Greenlee 93-172 User manual

93-172
DIGITAL LIGHT METER
93-172
FOTÓMETRO DIGITAL
LUXMÈTRE NUMÉRIQUE
93-172
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL DE L’UTILISATEUR
999 3086.2 © 2019 Greenlee Tools, Inc. IM 1366 REV 1 12/98
Read and understand all of the instruc-
tions and safety information in this manual
before operating or servicing this tool.
Lea y entienda todas las instrucciones y
normas de seguridad incluidas en este manual, antes de
manejar esta herramienta o darle mantenimiento.
Nous vous conseillons de lire attentivement et de bien
comprendre les instructions suivantes avant d’utiliser ou
de procéder à l’entretien de cet outil. Le non-respect
d’une telle consigne peut entraîner des blessures
corporelles ou même la mort.
Description
The Greenlee 93-172 is a digital light meter intended to measure
light emitted from fluorescent, metal halide, high-pressure
sodium and incandescent light sources.
Safety
Safety is essential in the use and maintenance of Greenlee
tools and equipment. This instruction manual and any decals on
the tool provide information for avoiding hazards and unsafe
practices related to the use of this tool. Observe all of the safety
information provided.
Purpose
This manual is intended to familiarize personnel with the safe
operation and maintenance procedures for the Greenlee 93-172
Digital Light Meter.
Keep this manual available to all personnel.
Replacement manuals are available upon request at no charge.
is a registered trademark of
Greenlee Tools, Inc.
Replace weak or discharged batteries as soon as either of
these conditions is detected.
Do not expose test instrument to extremes in temperature
or high humidity. See Specifications section of this manual.
Failure to observe these precautions can result in injury and
can damage the instrument.
Specifications
Ranges
Footcandles ...................................... 20 / 200 / 2000 / 5000
Lux ......................................... 200 / 2000 / 20,000 / 50,000
Accuracy
Incandescent Light Source ..........................................±4%
Other Light Source....................................................... ±7%
Temperature Range ........................... 0°– 40°C (32°– 104°F)
Relative Humidity............................................... Less Than 80%
Power............................................................. One 9-Volt Battery
Operation
1. Plug the sensor into the sensor jack.
2. Press the button.
3. Press the Lux/Fc selector to select either lux or footcandles.
4. Press the Rbutton to select the appropriate measurement
range.
Note: Set the display to 000 by twisting the zero adjustment
screw.
5. Place the sensor at the measurement location and remove
the cover. Read the display.
Additional Notes:
• If the display reads OL, switch to the next higher range.
• When the display reads X 10, multiply the reading on the
display by 10 for the actual value.
• When the display reads X 100, multiply the reading on the
display by 100 for the actual value.
• To store a reading on the display, press D-H (Data Hold).
Press D-H again to resume normal measuring.
• To store a maximum or peak reading, press M-H. Press M-H
again to resume normal measuring.
Maintenance
General
• Keep the tester clean and dry.
• When necessary, wipe clean with a damp cloth. Allow the
tester to dry completely before use.
Battery Replacement
1. Loosen screw on the back of the meter.
2. Remove the battery door.
3. Replace the battery.
4. Install the battery door.
Parts
UPC No. Part No. Description Qty
78-3310-
06061 500 6061.9 Sensor.......................................... 1
06083 500 6083.0 Sensor Cover ............................... 1
06200 500 6200.0 Case ............................................. 1
M-H D-H
Lux/Fc
R
200
20 200
20
20000
200
50000
5000
Lux
Fc
Lux
Fc
0 ADJ
MAX D-H
Lux/Fc
R
200
20 200
20
20000
200
50000
5000
Lux
Fc
Lux
Fc
0 ADJ
10
4
6
7
8
5
3
2
1
9
11
Identification
1. Range Button
2. Power Button
3. Maximum (Peak Hold)
4. Sensor Jack
5. LCD
6. Zero Adjustment Screw
7. Data Hold Button
8. Lux/Footcandle Selector Button
9. Sensor Plug
10. Sensor Cover
11. Battery Door
Identificación
1. Botón Range (margen)
2. Botón Power (encendido)
3. Botón Peak Hold (guardar
valor máximo)
4. Receptáculo del sensor
5. Pantalla de cristal líquido
(LCD)
6. Tornillo de ajuste en ceros
7. Botón Data Hold (guardar
datos)
8. Botón selector de luxios/
bujías-pies
9. Clavija de conexión del sensor
10. Tapa del sensor
11. Tapa del compartimiento de
las pilas
Identification
1. Bouton de gamme
2. Bouton Marche/Arrêt
3. Maximum (maintien de la
crête)
4. Jack du capteur
5. Affichage à cristaux
liquides
6. Vis de réglage sur 0
7. Bouton de maintien des
données
8. Bouton de sélection lux/
bougie pied
9. Prise du capteur
10. Couvercle du capteur
11. Couvercle du boîtier de la
pile
