GST I-9406 User manual

30309466 1 Issue 2.10
Features
With sandwich structure, it is easy to be installed
between DZ-03 base and a detector.
Three working modes settable (Mode I, II, III, and
the latter two available with pre-alarm state).
16 tones of sound and bright flashing light.
Electronically addressed. The address and tones
can be modified in field.
Description
I-9406 Addressable Flashing Beacon Base is installed
in field to warn people for evacuation with audible and
visual alarm in case of a confirmed fire.
The flashing beacon base can communicate with fire
alarm control panel (FACP) through a built-in
microprocessor. On receiving a start command from
the FACP, the microprocessor will control the buzzer to
generate the pre-set fire alarm sound and light the
bright LED.
Wiring and Connection
Terminals of the flashing beacon base are shown in
Fig. 1.
A
B
61mm
41.3mm
Fig. 1
Z1(1), Z2(3): Signal loop of FACP, polarity-insensitive.
Recommended Wiring
1.0mm2 or above fire cable, subject to local codes.
Installation
Warning: Before installing the flashing beacon
base, disconnect power from the loop and verify
that all the bases are securely fixed and that the
wiring is correct on each base.
1 Before installation, make sure the enclosure is
free from scratch or distortion, and labels are
complete.
2 Installation schematic of the flashing beacon base
is shown in Fig. 2.
3 Secure the detector base (Fig. 4) with 2 tapping
screws, and wire them properly. Align the
orientation mark B on the flashing beacon base to
mark C of detector base, and rotate the flashing
beacon base clockwise to D. Refer to Fig. 3 and 4.
4 If the flashing beacon base comes with a cover,
align the orientation mark on the cover to mark A
of the flashing beacon base (Fig.1), and rotate the
cover clockwise to B. If it's used as detector base,
remove the cover and install the detector on it with
the same method.
Electric Box
Flashing Beacon Base
Base
Cover or Detector
Fig. 2
B
C
D
Fig. 3 Flashing Beacon Base Fig. 4 Detector Base
Application
The flashing beacon base can be used as the base of
intelligent heat and smoke detectors to combine
detection and alarm in a single device. It can be
connected to the loop of FACP without additional
power supply.
Working Mode Setup and Tone Selection
The flashing beacon base has three working modes.
The factory default is tone 14, mode I.
The flashing beacon base has 16 tones, the setup of
which also decides the setup of working modes.
If the flashing beacon base is set with one of the
tones from No. 1 to 16, it works in Mode I.
If it is set with one of the tones from No. 17 to 32, it
works in Mode II.
If it is set with one of the tones from No. 33 to 48, it
works in Mode III.
Tone 1~16, 17~32 and tone 33~48 are completely
the same by one-to-one correspondence, with the
only difference that they work in different modes.
Please refer to the table of tones.
Working Modes:
M
ode
Address
Type of fire alarm
I
Single address,
occupying one loop
point
Note: Detector &
beacon base must
have different
addresses.
Standalone. The
beacon base gives
alarm signal when
started.
II
Dual addresses,
sharing high address
with detector
The beacon base
gives pre-alarm
signal when starting
the higher address
and alarm signal
when starting the
low
er
address.
III
Occupying dual
addresses
individually
The beacon base
gives pre-alarm
signal when starting
the lower address
and alarm signal
when starting the
higer
address.
I
-
9406
Addressable Flashing Beacon Base
0832
-
CPD
-
2100
548e/03

30309466 2 Issue 2.10
Operation
The address, working mode and tone of the flashing
beacon base can be programmed using P-9910B
programmer in field.
Address Programming
Connect the programmer with Terminal 1 and 3 of the
flashing beacon base. Turn on the programmer, enter
the address code (1 to 242), pressing Program, the
screen will show a P meaning the address is
programmed. Refer to P-9910B Hand Held
Programmer Installation and Operation Manual for
details.
Setting Tone and Working Mode
In standby state of the programmer, entering number 4,
5 and 6 followed by Clear, the screen will show 0 .
Pressing Function, the screen still shows 0 . Pressing
3 then, the screen shows - . Entering the tone
number, and pressing Program, P will show on the
screen, meaning the tone number has been set.
Pressing Clear, the screen shows 0 , further
operation can be done. If the tone number falls into
the range of 1 to 16, the flashing beacon base works in
Mode I; if the number falls into the range of 17 to 32, it
works in Mode II; if the number falls into the range of
33-48, it works in Mode III. Numbers outside these
three ranges will not be accepted, in which case, the
number will be defaulted to be 46 .
Application Method
The flashing beacon base can be used as a
detector base to mount intelligent detectors, so that
the detector can carry out both fire detection and
alarm.
It can also be directly connected into fire alarm
system. In case of a fire alarm, it will generate the
pre-set alarm sound.
Caution:
Please read this manual carefully before
operation.
DZ-03 base should be used together with this
product.
A loop can have maximum 30 flashing beacon
bases due to their current consumption.
Please order the special top cover if it s not
connected with fire detector.
Never try to repair it by yourself. Always contact
your distributor in case of any trouble.
Specifications
Operating Voltage Loop 24V (20V~28V)
Quiescent Current 1mA
Alarm Current 6mA
Mode Mode I, II & III.
Alarm tones
Optional
16
tones
.
Please
refer to the table of tones.
Flash indication
Bright
red flash, frequency
1Hz
Programming Electronically programmed
Code Range 1~242
Ingress Protection
Rating IP21C
Operating
Temperature -10 ~+50
Relative Humidity 95%, non condensing
Material of
Enclosure ABS
Dimension
Diameter:
1
5
2.4
mm
Height: 41.3mm (without
cover
)
Mounting
H
ole
D
istance
45mm~80mm
Weight About 235g
Table of Tones
Accessories and Tools
Model Name Remark
P-9910B
Hand Held
Programmer Order separately
WEEE Information
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste
in the European Union. For proper
recycling, return this product to your
local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points.
Limited Warranty
GST warrants that the product will be free from defects
in design, materials and workmanship during the
warranty period. This warranty shall not apply to any
product that is found to have been improperly installed
or used in any way not in accordance with the
instructions supplied with the product. Anybody,
including the agents, distributors or employees, is not
in the position to amend the contents of this warranty.
Please contact your local distributor for products not
covered by this warranty.
THIS PRODUCT IS NOT APPROVED TO EN54-23
(Beacon Functionality) AND MUST NOT BE USED AS
A VISUAL ALARM DEVICE OR TO PROVIDE A
PRIMARY WARNING NOTIFICATION OF FIRE.
Mode
Tone Description
Sound Level
1m Ahead/24V
dB
I II III
1
17
33
970Hz
87
2 18 34
800Hz /970Hz @ 2Hz
88
3 19 35
800Hz-970Hz@1Hz 84
4 20 36
970Hz 1s on /1s off 86
5 21 37
970Hz, 0.5s/630Hz,
0.5s 88
6 22 38
500Hz - 1200Hz 0.5s
on×3 / 1.5s off 81
7 23 39
2850Hz, 0.5s on/0.5s
off 3/1.5s off 86
8 24 40
2850Hz 0.4s on/0.3s
off 86
9 25 41
550Hz,0.7s/1000Hz,
0.33s 88
10 26 42
1500Hz -2700Hz
@3Hz 83
11 27 43
2400Hz 76
12 28 44
500Hz -1200Hz
@0.33Hz 85
13 29 45
2400Hz -2900Hz
@9Hz 82
14
*
30 46
2400Hz -2900Hz
@3Hz 92
15 31 47
800Hz-970Hz@3Hz 85
16
*
32 48
500Hz-1200Hz,3.75s
on /0.25s off 85
Pre-alarm
800Hz 1s on/1s off 84
* EN54 Compliant

30309466 3 Issue 2.10
Appendix 1 Operation Performance Data for LPCB Approved Tones
A1.1 Tone 14 Mode -Maximum Volume dB(A)
Measured with smoke detector fitted and in an
alarm condition Measured with blanking cap
Angle Horizontal Plane Vertical Plane Horizontal Plane Vertical Plane
Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V
15° 74.6 74.1 73.1 72.5 74.3 74.1 74.2 73.7
45° 71.1 70.5 74.1 73.7 68.3 67.6 71.6 71.0
75° 75.7 75.2 77.3 76.9 75.0 74.3 76.4 76.1
105° 77.3 77.3 74.2 73.7 77.1 76.6 74.4 72.8
135° 72.5 71.9 68.3 68.7 68.8 68.4 71.0 70.6
165° 74.3 74.1 70.3 69.6 73.4 73.0 71.4 70.9
A1.2 Tone 14 - Mode -Maximum Volume dB(A)
A1.3 Tone 16 - Mode - Maximum Volume dB(A)
A1.4 Tone 16 - Mode - Maximum Volume dB(A)
Measured with smoke detector fitted and in an
alarm condition Measured with blanking cap
Angle Horizontal Plane Vertical Plane Horizontal Plane Vertical Plane
Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V
15° 70.1 68.9 72.0 70.8 72.0 71.5 72.9 72.6
45° 70.8 69.9 71.2 71.5 70.6 69.5 70.3 71.1
75° 75.5 75.3 74.4 73.1 75.1 74.9 74.8 74.1
105° 75.1 74.2 77.4 77.0 74.4 73.2 76.0 76.6
135° 71.4 71.1 75.1 74.1 70.5 69.6 71.2 71.8
165° 71.6 71.9 74.9 74.5 71.8 71.6 75.5 75.8
Measured with smoke detector fitted and in an
alarm condition Measured with blanking cap
Angle Horizontal Plane Vertical Plane Horizontal Plane Vertical Plane
Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V
15° 76.6 75.8 75.1 74.9 76.3 75.1 78.2 76.6
45° 73.4 72.2 75.2 74.2 71.0 69.6 73.5 72.6
75° 77.1 76.5 78.8 78.4 76.6 75.7 78.7 78.0
105° 78.4 75.6 76.8 76.9 78.3 77.6 76.0 75.2
135° 73.2 70.1 70.2 71.8 68.9 69.3 71.6 70.9
165° 75.9 72.7 71.8 72.6 76.3 75.5 74.2 72.6
Measured with smoke detector fitted and in an
alarm condition Measured with blanking cap
Angle Horizontal Plane Vertical Plane Horizontal Plane Vertical Plane
Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V Max 28V Min 20V
15° 69.8 69.2 72.1 71.0 70.7 70.1 73.2 72.4
45° 70.7 69.6 71.3 70.9 70.0 69.1 70.1 68.9
75° 76.6 76.2 74.1 73.7 76.1 75.2 74.9 74.6
105° 74.6 74.0 76.8 76.1 74.8 73.7 77.1 76.1
135° 72.9 71.9 74.7 72.8 71.0 71.6 70.7 70.1
165° 72.5 72.3 74.9 74.5 73.4 73.1 75.8 75.1
