Guardian Fall Protection SSMR G-Rail Base User manual

Product Name: SSMR G-Rail Base
Instruction Manual
Part #: 15219
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction 1
Applicable Safety Standards 1
Worker Classifications 1
Compatible Roof List 5 - 7
Product Specific Applications 2
Components and Specifications 2
Maintenance, Cleaning, and Storage 3
Inspection 3
Installation and Use 2 - 3
Inspection Log 4
Labels 5

Introduction
Thank you for purchasing a Guardian Fall
Protection SSMR G-Rail Base. This manual
must be read and understood in its entirety,
and used as part of an employee training
program as required by OSHA or any
applicable state agency.
This and any other included instructions
must be made available to the user of the
equipment. The user must understand how
to safely and effectively use the SSMR
G-Rail Base, and all fall safety equipment
used in combination with the SSMR
G-Rail Base.
User Information
Date of First Use:
Serial #:
Trainer:
User:
Applicable Safety Standards
When used according to instruction specifications, this product meets or exceeds all applicable OSHA 1926
Subpart M and OSHA 1910 standards for fall protection. Applicable standards and regulations depend on the
type of work being done, and also might include state-specific regulations. Consult regulatory agencies for
more information on fall protection systems and associated components.
Worker Classifications
!
CAUTION
Understand the following definitions of those who
work near or who may be exposed to fall hazards.
Qualified Person: A person with an accredited degree or certification, and with extensive experience or
sufficient professional standing, who is considered proficient in planning and reviewing the conformity of fall
protection and rescue systems.
Competent Person: A highly trained and experienced person who is ASSIGNED BY THE EMPLOYER to be
responsible for all elements of a fall safety program, including, but not limited to, its regulation, management,
and implementation. A person who is proficient in identifying existing and predictable fall hazards, and who
has the authority to stop work in order to eliminate hazards.
Authorized Person: A person who is assigned by their employer to work around or be subject to potential or
existing fall hazards.
It is the responsibility of a Qualified or Competent person to supervise the job site and ensure all
applicable safety regulations are complied with.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
1

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
2
Installation and Use
Components and Specifications
Product Specific Applications
Materials: powder-coated steel.
Fall Prevention: SSMR G-Rail Bases may be used as a component in Fall Prevention
applications ONLY. Fall Prevention Systems are placed around the leading edges of any and all
fall hazards to prevent a worker from going over an edge, and may be used in substitute of
Fall Protection or safety netting systems. Installation requirements for SSMR G-Rail Bases set
forth in this manual MUST be adhered to. Personal Fall Arrest, Work Positioning, Climbing,
Rescue, and any other systems must NEVER be connected to Fall Prevention Systems.
Prior to installation, plan your system:
Always ensure that complete G-Rail System, of which SSMR G-Rail Base is a component, is fully compliant
with all applicable OSHA regulations. Always adhere to all instructions provided with equipment. G-Rail
equipment instructions provided separately.
1. Ensure SSMR G-Rail Base is compatible with applicable standing seam roof (see pgs. 5-7). If standing seam
roof is not listed, do not install SSMR G-Rail Base.
2. Ensure compatible seam attachment points exist between 9.5” to 25” apart.
3. Maximum substrate slope is 4/12. This supersedes the 1/12 maximum slope for the G-Rail, which applies
to freestanding systems only.
Assembly and use:
1. Adjust SSMR clamps to fit applicable roof seam spacing. To adjust, loosen clamp bolt, slide clamp to proper
position, and tighten bolt until snug. Repeat for all necessary clamps.
2. Install Guardrail Knuckles (part # 15186) onto SSMR G-Rail Base in accordance with Guardrail Knuckle
instructions.
Guardrail Knuckle
installation location
Standing seam metal
roof clamps (qty. 6)
Clamp bolt

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
3
Maintenance, Cleaning, and Storage
If SSMR G-Rail Base fails inspection in any way, immediately remove it from service, and contact Guardian to
inquire about its return or repair.
Cleaning after use is important for maintaining the safety and longevity of SSMR G-Rail Base. Remove all
dirt, corrosives, and contaminants from SSMR G-Rail Base before and after each use. If SSMR G-Rail Base
cannot be cleaned with plain water, use mild soap and water, then rinse and wipe dry. NEVER clean SSMR
G-Rail Base with corrosive substances.
When not in use, store equipment where it will not be affected by heat, light, excessive moisture, chemicals,
or other degrading elements.
Prior to EACH use, inspect SSMR G-Rail Base for deficiencies, including, but not limited to, corrosion,
deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating,
alteration, and missing or illegible labels. IMMEDIATELY remove SSMR G-Rail Base from service if defects or
damage are found. Ensure that applicable work area is free of all damage, including, but not limited to, debris,
rot, rust, decay, cracking, and hazardous materials.
At least every 12 months, a Competent Person other than the user must inspect SSMR G-Rail Base.
Competent Person inspections MUST be recorded in inspection log in instruction manual. The
Competent Person must sign their initials in the box corresponding to the month and year the
inspection took place.
During inspection, consider all applications and hazards SSMR G-Rail Base has been subjected to.
Inspection
3. Install SSMR G-Rail Base onto roof. Place all clamps over roof
seams, then insert (2) provided set screws in bottom holes of
each clamp.
- All set screws must face same direction. Ensure all set screws
will compress against roof seam when fully installed.
- Use 3/16” Allen wrench attachment with compatible ¼” drive
screw gun to install set screws.
- If roof is 22 gauge or thicker, torque all set screws to between
13.33-15 foot-pounds. If roof is thinner than 22 gauge, torque
all set screws to between 10.83-12.5 foot-pounds.
4. Install all G-Rails into Guardrail Knuckles.
On each clamp,
(2) set screws
must compress
against roof seam
NEVER over-torque set-screws; doing so could strip hardware or damage roof panels.
!
WARNING

Inspection Log
Date of First Use: __________________.
Product lifetime is indefinite, as long as it passes pre-use and Competent Person inspections. User must
inspect prior to EACH use. Competent Person other than user must complete formal inspection at least
every 12 months. Competent Person to inspect and initial.
Labels
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
4
90924 (Rev. A)
SSMR G-Rail Base
Part #: 15219
DOM:
Serial #:
This inspection log must be specific to one SSMR G-Rail Base. Separate inspection logs must be used
for each SSMR G-Rail Base. All inspection records must be made visible and available to all users at
all times.
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.

Compatible Standing Seam Metal Roofs
SSMR Manufacturer SSMR Name SSMR Thickness SSMR Manufacturer SSMR Name SSMR Thickness
A&S Double-Lok 22 gauge steel Bryer Company TBC-Ultra 22 gauge steel
A&S DuraSeal Seam 22 gauge steel Bryer Company TBC-Ultra 24 gauge steel
A&S DuraSeal Snap 22 gauge steel Bryer Company TBC-Superseam (Single Fold) 22 gauge steel
A&S Ultra Dek 22 gauge steel Bryer Company TBC-Superseam (Double Fold) 22 gauge steel
A&S DuraSeal Snap 24 gauge steel Bryer Company TBC-Superseam (Single Fold) 24 gauge steel
A&S Ultra Dek 24 gauge steel Butler MR24 24 gauge steel
A&S Double-Lok 24 gauge steel Butler VSR 24 gauge steel
A&S DuraSeal Seam 24 gauge steel Butler MR24 22 gauge steel
AB Marn Roong AB Seam 19.5 24 gauge steel Carlisle Engineered Metals, Inc. Architectural Panel 22 gauge steel
AEP Span Snap Seam 22 gauge steel Carlisle Engineered Metals, Inc. Architectural Panel 24 gauge steel
AEP Span Snap Seam 24 gauge steel Carlisle Engineered Metals, Inc. VersaLok Panel 22 gauge steel
AEP Span Span Seam (DBF) 22 gauge steel Carlisle Engineered Metals, Inc. VersaLok Panel 24 gauge steel
AEP Span Mullok (Quad Lok) 24 gauge steel CBC Steel Buildings SS 24 24 gauge steel
AEP Span Span Seam (DBF) 24 gauge steel Ceco CXP 22 gauge steel
AEP Span Span Lok HP 2" SF 22 gauge steel Ceco CRP 24 gauge steel
AEP Span Design Span hp 22 gauge steel Ceco CXP 22 gauge steel
All Weather Insulated Panels (AWIP) SR Series (Single Fold) 24 gauge steel Central States Manufacturing Central Seam Plus 22 gauge steel
American Buildings Company Loc Seam 360 22 gauge steel Central States Manufacturing Central Loc 22 gauge steel
American Buildings Company Standing Seam 360 22 gauge steel Central States Manufacturing Central Loc 24 gauge steel
American Buildings Company Loc Seam 360 24 gauge steel Central States Manufacturing Central Seam Plus 24 gauge steel
American Buildings Company Standing Seam II Panel 22 gauge steel Central Texas Metal Roong Supply ShurLoc 175 24 gauge steel
Architectural Building Components Permaseam 22 gauge steel Centria SDP 175 22 gauge steel
Architectural Building Components Permaseam 24 gauge steel Centria SDP 175 24 gauge steel
Architectural Building Components Permaseam 22 gauge steel Centria SDP 200 24 gauge steel
Architectural Building Components Permaseam 24 gauge steel Centria SDP 300 24 gauge steel
Architectural Metal Speciales, Inc. AMS175 1-3/4" Snap-Lock 24 gauge steel Chief Industries MSC Panel 22 gauge steel
Architectural Metal Speciales, Inc. AMS175 1-3/4" Snap-Lock 24 gauge steel Chief Industries STC Panel 22 gauge steel
Architectural Metal Speciales, Inc. Ultraseam US175LS Snap-Lock 24 gauge steel Chief Industries STC Panel 24 gauge steel
ASC Building Products Sterling Roof System 22 gauge steel Chief Industries MSC Panel 24 gauge steel
Associated Building Systems KA-2000 22 gauge steel Classic Roong Systems CR-S 38 (Single Fold) 22 gauge steel
Associated Building Systems KA-2000 24 gauge steel Classic Roong Systems CR-S 25 (Single Fold) 22 gauge steel
ATAS 2" Field-Lok 24 gauge steel Construcon Metals, Inc. Sur-Lock 22 gauge steel
Bax Steel Buildings Bax-Lock 22 gauge steel Construcon Metals, Inc. Barrier Roof 22 gauge steel
Bax Steel Buildings Bax-Lock 24 gauge steel Construcon Metals, Inc. Barrier Roof 24 gauge steel
Bax-Steel Buildings, Inc. Bax-Lock 22 gauge steel Construcon Metals, Inc. Sur-Lock 24 gauge steel
Bax-Steel Buildings, Inc. Bax-Lock 24 gauge steel Copper Sales UC4 24 gauge steel
BC Steel Buildings BCL 24-MS 22 gauge steel Corle Building Systems Seam-Lok 22 gauge steel
BC Steel Buildings BCL 24-SD 22 gauge steel Corle Building Systems Snap-Seal 22 gauge steel
BC Steel Buildings BCL 24-SD 24 gauge steel Corle Building Systems Snap-Seal 24 gauge steel
BC Steel Buildings BCL 24-MS 24 gauge steel Corle Building Systems Seam-Lok 24 gauge steel
Behlen Building Systems ZL-24 Triple-Lock 24 gauge steel Custom Bilt Metals SL 1750 NT 24 gauge steel
Behlen Building Systems ZL-16 Triple-Lock 22 gauge steel Custom Bilt Metals CB 150 (Double Fold) NT 22 gauge steel
Berridge Cee-Lock 24 gauge steel Dean Steel Buildings, Inc Pro Seam Panel 22 gauge steel
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
5

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
6
Compatible Standing Seam Metal Roofs (SSMR)
SSMR Manufacturer SSMR Name SSMR Thickness SSMR Manufacturer SSMR Name SSMR Thickness
Dean Steel Buildings, Inc Pro Seam Panel 24 gauge steel Kirby Building Systems Kirbylok 2000 24 gauge steel
Dimensional Metals SL-25 22 gauge steel Kirby Building Systems Kirbylok 2000 MS 24 gauge steel
Dimensional Metals IL-20 24 gauge steel Knudson Building Systems KR-20 24 gauge steel
Dimensional Metals SL-25 24 gauge steel Laura Star-Roof, BV Spanlock 22 gauge steel
Dimensional Metals DL-15 24 gauge steel Laura Star-Roof, BV Artlock 22 gauge steel
Drexel Metals DMC 175S Snap Lock 1-3/4 24 gauge steel Laura Star-Roof, BV Artlock 24 gauge steel
Drexel Metals DMC 210S (Armco Style) 22 gauge steel MBCI LokSeam 22 gauge steel
Drexel Metals DMC 175S Snap Lock 1-3/4 22 gauge steel MBCI DoubleLok 22 gauge steel
Drexel Metals DMC 200S 2" Double Fold 22 gauge steel MBCI LokSeam 24 gauge steel
Drexel Metals DMC 210S (Armco Style) 24 gauge steel MBCI LokSeam 22 gauge steel
Drexel Metals DMC 150SS (Double Fold) 22 gauge steel MBCI UltraDek 22 gauge steel
Drexel Metals DMC 175S Snap Lock 1-3/4 24 gauge steel MBCI UltraDek 24 gauge steel
Englert Series 2000 22 gauge steel MBCI DoubleLok 24 gauge steel
Englert Series 2500 (Double Fold) 22 gauge steel MBCI LokSeam 24 gauge steel
Englert Series 2000 24 gauge steel MBCI SuperLok 22 gauge steel
Englert Series 2400 (Double Fold) 22 gauge steel MBCI BaenLok 22 gauge steel
Englert Series 2000 24 gauge steel MBCI BaenLok 24 gauge steel
Englert Series 1300 22 gauge steel McElroy Metal Maxima 1.5" 22 gauge steel
Fab Tech, Inc. Seam-Lok 22 gauge steel McElroy Metal Medallion-Lok 22 gauge steel
Fab Tech, Inc. Snap-Seal 22 gauge steel McElroy Metal Maxima 2" ADV 22 gauge steel
Fab Tech, Inc. Snap-Seal 24 gauge steel McElroy Metal Medallion-Lok 24 gauge steel
Fab Tech, Inc. Snap-Seal 24 gauge steel McElroy Metal Medallion-Lok 22 gauge steel
Fab Tech, Inc. Seam-Lok 24 gauge steel McElroy Metal Master-Lok 90 (ML90) 22 gauge steel
Fabral Thin Seam 24 gauge steel McElroy Metal Master-Lok 90 (ML90) 24 gauge steel
Fabral Stand N Seam 24 gauge steel McElroy Metal Maxima 1.5" 24 gauge steel
Fabral 3" Snap Rib 24 gauge steel McElroy Metal Medallion-Lok 24 gauge steel
Firestone UC14 24 gauge steel McElroy Metal Maxima 2" ADV 24 gauge steel
Firestone UC4 24 gauge steel McElroy Metal ML-FS 22 gauge steel
Follansbee Steel 1in (25mm) DF (TCS) .018 TCS II Merchant & Evans Interlock 24 gauge steel
Galvak, S.A. De C.V. Galvalok II 22 gauge steel Merchant & Evans Interlock .040 aluminum
Galvak, S.A. De C.V. Galvalok I 22 gauge steel Merchant & Evans #305 24 gauge steel
Galvak, S.A. De C.V. Galvalok I 24 gauge steel Merchant & Evans #305 .040 aluminum
Galvak, S.A. De C.V. Galvalok II 24 gauge steel Mesco Double-Lok 22 gauge steel
Garco Building Systems Garco Standing Seam 22 gauge steel Mesco Ultra Dek 22 gauge steel
Garco Building Systems Garco Standing Seam 24 gauge steel Mesco Ultra Dek 24 gauge steel
Garland R-Mer Loc 22 gauge steel Mesco Double-Lok 24 gauge steel
Imetco Snap Lok 1-3/4" 22 gauge steel Metal Sales Vercal Seam 22 gauge steel
Inland Buildings IN-LOC 24 gauge steel Metal Sales Vercal Seam 24 gauge steel
Interlock Roong Snap Lock 1" .027 aluminum Metal Sales Magna Loc 22 gauge steel
Interlock Roong Future Roof 1.5" SF 26 gauge steel Metal-Fab Manufacturing MetFab Snap-On 675 24 gauge steel
Kingspan USA KingZip 1020 22 gauge steel Metal-Fab Manufacturing MetFab III Panel 22 gauge steel
Kirby Building Systems Kirbylok 2000 MS 22 gauge steel Metal-Fab Manufacturing MetFab III Panel 24 gauge steel
Kirby Building Systems Kirbylok 2000 22 gauge steel Metal-Fab Manufacturing MetFab Historic Panel 1.5" DBF 22 gauge steel

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
7
Compatible Standing Seam Metal Roofs (SSMR)
SSMR Manufacturer SSMR Name SSMR Thickness SSMR Manufacturer SSMR Name SSMR Thickness
M
etal-Fab Manufacturing MetFab Snap-on 550 Panel 24 gauge steel Steel Span, Inc. Architectural 24 gauge steel
M
orin SLR 22 gauge steel Steelco Sur-Lock 22 gauge steel
M
orin SWL 22 gauge steel Steelco Barrier Roof Panels 22 gauge steel
M
orin SLR 24 gauge steel Steelco Barrier Roof Panels 24 gauge steel
M
orin SWL 24 gauge steel Steelco Sur-Lock 24 gauge steel
N
CI/Midwest Metallic Double-Lok 22 gauge steel Steelway Building Systems RTL-24 Quad Loc 22 gauge steel
N
CI/Midwest Metallic Weather Roof III 22 gauge steel Steelway Building Systems RTL-24 Quad Loc 24 gauge steel
N
CI/Midwest Metallic Ultra Dek 22 gauge steel Taylor Metals Versa-Span 24 gauge steel
N
CI/Midwest Metallic Weather Roof II 22 gauge steel Taylor Metals MS 200 22 gauge steel
N
CI/Midwest Metallic Ultra Dek 24 gauge steel Taylor Metals MS 200 24 gauge steel
N
CI/Midwest Metallic Weather Roof II 24 gauge steel Tremco TremLock LSP 22 gauge steel
N
CI/Midwest Metallic Double-Lok 24 gauge steel Triad Corrugated Metal, Inc. Snap Lock 1-3/4 24 gauge steel
N
CI/Midwest Metallic Weather Roof III 24 gauge steel U.S. Metals US-175LS 22 gauge steel
N
CI/Midwest Metallic 216 22 gauge steel U.S. Metals US-175LS 24 gauge steel
N
CI/Midwest Metallic BaenLok 22 gauge steel U.S. Metals US-150 22 gauge steel
N
CI/Midwest Metallic 216 24 gauge steel Una-Clad UC14 24 gauge steel
N
CI/Midwest Metallic BaenLok 24 gauge steel Una-Clad UC4 24 gauge steel
N
ew Tech Machinery SS 675 Snap Lock 1-3/4 24 gauge steel Union Corrugang Company ML150 (Double Fold) 22 gauge steel
N
ew Tech Machinery SS 210A (Armco Style) 2 22 gauge steel Union Corrugang Company SL150 24 gauge steel
N
ew Tech Machinery SS 210A (Armco Style) 2 24 gauge steel United Structures of America Guardian II 22 gauge steel
N
ew Tech Machinery SS 150 (Double Fold) 22 gauge steel United Structures of America Guardian I 22 gauge steel
N
ew Tech Machinery SS 675 Snap Lock 1-3/4 24 gauge steel United Structures of America Guardian I 24 gauge steel
N
ew Tech Machinery SS 550 Snap Lock 1 1/2 24 gauge steel United Structures of America Guardian II 24 gauge steel
N
u Ray Metals Series 2000 Standing Seam 24 gauge steel Varco Pruden SSR 24 gauge steel
N
ucor Building Systems VR16-II Vise-Lock 360 24 gauge steel Varco Pruden SLR 22 gauge steel
N
ucor Building Systems CFR Vise Lock 360 Seam 24 gauge steel Whirlwind Building Systems Super Seam Plus 22 gauge steel
O
C Metals OCM 175 SL 24 gauge steel Whirlwind Building Systems Super Seam II 22 gauge steel
O
C Metals OCM 175 SL 24 gauge steel Whirlwind Building Systems Super Seam II 24 gauge steel
P
etersen Aluminum Corp Snap Clad 22 gauge steel Whirlwind Building Systems Super Seam Plus 24 gauge steel
P
etersen Aluminum Corp Snap Clad 24 gauge steel Zamil Steel Industries Max Seam 22 gauge steel
P
etersen Aluminum Corp Snap Clad 22 gauge steel Zamil Steel Industries Max Seam 24 gauge steel
P
etersen Aluminum Corp Snap Clad 24 gauge steel Zimmerman Metals, Inc. SL1750 22 gauge steel
P
etersen Aluminum Corp Tite-Loc Plus 22 gauge steel Zimmerman Metals, Inc. SL1750 24 gauge steel
P
etersen Aluminum Corp Tite-Loc 22 gauge steel
P
etersen Aluminum Corp Tite-Loc 24 gauge steel
R
igid Global Buildings Planum Series Quad-Lok 24 gauge steel
R
igid Global Buildings HI-Tech Series Quad-Lok 24 gauge steel
R
obertson Building Systems Starshield-SSR 24 gauge steel
S
chulte Building Systems TS-324 TripleLok 24 gauge steel
S
tar Starshield 24 gauge steel
S
teel Span, Inc. Trapezoidal 22 gauge steel
S
teel Span, Inc. Trapezoidal 24 gauge steel
Steel Span, Inc. Architectural 22 gauge steel
85347 (Rev. A)
