unit���������������������������������������������������������������������������������� 15

Cassette Type Fan Coil Unit Owner's Manual
2
1 Safety cautions
The gures in this manual may be different the material objects, please refer to the material
objects .
This symbol stands for the items should be forbidden.
This symbol stands for the items should be followed.
When the voltage is very high,
the components would be easily
damaged. When the voltage is
very low, the electric components
cannot work. The voltage should
be stable; there shouldn’t be big
uctuation.
Be sure to pull out the power
plug as the unit not in use for
a long time. Otherwise, the
accumulated dusts may cause
overheating or re.
Never splice the power cord or
use an extended cord.
It can cause overheating or re.
When a burning smell or smoke,
please turn off the power supply
and contact with the service
center.
If the abnormity still exists, the
unit may be damaged, and may
cause electric shock or re.
Keep combustible spray away
from the units more than 1m.
It can cause a re or explosion.
Don’t attempt to repair the air
conditioner by yourself.
The wrong repair will lead to an
electric shock or re, you contact
the service center repair.
The appliance shall be disconnected from its power source during service and when
replacing parts.
1.1 Important notices
(1) The unit installation must be done by qualied personnel according to the local rules and this
manual.
(2) The breaker should be installed in the xed circuit. All pole of the breaker should be switched off
and the distance of the contact should be at least 3mm.
(3) Do not use the unit for laundryroom , bathroom and swimming-pool.
(4) The motorized valve should be equipped with the unit.The motorized valve don't supply with
the unit.
1.2 Safety requirements for electric appliances
(1) The power supply should be used the rated voltage and AC excellusive circuit, the power cable
diameter should be satised.

Cassette Type Fan Coil Unit Owner`s Manual
3
(2) Don't drag the power cable emphatically.
(3) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
(4) It should be reliably earthed, and it should be connected to the special earth device. The air
switch must have the functions of magnetic tripping and heat tripping, in order to protect the
short circuit and overloading.
(5) The Min. distance the unit and combustive surface is 1.5m.
Make sure that the Line wire or Zero line as well as the earth wire in the family power socket
can not be wrong connected, there should be reliable and no short circuit in the diagram.
Wrong connection may cause re.
1.3 Earthing requirements
(1) The unit is type I electric appliance, thus please do conduct reliable earthing measure.
(2) The yellow-green wire is for earthing and cannot be used for other propose. It cannot be cut off
and can be xed it by screw, otherwise it would cause electric shock.
(3) The earth resistance should accord to the National Criterion.
(4) The user power must offer the reliable earthing terminal. Please don't connect the earthing wire
with the following place:
■ Tap water pipe . ■ Gas pipe
■ Contamination pipe . ■ Other places that professional personnel consider them unreliable
(5) The appliance shall be installed in accordance with national wiring regulations.
(6) Installation must be performed in accordance with the requirement of NEC and CEC by
authorized personnel only
1.4 Others
(1) The connection method of unit and power cable as well as the interconnect method of each
isolated component should refer to the circuit diagram stick on the unit.
(2) The model of the blown fuse and rated value should refer to the silk-screen on the controller or
fuse sleeve.
(3) The appliance shall be installed in accordance with national wiring regulations.
(4) Children should be supervised to ensure that they do not play with the appliance.
(5) After the eld commissioning, the water discharge valves, gas release valves, and drain pipes
shall be insulated properly, otherwise they if exposed directly in the air would lead to condensing
and dewing.
2 Notices for use
2.1 Working principle for cooling
Principle:
The unit absorbs the air from the indoors and sends it away through circulation of cooling water,
so as to reduce indoor ambient temperature. Accordingly, the lower of temperature of the water is,
the larger of cooling capacity of the unit.
2.2 Working principle for heating
Principle:
Air circulation forced by the fan transfers the energy from hot water to the air indoors so as to

Cassette Type Fan Coil Unit Owner's Manual
4
increase indoor ambient temperature. Accordingly, the higher of temperature of the water is, the
larger of heating capacity of the unit.
2.3 Anti-cool-wind function
In order to ensure comfort of the users, under circumstances such as the heat mode just starts
or the unit runs heat mode under low water temperature, the fan will stop running to prevent the
chilled wind blowing out.
2.4 Anti-heat-wind function
In order to ensure comfort of the users, under circumstances such as the cool mode just starts
or the unit runs cool mode under hot water temperature, the fan will stop running to prevent the hot
wind blowing out.
3 Name and function of parts
FAN
AUTO
OPER
HEALTH
AIR
FILTER
TURBO
ON/OFF
X-FAN
HOUR
HUMIDITY
ON/OFF
MODE
FAN
X-FAN
TURBO
TEMP TIMER
SLEEP LIGHT
Remote controller
Air intake grille
The built -in air filter
removes dust and dirty
Air flow flap
(At air outlet)
Air outlet
Chilled water piping
Connection electric wire
Drain pipe
Drainage device (built-in )
remove water from the unit
during cooling.
Fig.1

Cassette Type Fan Coil Unit Owner`s Manual
5
4 Installation of the Cassette Type FCU
4.1 Schematic diagram of installation spaces
Ceiling
Fig.2
4.2 Selection of the installation location of the FCU
(1) Obstruction shall be put away from the intake or outlet vent of the FCU so that the airow can
be blown through all the room.
(2) Make sure that the installation comply with the requirement of the schematic diagram of
installation spaces.
(3) Select the place where it can stand 4 times of the weight of the FCU and would not increase the
operating noise and oscillate.
(4) The horizontally of the installation place should be guaranteed.
(5) Select the place where condensate water can drain out easily.
(6) Make sure that there are enough space for care and maintenance. Make sure that the height
between the FCU and ground is above 2500mm.
(7) When installing the steeve bolt, check if the installation place can stand the 4 times of the weigh
of the unit. If not, reinforce it before installation. (Refer to the install cardboard and nd where
should be reinforced)
Note!
①
There will be lots of lampblack and dust stuck on the acentric, heat exchanger and water
pump in dining room and kitchen, which would reduce the capacity of heat exchanger, lead to water
leakage and abnormal operation of the water pump. The following treatment should be taken under
this circumstance:
②
Ensure that the smoke trap above cooker has enough capacity to obviate lampblack to
prevent the indraft of the lampblack by the air conditioner.
③
Keep the air conditioner far from the kitchen so that the lampblack would not be taken in by

Cassette Type Fan Coil Unit Owner's Manual
6
the air conditioner.
4.3 Important notice
(1) To guarantee the good performance, the FCU must be installed by professional personnel in
accordance with this instruction.
(2) Please contact the local Gree special nominated repair department before installation. Any
malfunction caused by the unit that is installed by the department that is not special nominated by
Gree would not deal with on time by the inconvenience of the business contact.
4.4 Dimension of ceiling opening and location of the hoisting screw
Fig.3 Installation Dimension Diagram
The drilling of holes in the ceiling must be done by the professional personnel.
(160)
Ceiling
Installation stands for main body of the unit
Above 20
Fig.4
Note:
The dimension for the ceiling openings with * marks can be as large as 910mm. But the
overlapping sections of the ceiling and the decorated surface boards should be maintained at no
less than 20mm.

Cassette Type Fan Coil Unit Owner`s Manual
7
4.5 Hanging preparations
Firmly fasten the hanging bolts as shown in Fig.7 or by another method.
Hole-in anchor
Hole-in plug
Concrete
Insert
Length(H)=h-9-21/32''
(Shown in Fig.6)
Hanging bolt M10
Fig.5
Fig.6
(1) Install special nut A, then special nut B onto the hanging bolt. (Fig.7)
(2) Raise the body and mount its hooks onto the hanging bolt between the special nuts. (Fig.7)
(3) Turn special nut B to adjust the height of the body. (Fig.7)
(4) Leveling a level, or vinyl hose lled with water. adjust it well so that the body is level.
Warning:Perform nal tightening by tightening the double nut rmly.
Fig.7

Cassette Type Fan Coil Unit Owner's Manual
8
Fig.8
4.6 Installing drainage hose
NOTE:
♦Install the drainage hose.
♦Install the drainage hose with downward gradient (1/50 t0 1/100) and there should be no
rises or traps in the pipe.
♦Use general hard polyvinyl chloride pipe (VP25) [outside diameter l -1/4" (32mm)] and
connect it with adhesive (polyvinyf chloride) so that there is no leakage.
♦When the pipe is long, install supporters.
♦Always heat insulate the indoor side of the drainage hose.
♦When desiring a high drain pipe height, raise it up to 15" (400 mm) or less from the ceiling
within a range of 6" (150mm) from the body. T he raised height over this range will cause leakage.
Fig.9
4.7 Installation connecting the pipes
(1) Be sure to use both a spanner and wrench together as shown in the gure when connecting
or disconnecting pipes to/from the unit.
(2) The pipe af water-in/out is pipe thread G3/4".The surface of thread should be enlaced by the
two or three-circles trap
(3) After the water-in pipe and water-out pipe is connected tightly, start the water pump, and
then check its airproof performance.
(4) Insulate it as shown in the gure below.
(5) Use sealing pad (12) to wrap the water-in/out pipe and the insulation (10).
