Grundfos D User manual

Pulsation dampers and Manual
vacuum pump kit
Damper design D, DB, DBG, SD, CSD
Installation and operating instructions
GRUNDFOS INSTRUCTIONS
Further languages
http://net.grundfos.com/qr/i/99207465

English (GB)
2
English (GB) Installation and operating instructions
Original installation and operating instructions
These installation and operating instructions describe the
Grundfos pulsation dampers D, DB, DBG, SD, CSD and the
Grundfos manual vacuum pump kit.
Sections 1-4 give the information necessary to be able to install
the product in a safe way.
Sections 5-12 give important information about the product as
well as information on service and disposal of the product.
CONTENTS
Page
1. General information
1.1 Target group
This document is intended for the operating company and the
users. It contains general instructions that must be observed
before installation and during operation and maintenance of the
product. The responsible staff must read these instructions prior
to any work on the product.
1.1.1 Qualification and training
The persons responsible for the tasks described in this document
must be appropriately qualified.
1.1.2 Obligations of the operating company
• Observe the local safety regulations.
• Keep the installation and operating instructions available at
the installation location at all times.
• Coordinate the preparation of the installation location
observing section 10. Technical data.
• Ensure that the users are trained for their tasks.
• Provide the stipulated safety equipment and personal
protective equipment.
• Arrange regular maintenance.
1.1.3 Obligations of the user
• Observe the recognised health and safety regulations as well
as the local accident prevention regulations.
• Wear protective equipment in accordance with local health
and safety regulations when working on the product and
handling chemicals.
• Read and understand this document.
1. General information 2
1.1 Target group 2
1.2 Symbols used in this document 3
1.3 Safe operation 3
2. Installing the product 3
2.1 Safety instructions 3
2.2 Location 3
2.3 Installation requirements and notes 3
2.4 Installation example of pulsation dampers CSD and
DBG 4
2.5 Installation example of pulsation damper D 5
3. Commissioning the product 5
3.1 Safety instructions 5
3.2 Checks before startup 5
3.3 Commissioning pulsation dampers SD and CSD 5
3.4 Commissioning pulsation dampers D 6
3.5 Commissioning pulsation dampers DB and DBG 6
4. Handling and storing the product 8
4.1 Handling the product 8
4.2 Storing the product 8
5. Product introduction 9
5.1 Intended use 9
5.2 Identification 9
5.3 Product description 11
6. Operating the product 13
6.1 Using pulsation damper CSD for pump calibration or
flow measurement 13
7. Maintaining the product 14
7.1 Safety instructions 14
7.2 Refilling pulsation dampers SD and CSD 14
7.3 Refilling pulsation damper D with air 14
7.4 Checking and adjusting the preload pressure of
pulsation dampers DB and DBG 15
7.5 Replacing the separating diaphragm of pulsation
dampers DB and DBG 15
8. Spare Parts 15
9. Fault finding 16
10. Technical data 16
10.1 Sizing of pulsation dampers 16
10.2 Permissible media temperature 16
10.3 Storage and ambient temperatures 16
10.4 Suction-side pulsation dampers SD 16
10.5 Suction-side pulsation dampers CSD 17
10.6 Discharge-side pulsation dampers D 18
10.7 Discharge-side pulsation dampers DB and DBG 18
11. Accessories 20
11.1 Manual vacuum pump kit for pulsation dampers CSD 20
11.2 Filling devices for pulsation dampers DB and DBG 20
11.3 Tyre-valve adapter for pulsation dampers DB and DBG 21
11.4 Pressure gauge for pulsation dampers D 21
11.5 Pressure gauge for pulsation dampers DB 21
12. Disposing of the product 21
Read this document before installing the product.
Installation and operation must comply with local
regulations and accepted codes of good practice.

English (GB)
3
1.2 Symbols used in this document
1.3 Safe operation
If safe operation is no longer possible, the product must be taken
out of operation and secured against unintentional operation.
This is the case in the following situations:
• If the product is visibly damaged.
• If the product does not seem operational.
• After long periods of storage under unfavourable conditions.
2. Installing the product
2.1 Safety instructions
2.2 Location
• The installation location must be protected from rain, humidity,
condensation, direct sunlight and dust.
• The installation location must have sufficient lighting to ensure
safe operation.
• Observe the permissible ambient conditions. See section
10.3 Storage and ambient temperatures.
2.3 Installation requirements and notes
2.3.1 General notes
• Install pulsation dampers always vertically with the dosing line
connection at the bottom side to ensure correct operation and
to prevent the accumulation of dirt.
• Shorten hoses and pipes at right angles.
• Make sure that there are no loops or kinks in the hoses.
• Keep the inlet line of the dosing pump as short as possible.
• Route the inlet line up towards the inlet valve of the dosing
pump.
• Observe the installation instructions in the manual of the
dosing pump.
• Heavy pulsation dampers must be fixed separately using the
fastening material supplied.
• To avoid flow deflection losses and frictional losses:
– Make sure that the dosing line is as straight as possible.
– Use dosing lines with the same nominal diameter as the
dosing line connector of the pulsation damper.
• Glued pipe connection for PVC: For correct sealing of glued
connections, prepare the surfaces with a proprietary solvent
cleaner and use a proprietary PVC glue. Follow the
instructions of the pipe manufacturer.
• Welded pipe connection for PP and PVDF: For correct sealing
of welded connections, follow the instructions of the pipe
manufacturer for the welding process.
• Threaded pipe connection: For threaded connections apply
appropriate sealing material to the threads. Follow the
instructions of the pipe manufacturer.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
A blue or grey circle with a white graphical symbol
indicates that an action must be taken.
A red or grey circle with a diagonal bar, possibly with
a black graphical symbol, indicates that an action
must not be taken or must be stopped.
If these instructions are not observed, it may result in
malfunction or damage to the equipment.
Tips and advice that make the work easier.
When working with chemicals, the accident
prevention regulations applicable at the installation
site must be applied.
Observe the chemical manufacturer's safety data
sheets when handling chemicals.
When working on the product or connections and
lines, always wear protective clothing (e.g. safety
goggles and gloves). The system must be
pressureless.
Only operate the system if all lines are connected
correctly.
The product must only be installed by authorised and
qualified persons.
Read the manuals of all system components before
starting any work on the system.
When working with chemicals, the accident
prevention regulations applicable at the installation
site must be applied.
Observe the chemical manufacturer's safety data
sheets when handling chemicals.
When working on the product or connections and
lines, always wear protective clothing (e.g. safety
goggles and gloves). The system must be
pressureless.
Observe section 4.1 Handling the product.
Wipe up spilled liquid immediately to avoid slipping
hazard.

English (GB)
4
2.3.2 Suction-side pulsation dampers SD and CSD
• Pulsation dampers SD and CSD must only be used as suction-
side pulsation dampers.
• Install pulsation dampers SD and CSD in the inlet line as close
as possible to the inlet valve of the dosing pump.
• Install a drain valve to enable draining of the pulsation
damper. See pos. 12, fig. 1.
• Install a shut-off valve in front of the pulsation damper. See
pos. 11, fig. 1.
2.3.3 Discharge-side pulsation dampers D, DB and DBG
• Pulsation dampers D, DB and DBG must only be used as
discharge-side pulsation dampers.
• Install pulsation dampers D, DB and DBG in the outlet line as
close as possible to the outlet valve of the dosing pump.
• Install a drain valve to enable draining of the pulsation
damper. See pos. 13, fig. 1. The drain valve is also used to
depressurise the discharge line between the dosing pump and
the pulsation damper.
• Install one pulsation damper per dosing pump.
• If the system pressure is below 3 bar or fluctuating, install a
pressure loading valve PLV after the pulsation damper to
optimise its function. See fig. 1.
• Pulsation damper DB and DBG:
For system pressures above 10 bar, only use nitrogen to
preload the pulsation damper.
2.4 Installation example of pulsation dampers CSD
and DBG
Fig. 1 Installation example of pulsation dampers CSD and
DBG
TM06 9110 3017
Pos. Description
1 Injection unit
2 Pressure loading valve PLV
3 Pulsation damper DBG
4 Pressure relief valve PRV
5 Dosing pump
6 Rigid suction lance RSL
7 Dosing tank
8 Electric stirrer
9 Manual vacuum pump
10 Pulsation damper CSD
11 Shut-off valve
12 Drain valve
13 Drain valve
7
6
8
9
10
1
4
3
2
5
11 12
13

English (GB)
5
2.5 Installation example of pulsation damper D
Fig. 2 Installation example of pulsation damper D
3. Commissioning the product
3.1 Safety instructions
3.2 Checks before startup
• Check that all components of the dosing system are mounted
and connected correctly.
• Check that all components of the dosing system are ready for
operation.
3.3 Commissioning pulsation dampers SD and CSD
3.3.1 Commissioning with flooded suction
This commissioning procedure applies to installations where the
level of the dosing medium in the tank is above the suction-side
pulsation damper.
1. Read section 3.1 Safety instructions.
2. Perform the checks before startup. See section 3.2 Checks
before startup.
Fig. 3 Commissioning with flooded suction
3. Make sure that the following prerequisites are in place:
– The dosing pump is off.
– Shut-off valve (1) is closed.
– Drain valve (12) is closed.
– The dosing tank is filled with the correct dosing medium.
4. For pulsation damper SD:
– Open the aeration screw at the top.
5. For pulsation damper CSD:
– Open aeration valve (4a).
6. Slowly open valve (1) and close it again when the pulsation
damper (4) is filled by 70 % with dosing medium.
7. For pulsation damper SD:
– Close the aeration screw at the top.
8. For pulsation damper CSD:
– Close aeration valve (4a).
9. Open shut-off valve (1).
The suction-side pulsation damper is commissioned now.
10. Deaerate the dosing pump according to the separate manual.
11. When the dosing pump is deaerated, proceed with the
commissioning of the discharge-side pulsation damper. See
section:
– 3.4 Commissioning pulsation dampers D
– 3.5 Commissioning pulsation dampers DB and DBG.
TM04 1360 2017
Pos. Description
1 Dosing pump
2 Pressure relief valve PRV
3Drainvalve
4 Pulsation damper D
5 Aeration screw
6 Optional pressure gauge assembly
6a Aeration valve
7 Pressure loading valve PLV
8 Injection unit
The product must only be adjusted and
commissioned by authorised and qualified persons.
Read the manuals of all system components before
starting any work on the system.
When working with chemicals, the accident
prevention regulations applicable at the installation
site must be applied.
Observe the chemical manufacturer's safety data
sheets when handling chemicals.
When working on the product or connections and
lines, always wear protective clothing (e.g. safety
goggles and gloves). The system must be
pressureless.
Wipe up spilled liquid immediately to avoid slipping
hazard.
WARNING
Danger of explosion
Death or serious personal injury
- Do not lead oxygen into pulsation dampers.
- Do not exceed the maximum operating pressure of
the pulsation damper.
1
3
4
5
6
6a
2
8
7
TM06 9271 2117
Pos. Description
1 Shut-off valve
2 Dosing pump
4 Pulsation damper
4a Aeration valve
12 Drain valve
2
4
4a
112

English (GB)
6
3.3.2 Commissioning without flooded suction
This commissioning procedure applies to installations where the
level of the dosing medium in the tank is below the suction-side
pulsation damper. The manual vacuum pump kit is required for
this kind of commissioning. See section 11.1 Manual vacuum
pump kit for pulsation dampers CSD.
1. Read section 3.1 Safety instructions.
2. Perform the checks before startup. See section 3.2 Checks
before startup.
Fig. 4 Commissioning without flooded suction
3. Make sure that the following prerequisites are in place:
– The dosing pump is off.
– Drain valve (12) is closed.
– The dosing tank is filled with the correct dosing medium.
4. Open shut-off valve (1).
5. Open shut-off valve (5b).
6. Close aeration valve (4a).
7. Use the manual vacuum pump (5) to fill the pulsation damper
(4) by 70 % with dosing medium.
8. Close shut-off valve (5b).
The suction-side pulsation damper is commissioned now.
9. Deaerate the dosing pump according to the separate manual.
10. When the dosing pump is deaerated, proceed with the
commissioning of the discharge-side pulsation damper. See
section:
– 3.4 Commissioning pulsation dampers D
– 3.5 Commissioning pulsation dampers DB and DBG.
3.4 Commissioning pulsation dampers D
The pulsation damper D has no separating diaphragm and thus
cannot be preloaded. During startup of the empty dosing system,
air is trapped inside the pulsation damper and forms the gas
cushion. The amount of air in the pulsation damper depends on
its size and cannot be adjusted.
1. Read section 3.1 Safety instructions.
2. Perform the checks before startup. See section 3.2 Checks
before startup.
3. Make sure that the pulsation damper and the discharge line
are drained completely. Otherwise see section 7.3 Refilling
pulsation damper D with air.
4. Make sure that aeration screw (5) or aeration valve (6a) is
closed. See fig. 2.
5. Start up the dosing system.
3.5 Commissioning pulsation dampers DB and DBG
3.5.1 Recommended pressure settings
The recommended preload pressure and the allowed preload gas
of the pulsation damper as well as the opening pressure of the
PLV depend on the system pressure of the dosing system.
* The installation of a PLV is optional.
To adjust the opening pressure of the PLV, see the separate
manual.
TM06 9270 2117
Pos. Description
1 Shut-off valve
2 Dosing pump
4 Pulsation damper
4a Aeration valve
5 Manual vacuum pump
5b Shut-off valve
12 Drain valve
2
5b
4
5
1
4a
12
Observe that the air in pulsation dampers D is
dissolved by the dosing medium over time. Regularly
check the dampening performance and refill the gas
cushion if necessary. See section 7.3 Refilling
pulsation damper D with air.
System
pressure
Pulsation damper
(DB, DBG) PLV
Allowed
preload gas
Preload
pressure
[bar]
Opening
pressure
[bar]
< 3 bar
constant air, nitrogen 2.7 3.0
3-10 bar
constant* air, nitrogen 80 % of
system
pressure
100 % of
system
pressure
≤10 bar
fluctuating air, nitrogen
> 10 bar nitrogen no PLV

English (GB)
7
3.5.2 Connecting the tyre-valve adapter for air filling (up to 8
bar)
The tyre-valve adapter can be used to preload the pulsation
damper with air using a compressed-air device. The adapter can
either be connected directly to the gas connector of the pulsation
damper or to the gas connector of the filling device.
Fig. 5 Tyre-valve adapter
Connecting the tyre-valve adapter directly to the pulsation
damper
1. Read section 3.1 Safety instructions.
2. Remove the protective cap from gas connector (2). See fig.
15.
– Make sure not to lose the O-ring.
3. Screw on the tyre-valve adapter and tighten it manually.
Connecting the tyre-valve adapter to the filling device
1. Read section 3.1 Safety instructions.
2. Remove the protective cap from gas connector (6). See fig. 6.
– Make sure not to lose the O-ring.
3. Screw on the tyre-valve adapter and tighten it manually.
3.5.3 Connecting the filling device
Fig. 6 Filling device
1. Read section 3.1 Safety instructions.
2. Make sure that the maximum operating pressure of the filling
device matches your local requirements. See section
11.4 Pressure gauge for pulsation dampers D.
3. Turn connection handle (1) counter-clockwise until the end
position.
– This ensures that the non-return valve of the pulsation
damper stays closed when connecting the filling device.
4. Turn gas relief handle (2) clockwise until the end position.
– This ensures that gas relief opening (2a) is closed.
5. Remove the protective cap from gas connectors (4, 6).
– Make sure not to lose the O-ring.
6. Connect union nut (3) to gas connector (4) of pulsation
damper.
7. For nitrogen filling:
– Connect the nitrogen bottle to gas connector (6).
8. For air filling:
– Connect the compressed-air device to gas connector (6)
using the tyre-valve adapter. See section 3.5.2 Connecting
the tyre-valve adapter for air filling (up to 8 bar).
3.5.4 Checking and adjusting the preload pressure of
pulsation dampers DB and DBG
Pulsation dampers with separating diaphragm are factory-set with
air to a preload pressure of 2.7 bar.
The pulsation damper DB has no pressure gauge.
The pulsation damper DBG is equipped with a pressure gauge.
For adjustment of preload pressure up to 8 bar via the tyre-valve
adapter, see section 3.5.5 Adjusting the preload pressure with air
via the tyre-valve adapter (DB and DBG, up to 8 bar).
1. Read section 3.1 Safety instructions.
2. Perform the checks before startup. See section 3.2 Checks
before startup.
3. Depressurise the dosing system.
TM06 9257 2017TM06 9237 2017
Pos. Description
1 Connection handle
2 Gas relief handle
2a Gas relief opening
3 Union nut
4 Gas connector of pulsation damper
5 Pressure gauge
6 Gas connector
5
1
1
2
2a
2
3
6
4
5
WARNING
Danger of explosion
Death or serious personal injury
- If the pressure in the nitrogen bottle exceeds the
maximum operating pressure of the filling device,
install a pressure reducing valve at the valve of the
nitrogen bottle and adjust it to the pressure limit.

English (GB)
8
Adjusting the preload pressure via the filling device
1. Connect the filling device. See section 3.5.3 Connecting the
filling device.
The following steps refer to fig. 6.
2. To check the preload pressure:
– Turn connection handle (1) clockwise until the preload
pressure is displayed at pressure gauge (5).
– Read the pressure at the pressure gauge.
– Observe section 3.5.1 Recommended pressure settings.
3. To decrease the preload pressure:
– Carefully turn gas relief handle (2) counter-clockwise to
relieve gas until the correct preload pressure is displayed at
pressure gauge (5).
4. To increase the preload pressure:
– Observe section 3.5.1 Recommended pressure settings.
– If only nitrogen is allowed for your application, relieve the air
from the pulsation damper before filling it with nitrogen.
– Fill the pulsation damper with the allowed preload gas until
the correct preload pressure is displayed at pressure gauge
(5).
5. To disconnect the filling device:
– Make sure that the gas source is closed.
– Turn connection handle (1) counter-clockwise until the end
position.
– Carefully depressurise the gas line by turning gas relief
handle (2) counter-clockwise.
– Turn gas relief handle (2) clockwise until the end position.
– Make sure not to lose any O-rings or gaskets.
– Disconnect the gas line.
– Unscrew union nut (3) and remove the filling device.
6. Reinstall the protective caps at gas connectors (4, 6).
– Make sure that the O-ring is placed correctly.
The product is ready for operation.
3.5.5 Adjusting the preload pressure with air via the tyre-
valve adapter (DB and DBG, up to 8 bar)
1. Read section 3.1 Safety instructions.
2. Perform the checks before startup. See section 3.2 Checks
before startup.
3. Depressurise the dosing system.
4. Connect the tyre-valve adapter. See section 3.5.2 Connecting
the tyre-valve adapter for air filling (up to 8 bar).
5. To check the preload pressure:
– Read the pressure at the pressure gauge of the pulsation
damper or at the pressure gauge of the compressed-air
device.
6. To decrease the preload pressure:
– Use the gas relief function of your compressed-air device to
relieve gas until the correct preload pressure is displayed at
the pressure gauge.
7. To increase the preload pressure:
– Observe section 3.5.1 Recommended pressure settings.
– Fill the pulsation damper with air until the correct preload
pressure is displayed at the pressure gauge.
8. Disconnect the compressed-air device and the tyre-valve
adapter.
– Make sure not to lose any O-rings or gaskets.
9. Reinstall the protective cap at the gas connector of the
pulsation damper.
– Make sure that the O-ring is placed correctly.
The product is ready for operation.
4. Handling and storing the product
4.1 Handling the product
• Wear safety shoes during transport and installation.
• Wear a helmet if lifting the product higher than hip level.
• Use appropriate lifting and transporting equipment.
• Make sure that the product is not exposed to any point load
during the transport.
• Avoid strong impacts.
• Observe the permissible ambient conditions. See section
10.3 Storage and ambient temperatures.
4.2 Storing the product
• Store the product in the original packaging.
• Observe the permissible ambient conditions. See section
10.3 Storage and ambient temperatures.
• The storage location must be protected from rain, humidity,
condensation, direct sunlight and dust.
WARNING
Danger of explosion
Death or serious personal injury
- Do not lead oxygen into pulsation dampers.
- For system pressures above 10 bar only use
nitrogen to preload the pulsation damper.
- For system pressures up to 10 bar use air or
nitrogen to preload the pulsation damper.
- Do not exceed the maximum operating pressure of
the pulsation damper.
WARNING
Danger of explosion
Death or serious personal injury
- Do not exceed the maximum operating pressure of
the pulsation damper.

English (GB)
9
5. Product introduction
5.1 Intended use
Pulsation dampers D, DB and DBG are intended to dampen
pressure pulsations in the discharge line of dosing systems with
dosing pumps.
Pulsation dampers SD and CSD are intended to dampen
pressure pulsations in the suction line of dosing systems with
dosing pumps. Pulsation dampers CSD can also be used to
calibrate the dosing pump. In installations without flooded
suction, pulsation dampers CSD can be filled with the manual
vacuum pump kit.
Pulsation dampers are suitable for liquid, non-abrasive, non-
flammable and non-combustible media.
Observe the freezing and boiling points of the medium.
Make sure that parts in contact with the medium are resistant to
the medium under operating conditions.
5.1.1 Improper operating methods
The operational safety of the product is only guaranteed, if it is
used in accordance with section 5.1 Intended use.
The product must not be used for:
• operation in potentially explosive areas
• frozen media
• crystallising media.
5.2 Identification
5.2.1 Nameplate
Fig. 7 Nameplate (type DB and DBG)
Fig. 8 Nameplate (type SD and D)
Fig. 9 Nameplate (all types)
The product must not be used for any other purpose
than the one mentioned above.
Grundfos pulsation dampers are classified by their
pressure-volume product according to the European
Pressure Equipment Directive. The pressure-volume
product is calculated by multiplying the pressure in
bar with the volume in litre.
In accordance with the European Pressure
Equipment Directive:
• Pulsation dampers with a pressure-volume product
below 50 are designed and assessed according to
sound engineering practice and carry no CE mark.
• Pulsation dampers with a pressure-volume product
of 50 and more are assessed according to Module
A and carry a CE mark.
TM06 9447 3917TM07 0052 3917TM07 0051 3917
Pos. Description
1 Supplier type designation
2 Maximum operating pressure [bar]
3 Maximum operating temperature [°C]
4Dampervolume[l]
5 Supplier year of production
6 Product number
7 Type key
8 Preload pressure (only DB, DBG)
9 Country of origin
10 Production code, week and year
11 Supplier plant code
12 Supplier date of production
13 Fluid type
14 Minimum operating temperature [°C]
15 Maximum operating pressure of pressure gauge [bar]
16 Type
14
4
2
8
3
11
12
13
1
x,xx
xx
xxxx
xx
xxxx
5
1
2
3
4
Grundfos Water Treatment GmbH - Reetzstr. 85 - D-76327 Pfinztal
16
99202692
Manufactured: 37/2017
Puls.damper-DBG0,36l SS/V G1/2-wo
pressure: 180.00 bar
Pressure gauge: 25 bar
6
4
10
7
2
15

English (GB)
10
5.2.2 Type key for pulsation dampers D, DB, DBG
The type key is designed for the precise identification of the
product and not for configuration purposes. It can be found on the
product packaging.
Example: PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
* For design DB and DBG: The material applies also to the
separating diaphragm.
5.2.3 Type key for pulsation dampers SD, CSD
The type key is designed for the precise identification of the
product and not for configuration purposes. It can be found on the
product packaging.
Example: PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
Product type
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
Pulsation damper
Design
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
D For discharge side, without separating diaphragm
DB For discharge side, with separating diaphragm
DBG For discharge side, with separating diaphragm and
pressure gauge
DBG-H For discharge side, with separating diaphragm and
pressure gauge for high pressure applications
Damper volume in litres
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
Body material
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
PP Body and connector material: polypropylene
PVC Body and connector material: polyvinyl chloride
PV Body and connector material: polyvinylidene fluoride
(PVDF)
SS Body material: stainless steel
Gasket material*
PULS.DAMPER-DBG0,30L PV/TG3/4-B4/B3
EEPDM
VFKM
T PTFE
- No gaskets included
Threaded connection
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
G1/4 Internal thread Rp 1/4
G3/8 Internal thread Rp 3/8
G1/2 Internal thread Rp 1/2
G3/4 Internal thread Rp 3/4
G1 Internal thread Rp 1
G1 1/2 Internal thread Rp 1 1/2
G2 Internal thread Rp 2
Dosing line connector
PULS.DAMPER-DBG0,30L PV/T G3/4-B4/B3
WO Without dosing line connector
B3/F External diameter 16 mm, internal diameter 12 mm
B4/B3 External diameter 25 mm, internal diameter 20 mm
B0/H External diameter 25 mm, internal diameter 20 mm
B4/H External diameter 25 mm, internal diameter 20 mm
K/B0 External diameter 40 mm, internal diameter 25 and
32 mm
B5/B4 External diameter 40 mm, internal diameter 25 and
32 mm
Product type
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
Pulsation damper
Design
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
SD For suction side, without calibration function
CSD For suction side, with calibration function
Damper volume in litres
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
Body material
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
PVC Body and connector material: polyvinyl chloride
SS Body material: stainless steel
Gasket material
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
V,E FKM and EPDM gaskets are included
- No gaskets included
Threaded connection
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
G1/4 Internal thread Rp 1/4
G1/2 Internal thread Rp 1/2
G3/4 Internal thread Rp 3/4
G1 Internal thread Rp 1
- No threaded connection
Dosing line connector
PULS.DAMPER-CSD0,5L PVC/V,E G1/2-B3/F
WO Without dosing line connector
B3/F External diameter 16 mm, internal diameter 12 mm
B0/H External diameter 25 mm, internal diameter 20 mm
B4/H External diameter 25 mm, internal diameter 20 mm
Y/K Internal diameters 40, 50 and 63 mm
50/K Internal diameters 40 and 50 mm
C9/ External ASTM / BS pipe 1/2", internal ASTM / BS
pipe 3/8"
C8/C7 External ASTM / BS pipe 1", internal ASTM / BS pipe
3/4"
-/C8 Internal ASTM / BS pipe 1"

English (GB)
11
5.3 Product description
Pressure fluctuations in dosing systems can cause stress and
damage to the equipment, especially with rigid pipe work.
Pulsation dampers are used to even out the pulsating flow and
pressure produced by positive displacement pumps like
diaphragm dosing pumps. They can be installed before and after
the pump.
5.3.1 Suction-side pulsation dampers SD and CSD
Pulsation dampers SD and CSD help to ensure the accuracy of
dosing pumps, which is highly dependent on proper suction
conditions. In installations with long inlet lines or inlet lines with a
small diameter, the use of an SD or CSD pulsation damper is
recommended.
Suction-side pulsation dampers SD
Pulsation dampers SD are made of stainless steel. They have two
dosing line connections for in-line installation. The flow direction
is arbitrary.
Fig. 10 Example of a suction-side pulsation damper SD with
flange connection
Suction-side pulsation dampers CSD
Pulsation dampers CSD have a transparent PVC cylinder with a
fine volume scale. When combined with a shut-off valve in the
inlet line, they can also be used for calibration or flow
measurement. In installations without flooded suction, the
optional manual vacuum pump kit simplifies startup of the dosing
pump.
Pulsation dampers CSD can be used for multiple pumps that are
supplied by the same inlet line. Observe section 10.5.1 Technical
data.
Fig. 11 Suction-side pulsation damper CSD (left) and CSD
with optional manual vacuum pump kit (right)
* Part of optional manual vacuum pump kit
TM06 9261 2117
Pos. Description
1 Aeration screw
2 Body
3 Dosing line connector (inlet/outlet)
4 Drain screw
1
2
33
4
TM04 1346 1617
Pos. Description
1 Aeration valve
2 Transparent PVC cylinder
3 Volume scale
4 Dosing line connector (inlet)
5* Manual vacuum pump
5a* T-piece
5b* Shut-off valve
1
2
3
4
2
3
5b5a
1
5
4

English (GB)
12
5.3.2 Discharge-side pulsation dampers D
Pulsation dampers D optimise the dosing accuracy and protect
the pump and the outlet line against pressure surges.
Pulsation dampers D have no separating diaphragm and thus
cannot be preloaded. During startup of the empty dosing system,
air is trapped inside the pulsation damper and forms the gas
cushion. The amount of air in the pulsation damper depends on
its size and cannot be adjusted.
Fig. 12 Principle of operation
As a standard, pulsation dampers D have no pressure gauge.
They can optionally be equipped with a pressure gauge assembly
for easy reading of the pressure during operation.
Fig. 13 Pulsation damper D
5.3.3 Discharge-side pulsation dampers DB and DBG
Pulsation dampers DB and DBG are especially designed for
installations with long outlet lines and with rigid pipes. The
pulsation dampers optimise the dosing accuracy and protect the
pump and the outlet line against pressure surges.
Pulsation dampers DB and DBG have an air or nitrogen cushion
inside, which is separated from the dosing medium by a
separating diaphragm. This keeps the preload pressure stable for
a long time and avoids that air or nitrogen is dissolved in the
dosing medium.
Fig. 14 Principle of operation
In PVC, PP, and stainless steel pulsation dampers, an FKM or
EPDM bladder is used as separating diaphragm, in PVDF
pulsation dampers a PTFE bellows is used as separating
diaphragm.
Pulsation dampers DBG include a pressure gauge for easy
setting of the correct pressure. Pulsation dampers DB have no
pressure gauge.
Fig. 15 PVC version of discharge-side pulsation damper DB
(left) and DBG (right)
TM06 9259 2117
Pos. Description
1Aircushion
3 Dosing medium
TM06 9260 2117
Pos. Description
1 Aeration screw
2 Body
3 Dosing line connector (inlet)
4 Optional pressure gauge assembly
4a Pressure gauge
4b Aeration valve
Observe that the air in pulsation dampers D is
dissolved by the dosing medium over time. Regularly
check the dampening performance and refill the gas
cushion if necessary. See section 7.3 Refilling
pulsation damper D with air.
1
3
2
3
1
4
4a
4b
TM04 1345 1617
Pos. Description
1 Air or nitrogen cushion
2 Separating diaphragm
3 Dosing medium
TM04 1347 2017
Pos. Description
1 Pressure gauge
2 Gas connector with non-return valve
3 Wall mounting material
4 Body
5 Dosing line connector (inlet)
1
2
2
3
4
3
2
5
4
3
2
1
5

English (GB)
13
6. Operating the product
6.1 Using pulsation damper CSD for pump calibration
or flow measurement
6.1.1 Calibration or flow measurement with flooded suction
Fig. 16 Calibration or flow measurement with flooded suction
1. Make sure that the system is commissioned correctly. See
section 3.3.1 Commissioning with flooded suction.
2. Stop the dosing pump.
3. Make sure that shut-off valve (1) is open and aeration valve
(4a) is closed.
4. For calibration (only for pumps with calibration function):
– Slowly open aeration valve (4a) and close it again when the
pulsation damper (4) is filled exactly to the "0 ml"
graduation.
– Close shut-off valve (1).
– Open aeration valve (4a).
– Perform the calibration according to the pump manual.
Avoid that the liquid level falls below the transparent part of
the pulsation damper.
– After the pump is calibrated, keep it stopped and set it back
to normal operation menu.
5. For flow measurement:
– Slowly open aeration valve (4a) and close it again when the
pulsation damper (4) is filled slightly above the "0 ml"
graduation.
– Close shut-off valve (1).
– Open aeration valve (4a).
– Have a stopwatch ready.
– Start the dosing pump.
– Start the stopwatch when the falling liquid level in the
pulsation damper passes the "0 ml" graduation.
– Stop the stopwatch when the falling liquid level in the
damper passes the lowest graduation.
– Stop the pump immediately. Avoid that the liquid level falls
below the transparent part of the pulsation damper.
– Calculate the flow rate of the dosing pump:
6. Slowly open shut-off valve (1) and close it again when the
pulsation damper (4) is filled by 70 % with dosing medium.
7. Close aeration valve (4a)
8. Open shut-off valve (1).
The system is ready to be started again.
6.1.2 Calibration or flow measurement without flooded
suction
Fig. 17 Commissioning without flooded suction
Observe that the air in pulsation dampers D is
dissolved by the dosing medium over time. Regularly
check the dampening performance and refill the gas
cushion if necessary. See section 7.3 Refilling
pulsation damper D with air.
TM06 9271 2117
Pos. Description
1 Shut-off valve
2 Dosing pump
4 Pulsation damper
4a Aeration valve
12 Drain valve
2
4
4a
112
Flow
[l/h] =Dosed volume
[ml] /time
[s] x3.6
TM06 9270 2117
Pos. Description
1 Shut-off valve
2 Dosing pump
4 Pulsation damper
4a Aeration valve
5 Manual vacuum pump
5b Shut-off valve
12 Drain valve
2
5b
4
5
1
4a
12

English (GB)
14
1. Make sure that the system is commissioned correctly. See
section 3.3.1 Commissioning with flooded suction.
2. Stop the dosing pump.
3. Make sure that shut-off valve (1) is open and aeration valve
(4a) is closed.
4. Open shut-off valve (5b).
5. For calibration (only for pumps with calibration function):
– Use the manual vacuum pump (5) to fill the pulsation
damper (4) exactly to the "0 ml" graduation.
– Close shut-off valve (5b).
– Close shut-off valve (1).
– Open aeration valve (4a).
– Perform the calibration according to the pumps manual.
Avoid that the liquid level falls below the transparent part of
the pulsation damper.
– After the pump is calibrated, keep it stopped and set it back
to normal operation menu.
6. For flow measurement:
– Use the manual vacuum pump (5) to fill the pulsation
damper (4) slightly above the "0 ml" graduation.
– Close shut-off valve (5b).
– Close shut-off valve (1).
– Open aeration valve (4a).
– Have a stopwatch ready.
– Start the dosing pump.
– Start the stopwatch when the falling liquid level in the
pulsation damper passes the "0 ml" graduation.
– Stop the stopwatch when the falling liquid level in the
damper passes the lowest graduation.
– Stop the pump immediately. Avoid that the liquid level falls
below the transparent part of the pulsation damper.
– Calculate the flow rate of the dosing pump:
7. Close aeration valve (4a)
8. Open shut-off valve (1).
9. Open shut-off valve (5b).
10. Use the manual vacuum pump (5) to fill the pulsation damper
(4) by 70 % with dosing medium.
11. Close shut-off valve (5b).
The system is ready to be started again.
7. Maintaining the product
7.1 Safety instructions
7.2 Refilling pulsation dampers SD and CSD
Pulsation dampers SD and CSD must be refilled with dosing
medium when the level of dosing medium in the pulsation damper
falls below 25 %.
To refill the pulsation damper, follow the instructions for
commissioning. See section 3.3 Commissioning pulsation
dampers SD and CSD.
7.3 Refilling pulsation damper D with air
To refill the pulsation damper D with air, the pulsation damper
must be drained completely.
1. Read section 7.1 Safety instructions.
2. Stop the dosing system.
Fig. 18 Installation example of pulsation damper D
Flow
[l/h] =Dosed volume
[ml] /time
[s] x3.6
The product must only be serviced by authorised and
qualified persons.
Read the manuals of all system components before
starting any work on the system.
When working with chemicals, the accident
prevention regulations applicable at the installation
site must be applied.
Observe the chemical manufacturer's safety data
sheets when handling chemicals.
When working on the product or connections and
lines, always wear protective clothing (e.g. safety
goggles and gloves). The system must be
pressureless.
Observe section 4.1 Handling the product.
Wipe up spilled liquid immediately to avoid slipping
hazard.
TM04 1360 2017
Pos. Description
1 Dosing pump
2 Pressure relief valve PRV
3 Drain valve
4 Pulsation damper D
5 Aeration screw
6 Optional pressure gauge assembly
6a Aeration valve
7 Pressure loading valve PLV
8 Injection unit
1
3
4
5
6
6a
2
8
7

English (GB)
15
3. Carefully open drain valve (3) to depressurise the dosing
system.
4. Aerate the pulsation damper by carefully opening aeration
screw (5) or aeration valve (6a), if installed.
– Wait until the pulsation damper is drained completely.
5. Close aeration screw (5) or aeration valve (6a).
6. Close drain valve (3).
7. Perform commissioning again. See section
3.4 Commissioning pulsation dampers D.
7.4 Checking and adjusting the preload pressure of
pulsation dampers DB and DBG
Check the preload pressure:
• one week after initial commissioning
• every three months
Readjust the preload pressure, if necessary. Proceed according
to the respective section:
•3.5.4 Checking and adjusting the preload pressure of
pulsation dampers DB and DBG
•3.5.5 Adjusting the preload pressure with air via the tyre-valve
adapter (DB and DBG, up to 8 bar)
7.5 Replacing the separating diaphragm of pulsation
dampers DB and DBG
7.5.1 Dismantling the pulsation damper from the dosing
system
1. Read section 7.1 Safety instructions.
2. Stop the dosing system.
3. Depressurise the dosing system.
4. Empty the complete discharge side of the dosing system and
flush it with a suitable non-hazardous liquid.
5. Remove the pulsation damper from the dosing system.
6. Connect the filling device. See section 3.5.3 Connecting the
filling device.
The following steps refer to fig. 6.
7. Relieve the preload pressure as follows:
– Turn connection handle (1) clockwise until the preload
pressure is displayed at pressure gauge (5).
– Carefully turn gas relief handle (2) counter-clockwise and
wait until the preload pressure is relieved completely.
8. Remove the filling device.
9. Remove the gas connector.
– This ensures that there is no residual gas pressure in the
pulsation damper.
10. Clean the pulsation damper with a suitable cleaning agent.
11. Make sure that no hazardous substances remain in the
pulsation damper.
12. Put the pulsation damper into a suitable packaging.
13. Fill in the safety declaration. See appendix of this document.
14. Send the safety declaration to Grundfos together with the
product.
8. Spare Parts
See service kit catalogue:
http://net.grundfos.com/qr/i/96488862_23
CAUTION
Chemical hazard
Minor or moderate personal injury
- Collect escaping dosing medium safely.
A special tool and training is required to replace the
diaphragm.
Depressurise and clean the pulsation damper and
send it back to Grundfos together with a filled-in
safety declaration. See appendix of this document.
CAUTION
Pressurised product
Minor or moderate personal injury
- Handle pressurised products with care.
- Do not drop the product.

English (GB)
16
9. Fault finding
10. Technical data
10.1 Sizing of pulsation dampers
Information on sizing of pulsation dampers can be found in the
data booklet:
http://net.grundfos.com/qr/i/96700284
10.2 Permissible media temperature
10.3 Storage and ambient temperatures
10.4 Suction-side pulsation dampers SD
Fig. 19 Suction-side pulsation damper SD
Fault Cause Remedy
1. Pulsation damping effect
too small or diminishing.
a) For pulsation dampers D: The air cushion has been absorbed by
the dosing medium. Deaerate the pulsation damper.
b) For pulsation dampers DB and DBG: Preload pressure is too high
or too low.
Set the correct preload
pressure.
2. After start-up, the
pulsation damper does
not produce the desired
effect.
a) Pulsation damper D is the wrong size. Use a pulsation damper of the
correct size.
b) For pulsation dampers DB and DBG: Preload pressure is too high
or too low.
Set the correct preload
pressure.
Body material
Maximum operating pressure
up to 10 bar > 10 bar
PVC, PP 0 °C to +45 °C -
PVDF -10 °C to +45 °C -10 °C to +45 °C
Stainless steel
70 °C (higher temperature possible with
reduced pressure)
145 °C (short-term with max. 2 bar)
Maximum operating pressure
up to 10 bar > 10 bar
Min./Max. ambient
temperature [°C] 0/+45 0/+45
Min./Max. storage
temperature [°C] -10/+50
TM04 1349 3917
Body material Stainless steel 1.4301
Damper
volume
[l]
Max.
operating
pressure
[bar]
Connections
AF
1 40 R 1/4 R 1/4
3 40 R 3/4 R 1/4
5 25 R 3/4 R 1/4
10 16 Flange DN 32 R 1/4
Damper
volume
[l]
Max.
operating
pressure
[bar]
Dimensions
[mm]
BDEGHL
1 40 139 89 155 85 65 295
3 40 205 133 215 105 87 375
5 25 240 168 245 110 100 395
10 16 248 168 500 125 100 645
H
B
8E
F
Ø6.5
L
G
F
A
D

English (GB)
17
10.5 Suction-side pulsation dampers CSD
10.5.1 Technical data
10.5.2 Dimensions
Fig. 20 Suction-side pulsation damper CSD, 0.25 l to 3 l
Fig. 21 Suction-side pulsation damper CSD, 5 l and10 l
Maximum operating pressure [bar] 2
Body material PVC
Sight glass material PVC
Gasket material
FKM
EPDM
PTFE
Damper
volume
[l]
Max. pump
stroke volume
[ml]
Max. number of
pumps with max.
stroke volume
Scale
division
[ml]
0.25 2 3 2
0.5 7 3 5
1.5 19 3 20
3.0 45 2 25
5.0 75 3 10
10.0 171 3 50
TM06 9449 2317
I
ØD
Ød
G
H
A B
C E
M
ØL
O
TM07 0197 4517
Damper
volume
[l]
Dimensions
[mm]
ABC∅D∅dEG
0.25 50 270 360 16 12 92 14
0.5 50 340 431 16 12 92 14
1.5 75 343 465 25 20 92 19
3.0 79 435 568 25 20 92 19
5.0 118.5 700 871 50 40 92 51
10.0 139.5 600 824 63 50
40 92 64
Damper
volume
[l]
Dimensions
[mm]
HI∅L∅MO
0.25 12 40 6.5 - 8-13
0.5 12 47 6.5 - 8-13
1.5 16 70 6.5 40 8-13
3.0 16 78 6.5 60 8-13
5.0 71.5 77.5 6.5 60 8-13
10.0 111.5 95 6.5 90 8-13
Ød
M
H
ØD
A
E
C
ØL
I
G
B
O

English (GB)
18
10.6 Discharge-side pulsation dampers D
10.6.1 Technical data
10.6.2 Dimensions
Fig. 22 Discharge-side pulsation damper D
10.7 Discharge-side pulsation dampers DB and DBG
10.7.1 Technical data
* Different value possible on customer request.
* Stainless steel 1.4404
** For pulsation damper DBG observe the maximum operating
pressure of the pressure gauge.
Separating diaphragm included No
Recommended number of pumps per pulsation damper 1
Damper
volume
[l]
Max. pump
stroke
volume
[ml]
Body
material
Connection
material
Max.
operating
pressure
[bar]
0.35 2 Stainless
steel
1.4301
Stainless
steel 1.4571
4017
345
575 25
10 131 Stainless
steel
1.4571
Stainless
steel 1.4571
16
20 500 6
TM04 1352 3917
Damper
volume
[l]
Dimensions
[mm] G
ABEF∅H
0.35 215 85 50 83 6.5 R 1/4
1 277 125 65 101 6.5 R 1/4
3 335 160 87 150 6.5 R 3/4
5 345 190 100 170 6.5 R 3/4
10 615 460 100 170 6.5 Flange DN 32
20 562 300 162 270 8.5 Flange DN 65
A
B
E
E
ØH
G
F
Separating diaphragm included Yes
Separating diaphragm material see section 5.2.2
Factory-set preload pressure*[bar] 2.7
Recommended number of pumps per
pulsation damper 1
Damper
volume
[l]
Max. pump
stroke volume
[ml]
Body
material
Max. operating
pressure**
[bar]
0.09 2 SS*250
0.15 7 PVDF 20
0.18 7 PVC, PP 10
SS*180
0.3 19 PVDF 20
0.36 19 PVC, PP 10
SS*180
0.7 45 PVDF 20
0.65 45 PVC, PP 10
SS*50
1.4 75 PVDF 20
1.5 75 PVC, PP 10
SS*40
2.6 131
PVC, PP 10
PVDF 20
SS*30
5.6 280
PVC, PP 10
PVDF 20
SS*40
10.0 460 PVDF 20
10.4 460 PVC, PP 10
SS*30

English (GB)
19
10.7.2 Dimensions
Fig. 23 Pulsation damper DBG, PVC version
Fig. 24 Pulsation damper DB, stainless steel version
Dimensions of the product
Dimensions of the connections
TM06 9613 5117TM06 9614 5117
Damper
volume
[l]
Body
material
A1
[mm]
A2
[mm]
A3
[mm]
∅D1
[mm]
∅D2
[mm]
0.09 SS 100 14 - 55 -
0.15 PVDF 205 12 14 70 53
0.18 PVC, PP 161 12 14 80 -
SS 118 14 - 70 -
0.3 PVDF 267 20 25 84 63
0.36 PVC, PP 203 20 25 90 -
SS 161 16 - 85 -
0.7 PVDF 138 20 25 98 84
0.65 PVC, PP 263 20 25 100 -
SS 205 20 - 90 84
1.4 PVDF 270 22 28 125 104
1.5 PVC, PP 335 22 28 130 -
SS 245 25 - 110 104
2.6
PVC, PP 365 22 28 160 -
PVDF 360 22 28 170 156
SS 295 27 - 140 129
A2
A3 A1 B
H
H
E
ØF
ØD1
ØD
Ød
G
ØD2
G
A2
A1
ØD1
H
H
E
ØF
5.6
PVC, PP 458 32 - 198 -
PVDF 490 32 - 170 156
SS 414 30 - 170 156
10.0 PVDF 500 50 - 250 -
10.4 PVC, PP 441 50 - 250 206
SS 442 30 - 220 206
Damper
volume
[l]
Body
material
H
[mm]
∅F
[mm]
B
[mm] E
0.09 SS 52.5 - 152.5
0.15 PVDF 53-127
12 129 M 10
0.18 PVC, PP 67-171
SS 64-168
0.3 PVDF 58-175
0.36 PVC, PP 71-175
SS 67-171
0.7 PVDF 67-171
0.65 PVC, PP 78-152
SS 67-171
1.4 PVDF 77-177
1.5 PVC, PP 90-190
SS 77-177
2.6
PVC, PP 105-205
PVDF 103-203
SS 89.5 - 189.5
5.6
PVC, PP 124-224
PVDF 103-203
SS 103-203
10.0 PVDF 150-250
10.4 PVC, PP 128-228
SS 128-228
Damper
volume
[l]
Body material
Connection
∅D
[mm]
∅d
[mm]
G
internal thread
0.09 SS -- G3/8
0.15 PVDF 16 12 G 1/2
0.18 PVC, PP
SS - -
0.3 PVDF 25 20 G 3/4
0.36 PVC, PP
SS - - G 1/2
0.7 PVDF 25 20 G 3/4
0.65 PVC, PP
SS - -
1.4 PVDF 40 32 G 3/4
1.5 PVC, PP G 1
SS - - G 3/4
2.6
PVC, PP 40 32 G 1
PVDF G 3/4
SS - - G 1
5.6
PVC, PP - - G 1 1/2
PVDF - - G 1
SS - - G 1 1/2
10.0 PVDF
-- G2
10.4 PVC, PP
SS
Damper
volume
[l]
Body
material
A1
[mm]
A2
[mm]
A3
[mm]
∅D1
[mm]
∅D2
[mm]

English (GB)
20
11. Accessories
11.1 Manual vacuum pump kit for pulsation dampers
CSD
In installations without flooded suction, the pulsation damper
CSD can be filled by the manual vacuum pump kit. This makes
startup of the dosing pump easier and prepares the pulsation
damper CSD for calibration of the pump.
A manual vacuum pump kit includes:
• Ball valve, connection G 5/8
• T-piece, connection G 5/8
•Hose
• Manual vacuum pump
• Holder for wall mounting
Materials:
• Vacuum pump: PVC
• Ball valve and T-piece: PVC
• Gasket: FKM.
11.1.1 Dimensions
Fig. 25 Manual vacuum pump kit
11.1.2 Order data
11.2 Filling devices for pulsation dampers DB and
DBG
Filling devices make the adjustment of the preload pressure of
pulsation dampers easy. A filling device can be connected to the
filling valve of a pulsation damper and to a local compressed-air
source or a nitrogen bottle. When the pressure is adjusted, the
filling device can be removed.
Filling devices are available with different pressure gauges.
A set includes a filling device with pressure gauge and a hose
with connections for a nitrogen bottle.
Hose connections:
• Nitrogen bottle: W24.3 x 1 1/4"
• Filling device: G 1/4.
11.2.1 Dimensions and order data
Fig. 26 Filling device for plastic or stainless-steel pulsation
dampers
TM06 9603 2517
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
∅F
[mm]
G
[mm]
131 34 132.5 50 242 6.2 675-875
Description Product
number
Manual vacuum pump kit 99218131
AB
C
G
EØF
D
TM06 9620 2517
Description L
[mm]
Max. operating
pressure
[bar]
Product
number
Filling device with
hose 136
25 96727342
60 96727343
160 96727344
250 96727345
L
