Grizzly G0626 User manual

MODEL G0626/G0627

DOWNDRAFT TABLE

OWNER'S MANUAL

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TS8419 PRINTED IN TAIWAN



































 

 

 











Table of Contents

INTRODUCTION ............................................................................................................................... 2

Foreword .................................................................................................................................... 2

Contact Info ................................................................................................................................ 2

G0626 Machine Data Sheet ....................................................................................................... 3

G0627 Machine Data Sheet ....................................................................................................... 5

Identification ............................................................................................................................... 7

SECTION 1: SAFETY ....................................................................................................................... 8

Safety Instruction for Machinery ................................................................................................ 9

Additional Safety Instructions for Downdraft Tables ................................................................ 10

SECTION 2: CIRCUIT REQUIREMENTS ...................................................................................... 11

110V Operation ........................................................................................................................ 11

SECTION 3: SET UP ...................................................................................................................... 12

Set Up Safety ........................................................................................................................... 12

Items Needed for Set Up ......................................................................................................... 12

Unpacking ................................................................................................................................ 12

Inventory ................................................................................................................................... 13

Hardware Recognition Chart .................................................................................................... 14

Site Considerations .................................................................................................................. 15

Assembly .................................................................................................................................. 15

Test Run ................................................................................................................................... 17

SECTION 4: OPERATIONS ........................................................................................................... 18

Operation .................................................................................................................................. 18

SECTION 5: ACCESSORIES ......................................................................................................... 19

SECTION 6: MAINTENANCE ........................................................................................................ 20

Schedule .................................................................................................................................. 20

Cleaning ................................................................................................................................... 20

Filters ........................................................................................................................................ 20

SECTION 7: SERVICE ................................................................................................................... 21

Troubleshooting ........................................................................................................................ 21

G0626/G0627 Electrical Components ...................................................................................... 22

G0626 Wiring Diagram ............................................................................................................. 23

G0627 Wiring Diagram ............................................................................................................. 24

G0626 Parts Breakdown .......................................................................................................... 25

G0626 Parts List ...................................................................................................................... 26

G0627 Parts Breakdown .......................................................................................................... 27

G0627 Parts List ...................................................................................................................... 28

G0626/G0627 Safety Label Placement ................................................................................... 29

WARRANTY AND RETURNS ........................................................................................................ 30

-2- G0626/G0627 Downdraft Table

If you have any comments regarding this manual,

please write to us at the address below:

Grizzly Industrial, Inc.

C/O Technical Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

We stand behind our machines. If you have any

service questions or parts requests, please call or

write us at the location listed below.

Grizzly Industrial, Inc.

1203 Lycoming Mall Circle

Muncy, PA 17756

Phone: (570) 546-9663

Fax: (800) 438-5901

E-Mail: [email protected]

Web Site: http://www.grizzly.com

Foreword

INTRODUCTION

Contact Info

We are proud to offer the Model G0626/G0627

Downdraft Table. This machine is part of a grow-

ing Grizzly family of fine woodworking machinery.

When used according to the guidelines set forth in

this manual, you can expect years of trouble-free,

enjoyable operation and proof of Grizzly’s com-

mitment to customer satisfaction.

We are pleased to provide this manual with the

Model G0626/G0627. It was written to guide you

through assembly, review safety considerations,

and cover general operating procedures. It repre-

sents our effort to produce the best documenta-

tion possible.

The specifications, drawings, and photographs

illustrated in this manual represent the Model

G0626/G0627 as supplied when the manual was

prepared. However, owing to Grizzly’s policy

of continuous improvement, changes may be

made at any time with no obligation on the part

of Grizzly. For your convenience, we always

keep current Grizzly manuals available on our

website at www.grizzly.com. Any updates to

your machine will be reflected in these manuals

as soon as they are complete. Visit our site often

to check for the latest updates to this manual!

G0626/G0627 Downdraft Table -3-

The information contained herein is deemed accurate as of 7/27/2007 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G0626

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0626 25" X 15" DOWNDRAFT TABLE W/ STAND

Product Dimensions:

Weight................................................................................................................................................................ 72 lbs.

Length/Width/Height............................................................................................................................. 25 x 15 x 38 in.

Foot Print (Length/Width)................................................................................................................. 25-1/4 x 15-1/4 in.

Shipping Dimensions:

Type......................................................................................................................................................... Not Available

Content............................................................................................................................................................ Machine

Weight................................................................................................................................................................ 82 lbs.

Length/Width/Height............................................................................................................................. 29 x 22 x 22 in.

Electrical:

Switch.................................................................................................................................................... Sealed Rocker

Switch Voltage...................................................................................................................................................... 110V

Cord Length............................................................................................................................................................ 8 ft.

Cord Gauge....................................................................................................................................................16 gauge

Recommended Breaker Size............................................................................................................................ 15 amp

Plug.........................................................................................................................................................................Yes

Motors:

Main

Type............................................................................................................................ ODP Capacitor Induction

Horsepower..............................................................................................................................................1/8 HP

Voltage........................................................................................................................................................110V

Prewired......................................................................................................................................................110V

Phase........................................................................................................................................................ Single

Amps............................................................................................................................................................2.2A

Speed.................................................................................................................................................1725 RPM

Cycle..........................................................................................................................................................60 Hz

Number Of Speeds........................................................................................................................................... 1

Power Transfer ................................................................................................................................Direct Drive

Bearings....................................................................................................................... Shielded and Lubricated

Main Specifications:

Operation Info

Air Suction Cap.................................................................................................................................... 400 CFM

Filter Micron...................................................................................................................................................... 1

Filter Efficiency.................................................................................................................................. 96 Percent

Impeller Type................................................................................................................................ Squirrel Cage

Impeller Size.................................................................................................................................................8 in.

Impeller Blade Thickness...................................................................................................................... 0.030 in.

Filter Info

No. Of Filters..................................................................................................................................................... 1

Filter Length......................................................................................................................................... 11-3/8 in.

Filter Width........................................................................................................................................... 11-3/8 in.

Filter Thickness.......................................................................................................................................... 11 in.

-4- G0626/G0627 Downdraft Table

The information contained herein is deemed accurate as of 7/27/2007 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2Model G0626

Table Info

Table Size Length...................................................................................................................................... 25 in.

Table Size Width........................................................................................................................................ 15 in.

Floor To Table Height.................................................................................................................................38 in.

Construction Info

Frame Const........................................................................................................................... Pre-Formed Steel

Base Const............................................................................................................................. Pre-Formed Steel

Impeller Const..........................................................................................................................Zinc Plated Steel

Table Const............................................................................................................................ Pre-Formed Steel

Side Wall Const.......................................................................................................................................... Steel

Filter Const............................................................................................................Woven Fabric and Aluminum

Paint........................................................................................................................................... Powder Coated

Other Specifications:

Country Of Origin ..............................................................................................................................................Taiwan

Warranty ............................................................................................................................................................ 1 Year

Serial Number Location .................................................................................................................................. ID Label

Assembly Time ........................................................................................................................................... 15 minutes

Features:

Non-marring Slip Resistant Table Top

Convenient Access Filter Bay

G0626/G0627 Downdraft Table -5-

The information contained herein is deemed accurate as of 7/27/2007 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G0627

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0627 40" X 20" DOWNDRAFT TABLE W/ STAND

Product Dimensions:

Weight.............................................................................................................................................................. 124 lbs.

Length/Width/Height............................................................................................................................. 40 x 20 x 38 in.

Foot Print (Length/Width)................................................................................................................. 40-1/4 x 20-1/4 in.

Shipping Dimensions:

Type......................................................................................................................................................... Not Available

Content............................................................................................................................................................ Machine

Weight.............................................................................................................................................................. 143 lbs.

Length/Width/Height............................................................................................................................. 45 x 27 x 23 in.

Electrical:

Switch.................................................................................................................................................... Sealed Rocker

Switch Voltage...................................................................................................................................................... 110V

Cord Length............................................................................................................................................................ 8 ft.

Cord Gauge....................................................................................................................................................16 gauge

Recommended Breaker Size............................................................................................................................ 15 amp

Plug.........................................................................................................................................................................Yes

Motors:

Main #2
