Greentouch Roveland User manual

( 60-IN W x 22-IN D x 35-IN H)
60-IN Vanity Base and Top
Date Purchased _______________________
TM
Questions, problems, missing parts?
Before returning to your retailer,
call our customer service department at
1-855-571-1044 9 a.m. - 5 p.m., EST, Monday-Friday.
www.greentouchhome.com
Roveland Bathroom Vanity

2
TM
MODEL NUMBER DESCRIPTION
2500VT-60-904 60" Black Granite Top with Backsplash
2026VA-60-200 60" Gray Painted Vanity Base & Sink
2026VA-60-201 60" White Painted Vanity Base & Sink
2026VA-60-202 60" Mahogany Vanity Base & Sink
2026VA-60-205 60" Black Oak Vanity Base & Sink
2500VT-60-900 60" Carrara Marble Top with Backsplash
2500VT-60-901 60" White Quartz Top with Backsplash
2500VT-60-906 60" Dark Gray Quartz Top with Backsplash
2500VT-60-905 60" Terrazzo Top with Backsplash
2026VA-60-242 60" Light Gray Finish Vanity Base & Sink

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
BTop 1
AVanity 1
C Backsplash 1
DSink 2
G Shelf 2
E 2
F
Right Door
(preassembled
to Vanity (A))
2
Left Door
(preassembled
to Vanity (A))
HARDWARE CONTENTS
WARNING
CAUTION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
• Use care when assembling the vanity, take your time and follow the assembly instructions closely.
• Weight capacity for shelf is 10 lb.
SAFETY INFORMATION
• Some steps are more easily handled with two adults.
C
B
AE
E
G
D
F
F
Touch-up Pen
Qty. 1
Shelf Pin
Qty. 8
FF GG
Sink Bracket
Qty. 8
Lock Washer
Qty. 8
Nut
Qty. 8
Wrench
Qty. 1
Bolt
Qty. 8
AA BB CC DD EE

4
INSTALLATION INSTRUCTIONS
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Installation Time: 45 minutes (24 hours for adhesive to dry).
Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, adhesive,
power drill with drill bit, measuring tape, level
2. Apply silicone adhesive (not included) to
the top edge of sink (D). With the help of
another adult, lower the sink onto the back
side of the stone top. Make sure the sink
over-flow hole is facing the front of stone top.
Be sure to align the sink well with the stone top
cut out allowing for equal stone overhang on the
front, back and sides of the ceramic sink (D).
Repeat for the remaining sink.
Note: To install the sink onto the top correctly,
ensure that the two "BACK" stamps on the sink
and the top are aligned on the same sides.
Use the glide lines marked on the sink and
bottom side of stone top to assist with sink
location.
1
1
1
B
A
2
33
BACK
FRONT
BACK
FRONT
2
2
2
2
BACK
BACK
BACK
BACK
D
B
2
BACK
1
Sink Lip
Top
BACK
BACK
1. To remove the top (B) from vanity (A), please use scissor to snip the zip ties that hold top (B)
to Vanity (A), remove the Top (B) and Backsplash (C) and place them face onto a scratch- free
surface such as a foam sheet that came in the packaging.

5
INSTALLATION INSTRUCTIONS
Hardware Used
AA Bolt x 8
3. Screw bolts (AA) into the threaded holes of
stone top (B)
Hardware Used
BB Sink bracket x 8
CC Nut x 8
x 8
DD Lock Washer
EE Wrench x 1
4. Lower the sink brackets (BB) over the bolts
(AA) and allow to rest on the sink lip. Adjust
location of bracket to firmly grasp sink lip.
Lower lock washers (DD) over bolts (AA) and
secure with nuts (CC). Hand tighten nuts (CC)
with included wrench (EE).
DO NOT OVER TIGHTEN!
Repeat for the remaining sink.
Tip: check that the sink placement is well
centered front to back and side to side of the
stone top cut out before allowing the silicone
adhesive to dry. If the sink is not centered well
unscrew sink clamps, readjust the sink position
and re-tighten the sink brackets.
Assembly is now complete, Install top with sink
to vanity cabinet.
3
AA
D
B
BACK
BACK
BACK
BACK
4
3
CC
DD
EE
2
BB
1
D
B
BACK
BACK
BACK
BACK

6
INSTALLATION INSTRUCTIONS
6. Using hardware appropriate for your wall type
(not included), secure Vanity Cabinet (A) to
two wall studs anywhere through the Vanity
Mounting Plates. Be careful not to disturb
any electrical or water lines that may be
concealed in the wall.
5. Clean area where the vanity (A) will be
permanently located prior to beginning
installation, ensuring the vanity (A) will not
interfere with any water supply and drain lines
once mounted.
Locate wall studs and mark locations. With the
help of another adult, place completed Vanity
Cabinet Assembly to its final location. Adjust
the height of the Vanity Cabinet (A) by
twisting the adjustable leveler foot pins on the
bottom of each leg. Twist clockwise to
decrease height or twist counter-clockwise to
increase vanity height.
5
A
6
A
WARNING
Vanity (A) MUST be secured to the wall.

7
INSTALLATION INSTRUCTIONS
7. To install the top with sink to the vanity (A).
Apply silicone adhesive to the top edge of the
wood cabinet. With the help of another adult,
gently lower the stone top with assembled sink
onto the cabinet. Make sure the stone top is flush
with the back side of the wood cabinet and the
stone overhang is equal on both sides over the
wood cabinet left and right side walls. Remove
any excess adhesive before allowing to dry.
Tip: it may be easier to install the faucet and/or
drain assembly (not included) before
securing the stone top to the wood cabinet.
8
1
GG
22
G
G
8. Insert shelf pins (GG) at desired height,
ensuring they are level. Place shelf (G) on
top of shelf pins (GG).
Repeat for the remaining shelf (G).
Hardware Used
GG Shelf Pin x 8
71
A
B
2
2

8
INSTALLATION INSTRUCTIONS
10. To reinstall drawers into vanity (A). Please fully
extend metal glide tracks, gently lower and slide
drawer box into rear glide catch, then, lower
drawer box down to completely rest on
extended glides, push plastic levers to
lock the drawer box in place.
Repeat for remaining drawers.
Note: To Adjust the drawer box height. Please
spin the adjustment wheel to the left to raise the
drawer box or spin the adjustment wheel to
the right to lower the drawer box. You can
adjust the left and right side glide heights
independently in order to find the drawers best
alignment position.
CAUTION
DO NOT force drawer or damage to glide may
occur. If drawer does not slide in with ease,
remove and try again from the start.
9. To remove drawers preassembled in vanity (A).
Fully extend drawers, locate plastic levers on
metal glide tracks at left and right sides of
drawer box, push on plastic levers on both
sides at the same time, to disengage drawer
box from the glides, Then gently lift the drawer
up to remove it from the glide tracks.
9
12
A
B
10
A
B

9
INSTALLATION INSTRUCTIONS
11. If you need to adjust the doors, do so in the following manner.
To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.
To adjust door left or right, turn screws (b) on both hinges, in or out.
To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
12. Apply adhesive (not included) to unpolished
side and bottom of backsplash (C). Position
backsplash (C) on top (B) and against wall.
Clean any excess adhesive before allowing
to dry.
11
a
3
a
1
b
1
1
c
1
c
3
2
2
2
2
22
12
A
C
B
22
1
Assembly is now complete. Install desired
faucet and drain assemblies (neither included)
if not already done at step 7. Per the
manufacturers’ instructions to complete the
installation.

10
• Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the vanity with a gentle, non-abrasive household cleaner.
• Make sure to dry the wood immediately with a soft cloth or towel.
• The stone top can be cleaned using standard marble cleaning agents available at your local
supplier.
• Tips for using touch-up pen (FF): For scratches, stroke in direction of scratch. Rub off excess
colorant promptly with a soft cloth.
IMPORTANT
• Shade variations and patterns are an inherent characteristic of stone (e.g. granite, marble,
engineered stone). Stone tops will vary from product to product. Use caution placing items
such as soap or any fragranced material on the stone surface. Use a soap dish, coaster or
similar item to protect the surface if placing any soap or fragranced products on the stone.
• If soap or fragranced products come in contact with the stone top, rinse the surface with water
and dry using a soft non-abrasive cloth.
• WARNING: Must use cleaning agents safe for stone. Check your cleaning agents use
restrictions before using on any stone. Damage to the stone may result. Vanity Manufacturer not
responsible for damage caused by improper cleaning agents or soaps used. Warranty will not
cover damage caused by the use of improper soaps or cleaning agents.
• DO NOT use products to clean the stone top that contain acetone, lemon, vinegar or other
acids as these may cause damage to the stone surface.
• Periodically reseal the stone top using an appropriate stone sealer available from your local
home store. Follow the manufacturer’s directions on how to apply.
WARRANTY
The manufacturer warrants this item against defects in materials and workmanship for a period
of one (1) year from the date of original retail purchase. This warranty applies only to the original
purchaser. This warranty does not apply to any damage on the product by accident, misuse, or
modified, improper installation or by affixing accessories not produced by the manufacturer. The
manufacturer is not accountable whatsoever for product installation during the warranty period.
There is no further expressed warranty. The manufacturer shall not be legally responsible for
incidental, consequential or special damages arising at or in connection with product use or
performance except as may otherwise be accorded by law. The manufacturer disclaims any and
all implied warranties.
CARE AND MAINTENANCE

11
REPLACEMENT PARTS FOR 2026VA-60-200
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
D
C
H
G
I
J
E
F
PART DESCRIPTION PART#
EE Wrench
OX-0180Z
FF
Shelf pin
Touch-up Pen
GG B1044
HH Glide Track Set PUDTC-12x3-Handle
II Pull (with screw) CF-96-004-BN
JJ Knob (with screw) CF-D25-005-BN
KK Hinge C-90-107
LL Leveler T-1007
AA
Sink Bracket
Bolt
BB
PU-Sink Clips-002CC Nut
DD Lock Washer
PART DESCRIPTION PART#
H Small Drawer Front 2026VA-60-200-004
I Middle Drawer Front 2026VA-60-200-005
J Large Drawer Front 2026VA-60-200-006
PU17-18x14-SQUARE
D
Left Door
Sink
PUBS-25-906-60
PUBS-25-905-60
PUBS-25-901-60
PUBS-25-900-60
C Backsplash
E2026VA-60-200-
001/002
F Right Door
G Shelf 2026VA-60-200-003
AA BB CC DD FFEE
GG HH II KK LLJJ

12
REPLACEMENT PARTS FOR 2026VA-60-201
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART#
EE Wrench
OF-0010
FF
Shelf pin
Touch-up Pen
GG B1044
HH Glide Track Set PUDTC-12x3-Handle
II Pull (with screw) CF-96-004-BN
JJ Knob (with screw) CF-D25-005-BN
KK Hinge C-90-107
LL Leveler T-1007
AA
Sink Bracket
Bolt
BB
PU-Sink Clips-002CC Nut
DD Lock Washer
PART DESCRIPTION PART#
H Small Drawer Front 2026VA-60-201-004
I Middle Drawer Front 2026VA-60-201-005
J Large Drawer Front 2026VA-60-201-006
PU17-18x14-SQUARE
D
Left Door
Sink
PUBS-25-906-60
PUBS-25-905-60
PUBS-25-901-60
PUBS-25-900-60
C Backsplash
E2026VA-60-201-
001/002
F Right Door
G Shelf 2026VA-60-201-003
AA BB CC DD FFEE
GG HH II KK LLJJ
D
C
H
G
I
J
E
F

13
REPLACEMENT PARTS FOR 2026VA-60-202
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART#
H Small Drawer Front 2026VA-60-202-004
I Middle Drawer Front 2026VA-60-202-005
J Large Drawer Front 2026VA-60-202-006
PU17-18x14-SQUARE
D
Left Door
Sink
PUBS-25-906-60
PUBS-25-905-60
PUBS-25-901-60
PUBS-25-900-60
C Backsplash
E2026VA-60-202-
001/002
F Right Door
G Shelf 2026VA-60-202-003
PART DESCRIPTION PART#
EE Wrench
W3350A
FF
Shelf pin
Touch-up Pen
GG B1044
HH Glide Track Set PUDTC-12x3-Handle
II Pull (with screw) CF-96-004-BN
JJ Knob (with screw) CF-D25-005-BN
KK Hinge C-90-107
LL Leveler T-1007
AA
Sink Bracket
Bolt
BB
PU-Sink Clips-002CC Nut
DD Lock Washer
AA BB CC DD FFEE
GG HH II KK LLJJ
D
C
H
G
I
J
E
F

14
REPLACEMENT PARTS FOR 2026VA-60-205
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART#
H Small Drawer Front 2026VA-60-205-004
I Middle Drawer Front 2026VA-60-205-005
J Large Drawer Front 2026VA-60-205-006
PU17-18x14-SQUARE
D
Left Door
Sink
PUBS-25-906-60
PUBS-25-905-60
PUBS-25-901-60
PUBS-25-900-60
C Backsplash
E2026VA-60-205-
001/002
F Right Door
G Shelf 2026VA-60-205-003
PART DESCRIPTION PART#
EE Wrench
W3504A
FF
Shelf pin
Touch-up Pen
GG B1044
HH Glide Track Set PUDTC-12x3-Handle
II Pull (with screw) CF-96-004-BN
JJ Knob (with screw) CF-D25-005-BN
KK Hinge C-90-107
LL Leveler T-1007
AA
Sink Bracket
Bolt
BB
PU-Sink Clips-002CC Nut
DD Lock Washer
AA BB CC DD FFEE
GG HH II KK LLJJ
D
C
H
G
I
J
E
F

15
REPLACEMENT PARTS FOR 2026VA-60-242
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART#
H Small Drawer Front 2026VA-60-242-004
I Middle Drawer Front 2026VA-60-242-005
J Large Drawer Front 2026VA-60-242-006
PU17-18x14-SQUARE
D
Left Door
Sink
PUBS-25-906-60
PUBS-25-905-60
PUBS-25-901-60
PUBS-25-900-60
C Backsplash
E2026VA-60-242-
001/002
F Right Door
G Shelf 2026VA-60-242-003
PART DESCRIPTION PART#
EE Wrench
OF-0120R
FF
Shelf pin
Touch-up Pen
GG B1044
HH Glide Track Set PUDTC-12x3-Handle
II Pull (with screw) CF-96-004-BN
JJ Knob (with screw) CF-D25-005-BN
KK Hinge C-90-107
LL Leveler T-1007
AA
Sink Bracket
Bolt
BB
PU-Sink Clips-002CC Nut
DD Lock Washer
AA BB CC DD FFEE
GG HH II KK LLJJ
D
C
H
G
I
J
E
F
