GST DI-9104Exd User manual

Features
Built-in MCU processes signals and controls
communication digitally.
Intelligent algorithm ensures quick response to
reduced false alarms.
3 classifications available.
High sensitivity, reliable performance, and
dust-proof, damp-proof and corrosion-proof
abilities.
Description
DI-9104Exd is a light-sensitive detector that detects
fire by picking up the ultraviolet light from flaming
material. It’s designed for areas where an open fire is
liable to occur with large amount of radiation and no
smoldering stage, or where quick response to a fire is
required. This detector can be applicable to zone 1
and 2 of explosive hazardous areas.
The detector is able to work either in addressable
mode connecting with GST intelligent fire alarm
control panel(FACP) to transmit signal through
detection loop or in non-addressable mode connecting
to 24VDC power supply to transmit signal by
outputting different resistance values.
Connection and Wiring
Screened 2-core cable with cross section 1mm2or
above, and outer diameter φ8 mm is required for field
wiring. Please follow the steps below:
(1) Rotate down the back cover and the pressing nut.
(2) Thread a proper length of the cable through the
pressing nut, metal washer and joint washer in
sequence.
(3) Peal away the outer layer of the cable with 5mm of
metal core exposed, rotate in the cable together
with the joint washer, metal washer and the nut into
the detector housing, and fasten the nut using a
spanner.
(4) Connect the cables to corresponding terminals of
the detector, and the screen layer to the safety
earth position inside the housing.
(5) Fasten the back cover with tools, and make sure
the detector is earthed through its safety earth
position on the cover.
Installation
(1) Fig. 1 is the schematic diagram for installing the
detector.
(2) Please check the following after installation:
There shall not be any crack or air bubbles.
The back cover and the detector shall be
securely fastened.
There shall not be any scratch or crack on the
detecting window.
There shall be joint washer in the wiring hole.
The joint washer matches with the cable
diameter.
The pressing nut is locked.
There is earth cable at the “earth” mark.
The detection window shall face the protected
area.
Note: The detector shall be installed in compliance
with relative installation codes. Make sure the
housing is in good condition.
Fig. 1
Application
Schematic of system connection is shown in Fig. 2
(addressable mode) and Fig .3 (non-addressable mode).
Fig. 2
Fig. 3
Operation
The detector powered by 24VDC voltage, which may
come from control panel in addressable working mode
or 24VDC power supply in non-addressable working
mode.
In addressable mode, Terminal Z1 and Z2 are to be
connected with the loop of FACP polarity-insensitively.
The FACP polls the detector status through the loop,
and displays its fault and fire alarm messages.
M3×16
M6×60
NPT 1/2
M24×1.5
Sealing and washer,
φ8mm(internal diameter)
DI-9104Exd Digital Flame Proof
UV Flame Detector
FACP
Z1
Z2
Z1 Z2 K1 K2
DI-9104Exd Detector
Hazardous Area
Safety Area
Input Equipment
Z1 Z2 K1 K2
DI-9104Exd Detector
24VDC
Signal
Input
Hazardous Area
Safety Area
Z1and Z2 connects with the loop
of FACP, polarity-insensitive.
Z1, Z2: Power input,
polarity-insensitive.
K1, K2: Signal output.
Resistance between the
terminals is 4.7kΩ normally.
Shorted in fire alarm
condition.
Open in fault condition.
30309304 Issue 1.06

In non-addressable mode, 24VDC power supply can
be directly applied to Terminal Z1 and Z2. K1 and K2
output different resistance in different conditions. If the
resistance is 4.7kΩ, the detector is in normal standby
state; if the terminals are shorted, the detector is in fire
condition; if the terminals are open, the detector is in
fault condition.
The detector has 3 classifications. The factory default
is Class 1. The address and sensitivity can be read
and changed using P-9910B Programmer. Please
refer to P-9910B Hand Held Programmer Operation
Manual for details.
Specification
Operating Voltage
Addressable Mode:
Loop voltage: 24VDC come
from FACP Z1,Z2 terminals
Non-addressable Mode:
Voltage: 24VDC come from
power supply
Operating Current
Addressable Mode:
Standby current ≤2mA
Alarm current ≤3mA
Non-addressable Mode:
Standby current ≤13mA
Alarm current ≤23mA
Power-up Time
≤10s
Indicator
In addressable mode and
non-addressable mode,
indicator is red. It flashes
when polling, and
illuminates steadily in alarm.
Programming Mode
Electronic programming.
Occupying one loop
address.
Address Range
1
～
242
Spectrum Response
Range
185nm
～
260nm
Detection Angle
Detection
Distance
※
25m for Class 1, 17m for
Class 2 and 12m for Class 3.
Alarm Response time
≤30s
Ingress Protection
IP66
Ambient Temperature
－20 ℃～＋60 ℃
Relative Humidity
≤95%RH, non-condensing
Dimensions
147mm×106mm×92mm
Material and Color
ZL102 aluminum alloy,
silvery grey.
Weight
1.5kg
Installation Hole
Spacing
110mm×72mm
ATEX Certificate NO.
Presafe 14 ATEX 5547
Explosion-proof Mark
Ex d
Ⅱ
CT6Gb
※Test fire: The flame generated by 2000g of alcohol
(concentration above 90% ) in a container with bottom
area 33cm×33cm and height 5cm.
Accessories and Tools
Name and Model
Qty.
Remarks
P-9910B Hand Held
Programmer
1
Order separately
Expansion Bolt M6×60
3
Screws M3×16
2
Maintenance
(1) The detector shall be cleaned at least once a year
to ensure normal operation of the system.
(2) Before cleaning, notify the proper authorities that
the system is undergoing maintenance and will
temporarily be out of service. Disable the zone or
system undergoing maintenance to avoid
unwanted alarms.
(3) The detector shall be tested after being cleaned
and re-installed. After testing, notify the proper
authorities the system is back in operation.
Caution
(1) The detector should be handled with care during
storage, transportation, installation, commission
and maintenance to avoid damage from falling,
impact, outside force and friction.
(2) Installation and maintenance should strictly comply
with relative codes for explosive and hazardous
areas.
(3) Never open the cover for maintenance in field.
(4) The enclosure must be earthed.
(5) The len only endures low impact energy, so the
detector shall be installed the position where the
foreign objects can’t attack it.
(6) The following places are not suitable for the
detector:
Where flameless fire is to be expected.
Where intensive smoke spreads before flames.
Where the "view" of the detector is opt to be
obscured.
Where the sun can directly shine or indirectly
shine the detection window.
Where there is strong UV light source in field,
like a tungsten halogen lamp.
Where open fire, welding, X rays, arc or sparks
may exist in normal condition.
(7) The threaded entries comply with following
parameters：
Position on the equipment: see Fig.1
The number permitted:1
Sealing and washer size: φ8mm(internal
diameter) ×φ18mm(external diameter) ×
20mm(thickness)
Cable external diameter φ6~φ8 mm is
recommended
The torque for cable nut is 25 N.m to compress
sealing ring
Limited Warranty
GST warrants that the product will be free from defects
in design, materials and workmanship during the
warranty period. This warranty shall not apply to any
product that is found to have been improperly installed
or used in any way not in accordance with the
instructions supplied with the product. Anybody,
including the agents, distributors or employees, is not
in the position to amend the contents of this warranty.
Please contact your local distributor for products not
covered by this warranty.
This Data Sheet is subject to change without notice. Please contact GST for more information or questions.
Gulf Security Technology Co., Ltd.
No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei, P. R. China 066004
Tel: [phone] Fax: [phone]
[e-mail] www.gst.com.cn
30309304 Issue 1.06
