GreenTech PortOzone 3.5G User manual

Owner’s Manual
Portable Ozone Generation
PortOzone 3.5G

2
About PortOzone 3.5G
Table of Contents
The PortOzone 3.5G portable ozone generation device is an advanced and
convenient contaminant remediation product. PortOzone 3.5G features high-
powered oxidation in a compact, lightweight, rugged, and simple design. Utilizing
controlled corona discharge ozone technology developed specifically to reduce
odors and smoke in unoccupied spaces, PortOzone 3.5G is ideal for the treatment of:
• Odors & Smoke
• Freshly Painted Homes & Oces*
• Newly Vacated Real Estate
• Pet Stores & Kennels*
• Automobiles & Boats*
• and More!
*Unoccupied by Humans and Pets
PortOzone 3.5G covers spaces up to 3,000 square feet, so the applications are
endless! We hope our product exceeds your expectations and we thank you so
much for your purchase. Should you ever need assistance, please contact your
GreenTech Environmental Authorized Distributor or contact us directly. You can find
our information at www.GreenTechEnv.com.
About .................................................................. 2
Specifications ........................................................... 3
Cautions & Warnings ..................................................... 3
Unit Diagrams ........................................................... 4
Operation & Control...................................................... 5
Cleaning the Unit ........................................................ 6
Part Replacements....................................................... 7
Warranty ............................................................... 8
Please record the name and phone number of your Distributor/Contractor.
Name______________________________________________________________________________
Phone #: ___________________________________________________________________________
Please record the serial number of your PortOzone 3.5G
Serial #: ____________________________________________________________________________

3
Specifications
Models ................................................ PORTOZONE3.5G120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PORTOZONE3.5G240
Dimensions ......................................5.9” x 6.89” x 8.07” (HxWxD)
Gross Weight ........................................................ 5.73lb
Maximum Coverage ...............................................3,000ft2*
Maximum Ozone Output ........................................ 3,500mg/hr
AC Power Cord ......................................................300V
Input ...........................................Europe AC 220-240V/50-60Hz
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .USA/Japan AC 100-120V/50-60Hz
Output ................................................................2A
Warranty .............................................1 Year Manufacturer’s
*Depending on variables such as the severity and frequency of pollution, flow of air
in the environment, humidity, and temperature.
Warnings
WARNING: Never operate the unit near a heat source, open flame, or
flammable/combustible fluids.
WARNING: Never operate the unit unless all parts are properly installed.
CAUTION: Do not use in areas occupied by humans or pets.
CAUTION: Unit should be placed on a towel when being used in a vehicle
to prevent discoloration of the upholstery from the ozone.
NOTE: The REAR FILTER ASSEMBLY is the only part of the unit that is user-
serviceable. Any other tampering with the unit by non-certified persons
will void the warranty.

4
Unit Diagrams
Unit Front
FUSE BOX
(+1 SPARE)
FILTER
POWER CORD PORT
FILTER COVER
MINUTES
CAUTION: USE IN UNOCCUPIED SPACE ONLY
OFF
120
100
80
40
20
60
FRONT GRILLE
POWER LIGHT
TIMER KNOB
Unit Rear

5
Operation & Control
Unit Set Up
Ideal Placement
In order to maximize the disbursement of ozone into the environment, you should
consider air circulation, source of odor/pollutant, HVAC returns and vents, and type
of odor/pollutant. Generally, place the unit as high up in the environment as possible
and point the front of the unit towards the center of the area for maximum eect.
Alternatively, you may point the unit into an HVAC cold air return to disburse ozone
throughout the entire home or business serviced by that HVAC system. Note that
PortOzone 3.5G should not be used in spaces occupied by humans or pets.
Installing Power Cords
Plug the appropriate POWER CORD into the POWER CORD PORT on the rear of the unit
first, then plug the POWER CORD PLUG into the wall outlet.
Running the Unit
Using the Control Knob
Turn the TIMER KNOB clockwise until the TIMER KNOB points to the desired number
of minutes. The timer can be set to expire after any elapsed time of 10 minutes to
120 minutes.
Determining Proper Running Time
Proper running time depends on air circulation, severity of contamination, and
environment size. Use the following table as a starting point in determining proper
running time.
Automobile
Normal Pollution Heavy Pollution
10 - 30 Minutes 1 Hour
15 - 60 Minutes 4 - 8 HoursAverage Room
2 - 12 Hours 24 - 48 HoursHome or Office

6
Cleaning the Unit
Filter
Unit
1. Begin by unplugging the unit from the receptacle.
2. Remove the FILTER COVER from the REAR of the unit. Use a FLAT HEAD
SCREWDRIVER to get behind the FILTER COVER and pop it o. There will be a
strong resistance but it will come o without problem.
3. Remove and clean the FILTER and FILTER COVER by vacuuming or wiping them
down with a damp cloth.
4. Clean the grille behind the FILTER using a damp cloth as well.
5. Replace the FILTER and FILTER COVER once cleaning is complete.
1. Begin by unplugging the unit from the receptacle.
2. Remove the SCREWS from each of the SIDE PANELS and store them in a safe
place before removing the UNIT COVER.
3. Use a can of compressed air to remove any dust or debris from the unit’s insides.
4. Wipe the inside of the UNIT COVER down with a damp cloth.
5. Place the UNIT COVER back into position and replace the SCREWS on each of the
SIDE PANELS.
NOTE: The REAR FILTER ASSEMBLY and CORONA DISCHARGE PLATE are the
only parts of the unit that are user-serviceable. Any other tampering with
the unit by non-certified persons will void the warranty.
WARNING: Make sure to unplug the unit before any maintenance or
cleaning is done.
Occasionally, the REAR FILTER ASSEMBLY should be cleaned in order to optimize the flow
of air through the unit. Follow these instructions to properly clean the REAR FILTER.
The unit will need to be cleaned inside from time to time as well. Be sure to use extreme
caution when doing this in order to avoid any damage to the unit or harm to yourself.

7
Corona Discharge Plate (Contact GreenTech or Dealer for Replacement)
Fuse (2A)
Part Replacements
1. Begin by unplugging the unit from the receptacle.
2. Remove the SCREWS from each of the SIDE PANELS and storing them in a safe
place before removing the UNIT COVER.
3. Pull the ceramic plate out of the ozone generator module and replace with the
new Corona Discharge Plate.
4. Place the UNIT COVER back into position and replace the SCREWS on each of the
SIDE PANELS.
1. Begin by unplugging the unit from the receptacle.
2. Open the FUSE BOX COVER and remove the OLD FUSE.
3. Replace with the included FUSE.
4. Replace the FUSE BOX COVER.
NOTE: The REAR FILTER ASSEMBLY and CORONA DISCHARGE PLATE are the
only parts of the unit that are user-serviceable. Any other tampering with
the unit by non-certified persons will void the warranty.
WARNING: Make sure to unplug the unit before any maintenance or
cleaning is done.
The corona discharge plate requires replacement every 5000 hours of use. Please
note, frequency of replacement may be significantly shorter depending upon
environmental conditions.
Should the unit stop working, check the fuse to see if it has expired. If it has blown,
replace it with the included spare fuse.
Consumer Information
GreenTech Environmental declines all responsibility for all damages arising from
improper use of the unit or in case of tampering with the unit.

8
Warranty Information
Your PortOzone 3.5G portable ozone generation device is warranted to be free from all defects in material
and workmanship in normal use for a period of (1) year from date of purchase. The warranty is granted only to
the original purchaser. The warranty is subject to the following provisions.
This warranty does not cover parts of the unit that require replacement under normal use. This includes the
filter. Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Owner’s
Manual are not covered by this warranty. Likewise, any defects or damages caused by unauthorized service
or the use of other than Genuine GreenTech Environmental parts are not covered.
GreenTech Environmental will, at its option, repair or replace a defective unit or part(s) for the unit that
is(are) covered by this warranty. As a matter of warranty policy, GreenTech Environmental will not refund the
customer’s purchase price.
OBTAINING WARRANTY SERVICE
To obtain warranty service you must return the defective product along with proof of purchase to the
GreenTech Environmental Authorized Service Center. All shipping costs submitted under this Warranty shall
be borne by purchaser. Unless this Warranty is expressly renewed or extended by GreenTech Environmental,
any repaired or replaced part of unit shall be warranted to the original purchaser only for the length of
the unexpired portion of the original warranty. For the location of the nearest GreenTech Environmental
Authorized Service Center or for other service information, please visit us online at:
www.GreenTechEnv.com/Support
Before any product is sent for service, the customer should contact the GreenTech Environmental Service
Center to obtain a Return Merchandise Authorization (RMA) Number. This RMA Number should be clearly
written on the box before shipping. All components/parts including the remote (if applicable), manuals,
and original packaging should be included in the return if available.
FURTHER LIMITATIONS AND EXCLUSIONS ARE AS FOLLOWS
Any warranty that may be implied in connection with your purchase or use of the Product, including any
warranty of merchantability or any warranty for Fitness For A Particular Purpose is limited to the duration of this
warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations
may not apply to you.
Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall
GreenTech Environmental be liable for any consequential or incidental damages loss of profit, or medical
expenses caused by any misuse, abuse, accident, negligence, or failure to follow instructions. The company
will not be responsible for any written or oral statements made that are inconsistent with this written warranty,
or which are misleading or inconsistent with the facts as published by the company in the literature or
specifications. Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This Warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
REGISTRATION
Please register your Product within 10 days of purchase by contacting GreenTech Environmental at:
www.GreenTechEnv.com/Warranty
Registering your new GreenTech Environmental product entitles you to the most up-to-date GreenTech
Environmental warranty and promotion information.
