Griven Capital 600 Series User manual

Capital User Manual
600 Rev.1.0
Date: 31/08/2020
page 1 of 12
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goredo
Mantova - Italy
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
Tel. [phone]
Fax [phone]
E-mail: [email protected]
Web: www.griven.com
551090
Dimensions
20 3/8"
517mm
29 3/4"
756mm
5 7/8"
150mm
Capital 600 Capital 600 US Capital 600 MC
Code AL5020 - AL5022 (PE) AL5024 (US) - AL5025 ( US PE) AL5021 - AL5023 (PE)
Power consumption 2x 256 W(RN), 2x 285 W (W) 2x 266 (MC)
Nominal current 2x 1.6 A (RN), 2x 1.29 A(W), 2x1.2(MC)
Power supply 100-277VAC 50-60Hz
Inrush current 2x 70 A@240VAC, cold start
Power factor cos.φ= 0.96 (RN&W), 0.94(US)
Electrical class I
Weight 32.8 Kg
Operating temperature -40°C to +50°C ( -40°F to 122°F )
IP rating IP67
IK rating IK09

Capital - Rev. 1.0
page 2 of 12
CAUTION: Prolonged staring at LED source should be avoided by placing the xture in a proper position.
WARNING ! Fixing and connecting operations must mandatorily be carried out by qualied personnel only !
WARNING ! Make sure that power supply is o before connecting or disconnecting xtures !
Important notices
- This product must be installed in accordance with the local applicable electrical and construction co-
des by a person familiar with the construction and operation of the product and the hazards involved.
Failure to comply with the following installation instructions may result in death or serious injury.
- Do not stare at the operating light source.
- The xture might be damaged by excess voltage. The installation of an overvoltage protection device on the
electrical system can reduce the risk of damage.
- The use of an adequate magnetothermic switch along the power supply line is recommended.
- Connect the xtures one to each other only when disconnected from mains power.
- Never leave cables and connectors disconnected or unprotected for long periods.
- Disconnect mains power before installing or servicing to avoid electrical shock.
- Disconnect mains power before any connection operation.
- Check voltage and frequency before powering the xture. Do not exceed the xture specied voltage.
- Do not handle the unit with wet hands or in wet environments.
- Apply to qualied sta for any maintenance service not described in this instructions manual.
- Do not exceed the maximum quantity of xtures per line in order to avoid power surges.
- Before powering the unit, ensure to use cables and connectors with proper section and length, according to its
power consumption.
- Fix the projector by using screws, hooks or other adequate supports that can bear its weight.

Capital - Rev. 1.0
page 3 of 12
Installation
1/2"
12,50mm
6 7/8"
175mm
6 7/8"
175mm
1/2"
12,50mm
35°
100°
+100° -30°
+100° -30°
Vertical beam-aiming
A
A=size 13 (ISO) Wrench
100°
+100° -30°
+100° -30°
both screws
both screws
both screws
A
A

Capital - Rev. 1.0
page 4 of 12
Connection
RED= DMX +
BLACK= DMX -
WHITE=COMMON
RED= DMX +
BLACK= DMX -
WHITE=COMMON
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND MAINS:
100-277VAC 50/60Hz
“S” type cable ( Power in, DMX In, DMX Out )
RED= DALI bus +
BLACK= DALI bus -
RED= DALI bus +
BLACK= DALI bus -
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
“D” type cable ( Power in, DALI In, DALI Out )
DMX IN/OUT
DALI IN/OUT
RED= DMX +
BLACK= DMX -
WHITE=COMMON
RED= DMX +
BLACK= DMX -
WHITE=COMMON
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND MAINS:
100-277VAC 50/60Hz
DMX IN/OUT
RED= DALI bus +
BLACK= DALI bus -
RED= DALI bus +
BLACK= DALI bus -
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
DALI IN/OUT
MAINS:
100-277VAC 50/60Hz
MAINS:
100-277VAC 50/60Hz
Note: the power and signal connections of S and M cable types can be carried out by using the
connection kit included in the packing box. Follow the instructions provided along with the con-
nection kit.

Capital - Rev. 1.0
page 5 of 12
“C” type cable ( Monocable + connectors )
POWER + DMX IN
POWER + DMX OUT
A=DMX-
B=DMX+
C=common
1=N
2=L
3=GND
“M” type cable ( Monocable without connectors )
POWER + DMX IN
POWER + DMX OUT
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
RED= DMX +
BLACK= DMX -
WHITE=COMMON
POWER + DMX IN/OUT
POWER + DMX IN/OUT
POWER + DMX IN
POWER + DMX OUT
POWER + DMX IN
POWER + DMX OUT
POWER + DMX IN/OUT
POWER + DMX IN/OUT
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
RED= DMX +
BLACK= DMX -
WHITE=COMMON
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
RED= DMX +
BLACK= DMX -
WHITE=COMMON
Blue= N (Neutral)
Brown=L (Live)
Yellow/Green=GND
RED= DMX +
BLACK= DMX -
WHITE=COMMON
Note: the power and signal connections of S and M cable types can be carried out by using the
connection kit included in the box. Follow the instructions provided along with the connection kit.

Capital - Rev. 1.0
page 6 of 12
¹WARNING ! in this mode, no DMX control device must be present along the line.
² Only on wireless xtures
The xture must be congured only by using AL1321 IR remote control ( sold separately ) or via any
DMX-RDM compatible controller.
IR Remote Control operations
LOGIN
DMX MODE
DMX MODE SETTING
DMX ADDRESS SETTING
Enter the corresponding “IR” value
( see the DMX chart, Mode Column
to select the desired DMX mode
( e.g.: for IR=4 press button 4)
001~512 = OK
FLASH
FLASH FLASH FLASH
= OK
FLASH FLASH
= OK
MASTER/SLAVE
AUTOMATIC
MODE
TO BE USED ONLY
WITH DMX MODE #
1
AUTOMATIC/MASTER
5”→10”→20”→ 40”
40”→ 20”→ 10”→ 5”
001
SLAVE FIXTURE SETTING
= OK
FLASH FLASH FLASH
FLASH
2 xFLASH
3 xFLASH
4 xFLASH
4 xFLASH
3 xFLASH
2 xFLASH
FLASH
FIXED
COLOR
MODE
(RGB-RGBW-DW)
TO BE USED ONLY
WITH DMX MODE #1
1 = RED
2= GREEN
3 = BLUE
DIMMER
MODE
(Monochromatic)
TO BE USED ONLY
WITH DMX MODE #1
0%→100%
100%→0%
5’ inactivity = Automatic
LOGOUT
Green-Cyan-Blue-Magen-
ta-Red-Yellow-White.
4 = COLD WHITE
5 = WARM WHITE
RGBWRGB
DW
LOGOUT OK
RESET OK Reset to default settings
1 = RED
2= GREEN
3 = BLUE
4 = WHITE
WIRELESS
1 = Unlink
2= Wireless LED status ON
3= Wireless LED status OFF
¹
²

Capital - Rev. 1.0
page 7 of 12
When operating in DMX mode the xture can accept the
following RDM commands:
• Discovery: upon request of the RDM controller, the xture
will signal its own presence (the RDM controller will display
the xture on a list).
• DMX address reading and setting.
• Channels number reading and setting.
• On / O identication: this command is used to identify the
xture you want to get access to (the identication happens
by switching on all the LEDs at full intensity).
• Manufacturer: it displays the name of the manufacturer
(Griven).
• Model description: it displays the xture’s model.
• Software version description: it displays the current version
of the rmware.
• Temperature: it displays the LEDs operating temperature
value.
DMX Chart ( per each cluster )
RDM functions
Mode Channel Function Value
#1
IR=4
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
#2
IR=5
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
5 0→100% Dimmer 0-255
#3
IR=6
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
5
0% Dimmer 0-5
0%-100% Dimmer 6-250
100% Dimmer 251-255
6
No Strobo 0-5
0-100% Strobo 6-250
100% Strobo 251-255
#4
IR=7
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
5
NO FUNCTION 0-5
2700K 6-7
2700K-3000K 8-40
3000K 41-42
3000K-3500K 43-75
3500K 76-77
3500K-4000K 78-110
4000K 111-112
4000K-4500K 113-145
4500K 146-147
4500K-5000K 148-179
5000K 180-181
5000K-5500K 182-214
5500K 215-216
5500K-6000K 217-249
6000K 250-255
6 0-100% Dimmer 0-255
#5
IR=8
1 0-100% Red 0-255
20-100% Red ne tuning 0-255
3 0-100% Green 0-255
40-100% Green ne tuning 0-255
5 0-100% Blue 0-255
60-100% Blue ne tuning 0-255
70-100% White 0-255
80-100% White ne tuning 0-255
RGBW
DW (Dynamic White)
Mode Channel Function Value
#1
IR=2
(Default)
10%→100% Warm white 0-255
20%→100% Cold White 0-255
#2
IR=3
10%→100% Warm white 0-255
20%→100% Cold white 0-255
3 0%→100% dimmer 0-255
#3
IR=3
10%→100% Warm white 0-255
20%→100% Warm white ne 0-255
30%→100% Cold white 0-255
40%→100% Cold White ne 0-255
Note: in absence of DMX signal the LEDs will remain ON.
Channel Function Value
1 0%→100% dimmer 0-255
Note: in absence of DMX signal the LEDs will remain ON.
Monochromatic version
Mode Channel Function Value
#6
IR=9
(Default)
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% Calibrated White
(aects RGB channels) 0-255
Note: in absence of DMX signal the LEDs will remain OFF.

Capital - Rev. 1.0
page 8 of 12
Command # Description
1 O
2 Up (Fade rate)
3 Down (Fade rate)
4 Step Up ( Increment arc power level )
5 Step Down ( Decrement arc power level )
6 Recall MAX level
7 Recall MIN level
8 Step down and o ( Decrement arc power level if at min level turn down )
16...31 Go to scene 0...15
32 Reset ( DALI factory default parameters )
33 Store actual level in the DTR
42 Store DTR as MAX level
43 Store DTR as MIN level
45 Store DTR as Power On level
46 Store DTR as Fade Time
47 Store DTR as Fade Rate
64-79 Store DTR as Scene 0...15
80-95 Remove from Scene 0...15
96...111 Add to Group 0...15
112...127 Remove from Group 0...15
128 Store DTR as Short Address
144 Query Status
145 Query Ballast
151 Query Version Number
152 Query Content DTR
153 Query Device Type
154 Query Physical Minimum Level
155 Query Power Failure
160 Query Actual Level
161 Query Max level
162 Query Min level
163 Query Power On level
164 Query System Failure level
165 Query Fade Time/Fade Rate
176...191 Query Scene level
192 Query Groups 0...7
193 Query Groups 8...15
194 Query Random Address High
195 Query Random Address Middle
196 Query Random Address Low
DALI supported commands
DALI version: 1, Device Type: 6(LED), Physical Min Level: 1 (0.1%)

Capital - Rev. 1.0
page 9 of 12
B
DMX IN
DMX OUT
DMX IN
DMX OUT
DMX IN
DMX OUT
DMX IN
DMX OUT
DMX IN
DMX OUT
120Ω DMX TERMINATOR
A
BI
DMX
C
G
A
A
BI
DMX
C
H
A
C
I
A - Power Input
B - DMX/RDM Controller
C - Start Line Box - AL5058C with connectors / AL5058M without connectors
D - Capital 600
E - Connection Cable - AL8264 L=1m (3 ft) AL8265 L=2m (6 ft) AL8266 L=3m ( 10 ft) AL8267 L=5m ( 16 ft) AL8268 L=10m ( 32 ft)
F - DMX Terminator - AL5169 (with connector)
G - Repower Box - AL5167C with connectors / AL5167M without connectors
H - DMX Junction Box - AL5059C with connectors / AL5059M without connectors
I - DMX Cable - AL0512
120Ω DMX TERMINATOR
A
BI
DMX
C
DMX Chain conguration - S type cable
DMX cable type: 2x0.34 mm, impedance 110, capacity 43pF/m, resistance 50/Km.
Single Chain conguration - M or C type cable
Multi Chain conguration using Repower Box - M or C type cable
Multi Chain conguration using DMX junction Box - M or C type cable
A A A A
Max. 10 A
per
daisy chain
Use a DMX repeater on each 16th
the total DMX LINE length exceeds
300m (1000 ft)
Max. 10 A
per
daisy chain
Use a DMX repeater on each 16th
the total DMX LINE length exceeds
300m (1000 ft)
Max. 10 A
per
daisy chain
Use a DMX repeater on each 16th
the total DMX LINE length exceeds
300m (1000 ft)
Max. 10 A
per
daisy chain
Use a DMX repeater on each 16th
the total DMX LINE length exceeds
300m (1000 ft)
DMX OUT
DMX IN
A
DMX OUT
DMX IN
A
DMX OUT
DMX IN
A
DMX OUT
DMX IN
A
DMX OUT
DMX IN
A
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
POWER +DMX OUT
POWER+DMX IN POWER +DMX OUT
D D D D
D D D D
DD
D
120Ω DMX TERMINATOR
120Ω DMX TERMINATOR
Conguration examples

Capital - Rev. 1.0
page 10 of 12
B
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT 120Ω DMX TERMINATOR
DMX Mode
Master-Slave / Automatic / Fixed color Mode
Addr. 001 Addr. 001 Addr. 001 Addr. 001
Example with xtures set to 4 DMX channels
Addr. 001 Addr. 009
Addr. 017
Addr. 025 Addr. ###
AA A A A
Master
Addr. 001 Addr. 001 Addr. 001 Addr. 001Addr. 001
Addr. 005 Addr. 013
Addr. 021
Addr. 029
DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT 120Ω DMX TERMINATOR
AA A A A
WARNING ! in this mode, no other DMX control device must be present along the line.
The POLAR Edition is tted with a thermal frontal glass which is particularly useful for outdoor applica-
tions.
In fact, by warming up, the glass melts ice and snow which might interfere with the projection.
When the projector is on, if required by the weather conditions, the glass is automatically warmed up.
WARNING: If the projection is to be started at a denite time, deice the glass in advance, so that
when the LEDs are switched on at the denite time the glass will be clean.
WARNING: At very low temperatures (below -20° C), it is recommended to leave the xture
always powered and to switch on the LEDs when needed.
Polar features (only on Polar Edition xtures )
Operating modes
( Only DMX Mode #1 )
Std. US MC
Capital 600 Polar AL5022 AL5025 AL5023

Capital - Rev. 1.0
page 11 of 12

Capital - Rev. 1.0
page 12 of 12
