Grossenbacher Systeme WebPanel WP-284-10P-000 User manual

WebPanel
WP-284-10P-000
Grossenbacher Systems AG
Spinnereistrasse 10, CH-9008 St. Gallen
Phone [phone] / Fa [phone]
[e-mail] / www.gesys.ch
Grossenbacher Systems GmbH
Feldwiesenstrasse 8, DE-79807 Lottstetten
Phone [phone] / Fa [phone]
[email protected]
OPERATI G I STRUCTIO S
ARM
i.MX 8
Quad

WebPanel
WP-284-10P-000
Grossenbacher Systems AG
Spinnereistrasse 10, CH-9008 St. Gallen
Phone [phone] / Fa [phone]
[e-mail] / www.gesys.ch
Grossenbacher Systems GmbH
Feldwiesenstrasse 8, DE-79807 Lottstetten
Phone [phone] / Fa [phone]
[email protected]
Copyright notice
These operating instructions and all illustrations contained therein are protected by copy-
right. Any use outside the limits of copyright law is prohibited without the prior written
consent of Grossenbacher Systeme AG and is punishable by law. This applies to
reproductions, translations, microfilming, storage, and processing in electronic systems.
The Grossenbacher Systeme AG accepts no liability for damage, caused by the use of
incorrect or inadequate information or due to missing information in these documents.
The Grossenbacher Systeme AG reserves the right to change this document in part or in
full.
All brand and product names are trademarks or registered trademarks of their respective
titleholders/owners.
Overview of changes
Version Date of issue Change / Remark
01 (V1.0) 02.05.2022 / jh Initial document as working version.
Later ported into SAP/DMS as 122517-01.
02 (V1.1) 10.06.2022 / jh Preliminary version for technical approbation.
Update for supply rating/classification.
Later ported into SAP/DMS as 122517-02.
03 10.11.2023 / wm Preliminary release for customer.
04 15.11.2023 / wm First formal release.
Bases on German version with Doc-ID 122516-02.
05 14.12.2023 / wm Corrections, additions, and alignments with the
SmartPanel operating instructions.
Bases on German version with Doc-ID 122516-03.

Content
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
I
-
Content
1 Introduction ........................................................................................................................... 3
1.1 Means of presentation ............................................................................................................... 3
1.1.1 Section-related warnings ................................................................................................ 3
1.1.2 Embedded warnings ....................................................................................................... 4
1.1.3 Other means of presentation ......................................................................................... 4
1.2 Symbols used in the instructions ............................................................................................... 5
1.3 Warranty and liability ................................................................................................................. 5
1.4 Applicable documents ............................................................................................................... 5
1.5 Order number ............................................................................................................................ 6
1.6 Service / Product support .......................................................................................................... 6
2 Security .................................................................................................................................. 7
2.1 Intended use .............................................................................................................................. 7
2.1.1 Structural changes to the device .................................................................................... 7
2.1.2 Foreseeable misuse ........................................................................................................ 7
2.2 Requirements for personnel ...................................................................................................... 8
3 Description ............................................................................................................................. 9
3.1 Device overview ......................................................................................................................... 9
3.2 Connections / Interfaces .......................................................................................................... 10
3.3 Technical data .......................................................................................................................... 11
3.3.1 Dimensions ................................................................................................................... 11
3.3.2 Power supply / Power consumption ............................................................................ 12
3.3.3 Electromagnetic compatibility / Protection class ......................................................... 13
3.3.4 Specifications ................................................................................................................ 14
3.3.5 Ambient conditions ...................................................................................................... 15
3.3.6 Certification .................................................................................................................. 15
4 Transportation / Storage / Scope of delivery ......................................................................... 17
4.1 Transportation .......................................................................................................................... 17
4.2 Storage ..................................................................................................................................... 17
4.3 Scope of delivery ...................................................................................................................... 17
5 Assembly .............................................................................................................................. 19
5.1 Preparatory measures .............................................................................................................. 19
5.2 Dimensions / Installation cut-out............................................................................................. 20
5.3 Device installation .................................................................................................................... 23
6 Connection ........................................................................................................................... 25
6.1 Power supply ............................................................................................................................ 25
6.2 Data connections ..................................................................................................................... 28
6.2.1 Ethernet interface ........................................................................................................ 28

Content
-
II
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
7 Cleaning / Repairs ................................................................................................................. 31
7.1 Cleaning ................................................................................................................................... 31
7.2 Repairs ..................................................................................................................................... 31
8 Disposal ................................................................................................................................ 33
9 Conformity and standards ..................................................................................................... 35
9.1 EC Declaration of Conformity .................................................................................................. 35

1 Introduction
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
3
-
1Introduction
These operating instructions are an integral part of the WebPanel WP-284-10P-000 (herein-
after referred to as device or WebPanel).
The operating instructions must be read, understood, and applied by all persons responsible
for installing the device.
In addition to the operating instructions, generally applicable, statutory, and other binding
regulations for accident prevention and environmental protection in the country of use
must be observed.
1.1 Means of presentation
As a note and as a direct warning of dangers, te t passages in these operating instructions
that require special attention are marked as follows:
1.1.1 Section-related warnings
Section-related warnings apply not only to a specific action, but to all actions within a
section.
Structure
SIG AL WORD
Symbol to
explain the
danger
ature and source of the danger
Possible consequences of non-compliance
►Measures to avoid the danger
Hazard levels
DA GER
Danger with a high degree of risk
If the danger is not avoided, this will result in death or serious injury.
WAR I G
Danger with medium degree of risk
If the danger is not avoided, it can result in death or serious injury.

1 Introduction
-
4
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
CAUTIO
Danger with low risk level
If the danger is not avoided, this may result in minor or moderate bodily in-
jury.
NOTE
Risk of property damage with a low degree of risk
If the danger is not avoided, this can result in material damage.
1.1.2 Embedded warnings
Embedded warnings apply to specific actions and are directly integrated into the action.
Structure
SIG ALWORD Nature and source of danger
Possible consequences of non-compliance
►Measures to avoid the danger
Hazard levels
‒ DA GER / WAR I G / CAUTIO
‒ NOTE
For e planations of the hazard levels, see chapter "1.1.1".
1.1.3 Other means of presentation
The info symbol refers to important information about the device.
- Te ts that follow this marking are enumerations.
►
Te ts that follow this marking describe measures in warnings and action steps.
" "
Te ts in quotation marks are references to other chapters or sections.

1 Introduction
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
5
-
1.2 Symbols used in the instructions
In warnings, special dangers are additionally marked as follows:
Danger to life due to electric current
This symbol warns of the danger to life from electric current.
General
dangers
This symbol warns of general hazards that may occur during all phases
of the device's life.
ESD protection measures
This symbol warns of destruction due to electrostatic discharge on
electronic components if ESD protection measures are not observed.
1.3 Warranty and liability
The obligations agreed in the delivery contract, the general terms and conditions, as well as
the delivery conditions of the device(s) and the statutory regulations, valid at the time the
contract is concluded, shall apply.
All information and notes in these operating instructions have been compiled taking into
account the applicable standards and regulations, the state of the art and our many years of
knowledge and e perience.
Warranty and liability claim for personal injury and property damage are e cluded if they
are attributable to one or more of the following causes:
‒Defects caused by improper use or improper handling of the devices.
‒Consequential damage caused by failure or malfunction of the device(s).
‒Non-observance of the operating instructions
‒Use of unqualified or untrained personnel
‒Structural modifications to the equipment
1.4 Applicable documents
Document Document o.
No document defined -

1 Introduction
-
6
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
1.5 Order number
Type Format Structure / Mounting Order number
WP-284-10P-000 10.1" special mounting,
flat-on-front
(custom design)
5082024
1.6 Service / Product support
For technical information, please contact our customer service:
Manufacturer address Representation Germany
Grossenbacher Systems AG
Spinnereistrasse 10
CH-9008 St. Gallen
Switzerland
Grossenbacher Systems GmbH
Feldwiesenstrasse 8
DE-79807 Lottstetten
Germany
Tel: [phone]
Fa : [phone]
E-Mail: [email protected]
Homepage: www.gesys.ch
Tel: [phone]
Fa : [phone]
E-Mail: [email protected]
Homepage: www.gesys.ch
In addition, our employees are constantly interested in new information and e periences
that result from the application and can be valuable for the improvement of our products.

2 Security
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
7
-
2Security
►Read the operating instructions thoroughly before installing and connecting the device.
►In addition to the operating instructions, also observe the e isting national/regional
work safety and accident prevention regulations.
2.1 Intended use
The device is designed for use in industrial and commercial applications.
The operational safety of the device is only guaranteed if it is used as intended.
The device is designed e clusively for
‒indoor use,
‒installation in higher-level machines/systems,
‒the visualization of control processes in machines/systems.
This device is equipment of protection Class III and may only be supplied with safety e tra-
low voltage (SELV/PELV).
The device is not intended for any other use than that listed here; this is considered im-
proper use.
Intended use also includes
‒observance of the operating instructions,
‒compliance with the operating conditions and technical specifications.
2.1.1 Structural changes to the device
Structural changes (e tensions and conversions) mean that warranty and liability claim for
personal injury and property damage are e cluded.
►Replace devices that are not in perfect condition immediately.
Parts and components that are not supplied by Grossenbacher Systeme AG are not ap-
proved for use on the device.
2.1.2 Foreseeable misuse
Any use of the devices that goes beyond the intended use and/or any other use may result
in damage to the devices.
In particular:
‒The device must not be switched on when dew is present. After a change of location
from cold to warm, the temperature of the device must be allowed to equalize before
commissioning.
‒No safety-relevant functions - in terms of personal, machine and system protection - may
be implemented via the device.

2 Security
-
8
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
2.2 Requirements for personnel
The device may only be installed, connected, commissioned, and repaired by technically
qualified personnel.
Technically qualified personnel
Technically qualified staff is
‒as project planning personnel, familiar with the safety concepts of automation technol-
ogy.
or
‒has been instructed as operating personnel in the use of automation technology equip-
ment and has knowledge of how to operate the devices.
or
‒are qualified to carry out repairs on such equipment as commissioning and service per-
sonnel, as a result of competent training in automation technology.
or
‒are qualified to commission circuits and devices/systems in accordance with safety
engineering standards.
Obligation of the staff
All persons responsible for installation are obliged to observe the basic regulations on work
safety and accident prevention and to read the safety instructions and warnings in these op-
erating instructions.

3 Description
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
9
-
3Description
The WebPanel WP-284-10P-000 is based on a powerful and energy-efficient RISC proces-
sors (Arm Corte -A) and is used in the function of a web browser (web panel) for display
and operation (HMI) in industrial and commercial environments.
3.1 Device overview
Pos. Element
1 Cover

3 Description
-
10
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
3.2 Connections / Interfaces
Pos. Element Short designation Description
1 Ethernet (LAN) ETH see chapter "6.2"
2 Power supply Supply see chapter "6.1"

3 Description
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
11
-
3.3 Technical data
3.3.1 Dimensions
Device Structure /
Installation type
Length
(mm)
Wide
(mm)
Depth
(mm)
WP-284-10P-000 special shape/mounting,
flat-on-front
(custom design)
257.4 173.7 41.0

3 Description
-
12
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
3.3.2 Power supply / Power consumption
Parameter Value
Nominal voltage +24 VDC
Protective e tra-low voltage (PELV), protection class III
Permissible voltage range 19.2 - 30.0 VDC, absolute with ripple
(nominal voltage -20/-25 %)
Transient 35.0 V, for a duration < 100 ms
Electrical isolation No
0V-terminal connected to housing potential (FE)
Reverse polarity protection Yes, diode
No operation possible if polarity is reversed
Protection fuse
(interrupting capability)
Yes, lead fuse,
cannot be changed from outside
(1)
1.5 AT (300A @32VDC)
Ma . current consumption
(2)
in operation without backup
charging current
0.50 A @24V (0.60 A @19.2 V)
Ma . current consumption
(2)
with backup charging current
0.70 A @19.2V
Ma . inrush current (I
2
t) 0.7 A
2
s
Ma . power consumption
(2)
w/o backup charging current
11.0 W
Backup charging current
(2)
(after power-on)
2.0 W peak, time constant (τ) 220 ms
Voltage dips and bridging
(3)
typ. 18 ms @24V (min. 8 ms)
(1) The fuse can/may only be replaced by service personnel from Grossenbacher
Systeme AG.
(2) After switching on or a voltage dip with bridging, the backup storage is
charging/recharging for a short time (backup charging current after power on).
This additional power must be considered when determining the ma imum power
consumption and current limit of the power supply.
(3) Bridging of short voltage dips, with temporary display backlight switch-off.

3 Description
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
13
-
3.3.3 Electromagnetic compatibility / Protection class
Parameter Version
EMC immunity Interference immunity for industrial environments,
in accordance with EN 61000-6-2
EMC interference
radiation
Interference emission for residential, commercial and
light-industrial environments,
in accordance with EN 61000-6-3
Protection class
(4)
Front component of the device: IP 65
Rear component of the device: IP 20
(4) IP protection class according to comparable device design.
The device is only suitable for indoor use.

3 Description
-
14
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
3.3.4 Specifications
Art Version
Screen technology TFT-LCD
Screen size and resolution 10.1“, 1280 800 (WXGA, 16:10)
Display area 217 136 mm
Image contrast 500:1
Backlight
(5)
LED, dimmable via software
Service life: 50000 hrs
Brightness: 350 cd/m
2
Touch screen PCAP touch
Processor Arm Corte -A53, NXP i.MX8M-Mini, Quad Core
Working memory 2 GB, DDR4, soldered
Nonvolatile memory (SSD) 8 GB, MLC eMMC, soldered
Real-time clock (RTC) not available
Communication interfaces Gigabit Ethernet (1000Base-T)
Device cooling passive (fan-less)
Cover glass Scratch-resistant glass,
glass thickness typ. 1 mm
(5) The intensity of the display backlighting can be set by the application. The backlight is
temporarily switched off, in the event of power supply interruptions, which can be de-
tected and bridged by the system.

3 Description
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
15
-
3.3.5 Ambient conditions
Art Condition
Climate operation Temperature
(6)
:
0 - 50 °C
Rel. humidity: 10 - 85 %, non-condensing
Climate storage/transport Temperature: -20 - 70 °C
Rel. humidity: 10 - 85 %, non-condensing
Vibration operation 10 - 53 Hz: 0.35 mm
53 - 500 Hz: 2 g
Vibration transport 10 - 84 Hz: 0.35 mm
84 - 500 Hz: 5 g
Shock 15 g / 11 ms
Ma . height for operation 2000 m above sea level
(6) Temperature measurement: 5 cm below the WebPanel (vertical installation).
3.3.6 Certification
Device Structure /
Mounting Certification
WP-284-10P-000 special mounting,
flat-on-front
(custom design)
- CE
- UL approval (AZOT2.E492671)

3 Description
-
16
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000

4 Transportation / Storage / Scope of delivery
WP
-
284
-
10P
-
000
Doc
-
ID: 122517
-
05
-
17
-
4Transportation / Storage / Scope of delivery
4.1 Transportation
Check for transport damage
►Check the device for visible transport damage and report any transport damage
immediately to the delivery office.
Protection of the device
►Only use the original packaging for transport the device.
►Observe the ambient conditions (see chapter "3.3.5").
4.2 Storage
►Observe the ambient conditions (see chapter "3.3.5").
Recommendation: Store the device at room temperature.
4.3 Scope of delivery
The scope of delivery of the device consists of the following components:
‒WebPanel, WP-284-10P-000

4 Transportation / Storage / Scope of delivery
-
18
-
Doc
-
ID: 122517
-
05
WP
-
284
-
10P
-
000
