Groen Eclipse BPM-30E User manual

MENU APPLICATIONS & COOK TIMES
MENU ITEMS TOTAL QUANTITY COOK TIME* MIN.
SCRAMBLED EGGS
100 Servings 5
BACON
90 Servings 10-12
HAMBURGER
60 Servings (4oz) 5
STEAK SANDWICH
26 Servings (7oz) 5
MEAT LOAF
16 Loaves 90
CHICKEN
150 lbs 40
FISH FILLETS
50-100 Fillets 10-14
CHILI
400 Servings 20
POTATOES : Cut & Peeled
10 lbs 25
GRAVY
23 Gallons 15
CHOCOLATE MOUSSE
200-300 Portions 15
*Cook times are approximate and do not include preparation or warm-up time. Actual cook times
may vary due to normal differences in raw ingredient quality, portion size, production quantity,
room temperature, and the condition of product and braising pan at time of preparation.
Performance plus
It’s ready when you are. The Eclipse
heats to 350˚F in just four minutes
and evenly delivers tremendous
cooking power. The floor of the pan is
specially designed to distribute heat
uniformly across the entire flat surface,
eliminating troublesome uneven hot or
cold areas found in competitive units.
The flat cooking surface is designed to
stay that way year after year so there’s
no burning or pooling.
Ergonomic by design
The narrow-width footprint saves
on expensive hood space. With
only one control box, controls are
centrally located and at an angle that
ensures easy viewing and access.
The streamlined, rounded leg stands
are easy to clean, meeting all NSF
requirements. The faucets are easier to
reach by being located closer to the
front and have the option of being
right-, left-handed, or rear-mounted.
The famous easy to clean, rounded
interior has no corners to clean.
Precision controls
The precision thermostat regulates
temperature for accurate cooking every
time and has a dependable electronic
ignition. The patented burner system,
with high efficiency, means lower
energy costs.
Performance &
Cooking Versatility
— Braise, Grill,
Poach, Steam,
Bain Marie, Cook
and/or Hold!
The Eclipse ergonomic tilting
braising pan continues to
outperform the competition
in performance, water
resistance and ergonomics
— all with a streamlined,
efficient design.
The Eclipse is a multi-
tasking, hard-working, high-
performance braising pan —
so versatile it can braise, grill,
poach, steam, bain marie,
cook and/or hold almost all
menu options.
Whether you choose the 30
or 40 gallon model, either gas
or electric, manual or power
tilt, you’ll own a fast, high-
capacity unit that will get the
job done year after year.
Defies water ingress
Kitchens get wet, especially during clean-
up time, and the Eclipse is designed to
resist splashback and spray. The control
box is sealed and the gas igniter or pilot
is shielded. The worm gear mechanism is
covered to block water so there’s no worry
when cleaning.
Easy, steady pouring
The center-tilt design has a shorter
pour, consumes less aisle space and is
designed to effectively flow the contents
of the unit with minimal surge or drip.
Smooth tilting action
Our smooth-action, quick-tilting
mechanism is tightly toleranced to
prevent jerking or halting, making it
easy to gently and steadily transfer
large-capacity batches. Available in
both manual tilt and electric tilt (with
easy-to-access manual override). Manual
tilt has a smooth-action, self-locking
hand crank that provides precise control
when pouring. Ten-inch high pan sides
and cover minimize grease and splatter
— especially important when pouring
product during tilting.
Increased flexibility
Four standard bullet feet are field-
retrofittable and interchangeable with
optional flanged feet or casters.
Competitive Advantages

BPM-40G, 40-gallon, gas unit, manual
tilt, shown with optional casters, faucet
and pan carrier
3
7
8
6
4
2
SPECIFICATIONS
POWER INPUT
(per cavity)
DIMENSIONS
W x D x H
APPROX.
WEIGHT
30 Gallon Electric: BPM-30E ManualTilt & BPP-30E PowerTilt
11.5 KW 39” x 40” x 38”
(991mm x 1016mm x 965mm)
425 LBS
(193 Kg)
30 Gallon Gas: BPM-30G ManualTilt & BPP-30G PowerTilt
104,000 BTU 39” x 40” x 38”
(991mm x 1016mm x 965mm)
440 LBS
(200 Kg)
40 Gallon Electric: BPM-40E ManualTilt & BPP-40E PowerTilt
15 KW 48” x 40” x 38”
(1219mm x 1016mm x 965mm)
510 LBS
(232 Kg)
40 Gallon Gas: BPM-40G ManualTilt & BPP-40G PowerTilt
144,000 BTU 48” x 40” x 38”
(1219mm x 1016mm x 965mm)
540 LBS
(246 Kg)
3
1
4
2
3”Radius seamless interiors
for durability and ease of cleaning
Water resistant controls
(shown for electric unit, power tilt)
Easy-to-clean rounded leg stands
Center tilt pour lip for minimal surge or drip
Optional pan carrier for ease of pouring
Dial thermostat for gas units
Easy to reach optional faucet for
conveniently adding water to the pan
Hand crank wheel for manual tilt units
5-Gallon etch marks standard for
fill guidelines
5
6
7
8
5
1
Counterbalanced cover design
The Eclipse tilting braising pan’s improved, counterbalanced
cover design ensures ease of assembly and easier cleaning to meet
all NSF standards. The fully adjustable cover will stay put wherever
it’s set for ease of operation. The cover allows for controlled steam
venting while the adjustable steam vent controls condensate during
cooking. The integral condensate drip lip returns water to the
product, not on the floor behind the unit.The heavy-duty cover lets
you oven-cook all meats, poultry, and seafood. Fewer working parts
assure increased durability and higher performance.
Pan cooking volume to nominal
Eclipse has increased pan cooking volume to nominal for
increased holding capability, while maintaining safety standards.
Cook more food product faster in fewer batches while preserving
food quality, texture, and flavor.
Groen quality and durability
No one beats our build quality. We’ve strengthened our hinges on
the cover for increased durability and longer life. Easy-to-clean,
three-inch rounded interiors are unmatched by any competitor.
The rounded corners eliminate food build-up which means less
burning. The stainless steel interior with sanitary finishes make
clean-up easy and fast, even after cooking sticky foods.
Eclipse one-year warranty
Each Eclipse model has a full one-year warranty.
9
9

FOODSERVICE EQUIPMENT SOLUTIONS
BRAISING PANS KETTLES
SMARTSTEAM100™
BOILERLESS
STEAMERS
VORTEX100®
CONNECTIONLESS
STEAMERS
EBP 06/07
888-994-7636 • groen100.com
Information contained in this document is known to be current and accurate at the time of printing.
Unied Brands recommends referencing our product line websites for the most updated product information and specications.
