Growatt MOD TL3-XA Series User manual

Download
Manual
Growatt New Energy
Installation
&
Operation Manual
GR-UM-287-A-00
Shenzhen Growatt New Energy Co., Ltd
4-13/F,Building A,Sino-German(Europe) Industrial Park,
Hangcheng Ave,Bao’an District, Shenzhen, China
[phone]
www.ginverter.com
T
E
W
[e-mail]

Index
1 Notes on this manual
2 Safety
3 Product overview 3.1 Appearance overview
3.2 Dimensions
3.3 Storage environment
1.1 Validity
1.2 Applicable personnel
1.3 Symbols in this document
2.1 Product description and features
2.2 Qualification of skilled person
2.3 Safety instruction
4 Unpacking inspection
5 Installation 5.1 Basic installation requirements
5.2 Mounting wall mount
5.3 Installing the inverter
6.1 Security
6.2 AC side wiring
6.3 Connecting the Bidirectional DC/
DC Box
6.4 Connect the signal cable
6.5 Grounding the inverter
6.6 Active power control with smart
meter or ripple control signal
receiver
6.7 Inverter demand response modes
(DRMS)
6.8 GFCI(Standard)
6.9 Backup(optional)
6 Inverter wiring

8.1 Normal mode
8.2 Failure mode
13.1 Error message
13.2 Syetem error
15.1 Dismantling the inverter
15.2 Packing the inverter
15.3 Storing the inverter
15.4 Disposing of the inverter
13 Troubleshooting
8 Working mode 14 Manufacturer warranty
15 Decommissioning
17 Specification
16 EU declaration of conformity
18 Compliance certificates
9.1 Start the inverter
9.2 General setting
9.3 Advanced setting
12.1 Start the inverter
12.2 Shut down the inverter
9 OLED display and touch
buttons
19 Contect us
12 Start the inverter and shut
down the inverter
10 Communication and
monitoring
11 Maintenance and Cleaning
10.1 COM port
10.2 USB-A
11.1 Checking heat dissipation
11.2 Cleaning the inverter
11.3 Checking the DC disonnect
7 Debugging

This manual will provide detailed product information and installation instructions for
users of MOD TL3-XA series AC coupled inverter of Shenzhen Growatt new energy Co.,
Ltd. (hereinafter referred to as Growatt new energy). Please read this manual carefully
before using this product. Growatt new energy will not inform users of any changes to
this manual.
MOD 3000TL3-XA
MOD 4000TL3-XA
MOD 5000TL3-XA
MOD 6000TL3-XA
MOD 7000TL3-XA
MOD 8000TL3-XA
MOD 9000TL3-XA
MOD 10KTL3-XA
WARNING
DANGER
DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
1.3 Symbols in this document
1.3.1 Symbols in this document
Warnings indicate hazards to equipment or personnel. It draws your attention to a certain
procedure or practice. If the procedure or practice is not properly implemented or
followed, it may cause damage or destruction of part or all of the Growatt device and/or
other equipment connected to the Growatt device, or cause personal injury.
1.3.2 Markings on this product
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
Information that you must read and know to ensure optimal
operation of the system.
NOTICE
Information
Danger: Electricity!
Point of connection for grounding protection
Danger:Hot surface!
Alternating Current (AC)
Danger:Flame!
Direct Current (DC)
Operation after 5 minutes
Read the manual
CE mark.
The inverter complies with the requirements of the applicable CE
guidelines.
The inverter must not be disposed of with the household waste.
The inverter must be installed by professional electricians who are certified by relevant
departments. By reading this manual in detail, the installer can install the MOD TL3-XA
series inverter correctly and quickly, and can carry out troubleshooting and
communication system construction.
If there are any problems during the installation process, the installer can log on to
www.growatt.com to leave a message on the website or call our 24-hour service
phone: .[phone]
1.2 Applicable personnel
1 Notes on this manual
1.1 Validity
Symbol Description
Symbol Explanation

1.3.3 Glossary
AC
Abbreviation for "Alternating Current”
DC
Abbreviation for "Direct Current”
Energy
Energy is measured in Wh (watt hours), kWh (kilowatt hours) or MWh (megawatt hours).
The energy is the power calculated over time. For example, your inverter operates at a
constant power of 4600 W for half an hour and then at a constant power of 2300 W for
another half an hour, it has fed 3450Wh of energy into the power distribution grid within
that hour.
Power
Power is measured in W (watts), kW (kilowatts) or MW (megawatts). Power is an
instantaneous value. It displays the power your inverter is currently feeding into the
power distribution grid.
Power rate
Power rate is the radio of current power feeding into the power distribution grid and the
maximum power of the inverter that can feed into the power distribution grid.
Power factor
Power factor is the ratio of active power or watts to apparent power or volt amps. They
are identical only when current and voltage are in phase then the power factor is 1.0. The
power in an ac circuit is very seldom equal to the direct product of the volts and amperes.
In order to find the power of a single phase ac circuit the product of volts and amperes
must be multiplied by the power factor.
Wireless communication
The external wireless communication technology is a radio technology that allows the
inverter and other communication products to communicate with each other.The
wireless communication device is not standard. Require to order extral if you need it.
Safety 2
2.1 Product description and features
2.1.1 Product description
Position
Description
A
Battery matched with XA inverter
B
DC circuit breaker
C
MOD XA Inverter
D、I
AC circuit breaker
E、J
Electric energy meter
F
Utility grid
G
Solar panel
H
The other inverter
2.1.2 Product features
The characteristics of the inverter are as follows:
Ø Compatible with RS485/Wifi/GPRS/4G communication
Ø OLED+LED/WIFI+APP display
Ø Integrated with touch button
Ø Protection grade IP66
Ø The weight is only 13kg
Ø Simple installation
Ø Integrated with energy storage and backup functions(backup function needs to be
equipped with a backuo box)
Ø Integrated with phase-level export limitation function
Ø Integrated with AC power supply function
Ø Integrated with energy storage one-key detection function
Ø Integrated with AC power supply function to realize the 24h self-consumption
monitoring
Fig 2.1
3 4
MOD TL3-XA series are the AC Coupled inverter which can store energy into battery with
or without existing grid-tied inverter system. MOD TL3-XA can be used to optimize
selfconsumption、stored in the battery or feed into public grid. It also can provide power
for emergency use during the grid lost by using the energy from the battery.

2.3 Safety instructions
1.Please read this manual carefully before installation.If you fail to install according
to the instructions in this manual,or ignore the warnings in the manual and the
equipment is damaged,our company reserves the right not to guarantee the quality;
2.All operations and wiring should be finished by the professional electrical or mechanic-
al engineers;
3.During installation,except for the wiring terminals,please do not move other parts
inside the chassis;
4.All electrical installations must comply with local electrical safety standards;
5.If the machine needs maintenance,please contact the local designated system
installation and maintenance personnel;
6.The use of this machine for grid-connected power generation requires permission
from the local power supply department;
2.2 Qualification of skilled person
This AC coupled inverter system operates only when properly connected to the AC
distribution network. Before connecting the MOD TL3-XA to the power distribution
grid, contact the local power distribution grid company. This connection must be made
only by qualified technical personnel to connect, and only after receiving appropriate
approvals, as required by the local authority having jurisdiction.
ØGrounding the PV modules：MOD TL3-XH is a transformerless
inverter. which means there is no galvanic separation. Do not
grounding the DC side of the MODTL3-XH inverter. Only
grounding the mounting frame of the photovoltaic module.
Otherwise there will be an error message "PV ISO Low".
ØComply with the local requirements for grounding the PV
modules and the PV generator. GROWATT recommends
connecting the generator frame and other electrically conductive
surfaces in a manner which ensures continuous conduction with
ground in order to have optimal protection of the system and
personnel.
CAUTION
2.3.2 Electrical Connection Warnings
ŸDo not open the inverter except the wire box by qualified persons.
ŸElectrical installation, repairs and conversions may only be carried
out by electrically qualified persons.
ŸForbid live line work.
ØDanger to life due to high voltages in the inverter
ØPersons with limited physical or mental abilities may only work
with the Growatt inverter following proper instruction and under
constant supervision. Must keep the Growatt inverter away from
children.
ŸThere is residual voltage in the inverter after the device shutdown.
The inverter need to take 20 minutes to discharge for safety.
ØThe components in the inverter are live. Touching live components
can result in serious injury or death.
DANGER
ØMake all electrical connections (e.g. conductor termination,
fuses, PE connection, etc.) in accordance with prevailing
regulations. When using the inverter to provide the power,
adhere to all prevailing safety regulations to minimize risk of
accidents.
ØSystems with inverters typically require additional control (e.g.,
switches, disconnects) or protective devices (e.g., fusing circuit
breakers) depending upon the prevailing safety rules.
WARNING
56
ØBefore installation, pleae check the unit to ensure that there is no
transportation or handling damage, which may affect the
insulation integrity or safety clearances; otherwise, it may cause
safety hazards.
ØFollow the instructions in this manual to assemble the inverter.
Note that select the suitable mounting location and comply with
the specified requirements of cooling.
ØUnauthorized removal of necessary protections, improper use,
incorrect installation and operation may lead to serious safety and
shock hazards and/or equipment damage.
ØIn order to minimize the possibility of shock hazards due to
dangerous voltages, cover the entire solar array with dark colored
materials before connecting the array to any equipment.
WARNING
2.3.1 Assembly Warnings
2.3.3 Operation Warnings
CAUTION
WARNING
ØEnsure all connectors are sealed and secure during operation.
ØAlthough designed to meet all safety requirements, some parts
and surfaces of inverter are still hot during operation. To reduce
the risk of injury, do not touch the heat sink at the back of the PV-
inverter or nearby surfaces while inverter is operating.
ØIncorrect sizing of the PV panels may result in voltages being
present which could destroy the inverter. The inverter display will
read the error message “PV voltage High!”
ØAll operations regarding transport, installation and start-up,
including maintenance must be operated by qualified, trained
personnel and in compliance with all prevailing codes and
regulations.
ØWhen the inverter is disconnected from the grid, please be careful
because some components can retain enough charge to create a
shock hazard. In order to minimize the occurrence of this
situation,observe all corresponding safety symbols and marks in
this manual.
ØUnder special circumstances, the inverter may be subject to
electromagnetic interference from surrounding equipment. At this
time, the user is obliged to take correct measures to reduce the
interference from surrounding equipment to the inverter.
ØDo not stay close to the inverter less than 20cm at any time.

8
7
3 Product overview
3.1 Appearance overview
The appearance instructions are as follows:
No.
Name
No.
Name
A
Front panel
F
COM port
B
Touch button
G
USB port
C
OLED screen
H
Vent valve
D
LED indicator
I
AC terminal
E
Battery terminal
The label description on the inverter:
Fig 3.1
ABCDEFGHI
Touch symbol
Touch button.We can switch the OLED display and set
parameter by touching.
Inverter status
symbol
Inverter status
LED color
LED status
Standby
Green
0.5S on and
2S off
Normal
Green
Solid
Fault
Red
Solid
Inverter waring/Battery
fault
Green
0.5s on,0.5s
off/0.5s on,2s off
Inverter status
Yellow
1s on and 1s off
Symbol Description Explanation
3.2 Dimensions
Size and weight:
Model
Height (H)
Width (W)
Depth (D)
Weight
MOD 3-6KTL3-XA
387mm
425mm
147mm
11.5kg
MOD 7-10KTL3-XA
387mm
425mm
178mm
13kg
If you want to store the inverter in a warehouse, you must choose a suitable location for
the inverter.
ØThe equipment must be stored in its original packaging.
ØThe storage temperature should always be between -25° C and +60° C, and the
storage relative humidity should be less than 90%.
ØIf you need to store a batch of inverters, the maximum number of layers of the
original carton is 4.
3.3 Storage Environment
Fig 3.2

10
9
4 Unpacking inspection
Before opening the inverter package,please check whether the outer package is
damaged.After unpacking,please check whether the appearance of the inverter is
damaged or lack of accessories.If there is damage or missing parts,please contact the
dealer.
No.
Description
Qty.
A
Inverter
1
B
Quick Installation Manual
1
C
Wall bracket
1
D
COM port connector
1
E
AC connector
1
F
AC connector shell
1
G
Plastic expansion tube
3
H
Expansion screw
3
I
Security screw
1
J
PV terminal removal tool
1
Fig 4.1
Installation 5
5.1 Basic installation requirements
ØThe wall on which the inverter is mounted must be sturdy and can withstand the
weight of the inverter for a long time (refer to the specifications in Chapter 17 for the
weight of the inverter);
ØThe installation location must match the size of the inverter;
ØDo not install the inverter on a building constructed of flammable or heat-resistant
materials;
ØInstall the inverter in an eye-view orientation to facilitate inspection of the OLED
display and maintenance work;
ØThe machine's degree of protection is IP66 and can be installed indoors and outdoors;
ØIt is not recommended to expose the inverter directly to strong sunlight to prevent
overheating and cause power derating;
ØThe humidity of the installation environment should be between 0 and 90%;
ØThe ambient temperature around the inverter should be between -25 ° C ~ 60 ° C;
ØThe inverter can be mounted on a plane that is tilted vertically or backwards.
Please refer to the following figure:
ØIn order to ensure the normal operation of the machine and the convenience of
personnel operation, please pay attention to provide sufficient clearance for the inverter.
Please refer to the figure below:
Direction
Minimum clearance (mm)
Above
500
Under
500
Both sides
300
Forward
300
Fig 5.1 Installation diagram

11 12
ØDo not install the inverter on the TV antenna, other antennas or antenna cables;
ØDo not install the inverter in the living area;
ØDo not install the inverter where children can reach it;
ØThe inverter should be installed in a sheltered and protected location such as cool,
rain-proof;
Fig 5.2 Installation dimensions for one inverter
Fig 5.3 Installation dimensions for multiple inverters
Fig 5.4 Installation Environment
ØMake sure that the inverter is installed in a suitable place and is not allowed to be
installed in a closed box;
Fig 5.5 Closed box
ØIn order to reduce the inverter load and extend the life of the inverter due to direct
sunlight, we recommend installing a awning. The distance between the awning and the
inverter is as follows:
Fig 5.6 Sunshade

14
13
5.2 Install the wall mount
5.2.1 Install the wall mount
To prevent electric shock or other damage, be sure to check the wall
for power or other piping before opening the hole in the wall.
Danger
Secure the wall mount as shown, do not let the screws flush with the wall, instead expose
2 to 4 mm.
5.3 Installing the inverter
Note: Before installing the inverter, you must first make sure that the wall mount is firmly
fixed to the wall.
steps:
1.Hang the inverter on the wall mount and keep the inverter balanced when hanging.
2.To ensure that the inverter can be securely attached to the wall, secure the side of the
inverter with the M5 safety screw on the left.
Fig 5.7 Specifications of wall mount
Fig 5.8 Schematic diagram of wall mount installation
Fig 5.9 Schematic diagram of inverter wall mounting

Danger
Warning
16
15
6 Inverter wiring
6.1 Security
There may be a high voltage in the conductive part of the inverter,
which may cause electric shock.Therefore, when installing the
inverter,make sure that the AC and DC sides of the inverter are
powered off.
Static electricity may damage the electronic components of the
inverter.Anti-static measures should be taken during the
replacement or installation of the inverter.
Moisture and dust penetration can damage the inverter
ØMake sure that the waterproof cable gland is firmly tightened.
ØIf the cable connector is not installed correctly, the inverter
may be damaged due to the penetration of moisture and dust. All
warranty claims are void
Note
6.2 AC side wiring
Before making electrical connections, please make sure that
disconnect the battery and disconnect the AC side MCB,
otherwise the high voltage of the inverter may cause death.
ØEach inverter must be installed with an AC circuit breaker
independently, and it is forbidden to share multiple inverters.
ØIt is forbidden to use single-core wire at the output terminal of
the inverter.
ØIt is forbidden to use aluminum wires as output cables.
ØPlease ensure that the output cable is well connected
before turning on the inverter.Ignoring the above warning
may damage the machine or cause other losses.In this case,
the company reserves the right not to carry out the warranty
and bear any responsibility and related expenses.
Moisture and dust penetration can damage the inverter.
ØMake sure the cable connector is securely tightened.
ØIf the cable connector is not installed correctly, the inverter
may be damaged by moisture and dust. All warranty claims are
invalid.
Danger
Warning
Note
You must install a separate three phase circuit-breaker or other load disconnection unit
for each inverter in order to ensure that the inverter can be safely disconnected under
load.
We suggest you choice the AC breaker rating current in this table:
Inverter model
Switch specification
MOD 3000TL3-XA
10A(230/400V)
MOD 4000TL3-XA
10A(230/400V)
MOD 5000TL3-XA
15A(230/400V)
MOD 6000TL3-XA
15A(230/400V)
MOD 7000TL3-XA
15A(230/400V)
MOD 8000TL3-XA
20A(230/400V)
MOD 9000TL3-XA
20A(230/400V)
MOD 10KTL3-XA
20A(230/400V)
AC connection steps :
1.Pass the 5 wires (A,B,C,N and PE wires) through the AC shield,crimp the O/U terminal
and connect to the screw terminals on the AC connector.
a
b
c
Fig 6.1 AC output wiring diagram
Residual current protection device (RCMU)
Because the inverter itself has a high-precision residual current detection device,it is
not recommended to install a leakage protection switch in the system.If for some
special reason,it must be installed between the inverter output and the grid.Please
install a type A leakage protection switch no less than 300mA.When multiple
leakage protection switches are installed in the system,it is forbidden to share the
neutral line,otherwise the leakage protection function may be triggered by mistake
and cause the switch to trip.

18
17
2. Lock the AC cable to the corresponding AC terminal.
3.Lock the protective cover on the inverter frame, and finally tighten the protective cover
hole.
Fig 6.2 Wiring diagram of AC terminal
Fig 6.3 AC quick connection diagram
TheIn verte rSide
TheIn verte rSide
Suggested line length:
Model
Wire ross-sectional area(Cu)
Maximum wire length
MOD 3-6KTL3-XA
2
6-8mm
40m
MOD 7-10KTL3-XA
2
6-10mm
30m
6.3 Connecting the Bidirectional DC/DC Box
6.3.1 Conditions for Bidirectional DC/DC Box
The MOD
3-10KTL3-XA
three-phase
inverter has one
independent
BAT
input
:
BAT+/BAT-
connecting to the output of Bidirectional DC/DC Box.Notice
that the
connectors are
in
paired
(male
and female
connectors).
The connectorsfor Bidirectional
DC/DC Box and
inverters are Helios H4-R/VP-D4/MC4 connectors;The bidirectional DC/DC
box is used to
cooperate with the inverter to manage battery charge and discharge.
Note： DC/DC box must be purchased separately to inverter
Fig 6.4
6.3.2 Connecting the Bidirectional DC/DC Box
Connection of BAT input terminal
Danger to life due to lethal voltages!
Before connecting the Bidirectional DC/DC Box, ensure that the Box
do not connect any power supply. NEVER connect or disconnect the
BAT connectors under load.
Forbidden to reverse the positive and negative poles of the
Bidirectional DC/DC Box and the inverter.
Improper operation during the wiring process can cause fatal injury
to operator or unrecoverable damage to the inverter. Only qualified
personnel can perform the wiring work.
WARNING
DANGER
4~6mm²
4~6mm²
Cable
Cable Positive metal
terminal Positive connector
Negative metal
terminal Negative connector
Fig 6.5
1.Strip the cable 10mm through the waterproof gland, thread sleeve, and tighten the
screws.
Fig 6.7
6.4 Connect the signal cable
The MOD series inverter has an30-Pin signal connector except Vietnam models.Please
refer to Section 10.1 for details.The client signal line port is as follows:
Fig 6.6

Fig 6.8
Fig 6.9
3.Connect the client to the inverter plug until both are tightly locked on the inverter.
Remove the signal connector
1.Press down the fastener and pull it out of the inverter.
Fig 6.10
6.5 Grounding the inverter
The inverter must be connected to the AC grounding conductor of the power distribution
grid via the ground terminal (PE) .
WARNING
If an Earth Fault Alarm occurs, the fault code “Error 303,NE abnormal”
will be displayed on the inverter screen while the LED indicator red will
light up. (Applicable to inverters with graphical display only)
According to the relevant provisions of IEC 61643-32 "Connecting to photovoltaic
devices surge protectors - selection and use of guidelines", whether for household or
commercial photovoltaic power plants, it is necessary to ensure the implementation of
lightning protection measures for photovoltaic systems:
The lightning protection measures for photovoltaic systems shall be
carried out in accordance with the corresponding national standards
and IEC standards. Otherwise, photovoltaic devices such as
components, inverters and power distribution facilities may be
damaged by lightning.
In this case, the company does not carry out warranty and assumes
any responsibility.
Fig 6.11
6.6 Active power control with smart meter or ripple control
signal receiver
Information
ØThe position of export limitation Meter must between the Inverter
& Load and gird.
ØThe wiring of meter, please refer to the manual of smart meter in
details.
This series inverter has integrated export limitation functionality. To use this function,
you can connect the Growatt smart meter. For the detailed information, please contact
with Growatt.
Smart meters are classified into the following models
No.
Meter Brand
Meter Pin N0.
1
Growatt
A,RS485A/B,RS485B
WARNING
Note:
1.MOD 3-10KTL3-XA must connect Growatt Meter.
2.AC Couple System need to change inverter's system mode to "System retrofit".
20
19

Datasheet
Item
Parameter
General Data
Dimension(L/W/H)
90*45*65mm (Without buckle)
Weight
174g
Manual Language
Chinese,English
Environment Protection Rating
IP20
Mounting Type
Standard 35mm Rail
Certification
CE、UKCA、RCM、RoHS
Altitude
4000m
Electrical
Parameters
Application Scenario
Single Phase/Split
Phase/3P3W/3P4W
Single Phase
Rated Voltage
230Vac
（1）
Phase Voltage Range
100Vac - 416Vac
3P4W
Rated Voltage
230Vac/400Vac
（1）
Phase Voltage Range
100Vac – 416Vac
3P3W
Rated Voltage
230Vac/400Vac
Phase Voltage Range
100Vac – 240Vac
（1）
Line Voltage Range
173Vac – 416Vac
Split Phase
Rated Voltage
120Vac/240Vac
Phase Voltage Range
100Vac - 150Vac
Meter Rating
Class1
Starting Current
0.2% Ib
Ib
10A
CT
250A/40mA ,100A/40mA
Measurement Frequency
45-65Hz
Measurement Power
Active Power/Reactive
Power/Apparent Power
Average Power Consumption
1W
Operating Temperature Range
-30℃ ～ 65℃
Storage Temperature Range
-40℃ ～ 70℃
Operating Humidity
<85%RH
Pulse Constant
300imp/kWh
Datasheet
Item
Parameter
Application
Parameters
Communication Method
(Communication Distance)
RS485(200m)
Communication Protocol
MODBUS-RTU
Address Range
10-19
Bound Rate
9600bps,19200bps(Default),
38400bps
Update rate
100ms
Display
LED
Billing Function
None
Measurement
Accuracy
Voltage
0.5%
Current
0.5%
Frequency
0.2%
PF
1%
Active Power
1%
Reactive Power
2%
Apparent Power
1%
Active Energy
Class1
Reactive Energy
Class2
Fig 6.12
Active power control with a Radio Ripple Control Receiver(RRCR).
Monitor
Radio ripple
control receiver
Public Grid
Router
Internet
PC
22
21

6.7 Inverter demand response modes (DRMS)
This series inverter has the function of demand response modes, We use 16-Pin socket as
inverter DRMS connection.
6.7.1 16-Pin socket pin assignment
No.
Description
Remarks
11
DRM1/5
Relay contact 1 input
12
DRM2/6
Relay contact 2 input
13
DRM3/7
Relay contact 3 input
14
DRM4/8
Relay contact 4 input
15
REF/GEN
GND
16
DRM0/COM
/
DRMS application description
ØApplicable to AS/NZS4777.2:2015 or Commission Regulation
(EU) 2016/631.
ØDRM0, DRM5, DRM6, DRM7, DRM8 are available.
Damage to the inverter due to moisture and dust penetration
ØMake sure the cable gland has been tightened firmly.
ØIf the cable gland are not mounted properly, the inverter can be
destroyed due to moisture and dust penetration. All the warranty
claim will be invalid.
Information
CAUTION
WARNING
Excessive voltage can damage the inverter!
External voltage of DRM PORT don't over +5V.
6.7.2 Method of asserting demand response modes
Mode
Socket asserted by
shorting pins
Function
DRM 0
16
15
Operate the disconnection device.
DRM 5
11
15
Do not generate power.
DRM 6
12
15
Do not generate at more than 50% of rated power.
DRM 7
13
15
Do not generate at more than 75% of rated power and
reduce the reactive power as far as possible.
DRM 8
14
15
Increase power generation (subject to constraints from
other active DRMs).
6.7.3 Using the Power Control Interface for EU
Fig 6.13 Inverter – RRCR Connection
6.7.3.1 The following table describes the connector pin assignment and function:
DRM Socket Pin NO. Description Connect to RRCR
11
12
13
14
15
Relay contact 2 input
Relay contact 3 input
Relay contact 4 input
GND
Relay contact 1 input
K2 – Relay 2 output
K3 – Relay 3 output
K4 – Relay 4 output
Relays common node
K1 – Relay 1 output
6.7.3.2The inverter is preconfigured to the following RRCR power levels:
DRM Socket
Pin 11
DRM Socket
Pin 12
DRM Socket
Pin 13
DRM Socket
Pin 14
Active power
Cos(φ)
Short circuit
with Pin 15
0%
1
Short circuit
with Pin 15
30%
1
Short circuit
with Pin 15
60%
1
Short circuit
with Pin 15
100%
1
Active power control and reactive power control are enabled separately.
24
23

6.9 Backup(optional)
Backup means that the inverter can output 230/400V, 50/60Hz voltage to the load when
there is no grid. The MOD-XA inverter has the Backup function. If you need to use this
function, you need an additional Backup box. The system diagram is as the figure below.
Fig 6.14
6.8 GFCI(Standard)
This inverter includes an integrated residual current device .If the leakage current is
over 300mA and last for more than 300ms,the inverter will report 201 fault and the
OLED will display Residual I High.
The inverter has the function of detecting residual current and protecting the inverter
against residual current. If your inverter must equip a AC breaker which has the function
of detecting residual current ,you must choose a Type A RCD breaker with the rating
residual current more than 300mA.
Connection communication cable to the XA inverter
COM Port
XH Inverter COM
SYN 50-XH 30 COM
Control Board
RS 485 A
PIN17
PIN3
CN8
RS 485 B
PIN18
PIN4
BOX.EN+
PIN21
PIN5
BOX.EN-
PIN22
PIN6
As shown in Fig 6.14 above,a complete storage system includes PV panels(MOD XA
series inverter without PV panel), inverters, backup box, public grid and other
accessaries. In this system,the photovoltaic inverter is a key device. If the customer want
to enable the Backup mode, please refer to 9.3.3 Backup Mode Setting.
Note:
1.The max. power output at the off grid is 10kW when the battery power is enough.
2.The backup function is permitted to be commissioned only by professionals. The
backup function requires a backup box provided by Growatt.
Debugging 7
1.After connecting the battery (at least three ARK batteries) and turning on the
switch,the inverter display will show the following information:No AC connection
error,the inverter LED will turn red.
If other information is displayed,please refer to Chapter 13.If you encounter any
problems during the debugging process and cannot solve it,please contact customer
service.
2.Close the circuit breaker or switch between the inverter and the grid, the inverter
will start a countdown to the self-check,and after the self-check is normal,it will be
connected to the grid.
3.In normal operation,the leaves of the inverter indicator window will turn green.
4.Finish debugging.
Working Mode 8
8.1 Normal mode
In this mode, the inverter works normally.When the battery and the grid are connected
normally, the inverter counts down and connects to the grid, and the green light is on.
8.2 Failure mode
The inverter controls the chip monitors and adjusts the state of the system in real time.
When the inverter monitors any unexpected conditions,such as system failure and
inverter failure,the display will show the fault information.In the failure mode,the
inverter will indicate the leaves of the window will turn red and the inverter output will
be disconnected from the grid.
26
25

9 OLED display and touch button
The OLED display can display the running status of the inverter, as well as various
parameters information, and the display interface of the inverter can be switched
and the inverter parameters can be set by touching the button.
Mark
Describe
Explain
Touch mark
Single touch
Switch the display interface or
the current number plus 1
Double touch
Enter the setting state or
confirm
Triple touch
Return to the previous display
interface
Long press for 5s
The current data returns to the
default value
9.1 Start the inverter
9.1.1 Touch control
9.1.2 Set Country/Area
Growatt
PV Inverter
Country/Area
VDE0126
Country/Area
Germany
Single touch
Press
Set OK
Press
Country/Area
EN50549
Press
Multiple single
touch
9.2 General setting
9.2.1 Set inverter display language
9.2.3 Set inverter date
Language
English
Language
English
Language
German
Language
Spanish
Double touch
Single touch
Language
Italian
Set OK
Double touch
Double touch
Double touch
Double
touch
Single touch
Set Parameter
General
Advanced
Double
touch
Double
touch
Multiple single
touch
Date Setting
2019- 04 -18
Date Setting
2019-04-18
Doubl e touch
Date Setting
20NN-04-18
Doubl e touch
Doubl e touch
Date Setting
20NN-04-18
Multi ple
singl e touch
Date Setting
20NN-NN-18
Doubl e touch
Multi ple
singl e touch
Date Setting
20NN-NN-18
Date Setting
20NN-NN-NN
Multi ple
singl e touch
Set OK
Doubl e touchDoubl e touch
Date Setting
2020-04-18
Date Setting
20NN-05-18
Date Setting
20NN-NN-19
Singl e
touch
Singl e
touch
Singl e
touch
Address
001
Language
English
General
Advanced
Set Parameter
Doubl e touch
Doubl e touch
Singl e touch
Singl e touch
28
27
The right Country/Area must be selected before starting up, otherwise
the inverter will not work.For compliance with AS/NZS 4777.2:2020
please select from Australia Region A/B/C or New Zealand. Please
contact your local grid operator on which region to select.

9.2.4 Set inverter time
9.3 Advanced setting
Time Setting
20:05:00
Time Setting
20:05:00
Doubl e touch
Time Setting
NN:05:00
Doubl e touch
Doubl e touch
Time Setting
NN:05:00
Multi ple
singl e touch
Time Setting
NN:NN:00
Doubl e touch
Multi ple
singl e touch
Time Setting
NN:NN:00
Time Setting
NN:NN:NN
Multi ple
singl e touch
Set OK
Doubl e touchDoubl e touch
Time Setting
21:05:00
Time Setting
NN:06:00
Time Setting
NN:NN:01
Singl e
touch
Singl e
touch
Singl e
touch
Date Setting
2019-04-18
Address
001
Language
English
General
Advanced
Set Parameter
Singl e touch
Singl e touch
Singl e touch Doubl e touch
Country/Area
VDE0126
Country/Area
VDE0126
Country/Area
Germany
Single touch
Set OK
Country/Area
EN50549
Double touch
Password
123
General
Advanced
Multiple single
touch
Double touch
Double touch
Double touch
Double touch
Double touch
9.3.1Export limitation setting
The –XA series inverters can work in anti-backflow mode through external power
meter or CT,the user can set the percentage of power allowed to flow backward
the OLED, Single touch to switch display or make the number +1.Double touch to
confirm the setting, as described below:
9.3.2 Reset factory
ExportLimit
OFF ON OFF ON
OFF ON
Double touch
Single touch
Double touch
Set OK
Double touch ExportLimit Rate
000.0%
Double touch
Double touch
Export Limit Rate
000.0%
ExportLimit Rate
0N0.0%
Double touch
Multiple single
touch
ExportLimit Rate
0N0.0%
ExportLimit Rate
0NN.0%
Multiple single
touch
Set OK
Double touchDouble touch
ExportLimit Rate
100.0%
Export Limit Rate
010.0%
ExportLimit Rate
0N1.0%
Single
touch
Single
touch Single
touch
ExportLimit Rate
0NN.0%
ExportLimit Rate
0NN.N%
Multiple single
touch
Export Limit Rate
0NN.1%
Single
touch
Double touch
Double touch
Double touch
Double touch
Double touch
Double touch
Country/Aera
VDE0126
Password
123
General
Advanced
Double touch
Double touch
Multiple single
touch
Meter
Double touch Double touch
ExportLimit
ExportLimit
30
29
Reset Factory NO
YES
NO
YES
Double touch
Single touch
Double touch
Set OK
Double touch
Double touch
Double touch
Password
123
Country/Aera
VDE0126
General
Advanced
Double touch
Multiple single
touch

9.3.3 Backup mode setting (Off-grid models only）
:
Backup Setting
Disable
Doubl e touch
Singl e touch
Doubl e touch
Set OK
AC Volt
208V
AC Volt
AC Freq
50Hz 60Hz
AC Freq
50Hz 60Hz
Doubl e touch
Doubl e touch
Singl e
touch
Singl e
touch
Doubl e touch
Doubl e touch
Set OK
Singl e
touch
Doubl e touch
Doubl e touch
Backup Box
Disable
Doubl e touch
Singl e touch
Doubl e touch
Set OK
Set OK
Doubl e touch
Country/Aera
VDE0126
Password
123
General
Advanced
Doubl e touch
Doubl e touch
Multi ple
singl e touch
Singl e touch
Backup Box
Disable
Backup Box
Enable
Backup Setting
Disable
Backup Setting
Enable
220V
AC Volt
230V
AC Volt
240V
Singl e
touch
Grid Charge Disable
Enable
Disable
Enable
Set OK
Set OKStrorage Setting
Password
123
Country/Area
VDE0126
General
Advanced
Multiple single touch
Single touchDouble touch
Double touch
Double touch
Double touch Double touch
Double touch
9.3.4 Grid Charge setting
b
The inverter power output will vary in response to the AC grid voltage. This is switched
on by default.This function belongs to advanced function, if you need to change,
please contact the after-sales operation and maintenance to make adjustments.
9.3.6 Power derating for voltage variation (Volt-Watt mode)
9.3.5 System mode setting
When the MOD XA series inverter is used in AC Coupled system, the system mode
must be "System retrofit".
9.3.7 Reactive power regulation for voltage variation (Volt-VAr mode)
The power output or input will vary in response to the AC grid voltage. This function is
switched off by default..This function belongs to advanced function, if you need to
change, please contact the after-sales operation and maintenance to make
32
31
Grid Charge Disable
Enable
Disable
Enable
Set OK
Set OKStrorage Setting
Password
123
Country/Area
VDE0126
General
Advanced
Multiple single touch
Single touchDouble touch
Double touch
Double touch
Double touch Double touch
Double touch
9.3.4 Grid Charge setting
b
9.3.8 Viewing inverter firmware
Model：S21B00
D00T00P0FM0064 FW Ver: DN1.0
More Info
Double touch Single touch

Fig 10.1
Fig 10.2
This series of inverters provide four RS485 ports. You can monitor one or more inverters
via RS485. The other RS485 port is used to connect a smart meter (Export limitation and
self-consumption monitoring).
10.1 COM port
10 Communication and Monitoring
10.2 USB-A
The inverter side
The inverter side
The inverter side
The inverter side
Uninstall
▲up
Install
USB-A port is mainly used to connect monitoring module or firmware update：
We can connect the external optional monitoring modules,such as Shine WIFI-X, Shine
Shine 4G-X, Shine LAN-X, etc. to the USB interface for monitoring.
Steps for installing the monitoring module: Make sure △ is on the front side, then insert
the datalogger and tighten the screws.
21
22
BOX.EN+
BOX.EN-
Backup box identification
signal
Before turning the inverter on, please make sure the Battery input voltage and current
are within the MPPT limits.
Follow the steps below to turn the inverter on:
1.Pull the Battery and AC cable make sure there is no loose or shaking.
2.Make sure the cable polarity is correct and voltage is less than 1100V
3.Switch on the PV/Battery Array and DC isolator next to your inverter, if you can not find
this switch, skip this step.
4.Switch on the Solar AC isolator if the inverter is more than 3 meters away from your
switchboard.
5.Switch on the solar supply main switch in the switch board.
12.1 Start the inverter
12.2 Shut down the inverter
Steps to turn off the inverter:
1. Disconnect the AC circuit breaker to prevent the inverter from starting again;
2. Turn off the BAT input switch of the BAT;
3. Check the operating status of the inverter;
4. Wait until the LED and OLED display are off, indicating that the inverter is turned off.
Start and shut down the 12
inverter
Maintenance and Cleaning 11
11.1 Checking Heat Dissipation
11.2 Cleaning the Inverter
If the inverter regularly reduces its output power due to high temperature, please
improve the heat dissipation condition. Maybe you need to clean the heat sink.
If the inverter is dirty, turn-off the AC breaker and DC switch ,waiting the inverter shut
down ,then clean the enclosure lid, the display, and the LEDs using only a wet cloth. Do
not use any cleaning agents (e.g. solvents or abrasives).
34
33
