Grizzly H3142 Quick start guide

H3142 Pneumatic Palm Hammer Kit -9-
H3142 PART BREAKDOWN
1
2
3
4
31
5
6
7
8
9
10
11
12
13
14
15
16
17
33
30
18
19
20
21
32
22
23
24
25
26
27
28
29

H3142 Pneumatic Palm Hammer Kit-10-
1PH3142001 REAR BODY
2PH3142002 CRUSH SEAL
3PH3142003 RUBBER SEAL
4PH3142004 O-RING
5PH3142005 SLEEVE
6PH3142006 O-RING
7PH3142007 O-RING
8PH3142008 PUMP
9PH3142009 PUMP COVER
10 PH3142010 O-RING
11 PH3142011 O-RING
12 PH3142012 PISTON
13 PH3142013 DRIVER
14 PH3142014 GASKET
15 PH3142015 O-RING
16 PH3142016 ANTI-VIBRATION PAD
17 PH3142017 FRONT BODY
18 PH3142018 GUIDE CAP
19 PH3142019 WAVY WASHER
20 PH3142020 PLASTIC CASE
21 PH3142021 LARGE HEAD NAILER
22 PH3142022 SMALL HEAD NAILER
23 PH3142023 MAGNETIC FINISH NAILER
24 PH3142024 STANDARD FINISH NAILER
25 PH3142025 SOFT HAMMER
26 PH3142026 STEEL HAMMER
27 PH3142027 CHISEL
28 PAW04M ALLEN WRENCH 4MM
29 PH3142029 HAND STRAP BAG
30 PSB24M CAP SCREW M5 X 16
31 PH3142031 O-RING
32 PH3142032 NAILER ADAPTER
33 PH3142033 AIR COUPLER
REF PART # DESCRIPTION
