Introduction
The Model T32734 Gouge Grinding Attachment
secures your spindle gouges, bowl gouges, and
roughing gouges at angles up to 40° for sharp-
ening bevels at repeatable angles and shapes.
The brass knob locks in your tool and doubles
as a thumb rest while rounding gouges. The jig
holds tools up to 19⁄16" wide with shafts between
3⁄16"–13⁄8". Quickly grind fingernail profiles, side
grinds, and simple bevels, as well.
V1.10.21
For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T32734
GOUGE GRINDING
ATTACHMENT FOR T32732
INSTRUCTIONS
Eye and face injuries and respiratory prob-
lems can occur while operating this tool.
Wear personal protective equipment to
reduce your risk from these hazards.
Keep hair, clothing, and
jewelry away from mov-
ing parts at all times.
Entanglement can result
in death, amputation, or
severe crushing injuries!
Using Gouge Attachment
The gouge attachment secures your gouge and
rests in the V-holder of the long arm to pivot for
bevels, side grinds, and fingernail gouges.
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Figure 1. Example of gouge attachment in use.

-2- Model T32734 (Mfd. Since 10/21)
4. Loosen wing nut shown in Figure 4, adjust
attachment arm angle to match bevel angle
against grinding wheel, then tighten wing nut
to secure.
3. Rest gouge attachment arm in V-holder and
adjust long arm until gouge bevel contacts
grinding wheel (see Figure 3).
Figure 3. Gouge attachment resting in V-holder.
V-Holder
Gouge Attachment
Figure 4. Gouge installed in attachment and
positioned against grinding wheel.
5. Tilt tool away from grinding wheel, connect
grinder to power, and turn machine ON.
6. Use firm grip to return tool to surface of grind-
ing wheel to perform grinding operation (see
Figure 5). Pivot and move attachment to fol-
low gouge profile.
To use gouge attachment:
1. DISCONNECT GRINDER FROM POWER!
2. Secure gouge in gouge attachment by tight-
ening thumb screw shown in Figure 2.
Figure 2. Gouge secured in gouge attachment.
Gouge
Gouge
Attachment
Thumb Screw
Figure 5. Gouge attachment in use.
IMPORTANT: Refer to grinder manual or instruc-
tions for information on safely operating your
grinder.
Attachment
Arm
