Growatt MID TL3-XH Series User manual

Download
Manual
Growatt New Energy
Installation
&
Operation Manual
GR-UM-320-A-00
Shenzhen Growatt New Energy Co., Ltd
4-13/F, Building A, Sino-German (Europe) Industrial Park,
Hangcheng Ave, Bao’an District, Shenzhen, China
[phone]
www.ginverter.com
T
E
W
[e-mail]

Contents
1 Notes on this manual
2 Safety
3 Product overview 3.1 Appearance
3.2 Dimensions
3.3 Storage environment
1.1 Validity
1.2 Intended audience
1.3 Symbols in this document
2.1 Product description and features
2.2 Qualified personnel
2.3 Safety instruction
4 Inspection upon delivery
5 Installation 5.1 Basic installation requirements
5.2 Wall-mounted installation
5.3 Installing the inverter
6.1 Security
6.2 AC side wiring
6.3 DC side wiring
6.4 Connecting the Bidirectional DC/
DC Box
6.5 Connecting the signal cable
6.6 Grounding the inverter
6.7 Active power control with a smart
meter or a ripple control receiver
6.8 Inverter demand response modes
(DRMs)
6.9 GFCI (Standard)
6.10 AFCI (Optional)
6.11 Backup function (Optional)
6 Electrical connection

8.1 Operating mode
8.2 Failure mode
8.3 Shutdown mode
13.1 Error message
13.2 System warning
13.3 Systen error
15.1 Removing the inverter
15.2 Packing the inverter
15.3 Storing the inverter
15.4 Disposing of the inverter
13 Troubleshooting
8 Working mode 14 Manufacturer Warranty
15 Decommissioning
17 Specification
16 EU declaration of conformity
18 EU Certificate of Compliance
9.1 Starting the inverter
9.2 General settings
9.3 Advanced settings
12.1 Powering on the inverter
12.2 Powering off the inverter
9 OLED display and the touch
button
19 Contect us
12 Powering on/off the
inverter
10 Communication and
monitoring
11 Maintenance and cleaning
10.1 COM port
10.2 USB-A
11.1 Checking the heat dissipation
11.2 Cleaning the inverter
11.3 Checking the DC disonnect
7 Commissioning

This manual is intended to provide product information and installation instructions
regarding MID TL3-XH inverters manufactured by Shenzhen Growatt New Energy
Co.,Ltd.(hereinafter referred to as Growatt). Please read this manual carefully before
using the product. Please note that the content of this manual is subject to change
without notice.
MID 11KTL3-XH
MID 12KTL3-XH
MID 13KTL3-XH
MID 15KTL3-XH
MID 17KTL3-XH
MID 20KTL3-XH
MID 25KTL3-XH
MID 30KTL3-XH
WARNING
DANGER
Symbol
Description
DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
1.3 Symbols in this document
1.3.1 Symbols in this document
Warning notes indicate possible hazards to the equipment or personnel. It calls attention
to a procedure which, if not correctly performed or adhered to, could result in damage or
destruction of the instrument and personal injury.
1.3.2 Markings on this product
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
Information that you must read and know to ensure optimal
operation of the system.
NOTICE
Information
Symbol
Explanation
Beware of high voltages
Beware of fire
Beware of hot surface
Delay discharge: observing a waiting time of 5 minutes
Grounding: indicates the position for connecting the PE cable
Direct Current (DC)
Alternating Current (AC)
Refer to the manual
CE marking
The inverter complies with the requirements of the applicable EU
directives
Do not dispose of the product together with the household waste
but in accordance with the disposal regulations for electronic waste
applicable at the installation site
This manual is intended for professional electricians who possess the required
qualifications.Reading through this manual and observing all the precautions, qualified
electrical technicians will be able to properly install, configure and troubleshoot the MID
TL3-XH series inverters.
Should any questions arise during installation, you can visit www.ginverter.com and
leave a message. Or you can call our 24-hour service line at [phone].
1.2 Intended audience
1 Notes on this manual
1.1 Validity
2

1.3.3 Glossary
AC
Abbreviation for "Alternating Current”
DC
Abbreviation for "Direct Current”
Energy
Energy is measured in Wh (watt hours), kWh (kilowatt hours) or MWh (megawatt hours).
The energy is power multiplied by time. For example, if the inverter operates at a
constant power of 4600 W for 30 minutes and then at a constant power of 2300 W for
30 minutes, it would have generated a total energy output of 3450 Wh in that hour and
fed it into the power distribution grid.
Power
Power is measured in W (watts), kW (kilowatts) or MW (megawatts). Power is an
instantaneous value. It displays the power that the inverter is currently feeding into the
power distribution grid.
Power rate
Power rate is the ratio of current power fed into the power distribution grid and the
maximum power of the inverter that can be fed into the power distribution grid.
Power factor
Power factor is the ratio between real power (measured in watts) and apparent power
(measured in Volt-Amps). When the current and voltage are in phase, the power factor is
1.0. In an AC circuit, the power is not always equal to the direct product of volts and
amperes due to reactive components. In order to find the true power of a single-phase
AC circuit, the product of volts and amperes must be multiplied by the power factor.
PV
Abbreviation for photovoltaic.
Wireless communication
The external wireless communication technology is a radio technology that enables
communication between the inverter and other communication products. The external
wireless communication does not require line of sight between the devices and it is a
selective purchasing option.
Safety 2
2.1 Product description and features
2.1.1 Product description
Growatt series hybrid inverters are designed to convert the DC power generated by the
PV panels into three-phase AC power and export it to the grid or store the DC power in
the batteries. The MID 11-20K TL3-XH series inverters feature 2 maximum power point
(MPP) trackers. Each tracker is connected to two PV strings, allowing for the
configuration of two PV arrays of different solar panels. The MID 25-30K TL3-XH series
inverters feature 3 MPP trackers. Each tracker can be connected to two strings, enabling
the configuration of three PV arrays of different solar panels.
Position
Description
A
Solar panel
B
DC circuit breaker
C
Inverter
D
AC circuit breaker
E
Electric energy meter
F
Utility grid
G
DC circuit breaker
H
Battery matched with-XH series inverters
As shown in Fig 2.1 above, a PV Energy Storage System consists of PV modules, the solar
inverter, the utility grid and other components, among which the inverter plays a key
role.
Note: If the selected photovoltaic module requires positive or negative grounding,
please contact Growatt for technical support before installation.
The inverter features the following highlights:
ØThree MPP trackers for MID 25-30K TL3-XH series inverters (Two for MID 11-20K
series)
ØBuilt-in DC switch
ØSupport RS485/Wi-Fi/GPRS/4G communication
ØInput voltage range: 160V to 1100V
Ø98.0% Max. efficiency
ØOLED+LED/WIFI+APP display
ØDisplay options of OLED+LED/Wi-Fi+APP
ØEasy operation with the touch button
2.1.2 Product features
Fig 2.1
34

2.3 Safety instructions
1.Please read this manual carefully before installation. Growatt shall not be liable for any
damage caused by failure to follow the instructions and safety precautions specified in
this manual.
2.Only professional electricians and mechanical engineers are allowed to perform
operations on the inverter and connect cables.
3.When installing the inverter, do not move other parts inside the chassis other than the
wiring terminals.
4.All electrical installations must comply with local electrical safety standards.
5.For maintenance services, please contact designated professional personnel in the
local area.
6.Before operating the inverter to generate power in grid-tied mode, ensure that you
have obtained approval from the local power grid department.
7.When installing PV modules during the day, use opaque materials to cover the
modules. Failing to do so can result in high voltage at the terminals, posing a risk to
personal safety.
2.2 Qualified personnel
The grid-tied inverter system can only operate properly when correctly connected to the
AC distribution network. Before connecting the MID TL3-XH inverter to the power
distribution grid, you need to obtain approval from the local utility company. Only
qualified and trained technical personnel are allowed to perform the electrical
connection.
ØGrounding the PV modules: MID TL3-XH inverters are
transformerless, meaning that there is no galvanic separation. Do
not ground the DC side of the MID TL3-XH inverter, but you need
to ground the mounting frame of the PV module. Otherwise, it
will report the error message "PV ISO Low".
ØComply with the local requirements for grounding the PV
modules and the PV generator. GROWATT recommends
connecting the generator frame and other electrically conductive
surfaces in a manner which ensures continuous conduction with
ground in order to have optimal protection of the system and
personnel.
CAUTION
2.3.2 Electrical Connection Warnings
ØAll electrical connections, such as connecting terminals, the fuse,
PE cables, must in compliance with the prevailing regulations.
When performing any operations on the inverter while it is
powered on, it is important to adhere to all safety regulations to
minimize the risk of accidents.
ØSystems with inverters typically need additional control devices
such as switches and disconnects, as well as protective devices
like circuit breakers and fuses. The specific type of control and
protective devices needed will depend on the relevant safety
regulations in effect.
ŸDo not open the inverter except the junction box.
ŸOnly qualified and trained personnel can perform installation,
maintenance and replacement.
ŸForbid live-line work.
ØDanger to life due to high voltages in the inverter
ØPersons with limited physical or mental abilities may only work
with the Growatt inverter following proper instruction and under
constant supervision. Ensure that the inverter is inaccessible to
children.
ŸHigh voltage exists after the inverter is powered off. It takes 20
minutes to discharge to the safe voltage.
ØThe components in the inverter are live. Touching live components
can result in serious injury or death.
DANGER
WARNING
5 6
ØIP66 protection
ØLightweight designe: 30kg
ØEasy installation
ØSupport energy storage and backup mode, which requires the installation of a
backup box
ØIntegrated with phase-level export limitation function
ØIntegrated with AC power supply function
ØIntegrated with energy storage one-key detection function
ØIntegrated with AC power supply function to realize the 24h self-consumption
monitoring
ØBefore installation, pleae check the unit to ensure that there is no
transportation or handling damage, which may affect the
insulation integrity or safety clearances; otherwise, it may cause
safety hazards.
ØFollow the instructions in this manual to assemble the inverter.
Select a suitable mounting location and comply with the specified
requirements of cooling.
ØUnauthorized removal of necessary protections, improper use,
incorrect installation and operation may lead to serious safety and
shock hazards and/or equipment damage.
ØIn order to minimize the possibility of shock hazards due to
dangerous voltages, cover the entire solar array with dark colored
materials before connecting the array to any equipment.
WARNING
2.3.1 Assembly Warnings

8
7
2.3.3 Operation Warnings
CAUTION
ØAll operations regarding transport, installation and start-
up,including maintenance must be operated by qualified,
trainedpersonnel and in compliance with all prevailing codes
andregulations.
ØAfter the system powers off, take great caution as the remaining
charge may still cause electrical shocks; to minimize the risk of
accidents and damage, follow all safety symbols and markings on
the unit and in this manual.
ØAlthough standardized emission limit values are in place to
minimize interference, certain situations may still result in
interference for the specified application area. This can happen
when sensitive equipment is located near the setup location, or
when the setup location is near radio or television receivers. In
these cases, the operator is responsible for taking appropriate
measures to resolve the issue.
ØKeep a safe distance of at least 20cm from the inverter at all
times.
WARNING
ØEnsure all connectors are sealed and secured during operation.
ØAlthough designed to meet all safety requirements, some parts
and surfaces of the inverter are still hot during operation. To
reduce the risk of injury, do not touch the heat sink at the back of
the PV-inverter or nearby surfaces while inverter is operating.
ØIncorrect sizing of the PV panels may result in high voltages that
could damage the inverter. In this case, the inverter will display
the error message "PV Voltage High".
Product overview 3
3.1 Appearance
Product description:
The label description on the inverter:
Fig 3.1
Symbol
Description
Explanation
Touch button
You can switch the interface or set parameters by
tapping the button.
Inverter status
symbol
Inverter status
LED color
LED status
Standby
Green
0.5S on and
2S off
Normal
Green
Solid
Fault
Red
Solid
Inverter warning/Battery
fault
Green
0.5s on,0.5s
off/0.5s on,2s off
Programming
Yellow
1s on and 1s off
ABCDEFGHI J K
No.
Component
No.
Component
No.
Component
A
Front panel
E
DC switch
I
Vent valve
B
Touch button
F
PV terminal
J
COM port
C
OLED screen
G
Battery terminal
K
AC terminal
D
LED indicator
H
USB port

109
3.2 Dimensions
Size and weight:
To store the inverter in a warehouse, choose a suitable location.
ØInstall the inverter in its original packing materials.
ØKeep the storage temperature at -25℃ to +60℃ and the relative humidity below
90%.
ØTo store multiple inverters, a maximum of 4 inverters can be stacked.
3.3 Storage Environment
Inspection upon delivery 4
Before unpacking the inverter, check the outer packing materials for any externally
visible damage. After unpacking the inverter, check the scope of delivery for
completeness. If the scope of delivery is incomplete or damaged, contact your dealer.
No.
Description
Qty.
A
Inverter
1
B
Quick Installation Manual
1
C
Wall-mounting bracket
1
D
COM port connector
1
E
AC waterproof cover
1
F
AC connector shell
1
G
Plastic expansion tube
5
H
Expansion screw
4
I
Security screw
2
J
PV connector
6/6
K
PV metal contact
6/6
L
PV terminal removal tool
1
Fig 4.1
Fig 3.2
WD
H
Model
Height (H)
Width (W)
Depth (D)
Weight
MID 11-20KTL3-XH
433mm
579mm
217.5mm
29.5kg
MID 25-30KTL3-XH
433mm
579mm
217.5mm
30kg
A B C
DEF G H I JK L

11 12
5 Installation
5.1 Basic installation requirements
ØThe wall on which the inverter is mounted must be sturdy and can withstand the
weight of the inverter for a long time (refer to the specifications in Chapter 17 for the
weight of the inverter);
ØThe installation location should be suitable for the dimensions of the inverter;
ØDo not install the inverter in areas with flammable or thermolabile materials;
ØInstall the inverter in an appropriate place for the user's ease to view and operate on
the display;
ØThe inverter is protected to IP66 and can be installed indoors and outdoors;
Ø The mounting location cannot be exposed to direct solar irradiation, which may
cause overheating. As a redult, the inverter reduces its power output;
ØKeep the relative humidity at 0 to 90%;
ØKeep the ambient temperature at -25°C to +60°C;
ØInstall the inverter vertically or at a maximum back tilt of 15 degrees. Do not install
the inverter at a front tilt, horizontally, or upside down.
ØFor the optimal operation of the equipment and the convenience of operation,
please reserve enough clearances around the inverter. The minimum clearances are listed
below:
Direction
Minimum clearance (mm)
Top
500
Bottom
500
Both sides
300
Front
300
Fig 5.1 Installation diagram
ØDo not install the inverter near the television antenna or any other antennas and
antenna cables;
ØDo not install the inverter in the living area;
ØThe mounting location must be inaccessible to children;
ØProtect the inverter against direct sunlight and rain by installing a shelter or an
awning.
Fig 5.3 Clearance requirements for multiple inverters
Fig 5.2 Clearance requirements for a single inverter

14
13
Fig 5.4 Installation Environment
ØIt is not allowed to install or operate the inverter in a sealed box.
Fig 5.5 Closed box
ØIt is recommended to install an awning over the inverter to extend its service life. The
distance requirements between the awning and the inverter are as follows:
5.2 Wall-mounted installation
5.2.1 Installing the wall-mounting bracket
For safety reason, avoid water pipes and power cables when drilling
holes.
Danger
Fix the mounting bracket as the figure shows. The screws should not be fully flush when
inserted. Instead, leave 2 to 4mm of the screw exposed.
5.3 Installing the inverter
Note: Before installing the inverter, ensure that the wall-mounting bracket is securely
installed.
Follow the steps to install the inverter:
1. Place the inverter on the bracket and keep balance when moving the inverter.
2. To fix the inverter is to the wall, tighten the M5 safety locking screw on the left.
Fig 5.6 Awning
Fig 5.7 Dimensions of the wall-mounting bracket
Fig 5.8 Installing the wall-mounting bracket

Danger
Warning
16
15
Electrical connection 6
6.1 Security
High voltages in the conductive parts of a running inverter may
cause electric shocks. Therefore, ensure that the inverter is
disconnected from voltage sources and is not powered on before
starting installation
Static electricity may damage the electronic components of the
inverter. Anti-static measures should be taken during the
replacement or installation of the inverter.
Moisture and dust penetration can damage the inverter
ØMake sure that the waterproof cable gland is firmly tightened.
ØIf the cable connector is not installed correctly, the inverter
may be damaged due to the penetration of moisture and dust.In
this case, all warranties shall be void.
Note
6.2 AC side wiring
Before connecting cables, ensure that the DC switch of the inverter
is off and disconnect the AC circuit breaker. Otherwise, high
voltages may cause electric shocks, resulting in serious injury or
death from inverter in operation.
ØIn PV system with multiple inverters, protect each inverter with
a separate circuit breaker.
ØDo not use the single-core wire to connect the output terminal
of the inverter.
ØDo not use aluminum wires as the output cables.
ØEnsure that the AC output cable is securely connected before
powering on the inverter. Failure to follow the safety precautions
may cause device and property damage, which is beyond the
warranty scope.
Moisture and dust penetration can damage the inverter.
ØMake sure the cable connector is securely tightened.
ØIf the cable connector is not installed correctly, the inverter
may be damaged by moisture and dust. In these cases, all warranty
claims shall be void.
Danger
Warning
Note
Fig 5.9 Installing the inverter
You must install a separate three phase circuit-breaker or other load disconnection unit
for each inverter in order to ensure that the inverter can be safely disconnected under
load.
The recommended AC circuit breaker specifications are shown below:

18
17
AC connection:
1. Route the five wires (A, B, C, N, PE wires) through the AC protective cover; crimp the
ring or spade terminals; then connect them to the screw terminals on the AC connector.
2. Connect the AC cable to the corresponding AC terminal.
Fig 6.2 Crimping the AC output cable and terminal lugs
3.Secure the protective cover onto the inverter and tighten the screw on the protective
cover.
Fig 6.3 Connecting the AC output power cable
Fig 6.4Installing the waterproof cover
Residual current protection device (RCMU)
As the inverter is equipped with a highly accurate residual current detection device, it is
not recommended to install a leakage protection switch. If an external residual-current
device is required, install a Type-A leakage protection switch that trips at a residual
current of 300 mA or higher and install it between the inverter and the grid. When
multiple leakage protection switches are installed, do not connect them to a shared
neutral line. Otherwise, the leakage protection function may be triggered by mistake.
Recommended cable specifications:
Model
Cross-section area (Cu)
Maximum cable length
MID 11-20KTL3-XH
2
10-12mm
40m
MID 25-30KTL3-XH
2
14-16mm
40m
6.3 DC side wiring
ØThe PV panel will generate voltage with solar irradiation. High voltages
may occur when the panels are connected in serials, which can result in
personal injury. Therefore, cover the panels with opaque materials before
connecting the DC input cable and ensure that the DC switch is off.
ØTo avoid electric shock,do not touch the live parts,and connect the
terminals carefully.
ØPlease make sure that the AC switch has been disconnected before
wiring.
Danger
Inverter model
Switch specification
MID 11KTL3-XH
25A(230/400V)
MID 12KTL3-XH
25A(230/400V)
MID 13KTL3-XH
30A(230/400V)
MID 15KTL3-XH
30A(230/400V)
MID 17KTL3-XH
35A(230/400V)
MID 20KTL3-XH
40A(230/400V)
MID 25KTL3-XH
40A(230/400V)
MID 30KTL3-XH
50A(230/400V)

19 20
Please ensure that the following conditions are met, otherwise it may cause
a fire hazard or damage the inverter. In this case, Growatt shall not be liable
for any consequence.
ØThe maximum open circuit voltage of each string of photovoltaic
modules shall not exceed 1000Vdc under any conditions.
ØPV modules connected in series in each PV string should be of the same
specification type.
ØThe maximum short-circuit current of each PV string must not exceed
26A under any conditions.
ØThe total output power of all PV strings must not exceed the maximum
input power of the inverter.
ØThe negative port of the PV panel mustn't be grounded when there is
no isolation transformer (the inverter output is connected to the grid
directly).
ØIf a stable non-zero DC voltage is detected between the positive pole
of the photovoltaic string and the ground, it means that an insulation fault
has occurred at a certain position in the photovoltaic string. You need to
ensure that the fault is rectified before continuing the wiring.
Moisture and dust penetration can damage the inverter.
ØMake sure that the waterproof cable gland is firmly tightened.
ØIf the cable connector is not installed correctly, the inverter may be
damaged due to the penetration of moisture and dust. In this case, all
warranties shall be void.
Warning
Note
The MID 11-20KTL3-XH inverters have two independent inputs, and the
MID 25-30KTL3-XH inverters have three inputs.
Fig 6.5
When installing the PV modules, please note that:
ØThe PV modules in each PV string should be of the same specifications and model.
ØEach PV string should have the same number of PV modules connected in series.
Ø Before connecting to the PV panel, ensure the correct polarity. Connect
the positive and negative terminals of a PV module to the positive and
negative DC input terminals of the inverter respectively.
ØThe maximum DC input current and voltage of the inverter shall not
exceed the following limits.
Model
Max. input current per
MPPT
Maximum input
voltage
MID 11-20KTL3-XH
32A/32A
1100V
MID 25-30KTL3-XH
32A/32A/32A
1100V
Connect DC terminal
Cables
Cables
Positive metal terminal Positive connector
Negative connector
Negative metal terminal
4~6mm²
4~6mm²
Fig 6.6
Note
6.4 Connecting the Bidirectional DC/DC Box
The MID 11-30KTL3-XH three-phase inverters feature two independent BAT inputs: the
BAT+/BAT- terminal can be connected to a Bidirectional DC/DC Box.
Please note that the connectors used are paired male and female connectors. The
connectors for the Bidirectional DC/DC Box and the inverter are Helios H4-R/VP-D4/MC4
connectors.
The Bidirectional DC/DC Box is used to work with the inverter to manage the battery's
charging and discharging mode.
6.4.1 Conditions for Bidirectional DC/DC Box
Fig 6.7

21 22
6.4.2 Connecting the Bidirectional DC/DC Box
Connecting the BAT input terminals
Danger to life due to lethal voltages!
Before connecting the Bidirectional DC/DC Box, ensure that the Box
is disconnected from any power supply. NEVER connect or disconnect
the BAT connectors under load.
Ensure the correct polarity when connecting the Bidirectional DC/DC
Box to the inverter.
Improper operation during the wiring process can cause fatal injury
to the operator or unrecoverable damage to the inverter. Only
qualified personnel can perform the wiring work.
WARNING
DANGER
4~6mm²
4~6mm²
Cable
Cable Positive metal
terminal Positive connector
Negative metal
terminal Negative connector
Fig 6.8
1.Strip the cable by 10mm and pass it through the waterproof gland and the threaded
sleeve, then tighten the screws.
Fig 6.10
Fig 6.11
Fig 6.12
2.Connect the client-side to the port on the inverter and ensure that they are securely
connected.
Removing the signal connector
1.Press down the fastener and pull it out from the inverter.
6.5 Connecting the signal cable
The MID series inverter is equipped with a 30-Pin signal connector, except for Vietnam
models. Please refer to Section 10.1 for details. The port connected to the client-side
signal cable is shown below:
Fig 6.9
Fig 6.13
6.6 Grounding the inverter
The inverter must be connected to the AC grounding conductor of the power distribution
grid through the ground terminal (PE) .
WARNING
Because of the transformerless design, the DC positive pole and DC
negative pole of PV arrays are not permitted to be grounded.
This inverter complies with IEC 62109-2 clause 13.9 for earth fault alarm
monitoring.
If an Earth Fault Alarm occurs, the fault code “Error 303, NE abnormal”
will be displayed on the inverter screen while the LED indicator will turn
red. (Applicable to inverters with graphical display only)
The Inverer Side
Click!
Click!

In accordance with the regulations outline in IEC 61643-32 "Surge protective devices
connected to the d.c. side of photovoltaic installations - Selection and application
principles.", it is essential to implement lightning protection measures for both
household and commercial photovoltaic power plants.
The lightning protection measures for photovoltaic systems shall be
carried out in accordance with the corresponding national standards
and IEC standards. Otherwise, photovoltaic devices such as
components, inverters and power distribution facilities may be
damaged by lightning.
In this case, Growatt shall not be liable for the consequence and the
damage is not covered by warranty.
Fig 6.14
6.7 Active power control with a smart meter or a ripple control
receiver
Information
ØThe smart meter should be installed between the inverter and the
gird.
ØFor details about the meter wiring, please refer to the manual of
the smart meter.
Inverters of this series support the export limitation functionality. To enable this function,
you can install a Growatt smart meter. For details, please contact Growatt support.
23 24
Smart meter models
No.
Meter Brand
Meter Pin No.
1
Chint
24,RS485A/25,RS485B
2
Eastron
A,RS485A/B,RS485B
3
Growatt
A,RS485A/B,RS485B
WARNING
Base Current (Ib)
10A
Power consumption
≤2W
Frequency
50/ 60Hz(±10%)
AC voltage withstand
4KV for 1 minute
Impulse voltage withstand
6KV-1.2uS waveform
Overcurrent withstand
20Imax for 0.5s
Pulse output 1
1000imp/kWh (default)
Pulse output 2
400imp/kWh
Display Max. Reading
LCD with white backlit 999999kWh
Environment
Operating temperature
-25℃to +55℃
Storage and transportation temperature
-40℃to +70℃
Reference temperature
23℃ ±2℃
Relative humidity
0 to 95%, non-condensing
Altitude
up to 2000m
Warm up time
3s
Installation category
CAT II
Mechanical Environment
M1
Electromagnetic environment
E2
Degree of pollution
2
Mechanics
Din rail dimensions
72x66x100 (WxHxD) DIN 43880
Mounting
DIN rail 35mm
Ingress protection
IP51 (indoor)
Material
self-extinguishing UL94V-0
10A
Manufacturer
Eastron
Type
SDM630CT-Modbus V3
General Specifications
Voltage AC (Un)
3*230V
Voltage Range
184~299V AC
Fig 6.15
Active power control with a Radio Ripple Control Receiver (RRCR).
Monitor
Radio ripple
control receiver
Public Grid
Router
Internet
PC

6.8 Inverter demand response modes (DRMs)
Inverters of this series feature the demand response modes and use a 16-pin socket as
the DRMs connector.
6.8.1 16-Pin socket pin assignment
No.
Description
Remarks
11
DRM1/5
Relay contact 1 input
12
DRM2/6
Relay contact 2 input
13
DRM3/7
Relay contact 3 input
14
DRM4/8
Relay contact 4 input
15
REF/GEN
GND
16
DRM0/COM
/
DRMs application description
ØApplicable to AS/NZS4777.2:2015 or Commission Regulation
(EU) 2016/631.
ØDRM0, DRM5, DRM6, DRM7, DRM8 are available.
Damage to the inverter due to moisture and dust penetration
ØMake sure the cable glands have been tightened firmly.
ØIf the cable glands are not mounted properly, the inverter can be
destroyed due to moisture and dust penetration. In this case, all
the warranties shall be void.
Information
CAUTION
WARNING
Excessive voltage can damage the inverter!
External voltage of DRM PORT don't over +5V.
6.8.2 Method of asserting demand response modes
Mode
Socket asserted by
shorting pins
Function
DRM 0
16
15
Operate the disconnection device.
DRM 5
11
15
Do not generate power.
DRM 6
12
15
Do not generate at more than 50% of rated power.
DRM 7
13
15
Do not generate at more than 75% of rated power
and sink reactive power if capable.
DRM 8
14
15
Increase power generation (subject to constraints
from other active DRMs).
25 26
6.8.3 Using the Power Control Interface for EU models
Fig 6.16 Inverter – RRCR Connection
6.8.3.1 The following table describes the connector pin assignment and function:
DRM Socket Pin NO.
Description
Connect to RRCR
11
12
13
14
15
Relay contact 2 input
Relay contact 3 input
Relay contact 4 input
GND
Relay contact 1 input
K2 – Relay 2 output
K3 – Relay 3 output
K4 – Relay 4 output
Relays common node
K1 – Relay 1 output
6.8.3.2 The inverter is preconfigured to the following RRCR power levels:
DRM Socket
Pin 11
DRM Socket
Pin 12
DRM Socket
Pin 13
DRM Socket
Pin 14
Active power
Cos(φ)
Shorting
with Pin 15
0%
1
Shorting
with Pin 15
30%
1
Shorting
with Pin 15
60%
1
Shorting
with Pin 15
100%
1
Active power control and reactive power control are enabled separately.

6.10 AFCI (Optional)
6.10.1 Arc-Fault Circuit Interrupter (AFCI)
In accordance with the National Electrical Code R, Article 690.11, the inverter has a
system for the recognition of electric arc detection and interruption. An electric arc with
a power of 300 W or greater must be interrupted by the AFCI within the time specified by
UL 1699B. A tripped AFCI can only be reset manually. You can deactivate the automatic
arc fault detection and interruption (AFCI) via a communication product in "Installer"
mode if you do not require the function. The 2011 edition of the National Electrical Code
R, Section 690.11 stipulates that newly installed PV systems attached to a building must
be fitted with a means of detecting and disconnecting serial electric arcs (AFCI) on the PV
side.
6.10.2 Danger information
Be aware of fire caused by the electric arc
Only test the AFCI for false tripping in the order described below.
Do not deactivate the AFCI permanently.
If the "Error 200" message is displayed and the buzzer alarms, it indicates that an
electric arc has occurred in the PV system. The AFCI will be tripped, and the inverter is in
a permanent shutdown state. The inverter has significant electrical potential
differences between its conductors, which can result in arc flashes when high-voltage
current flows. Please do not perform operations on an inverter in operation.
The inverter has large electrical potential differences between its conductors. Arc has
flashes can occur through air when high-voltage current flows. Do not work on the
product during operation.
Whenthe inverter reports Error 200, please perform the following steps:
6.10.3 Operation step
6.10.3.1 Turn the DC & AC Switch to the position "OFF".
6.10.3.2 Perform troubleshooting on the PV system:
Wait until the screen is off.
Check if the open-circuit voltage of the PV strings is within the permissible range.
6.10.3.3 After the fault is rectified, restart the inverter:
Turn the DC & AC Switch to the position "ON".
Fig 6.17
Fig 6.18
27 28
6.11 Backup function (Optional)
The MID-XH series inverters can work in backup mode. In this mode, the inverter can
output power of 230/400 V, 50/60 Hz to the load when the grid goes down. To enable
this mode, you need to install a backup box. The system diagram is shown below:
Fig 6.19
6.9 GFCI (Standard)
6.9.1 Ground fault circuit interrupter (GFCI)
The inverter is equipped with a residual-current device. When the leakage current is over
300 mA and lasts for over 300 ms, the inverter will report Fault 201 and displays
"Residual I High".
The inverter features the function of detecting residual current and protecting the
inverter against residual current. If you need to install an external AC breaker which
supports residual current detection, you are advised to install a Type A RCD breaker with
the rated residual current greater than 300 mA.
COM Port
XH Inverter COM
SYN 100-XH-30 COM
(Contral Board Cn8)
RS 485 A
PIN23
PIN3
RS 485 B
PIN24
PIN4
BOX.EN+
PIN21
PIN5
BOX.EN-
PIN22
PIN6
As shown in Fig 6.19, the PV energy storage system comprises PV panels, the inverter, the
backup box, the utility grid and other components, among which the inverter plays a
crucial role. To enable the backup mode, please refer to Section 9.3.3 Setting the backup
mode.
Note:
1. When the grid goes down, the max. output power of a fully charged battery reaches
30kW.
2. Only professional personnel are allowed to configure the backup mode. To enable the
backup mode, you need to purchase a backup box from Growatt.

29 30
7 Commissioning
1. Turn on the DC switch on the inverter. Once the input DC voltage is greater than 160V,
the inverter will display "No AC connection" and the LED indicator will turn red.
If other error message is displayed, please refer to Section 13. If you encounter any
technical problems, please contact Growatt support.
2. Turn on the circuit breaker or the switch between the inverter and the grid, the inverter
will start a countdown to perform a self-check. If no fault is found, the inverter will be
connected to the grid.
3. When the inverter is working properly, the leaf-shape indicator will turn green.
4. Finish the commissioning process.
8 Working Mode
8.1 Operating mode
In this mode, the inverter works normally.
ØWhen the grid-connected requirements are met - the DC voltage is greater than
200V, and the grid voltage and frequency are within the permissible range, the
inverter will convert the DC power generated by the solar panels into AC power and
feeds it to the grid with the green LED indicator on.
ØWhen the DC voltage falls below 160V, the inverter will automatically disconnect
from the grid and exit the operating mode. It will enter the operating mode and be
connected to the grid automatically once the requirements are met.
8.2 Failure mode
When an unexpected condition occurs, such as a system failure or an inverter failure, the
inverter will report the error message on the screen. In failure mode, the leaf-shape
indicator will turn red and the inverter will be disconnected from the grid.
When PV power is insufficient or no PV power is generated, the inverter will shut down
automatically. In shutdown mode, the inverter does not consume energy from the grid or
the solar panels, and the display and the indicators will be off.
8.3 Shutdown mode
OLED display and the touch button 9
The OLED display shows the running status of the inverter. You can switch the interface
and set related parameters by tapping the touch button.
Symbol
Description
Explanation
Touch button
Single tap
Switch the display interface or
increase the value by one
Double tap
Assess the settings or confirm
your setting
Tripple tap
Return to the previous interface
Long press for 5s
Restore the default value
9.1 Starting the inverter
9.1.1 Touch control
9.1.2 Set Country/Area
Growatt
PV Inverter
Country/Area
VDE0126
Country/Area
Germany
Single touch
Press
OK
Press
Country/Area
EN50549
Press
Multiple single
touch
For the device to begin operation, a country data set must be configured
correctly. If no country data set is configured in 30s, it will operate
according to the default value: AS/NZS477.2 for Australia and
VDE0126-1-1 for other regions.
Information
When the inverter initializes, the OLED screen lights up automatically. Once the PV power
is sufficient, it will display "PV Inverter". Tap the touch button to scroll through the
country options until the desired selection is displayed.For instance, to select Germany,
tap the touch button until "VDE0126" is displayed; long press the button for 5s and the
screen will indicate that the configuration is completed.

31 32
9.2 General settings
9.2.1 Setting the display language
9.2.3 Setting the date
9.2.4 Setting the time
9.3 Advanced settings
Time Setting
20:05:00
Time Setting
20:05:00
Double tap
Time Setting
NN:05:00
Time Setting
NN:05:00
Multi-tap
Time Setting
NN:NN:00
Time Setting
NN:NN:00
Time Setting
NN:NN:NN
OK
Time Setting
21:05:00
Time Setting
NN:06:00
Time Setting
NN:NN:01
Date Setting
2019-04-18
Address
001
Language
English
General
Advanced
Settings
Single tap
Country/Area
VDE0126
Country/Area
VDE0126
Country/Area
Germany
OK
Country/Area
EN50549
Password
123
General
Advanced
Multiple language options are available for this series inverter. Single tap to view
different options; double tap to confirm your setting. Set the language as shown below:
Language
English
Language
English
Language
German
Language
Spanish
Single tap
Language
Italian
OK
Settings
General
Advanced
Multi-tap
Double
tap
Double
tap
Double
tap
Double
tap
Single tap
Double tap
Double tap
Double tap
Single tap to increase the number by one; double tap to confirm your setting. Set the
date as shown below:
Date Setting
2019- 04 -18
Date Setting
2019-04-18
Double tap
Date Setting
20NN-04-18
Double tap
Date Setting
20NN-04-18
Multi-tap
Date Setting
20NN-NN-18
Date Setting
20NN-NN-18
Date Setting
20NN-NN-NN
OK
Date Setting
2020-04-18
Date Setting
20NN-05-18
Date Setting
20NN-NN-19
Single tap
Address
001
Language
English
General
Advanced
Settings
Double tap
Single tap
Double tap Double tap Double tap
Single tap
Double tap
Single tap
Multi-tap Multi-tap
Double tap
Single tap
Single tap to increase the number by one; double tap to confirm your setting. Set the
time as shown below:
Double tap Double tap Double tap
Double tap
Double tap Double tap
Single tap
Single tap
Single tap
Multi-tap Multi-tap
Single tap Single tap
Single tap to scroll through the options or increase the number by one; double tap to
confirm your settings. The password for advanced settings is 123. After entering the
password, you can change the Country/Area setting and the PQRM settings.
Double tap Double tap
Double tap
Double tap
Double tap
Double tap
Single tap
Multi-tap

9.3.1 Setting the export limitation parameter
The -XH series inverters supports the export limitation function when working with an
external power meter or CT. Users can configure the parameter on the OLED screen.
Single tap to view the options available or increase the number by one; double tap to
confirm your setting. Set the export limitation parameter as shown below:
9.3.2 Restoring to factory settings
33 34
OFF ON OFF ON
OFF ON
Double tap
Single tap
OK
Export Limit Rate
000.0%
000.0%
0N0.0%
0N0.0%
0NN.0%
OK
100.0%
010.0% 0N1.0%
0NN.0%
0NN.N%
0NN.1%
Country/Area
VDE0126
Password
123
General
Advanced
Meter
Export Limit
9.3.3 Setting the backup mode (Off-grid models only)
Restore to factory
settings
NO
YES
NO
YES
OK
Double touch
Password
123
Country/Area
VDE0126
General
Advanced
Backup Setting
Disable
AC Volt
208V
AC Volt
AC Freq
50Hz 60Hz
AC Freq
50Hz 60Hz
Backup Box
Disable OK
Country/Area
VDE0126
Password
123
General
Advanced
Backup Box
Disable
Backup Box
Enable
Backup Setting
Disable
Backup Setting
Enable
220V
AC Volt
230V
AC Volt
240V
Double tap
Double tap
Double tap
Double tap
Double tap
Double tap
Export Limit
Export Limit Export Limit Rate
Single tap
Double tap
Double tap
Multi-tap
Export Limit Rate
Export Limit Rate
Export Limit Rate Export Limit Rate
Export Limit Rate
Export Limit Rate Export Limit Rate
Export Limit Rate
Export Limit Rate
Double tap Double tap Double tap
Double tap
Double tap
Double tap
Double tap
Double tap
Double tap
Single tap Single tap Single tap
Multi-tap Multi-tap Multi-tap
Take caution because after this operation, all parameters excluding the
current date and time, will restore to the default factory settings.
Information
Single tap to view the options available or increase the number by one; double tap to
confirm your setting.
Double tap
Double tap Double tap
Double tap
Single tap
Multi-tap
Working with the battery and the backup box, the -XH series inverters can operate in
backup mode to supply power to loads when the grid fails. The maximum output power
is equal to the inverter's rated power. You can configure the output voltage (set to
230V/400V by default) and the output frequency (set to 50HZ by default) for the backup
mode. If the backup mode is disabled (the inverter stops power output when the grid is
lost), you can enable the backup mode on the OLED screen. Single tap to view the
options or increase the number by one; double tap to confirm your setting. Configure the
backup mode as shown below:
Double tap
Double tap Double tap
Double tap
Double tap
Double tap Double tap Double tap
Double tap
Double tap
Double tap
Double tap
Double tap
Single tap
Single tap
Single tap
Double tap
Single tap
Single tap Single tap
Single tap
Single tap
Multi-tap
OK
OK
OK
