GST DC-9103E User manual
30309289 Issue 1.06
Features
3 classes programmable.
Reed switch testing.
The fire LED allows 360°viewing.
Output terminal for remote indicator available.
Complying with EN 54-5.
Description
DC-9103E Conventional Rate of Rise and Fixed Temperature
Heat Detector is a new generation product of GST. With built-in
microprocessor, it works stably by being fixed with highly reliable
fire judging program.
On detecting a fire signal, it can change its own current to
transmit the signal to fire alarm control panel (FACP) or
addressable zone monitor unit. The detector keeps illuminating
fire LED until it is reset by power-down.
Connection and Wiring
The detector bottom is shown in Fig. 1 and the base in Fig. 2.
C
B
A
Fig. 1 Fig. 2
There are four terminals with numbers on the base.
1: Detection zone positive IN
2: Detection zone positive OUT
3: Detection zone negative IN and OUT
2: Positive terminal of remote indicator
4: Negative terminal of remote indicator
Recommended Wiring
1.0mm2 or above fire cable for all terminals laid through metal
conduit or flame retardant conduit, subject to local codes.
Note: It’s recommended to use cables of different colors to
avoid incorrect wiring.
Installation
First fix the orientation base with two tapping screws. Then align
A (Fig. 1) on the bottom of the detector to B (Fig. 2) of the base,
and rotate the detector clockwise to mark C.
Mounting of the detector is shown in Fig. 3.
Detector
Base
Conduit
Electric Box
53.3mm
Fig. 3
Application
Warning: The alarm current depends on the current limit of
the FACP. 24VDC power cannot be applied to the detector
directly. Otherwise the detector may be damaged for lack of
current- limit resistor.
The default class of the detector is A1R and polling LED status is
“ON”which can be modified using a handheld programmer.
When the programmer is in standby state, entering unlock
password and pressing “Clear”, it will be unlocked. Pressing
Function followed by 4, there will be a “-”at the last digit. Entering
different number corresponding to the parameters followed by
“Program”, there will be a “P”shown on the screen, indicating its
class is programmed. Pressing “Clear”can clear the “P”, and
entering locking password followed by “Clear”will exit.
Table 1 Detector setting parameters
Parameters
Class
Polling LED Status
2
A1R
ON
3
A2S
ON
5
BS
ON
130
A1R
OFF
131
A2S
OFF
133
BS
OFF
Read Heat Detector Class: When the programmer is in standby
state, pressing “Test”, it will display address of the detector.
Pressing “Up”, it will display sensitivity level, device type and heat
detector class in turn.
The detector is especially applicable to places where fire occurs
with a sharp rise of temperature. Used together with smoke
detectors, it can help to increase the reliability of fire detection
thus reducing losses.
When the detector is connected with compatible FACP or
addressable zone monitor unit in series, if DP-9907 Active
End of Line Unit (AEOL) is connected to the end of output loop,
a DB-01D base should be used.
If the AEOL is used as the detector base, a conventional
detector can be installed on it. The system composition is
shown in Fig. 4.
Fig. 4
When the AEOL is not used as the detector base, a cover
should be put on it. The system composition is shown in
Fig. 5.
Fig. 5
DC-9103E
Conventional Rate of Rise and
Fixed Temperature Heat Detector
548c/03
0832-CPR-F0005
GST-0005-01
14
30309289 Issue 1.06
30° Testing
Area
Fig. 8
When the detector is connected with conventional FACP or
addressable zone monitor unit, if a 4.7kΩend of line resistor is
connected to the end of output loop, DB-01 base is used. The
system composition is shown in Fig. 6.
Fig. 6
When multiple detectors are connected with a remote
indicator, a diode 1N5819 should be connected to Terminal 4
of the orientation base in series before going to the positive of
the remote indicator. System composition is shown in Fig. 7.
Fig. 7
Maximum 15 detectors can be connected to the output of zone
monitor unit. In case of broken circuit or removal of any detector,
the unit will transmit a fault message to the FACP. If and AEOL is
connected, normal operation of other device in the system will not
be affected.
Testing
Note: Before testing, make sure the detector is properly
installed and powered up. Testing can only begin after the
detector is powered up for 10 seconds.
The detector must be tested
after installation and regular
maintenance. The methods are
as follows:
(1)Reed switch testing
The testing area of the detector
is shown in Fig. 8.
Approach the commission tool to
the testing area of the detector
and hold for several seconds
until the detector alarms.
(2)Temperature test
Approach a heater (such as a hair drier) to the thermistor of the
detector until it alarms.
After testing, disconnect power to the detector for over 10
seconds to reset it. Notify the proper authorities that the system is
back to normal operation.
If a detector fails in testing, clean it by the steps in “Maintenance”,
and retest it. If it still fails, return it for repair.
Maintenance
The detector should be installed just before commission and
kept well before installation, taken corresponding measures
for dust-proof, damp-proof and corrosion-proof.
The dust cover cannot be removed until the project has been
plunged into usage.
Clean the detector at least once a year to ensure normal
operation of the system.
Before cleaning, notify the proper authorities that the system
is undergoing maintenance and will temporarily be out of
service. Disable the zone or system undergoing maintenance
to avoid unwanted alarms.
The detector should be tested again after cleaning and
re-installing.
Protect the metal component on the PCB against damp and
improper distortion.
Do fire simulation test at least once every 6 months.
Specification
Operating Voltage
24VDC(16VDC~28VDC)
Standby Current
≤60μA
Alarm Current
≤55mA
Fire LED
Red, periodically flash once in
polling when the status is set to
“ON”; don’t illuminate when the
status is set to “OFF”. Periodically
flash twice in fault; illuminate in
alarming.
Remote Indication
Output
Polarity-sensitive, directly
connecting with remote indicator
(built in 10k resistor in series,
maximum output current is 2.0mA);
The remote indicator does not
illuminate in normal and flashes in
alarm.
Class and Setup
Classes A1R, A2S, BS
programmable.
Maximum Ripple
Voltage
2V ( peak-to-peak)
Alarm Reset
Instantaneous cut-out (10s Min,
1.0VDCMax.)
Wiring
Polarized two wire
Ingress Protection
Rating
IP2X
Ambient Temperature
Class A1: -10℃~+50℃
Class A2: -10℃~+50℃
Class B: -10℃~+65℃
Typical Fixed
Temperature
Class A1: 58℃
Class A2: 62℃
Class B: 77℃
Relative Humidity
≤95%, non-condensing
Material
ABS
Dimensions
Diameter: 100mm
Height: 53.3mm (with base)
Mounting Hole Spacing
45mm~75mm
Weight
About 110g (with base)
Accessories and Tools
Module
Name
Remarks
P-9910B
Handheld Programmer
Order separately
DB-01
Base
Order separately
DB-01D
Base
Order separately
DP-9907
Active End of Line Unit
Order separately
T-MT
Commission Tool
Order separately
WEEE Information
2012/19/EU (WEEE directive): Products marked with this
symbol cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return this
product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated
collection points.
Limited Warranty
GST warrants that the product will be free from defects in design,
materials and workmanship during the warranty period. This
warranty shall not apply to any product that is found to have been
improperly installed or used in any way not in accordance with
the instructions supplied with the product. Anybody, including the
agents, distributors or employees, is not in the position to amend
the contents of this warranty. Please contact your local distributor
for products not covered by this warranty.
This Data Sheet is subject to change without notice. Please contact GST for more information or questions.
Gulf Security Technology Co., Ltd.
No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei, P. R. China 066004
