GTO SW-2000XL User manual

tel: [phone]
fax: [phone] www.gtopro.com
Available from:
PRO-SW2000XL
For over twenty years we have been offering automated gate systems
designed to fit our customers needs and lifestyles.
RESIDENTIAL
AGRICULTURAL
For swing gates up to 12 ft. (3.7 m) long and 400 lbs. (181.5 kg) per leaf.
O
V
E
R
2
0
Y
E
A
R
S
o
f
i
n
n
o
v
a
t
i
o
n

GTO®,GTO/PRO®, Bulldog®, Mighty Mule® and E-Z Gate® are registered trademarks of GTO, Inc. Professional Access Systems™ , America's DIY Automatic Gate Openers™ are trademarks of GTO, Inc.
and are the exclusive property of GTO, Inc. (“GTO”). All rights are reserved by GTO, and these marks may not be used, in any for without the prior, written permission of GTO. Copyright 2007 rev-11-2007
www.gtopro.com
RESIDENTIAL
AGRICULTURAL
PRO2000XL-CS
Includes battery backup,
radio receiver, entry transmitter,
AC transformer and all necessary
mounting hardware for a post
mounted installation,
10” (25.4 cm) total offset.
PRO-SW2000XL
DRIVE
Powered by: a reliable 12 Volt (120 Watt)
DC motor, 57:1 gear reducer.
Temperature rating: of motor:-5°F (-28°C)
to +160°F (71°C) battery rating
Opening time: From 15 seconds.
Range of arm stroke: is up to 11” (.3 m)
Operator length with arm fully retracted is
33.75” (85.2 cm), mounting point to
mounting point.
POWER
The PRO-SW2000XL system is powered by
one 12 Volt DC / 7.0 amp hour, sealed,
rechargeable battery (included). Battery
charge is maintained by a120V AC/60
Htz input and 18V AC at 40 VA. output,
transformer rectied to 14V DC through
control board.
FEATURES
• Features GTO/PRO’s true soft start and stop operation.
Open and close times from 15 seconds.
• Full systems capable, single/dual control board includes an
adjustable obstruction sensing, gate sequencing and auto
close settings.
• U.L. rated for Class I, II, III & IV. System certied to be in
compliance with U.L. 325, 5th edition.
CONTROLS
• The GTO/PRO® control board can be programmed for
pull-to-open or push-to-open.
• Adjustable auto close, obstruction sensitivity and dual gate
sequencing.
• One button auto-memorization of digital transmitter code.
• Charging regulated circuit on control board. “Sleep draw”
is 20 mA; “active draw” is 2 to 7 amps.
• GTO/PRO® remote-mounted 318 MHz RF receiver and one
button transmitter included.
OPTIONS:
Solar Panel Charger: oat voltage 14.5 V DC output from
a 19-3/8” (49.21 cm) x 15 1/4” (38.74 cm) silicon alloy panel.
Generates minimum of 10 watts at 600 mA. A gated diode on the
control board prevents battery discharge. (FM123)
PRO-SW2002XL
The PRO-SW2002XL kit contains both the master arm and slave
operator arm with a 32 foot (9.8m) power cable for a dual gate
application.
Push to open applications: Require one (349IH) bracket
per operator.
SUGGESTED ACCESSORIES:
• Automatic Gate Lock (FM144/FM142)
• Residential Intercom/Keypad (F3100MBC)
• Gooseneck Pedestal (F100/F110)
• Driveway Exit Wands (FM139/FM140)
• Solar Panel (FM122/FM123)
• Transmitters (RB741/RB742)
• Digital Keypad (F310)
The PRO-SW2000XL/2002XL will operate a gate up to 12’ (3 m) long and weighing 400 lbs.
(182 kg) each leaf; if all proper installation procedures have been followed. Ball bearing
hinges should be used on all gates weighing over 250 lbs. (113.4 kg).
