Grizzly T27948 User manual

For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T27948
2-DOOR TOOL CABINET
INSTRUCTIONS
COPYRIGHT © MARCH, 2017 BY GRIZZLY INDUSTRIAL, INC., REVISED JULY, 2017 (MN)
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MFD. SINCE 10.16) #JH18539 PRINTED IN CHINA
Inventory Qty
• Tool Cabinet with Shelves ........................... 1
• Cabinet Feet ................................................ 4
• Keys ............................................................. 2
Figure 1. Model T27948.
• To reduce risk of crushing injuries from
tool cabinet tipping over on you:
— Do not stand on cabinet.
— Only move or transport cabinet with all
doors closed and locked.
— Push cabinet only (do not pull it) when
moving.
• Do not exceed weight capacities:
— Max individual shelf weight limit
is 325 lbs.
— Max total tool cabinet weight limit
(including contents) is 650 lbs.
• To prevent accidental tipping, ensure
adjustable feet are down and cabinet
body is level.
• Do not allow children to have unsupervised
access to cabinet.
V1.07.17
Introduction
The Model T27948 2-Door Tool Cabinet requires
some assembly. Follow the instructions below for
assembly, operation, and maintenance.
Assembly
The Model T27948 comes with four adjustable
feet for leveling the cabinet.
To install feet:
1. With help from another person, lay cabinet
upside down on floor (see Figure 2).
Note: We recommend sweeping the floor
clean and laying down a piece of cardboard
or a blanket to prevent scratching the finish
during this step.
2. Install one adjustable foot in each corner (see
Figure 2).
3. To prevent tipping or rocking, level the cabi-
net body by rotating the cabinet feet up or
down as needed.
Figure 2. Location of adjustable feet.
Adjustable Feet

-2- T27948 Tool Cabinet (Mfd. 10/16)
To adjust doors:
1. Close door and visually confirm gap spacing
around door edge is 1⁄8" all the way around
(see Figure 3).
— If door spacing is equal, no adjustments
are needed.
— If door spacing is not equal, proceed to
Step 2.
Adjusting Doors
Each 90° soft-close door hinge is riveted in place.
However, the doors may be adjusted inward or
outward, and left or right, as needed.
Figure 3. Checking door gap spacing.
1⁄8" Gap
2. Adjust door hinges using screws shown in
Figure 4.
Note: Only small adjustments, such as 1⁄8
or 1⁄4turn at a time, are required to move
door position. Check spacing after each
adjustment.
Figure 4. Hinge adjustments.
In/Out
Adjustment
Right/Left
Adjustment
Maintenance
• Use a soft, clean cloth and soapy water (use
regular dish soap) to remove grease, dirt, or
oil. Do not use solvents or flammable clean-
ing liquids.
• Use graphite to lubricate lock annually.
Installing Shelf Supports
Shelf
Support
Channel
Bracket
Figure 5. Shelf support and channel bracket.
Each shelf comes with four shelf supports, which
fit into the channel brackets inside the cabinet
(see Figure 5), making the height of each shelf
adjustable. (Shelf supports must be mounted
evenly to function properly.)

T27948 Tool Cabinet (Mfd. 10/16) -3-
1
2
3
4
5
6
7
8
9
10 6
12
11 15
13
14
16 17
Parts Breakdown & List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT27948001 CABINET BODY 10 PT27948010 DOOR HANDLE CAP
2 PT27948002 ADJUSTABLE FEET M12-1.75 X 30 11 PT27948011 FLAT HD SCR M4-.7 X 8
3 PT27948003 CABLE GROMMET 12 PT27948012 LOCK W/2 KEYS
4 PT27948004 SHELF SUPPORT 13 PT27948013 TOUCH-UP PAINT, GLOSSY BLACK
5 PT27948005 SHELF 14 PT27948014 TOUCH-UP PAINT, RED
6 PT27948006 HINGE, 90-DEG SOFT-CLOSE 15 PT27948015 WARNING LABEL
7 PT27948007 DOOR (RIGHT) 16 PT27948016 QR CODE LABEL
8 PT27948008 DOOR (LEFT) 17 PT27948017 GRIZZLY.COM LABEL, GOLD
9 PT27948009 DOOR HANDLE
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call [phone] or visit our online parts store at www.grizzly.com to check for availability.
Grizzly Cabinet Series
The T27948 2-Door Tool Cabinet is part of our heavy-duty 10-piece storage set. These modular cabinets
will enhance storage and workspace in the shop or garage, and they can be mixed and matched to create
a variety of storage solutions.
T27947 T27952 T27951
T27948
T27953
T27950
T27949
