Information on this Manual
Validity
This manual is valid for the following devices:
Three phase 380V solar pump inverter, 3000W~22000W
Scope
This manual describes the assembly, installation, operation and troubleshooting of this unit.
Please read this manual carefully before installations and operations.
Target Group
This document is intended for qualified persons and end users. Tasks that do not require any
particular qualification can also be performed by end users. Qualified persons must have the
following skills:
Knowledge of how a pump inverter works and is operated
Training in how to deal with the dangers and risks associated with installing and using
electrical devices and installations
Training in the installation and commissioning of electrical devices and installations
Knowledge of the applicable standards and directives
Knowledge of and compliance with this document and all safety information
Safety Instructions
WARNING: This chapter contains important safety and operating instructions.
Read and keep this manual for future reference.
Inspection
If missing components or damaged inverter is found after receiving, please do NOT install or operate it.
Otherwise, it may cause human injury or equipment damage.
Installation
1. Before installation, please make sure if the voltage range of PV panel meets the requirement.
2. Check if all wires are firmly connected without short circuit. Otherwise, it will cause equipment damage.
3. Do NOT install this inverter under direct sunlight because high temperature may cause equipment damage.
4. Please install the inverter away from inflammable and explosive objectives. Please ensure no liquid can
enter the inverter.
5. Please install the inverter on metal non-combustible surface.

2
1. CAUTION!! Only qualified personnel can install and operate this inverter.
2. To reduce risk of electric shock, disconnect power source before making wire connection. Otherwise, it may
cause electrical shock.
3. To reduce risk of electric shock, NEVER touch any terminals on electric circuits.
4. If connection cable between inverter and water pump is more than 50m, please be sure to install a
three-phase AC reactor. Inductance value for each phase is about 1mH. Otherwise, water pump would be
easily to be damaged.
Operation
1. Only after wire connection is complete and put cover back to the inverter, it’s Enter to do
commissioning. Otherwise, it will cause electric shock
2. If sunlight is sufficient but little water is pumped, maybe the wires on motor connection are reversely
connected. Please reverse any two wires of them.
3. When testing water pump, be sure to install water pump at appropriate water level. Never allow water
pump in dry running. Otherwise, the inverter will activate protection.
Maintenance
1. Only qualified personnel can maintain, repair, inspect the inverter and replace any components.
2. It may still contain energy after disconnecting power source within 5 minutes. Only service after the bus
voltage is within safe range.
Symbols
Grounding Wire of Equipment
AC Value
DC Value
Phase
Before operating inverter, please read the instruction.
5 minutes
In order to avoid electric shock, breack off machine with PV
terminal and AC terminal for at least 5 minutes, then contact
the wire of machine output terminal and input terminal
Warning: when machine works, the temperature of metal shell
may be very high.

3
Pump
Introduction
Solar Pumping System
This is a solar pump inverter which allows power to be switched from the DC power obtained from solar panels to the
AC power needed to control the pump.
This series solar pump inverters are built-in with MPPT solar charger to maximize solar power. The inverter is suitable
for submersible pumps, ground pumps, swimming pool pumps and other pumps using three phase asynchronous
motors.
Features
Rated power 3KW to 22KW
Inbuilt MPPT solar controller
IP65 protection level
Built-in full protection and self-diagnosis
Soft start function
Comprehensive LCD and LEDs display real-time system status
Remote monitoring through GPRS /WIFI(optional)
Groundwater
Residential
Water
Animal
Husbandry
Pump
Irrigation
Solar Pump Inverter
Solar Panel

4
Product Overview
1. LCD display
2. LED indicators
3. Function buttons
4. DC switch
5. PV input
6. Water level sensor port --WELL
7. Water level sensor port –TANK
8. AC output
9. GPRS/WIFI communication port

5
INSTALLATION
Unpacking and Inspection
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should
have received the following items inside of package:
 The unit x 1
 User manual x 1
Mounting the Unit
Consider the following points before selecting where to install:
 Do not mount the inverter on flammable construction
materials.
 Mount on a solid metal surface.
 Avoid direct sunlight. Be sure the environment is shady and
cool.
 Be sure to install the inverter into a box with waterproof and
dustproof.
 Install this inverter at eye level in order to allow the LCD
display to be read at all times.
 The recommended installation position is to be adhered to
the wall vertically.
 Be sure to keep other objects and surfaces as shown in the
diagram to guarantee sufficient heat dissipation and to
have enough space for removing wires.
3 phase 380V 3kw-5.5kw

6
3
3 phase 380V 7.5kw-11kw 3 phase 380v 13kw-22kw
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
Install Safety Nut

7
Wiring Introduction
There is DC switch, water level sensor connection terminal, GPRS (optional), and AC output terminal.
Terminal Introduction
Socket
Terminal Introduction
Wiring Introduction
DC Input
PV+
Connect with the positive pole of solar array
PV-
Connect with the negative pole of solar array
AC Output
M-1
Connect with motor U phase
M-2
Connect with motor V phase
M-L
Connect with motor W phase
M-PE
Connect with protective ground wire
Water Level Sensor Input
(Switch Value)
S1
Signa2 of water tank
Signa4 of water tank
S2
Signa2 of well
Signa4 of well
Warning: The places of input sockets of DC positive pole and negative pole of different models are different.
Warning: The signal marshalling sequence of AC output sockets of different models are different.

8
Assemble DC Connector
Strip the cable 6-8mm,then connect the bare wire core into core tube of connector.
Crimp contact barrel by using a hex crimping die. Put the contact barrel with striped cable in the corresponding
crimping notch and crimp the contact. Insert the core tube into slot of connection until hear the sound
indicating fit in place.
Tighten the nuts to finish the wiring.
Warning: Risk of electric shock! Before shifting solar panel, disconnect the pump inverter AC and DC. Besides,
allow 5-minute internal capacitance discharging.
Assemble AC Connector
AC connnector gets connection with the pump through 4 wires (U wire, V wire, W wire and PE wire)
Remove the parts of teh AC connection plug from the accessory bag. Guide the pressure screw sealing right, threaded
sleeve over the AC cable.
Socket element threaded sleeve sealing ring pressure screw
Insert the stripped and bared conductors U, V, W, PE in to screw terminals with sign U, V, W, PE on the socket element
and tighten the screws.
Connect the conductors

9
Push the threaded sleeve in to the socket element. Screw the pressue screw thightly onto the threaded sleeve.
Close the connector
Insert the AC onnnection plug into the AC connection receptable on the inverter.
Lock the housing Unlock the housing
Wiring of Water Level Sensor
DC Switch
Connect S2 and COM
Water Tube
Connect 3 Phase Output
Connect S4 and COM
Water Level Sensor 2
Water Pump
Water Level Sensor 1
Water Tank
Solar Panel

10
Assemble Sensor connector
Insert the stripped and bared conductors 2,4 in to screw termianls signal 2,4 on the socket element and tighten the
screws.
Push the threaded sleeve in to the socket element. Screw the pressue screw thightly onto the threaded sleeve.
Notice: connect water level sensor 1 and detect water shortage. Respectively connect two signal lines of sensor
with S4 and COM of I/O circuit board. When water level sensor 1 detects that the water level of well is lower than the
level set by sensor, the pump inverter will delay for 60s, then turn off output protection pump. The water level recovers.
Wait for 600s, then the pump inverter re-works normally.
Notice: connect water level sensor 2 to defect whether water is full. Connect two signal lines of sensor with S2
and COM. When water level sensor 2 detects that the water level of water tank exceeds the level set by sensor, the
pump inverter delays for 60s and turns off output; when water level is lower than set level, wait for 120s, then pump
inverter re-starts to work normally.

11
Recommended Diameter of Wire
Model
Recommended
output
current(A)
Output
voltage(V)
length≤
30m
length≤
60m
length≤
90m
length≤
120m
length≤
150m
length≤
180m
length≤
210m
SPI 3000
8
3PH 380V
1.5
2.5
2.5
6
6
6
6
SPI 4000
10
3PH 380V
1.5
2.5
2.5
6
6
6
6
SPI 5500
13
3PH 380V
2.5
2.5
4
6
6
6
6
SPI 7500
18
3PH 380V
2.5
2.5
4
6
6
10
10
SPI 9200
21
3PH 380V
4
4
4
6
10
10
10
SPI 11000
24
3PH 380V
4
4
6
10
10
10
16
SPI 13000
28
3PH 380V
6
6
6
10
10
10
10
SPI 15000
30
3PH 380V
6
6
6
10
10
16
16
SPI 18000
39
3PH 380V
6
6
10
10
16
16
25
SPI 22000
45
3PH 380V
10
10
10
16
16
25
25
Units: mm2
Notice: The environment temperature for the above recommended wire dimension should ≤50°C.
Notice: Large-power wall-mounted model uses multiple-channel DC input. The dimension of DC wire of each
channel shall be selected according to the above table.

12
OPERATION
Display Panel
Solar pump inverter uses LCD operation panel. The operation panel is shown in the figure, including 3 LED lights,
LCD display and 5 keys.
Indicator and Key
Name
Function Introduction
POWER
System running
indicator
Green
LED on, inverter is running
ALARM
Warning indicator
Yellow
LED on, warning, or LED flashing in auto
operation mode
FAULT
Failure indicator
Red
LED on, system failure
Operation /
Stop Key
1.Press for a short time, then the inverter starts
control;
2. Press for 2s, then inverter stops control.
Confirm /
Programming Key
1.Press for a short time to enter programming mode.
After altering parameter, “press for a short time” to
confirm the alteration
2. Press for 2s to enter the programming menu.
Increment Key
1.When control parameter displays state, increase
parameter number or parameter value;
2. When operation displays data state, according to
operation mode, increase output frequency or display
current operation data.
Decrement Key
1.When control parameter displays state, press for a
short time to decrease parameter number or
parameter value.
2. When operation shows data state, according to
operation mode, decrease output frequency or
display current operation data.
Return Key
Return the initial display.

13
LCD Display Information
The LCD display information includes operation data, control parameters, and historical parameters.
The information on the display will be switched in turns by pressing UP/DOWN key. The selectable information
will be switched as below.

14
Debugging guidance
Before setting the parameters, please make sure all the wiring is correct.
Inverter
temperature
Freq Run
50.00HZ
Output frequency of the
inverter
Freq Set
50.00HZ
Set frequency of the
inverter
PV Volt
550V
Input voltage of
the inverter
Output Volt
380V
Output Curr
0.7A
Output current
of the inverter
Capacity
+79.1%
The relative value
of rated power
Run time
20h
Inverter
running time
Temperature
28.9C
Output voltage
of the inverter

15
a. Setting P00.01=0. Manual operation mode settings.
b. Set water pump nameplate parameters: P02.01 motor rated power value; P02.02 motor rated power value;
P02.04 motor rated voltage value; P02.05 motor rated current value.
c. Water output test of pump
Click the run button to observe the running frequency and wateroutput.Under the normal strong light
condition,if the working frequency is low or the water volume is small,it indicates that the motor line may be
connected reversely,so it is necessary to set function code P00.13=1 or exchange the wiring of two motor
lines.
d. After finishing parameter setting of water pump, set P00.01=1. The operation code channel is altered as
original automatic mode instruction.
Notice: If the inverter fails,set P00.18 to restore the factory settings.
Water Level Switch
Water Tank
DC Switch
Solar Panel

16
Parameters Setting
1. Work Mode Setting
The inverter includes three work modes: manual work mode, fully-automatic terminal work mode, GPRS
work mode (optional). The default mode is fully-automatic terminal work mode.
Click the back
key to enter the
main page
Click the
key
again to
set OK
Press the enter key
again Change the default
value of 1 to 0
Work mode
P00
Enter the main parameter
modification interface for long
press 2s for Enter key
Work mode
P00.01
Press Enter key ,to
enter view the P00.01
Work mode
0
0：manual mode
1：automatic mode
2：GPRS mode
Work mode
Set OK
Freq Run
50.00HZ

17
2. Parameter Setting (Example)
3. Factory Data Reset
Click enter to
set OK to return
Power off
Long press for 3
seconds to shut down
Work mode
P00
Enter the main parameter
modification interface for long
press 2s for Enter key
Model set
P02.01
Turn up to group P02 and click
enter key to enter P02.00
Rating curr
P02.05
Flip up to P02.05
Rating curr
11.3A
Click enter
twice
Press /
to change motor rated current.
Motor Par
Set OK
Notice:This group of parameter
setting steps can be used as
reference for any group pasrameter
setting.

18
Notice: The set value of the parameter cannot be modified on the running state.if inverter is in auto mode，
but you need to set value of the parameter. First setting P00.01=0，manual operation mode settings，press
for 2s, then inverter stops control. then you can set the P00~P15 group of function parameter.
Warning: Do not change parameters at random, otherwise the system might not work normally.
Function Parameters
SN
Name
Scope
Introduction
Default
Value
P00.01
Run commamd
model
0~2
0: manual operation
NOTE:When set P00 and P02 paramaters,first must
set manual operation power off the inverter, P15
not need.
1: auto operation mode
2: communication operation mode
1
P00.03
MAX. Output
frequency
P00.04~400.00Hz
The paramater is used to set the maximum output
frequency of theinverter
50.00Hz
Click enter to
set OK to return
Click to enter
Power off
Long press for
3seconds to shut down
Work mode
P00
Work mode
P00.18
Enter the main parameter
modification interface for log
press 2s for Enter key
Flip up toP00.18
Reset
Press Enter
Work mode
Set OK
Notice:After the factory settings are restored,all group
parameters will return to the default settings except for group
P02.
