Introduction
The Model T32796/T32797 Knife Sharpening
Jigs are fixtures designed to work with the Model
T32720 10" Wet Grinder. The Model T32796 is
for blades longer than 4" while the Model T32797
supports blades that are shorter than 4".
Figure 1. Example of Model T32796 in use.
V1.07.21
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T32796/T32797
KNIFE SHARPENING JIGS
FOR T32720 WET GRINDER
INSTRUCTIONS
Description Qty
A. Jig (T32797 Shown) ................................... 1
B. Knob Bolt M6-1 x 20 ................................... 1
Inventory
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
Figure 2. Inventory.
A
B

-2- Model T32796/T32797 (Mfd. Since 07/21)
Lock Knob Clamp Knob
Figure 4. Clamp components.
Figure 5. Example of knife blade secured in
clamp (T32796 shown).
Clamp
Knob
Lock
Knob
3. DISCONNECT GRINDER FROM POWER!
4. Install tool rest in horizontal position over
grinding or stropping wheel as required by
your operation.
5. Loosen clamp knob enough to allow knife
blade to slide in (see Figure 4).
6. Loosen lock knob enough so it does not
extend through clamp plate (see Figure 4).
To use jig:
1. Rotate adjusting ring on jig shaft so flat por-
tions shown in Figure 3 are aligned.
2. Tighten adjusting ring knob until adjusting
ring is secure on jig shaft (see Figure 3).
Adjusting Ring
Jig
Shaft
Knob
Figure 3. Adjusting ring secured correctly on jig
shaft (T32797 shown).
Using Jig
Rest the tool jig against the tool rest on the Model
T32720 10" Wet Grinder to grind or strop knives
with the direction of wheel rotation. The Model
T32796 is for blades longer than 4" while the
Model T32797 supports blades that are shorter
than 4".
Eye and face injuries and respiratory prob-
lems can occur while operating this tool.
Wear personal protective equipment to
reduce your risk from these hazards.
Keep hair, clothing, and
jewelry away from mov-
ing parts at all times.
Entanglement can result
in death, amputation, or
severe crushing injuries!
7. Insert knife blade into clamp, as shown in
Figure 5, and tighten clamp knob to secure.
8. Tighten lock knob to secure (see Figure 5).
Clamp
Plate

Model T32796/T32797 (Mfd. Since 07/21) -3-
9. Rest clamp against tool rest (see Figure 6).
Figure 6. Example of grinding knife supported by
jig (T32796 shown).
Adjusting Ring
Tool Rest
10. Adjust tool rest closer to or further from
grinding or stropping wheel until approximate
desired grinding/stropping angle is achieved.
11. Adjust position of adjusting ring to fine-tune
grinding/stropping angle (see Figure 6).
12. Tilt jig and knife away from grinding wheel,
connect grinder to power, and turn machine
ON.
13. Use firm grip to return knife blade to surface
of grinding or stropping wheel to grind or strop
knife with the direction of wheel rotation. Use
smooth stroking motion and even pressure
with side of blade flat against wheel. Pivot jig
against tool rest as needed to follow contour
of blade.
